2ATOY-RT612AETRUE WIRELESS EARBUDS

TRUE WIRELESS EARBUDS Model#RT62AE Charge the earbuds Please be fully charged before first use. Place the earbuds into the case and they will charge automatically by the magnet. The LED light of earbuds will turn solid red while charging, and turn off once charging complete. The LED light of charging station will turn white breathing while charging for earbuds then turn off once charging complete for earbuds. Battery low: LED flashes red per 30seconds and prompt “battery low”. Charge the charging case: 1. Plug the provided Type-C charging cable into the bottom of charging case, the LED light will turn green breathing while charging then turn solid green once charging complete. If the charging case is in low battery, the LED flashes white. Charging time for charging case: around 2hours 2. The charging case support wireless charging function Put the charging case on the charging pad to do wireless charging Bluetooth Pairing Open the charging case, the earbuds will begin auto-pairing with each other. The earbuds LED will flash red and blue and going to device pairing mode. Activate the Bluetooth function on your device to search for “RT62AE” and connect it. It is ready to use. ENC Tech The ENC (Environmental Noise cancellation tech) algorithm cancels the background noise so that you can be heard crystal clear via voice calls. The earbuds are equipped with 4 mics and the ENC already activated by default during calling. Single earbuds usage Each earbud can be used independently. Calling/ Music: Answer/ END call: Touch L/R earbud twice： Rejecting an incoming call: Touch and hold L/R earbud 2 seconds until you hear a prompt tone ”du”: Play/Pause: Touch L/R earbud twice Next song: Touch R earbud 3 times Previous song: Touch L earbud 3 times: Voice Assistant: Touch and hold L earbud for 2 seconds until you hear a prompt sound to active the Voice Assistant/ Siri function. This function may not work for all devices. ANC Function Transparency ON: Touch and hold R earbud for 2 seconds ANC ON: Touch and hold R earbud for 2 seconds ANC OFF: Touch and hold R earbud for 2 seconds Power off: Method 1: Place the earbuds back into the charging case. Method 2: Touch and hold the earbuds for 5seconds until you hear prompt” Power off” Reset Earbuds Place L/R earbuds into the charging case, keep the case open and touch the reset button on the charging case for 5s-7s. This clears all connection records and all device. Remark: TWS without connecting any device within 5mins, it will power off automatically. What is in the box -Bluetooth earbuds -Charging case -Type-C cable -User manual -S,M,L 3 sizes silicon earplugs. Product’s specification Bluetooth Version: 5.3 ANC Level: -28dB Hall Switch: Yes Earbuds Battery: 35mAh (2C fast charging) Case Battery: 500mAh Usage time: 5H /25H ANC off 4H /20H ANC on Charging time: Earbuds 0.8H, 10mins=2.5H usage time Station 2H Waterproof: IPX5 FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement in portable exposure condition without restriction.

FCC ID:2ATOY-RT612AE Page 1 of 5 Exterior Photographs of EUT Fig.1 Fig.2 FCC ID:2ATOY-RT612AE Page 2 of 5 Fig.3 Fig.4 FCC ID:2ATOY-RT612AE Page 3 of 5 Fig.5 Fig.6 FCC ID:2ATOY-RT612AE Page 4 of 5 Fig.7 Fig.8 FCC ID:2ATOY-RT612AE Page 5 of 5 Fig.9

Label Location FCC ID: 2ATOY-RT612AE

FCC ID:2ATOY-RT612AE Page 1 of 5 Exterior Photographs of EUT Fig.1 Fig.2 FCC ID:2ATOY-RT612AE Page 2 of 5 Fig.3 Fig.4 Bluetooth antenna FCC ID:2ATOY-RT612AE Page 3 of 5 Fig.5 Fig.6 FCC ID:2ATOY-RT612AE Page 4 of 5 Fig.7 Fig.8 FCC ID:2ATOY-RT612AE Page 5 of 5 Fig.9

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 1 of 3 RADIO FREQUENCY EXPOSURE Limit According to section B.4 of 447498 D04 Interim General RF Exposure Guidance v01 SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time-averaged power or maximum time-averaged ERP, whichever is greater. If the ERP of a device is not easily determined, such as for a portable device with a small form factor, the applicant may use the available maximum time-averaged power exclusively if the device antenna or radiating structure does not exceed an electrical length of λ/4. As for devices with antennas of length greater than λ/4 where the gain is not well defined, but always less than that of a half-wave dipole (length λ/2), the available maximum time-averaged power generated by the device may be used in place of the maximum time-averaged ERP, where that value is not known. The separation distance is the smallest distance from any part of the antenna or radiating structure for all persons, during operation at the applicable ERP. In the case of mobile or portable devices, the separation distance is from the outer housing of the device where it is closest to the antenna. The SAR-based exemption formula of § 1.1307(b)(3)(i)(B), repeated here as Formula (B.2), applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power or effective radiated power (ERP), whichever is greater, of less than or equal to the threshold Pth (mW). This method shall only be used at separation distances from 0.5 cm to 40 cm and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by Formula (B.2). Where and f is in GHz, d is the separation distance (cm), and ERP 20cm is per Formula (B.1). Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 2 of 3 The example values shown in Table B.2 are for illustration only. Frequency (MHz) Distance (mm) 5 10 15 20 25 30 35 40 45 50 300 39 65 88 110 129 148 166 184 201 217 450 22 44 67 89 112 135 158 180 203 226 835 9 25 44 66 90 116 145 175 207 240 1900 3 12 26 44 66 92 122 157 195 236 2450 3 10 22 38 59 83 111 143 179 219 3600 2 8 18 32 49 71 96 125 158 195 5800 1 6 14 25 40 58 80 106 136 169 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE This report shall not be reproduced except in full, without the written approval of Shenzhen Tongzhou Testing Co.,Ltd Page 3 of 3 Conducted Power Results Test Mode Antenna Frequency[MHz] Result[dBm] DH5 Ant1 2402 -1.06 DH5 Ant1 2441 -0.74 DH5 Ant1 2480 -0.61 2DH5 Ant1 2402 -1.15 2DH5 Ant1 2441 -0.84 2DH5 Ant1 2480 -0.67 3DH5 Ant1 2402 -1.07 3DH5 Ant1 2441 -0.87 3DH5 Ant1 2480 -0.74 Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.5 -1.0 -1.0 Tolerance ±(dB) 1 1 1 π/4-DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.5 -1.5 -1 Tolerance ±(dB) 1 1 1 8-DPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) -1.5 -1.5 -1 Tolerance ±(dB) 1 1 1 Results Test Mode Max Conducted Tune Up Power(dBm) Max of ERP and Conducted Power including Tune Up (dBm) Max of ERP and Conducted Power including Tune Up (mW) Exemption Limit(mW) GFSK 0 0.0 1.00 3 π/4-DQPSK 0 0.0 1.00 3 8DPSK 0 0.0 1.00 3 Max of ERP and Conducted Power including Tune Up (dBm) = Max Conducted Tune Up Power(dBm) and Max Conducted Tune Up Power(dBm) + Antenna Gain(dBi)-2.15), whichever is greater. The antenna gain of the EUT for BT is 1.72 dBi (Max). the Maximum Eirp is used for Routine Evaluation Exemption according to B.4 of 447498 D04 Interim General RF Exposure Guidance v01. So, the SAR evaluation is not required.

Tolerances (Unless otherwise specified) 深圳市迎丰天线技术有限公司 SHENZHENYINGFENGANTENNATECHNOLOGYCO.,LTD X : ± 1X.X : ± 0.1X.XX : ± 0.01 Angle : ± Hole Dia. : ± Scale :Unit ： mm THIS SPECIFICATION IS THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED IN ALL CIRCUMSTANCES WITHOUT WRITTEN PERMISSION Drawn By : ShelleyChecked By : Simon Designed By :SimonApproved By :Simon TITLE ： BT FPC Antenna(RT6232F-L) PART S2B4BB1F1B61000 REV. NO.A PAGE 1 OF6 S 2 1 B B F B 1 0B 4 (1) (2) (3) (4) (5) 6 1 00 BT FPC Antenna (RT6232F-L) 1.Explanation of Product Number Product Description: (1) Product Categories: B:BT Antenna (2) Dimensions: B1:21.88*7.5(mm) (3) Material: F: FPC (4) Working Frequencies: 1B: 2.4G-2.5G (5) Antenna Series: 01: Serial number Tolerances (Unless otherwise specified) 深圳市迎丰天线技术有限公司 SHENZHENYINGFENGANTENNATECHNOLOGYCO.,LTD X : ± 1X.X : ± 0.1X.XX : ± 0.01 Angle : ± Hole Dia. : ± Scale :Unit ： mm THIS SPECIFICATION IS THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED IN ALL CIRCUMSTANCES WITHOUT WRITTEN PERMISSION Drawn By : ShelleyChecked By : Simon Designed By :SimonApproved By :Simon TITLE ： BT FPC Antenna(RT6232F-L) PART S2B4BB1F1B61000 REV. NO.A PAGE 2 OF6 2.Features *Stable and reliable in performances *RoHS compliance *Low cost 3.Applications *BT 4 ． Description * YINGFENMG FPC antenna series are specially designed for 2.4G-2.5G band application. Based on YINGFENG proprietary designs and processes, this FPC antenna has excellent stability and sensitivity to consistently provide high signal reception efficiency. 5. AntennaElectrical Specifications : CharacteristicsSpecificationsUnit Outline Dimensions 21.78*7.5 mm Frequency2400~2500MHz Impedance50  PolarizationLinear Polarization Return Loss TableReturn Loss Freq.Band2.4GHz2.45GHz2.5GHz dB-16.98-29.81-17.34 VSWR TableVSWR Freq.Band2.4GHz2.45GHz2.5GHz 1.181.081.29 GAIN Table Total Gain = Xpol + Ppol Freq.Band 2400MHz2450MHz2485MHz2500MHz PeakGain(dBi) 1.511..721.691.23 Tolerances (Unless otherwise specified) 深圳市迎丰天线技术有限公司 SHENZHENYINGFENGANTENNATECHNOLOGYCO.,LTD X : ± 1X.X : ± 0.1X.XX : ± 0.01 Angle : ± Hole Dia. : ± Scale :Unit ： mm THIS SPECIFICATION IS THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED IN ALL CIRCUMSTANCES WITHOUT WRITTEN PERMISSION Drawn By : ShelleyChecked By : Simon Designed By :SimonApproved By :Simon TITLE ： BT FPC Antenna(RT6232F-L) PART S2B4BB1F1B61000 REV. NO.A PAGE 3 OF6 6 ． Dimensions (unit: mm) blic errand：±0.2mm 正面加双面胶3.5mm 7.Measurement Characteristics: (1) Return Loss (2) VSWR Tolerances (Unless otherwise specified) 深圳市迎丰天线技术有限公司 SHENZHENYINGFENGANTENNATECHNOLOGYCO.,LTD X : ± 1X.X : ± 0.1X.XX : ± 0.01 Angle : ± Hole Dia. : ± Scale :Unit ： mm THIS SPECIFICATION IS THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED IN ALL CIRCUMSTANCES WITHOUT WRITTEN PERMISSION Drawn By : ShelleyChecked By : Simon Designed By :SimonApproved By :Simon TITLE ： BT FPC Antenna(RT6232F-L) PART S2B4BB1F1B61000 REV. NO.A PAGE 4 OF6 8.Three D Radiation Pattern measurements 9.Radiation Pattern Tolerances (Unless otherwise specified) 深圳市迎丰天线技术有限公司 SHENZHENYINGFENGANTENNATECHNOLOGYCO.,LTD X : ± 1X.X : ± 0.1X.XX : ± 0.01 Angle : ± Hole Dia. : ± Scale :Unit ： mm THIS SPECIFICATION IS THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED IN ALL CIRCUMSTANCES WITHOUT WRITTEN PERMISSION Drawn By : ShelleyChecked By : Simon Designed By :SimonApproved By :Simon TITLE ： BT FPC Antenna(RT6232F-L) PART S2B4BB1F1B61000 REV. NO.A PAGE 5 OF6 9-1.3D Gain Pattern (Radiation Pattern at 2450 MHz) 9-2.2D Gain complete machine (Radiation Pattern at 2450 MHz) -Y -Z X Tolerances (Unless otherwise specified) 深圳市迎丰天线技术有限公司 SHENZHENYINGFENGANTENNATECHNOLOGYCO.,LTD X : ± 1X.X : ± 0.1X.XX : ± 0.01 Angle : ± Hole Dia. : ± Scale :Unit ： mm THIS SPECIFICATION IS THE PROPERTY OF UNICTRON TECHNOLOGIES CORPORATION AND SHALL NOT BE REPRODUCED OR USED IN ALL CIRCUMSTANCES WITHOUT WRITTEN PERMISSION Drawn By : ShelleyChecked By : Simon Designed By :SimonApproved By :Simon TITLE ： BT FPC Antenna(RT6232F-L) PART S2B4BB1F1B61000 REV. NO.A PAGE 6 OF6 9-3.complete machine Efficiency Table 10.Revision Control: RevisionDateContentRemark A2024-1-20New Issued.N/A Frequency(MHz) 2400 2420 2450 2460 2480 2500 Efficiency (dB)-2.22 -1.71 -2.09 -2.13 -2.24 -2.07 Efficiency (%)27.9 29.33029 28.726 Gain (dBi)1.02 1.15 1.24 1.23 1.06 0.95

Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 1 of 46 Appendix Test Data for BT(BDR/EDR) (Conducted Measurement) Product Name: TRUE WIRELESS EARBUDS Trade Mark: BarbetSound Test Model: RT62AE FCC ID: 2ATOY-RT612AE Environmental Conditions Temperature: 23.8°C Relative Humidity: 58% ATM Pressure: 100.0 kPa Test Engineer: Allen Lai Supervised by: Hugo Chen NOTE N/A Appendix A: 20dB Emission Bandwidth Test Result Test Mode Antenna Frequency [MHz] 20db EBW [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 1.10 2401.47 2402.57 --- --- DH5 Ant1 2441 1.10 2440.47 2441.58 --- --- DH5 Ant1 2480 1.11 2479.47 2480.58 --- --- 2DH5 Ant1 2402 1.33 2401.36 2402.68 --- --- 2DH5 Ant1 2441 1.33 2440.35 2441.68 --- --- 2DH5 Ant1 2480 1.35 2479.35 2480.69 --- --- 3DH5 Ant1 2402 1.34 2401.35 2402.69 --- --- 3DH5 Ant1 2441 1.34 2440.35 2441.69 --- --- 3DH5 Ant1 2480 1.35 2479.34 2480.69 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 2 of 46 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 3 of 46 DH5-Ant1-2480 2DH5-Ant1-2402 2DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 4 of 46 2DH5-Ant1-2480 3DH5-Ant1-2402 3DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 5 of 46 3DH5-Ant1-2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 6 of 46 Appendix B: Occupied Channel Bandwidth Test Result Test Mode Antenna Frequency [MHz] OCB [MHz] FL [MHz] FH [MHz] Limit [MHz] Verdict DH5 Ant1 2402 0.974 2401.5325 2402.5065 --- --- DH5 Ant1 2441 0.98 2440.5265 2441.5065 --- --- DH5 Ant1 2480 0.992 2479.5235 2480.5155 --- --- 2DH5 Ant1 2402 1.244 2401.4006 2402.6444 --- --- 2DH5 Ant1 2441 1.247 2440.3976 2441.6444 --- --- 2DH5 Ant1 2480 1.262 2479.3916 2480.6533 --- --- 3DH5 Ant1 2402 1.229 2401.4066 2402.6354 --- --- 3DH5 Ant1 2441 1.235 2440.4066 2441.6414 --- --- 3DH5 Ant1 2480 1.247 2479.3976 2480.6444 --- --- Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 7 of 46 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 8 of 46 DH5-Ant1-2480 2DH5-Ant1-2402 2DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 9 of 46 2DH5-Ant1-2480 3DH5-Ant1-2402 3DH5-Ant1-2441 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 10 of 46 3DH5-Ant1-2480 Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 11 of 46 Appendix C: Maximum peak conducted output power Test Result Test Mode Antenna Frequency [MHz] Conducted Peak Power [dBm] Conducted Limit [dBm] Verdict DH5 Ant1 2402 -1.06 ≤20.97 PASS DH5 Ant1 2441 -0.74 ≤20.97 PASS DH5 Ant1 2480 -0.61 ≤20.97 PASS 2DH5 Ant1 2402 -1.15 ≤20.97 PASS 2DH5 Ant1 2441 -0.84 ≤20.97 PASS 2DH5 Ant1 2480 -0.67 ≤20.97 PASS 3DH5 Ant1 2402 -1.07 ≤20.97 PASS 3DH5 Ant1 2441 -0.87 ≤20.97 PASS 3DH5 Ant1 2480 -0.74 ≤20.97 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 12 of 46 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 13 of 46 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS 2DH5-Ant1-2441-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 14 of 46 2DH5-Ant1-2480-PASS 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 15 of 46 3DH5-Ant1-2480-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 16 of 46 Appendix D: Carrier frequency separation Test Result Test Mode Antenna Frequency [MHz] Result [MHz] Limit [MHz] Verdict DH5 Ant1 Hop 0.974 ≥0.740 PASS 2DH5 Ant1 Hop 1.096 ≥0.900 PASS 3DH5 Ant1 Hop 0.922 ≥0.900 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 17 of 46 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 18 of 46 3DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 19 of 46 Appendix E: Time of occupancy Test Result Test Mode Antenna Frequency [MHz] BurstWidth [ms] TotalHops [Num] Result [s] Limit [s] Verdict DH5 Ant1 Hop 2.910 80 0.233 ≤0.4 PASS 2DH5 Ant1 Hop 2.917 120 0.35 ≤0.4 PASS 3DH5 Ant1 Hop 2.918 60 0.175 ≤0.4 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 20 of 46 Test Graphs DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 21 of 46 2DH5-Ant1-Hop-PASS 3DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 22 of 46 Appendix F: Number of hopping channels Test Result Test Mode Antenna Frequency [MHz] Result [Num] Limit [Num] Verdict DH5 Ant1 Hop 79 ≥15 PASS 2DH5 Ant1 Hop 79 ≥15 PASS 3DH5 Ant1 Hop 79 ≥15 PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 23 of 46 Test Graphs DH5-Ant1-Hop-PASS 2DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 24 of 46 3DH5-Ant1-Hop-PASS Shenzhen Tongzhou Testing Co.,Ltd FCC ID: 2ATOY-RT612AE Report No.: TZ0004240901-FRF01 Page 25 of 46 Appendix G: Band edge measurements Test Result Test Mode Antenna Ch.Name Frequency [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -2.23 -47.48 ≤-22.23 PASS DH5 Ant1 High 2480 -1.87 -46.18 ≤-21.87 PASS DH5 Ant1 Low Hop_2402 -2.76 -47.59 ≤-22.76 PASS DH5 Ant1 Hig…
