2ATQ2-CEGW02Gateway

CrisisAlert™ Gateway Installation Guide A step-by-step guide to install the Gateway with CENTEGIX’sCrisisAlert™ Parts List Please ensure the following are all included in your box. If not, reach out to your Onboarding Specialist so they can assist you with the missing equipment. Gateway Device x 1 Power Supply (Micro USB) x 1 Antenna x 1 Ethernet Cable x 1 Gateway Setup Instructions 1. Install Antenna ○ Connect the provided antenna to the coaxial port on the front of the gateway. 2. Install Power Supply ○ Connect the provided power supply to the mini usb port on the back of the gateway. ○ Ensure that the power supply is 5v DC and between 2 amp and 3.5 amps 3. Install Ethernet Cable ○ Connect the provided ethernet cable to the ethernet port on the back of the gateway. 4. Power on and Install Device ○ Connect the ethernet cable to your existing switch. ○ Plug the gateway device into a power outlet and power on the gateway. ○ The screen should turn on and within 2-5 minutes the IP information will be displayed indicating that the gateway is connected and ready. If not, please reach out to your Onboarding Specialist for assistance. 5. Position Gateway ○ For proper installation, the gateway must be between 5”-8.25” in length and the antenna must be at least 4” away from other RF emitting devices. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF Exposure Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

34ED LLC Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/7/2023 U.S. Agent Designation 34ED LLC acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2ATQ2-CEGW02): Name and company of U.S. agent: 34ED LLC Physical U.S. address of agent: 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia United States FRN of U.S. agent: 0028589364 Email address of U.S. agent: [email protected] 34ED LLC acknowledges their obligation to accept service of process on behalf of 34ED LLC. 34ED LLC with the FRN 0028589364 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Adam Williams CTO 34ED LLC Signature Adam Williams CTO 34ED LLC 48_[mo del] US_Agent_2.911(d)(7) - U, V05

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: 34ED LLC Address: 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia, United States Phone: +1-678-294-5466 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2023-08-07 Name / Title: Adam Williams / CTO Company: 34ED LLC Address: 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia, United States Phone: +1-678-294-5466 Fax: N/A E-Mail: [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2ATQ2-CEGW02 Z120 We, applicant Company Name: 34ED LLC Address: 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia, United States Phone: +1-678-294-5466 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2023-08-07 Name / Title: Adam Williams / CTO Company: 34ED LLC Address: 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia, United States Phone: +1-678-294-5466 Fax: N/A E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2ATQ2-CEGW02 Z120 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Signature Date:2023-08-07 Name / Title: Adam Williams / CTO Company: 34ED LLC Address: 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia, United States Phone: +1-678-294-5466 Fax: N/A E-Mail: [email protected]

Audit Mode Request Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern The company as listed hereby requests to supersede the exhibits listed in the table below from the application with the FCC ID as listed after the 30 days period. MODEL NUMBER: (MODEL NUMBER OF UNIT TESTED) Z120 FCC ID: 2ATQ2-CEGW02 Granted on: 08/07/2023 Company Name: 34ED LLC Address: 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia, United States Phone: +1-678-294-5466 The Reason for the supersede are as follows: Exhibit type Reason for supersede Appendix A test data_rev Update radiated band-edge as update antenna gain Antenna information_rev Customer provide wrong antenna report by mistake and update correct antenna test report Operation description_rev Update correct antenna gain information RF exposure evaluation_rev Update RF exposure evaluate values based on revised correct antenna gain information Test Report _rev Update correct antenna gain information New exhibits will be uploaded to the application once the audit mode is active, Sincerely, 2023-08-14 Signature Date Printed Name Adam Williams Job Title CTO Company 34ED LLC Address 2120 Powers Ferry Rd UNIT 110 Atlanta Georgia, United States Phone +1-678-294-5466 Email [email protected]

Page 1 of 5 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Antenna Page 2 of 5 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 5 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 5 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 5 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10

Page 1 of 1 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L4.0cm x 2.0cm) Label Location Gateway Model: Z120 FCC ID: 2ATQ2-CEGW02

Page 1 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 Page 2 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10 Page 6 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 11 Fig. 12 Page 7 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 13 Fig. 14 Page 8 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 15 Fig. 16 Page 9 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 17 Fig. 18 Page 10 of 10 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 19

Page 1 of 3 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information FCC ID : 2ATQ2-CEGW02 Product name : Gateway Test Model : Z120 Power Supply : Input: 5V3.5A For Adapter Input: 100-240V~, 50/60Hz, 0.8A For Adapter Output: 5V3.5A Hardware Version : / Software Version : / Zigbee : 2405MHz-2480MHz Channel Number : 16 Channels Channel Spacing : 5MHz Modulation Type : O-QPSK Antenna Type : External Antenna Antenna Gain : 3.15dBi Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Devices 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. Page 2 of 3 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Antenna type and antenna number Operate frequency band Maximum antenna gain Note External Antenna 2400MHz-2500MHz 3.15dBi Zigbee Antenna Page 3 of 3 FCC ID: 2ATQ2-CEGW02 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 6. Conducted Power < Zigbee > Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) O-QPSK 0 2405 -0.82 7 2440 -0.68 15 2480 -0.64 7. Manufacturing Tolerance < Zigbee Max Conducted Power > Mode Channel Peak Conducted Output Power (dBm) ANT Max. Tune Up Power (dBm) O-QPSK 0 -0.82 0±1.0 7 -0.68 0±1.0 15 -0.64 0±1.0 8. Measurement Results Standalone MPE Evaluation As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna refer to antenna information, the RF power density can be obtained. [Zigbee] Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm2) MPE Limits (mW/cm2) dBm mW O-QPSK 1.0 1.2589 3.15 2.0654 0.000518 1.0000 Remark: 1. Output power including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is …

Text truncated - open the document above for the full version.

Antenna Study  Project Name ： G ate w a y  Debugging frequency band: 2.4G  Valuation date ： 2023.07.25 08  Client Name: 34ED LLC, DBA Centegix 1 Room 101, Building 2, No. 9 Xinfa Road, Lincun, Tangxia Town, Dongguan City, Guangdong Province, China External Antenna 2 Testing 3D microwave darkroom(6m*6m*6m) Testing environment External Antenna 3 Antenna • Antenna name: 2.4G • Antenna Type ： External • Covers ： 2.4G 4 S Parameter_Return Loss&VSWR 5 Efficiency and Gain‐Smith Frequency ID 1 2 3 4 5 6 7 8 9 10 11 Frequency (MHz) 2400.0 2410.0 2420.0 2430. 0 2440.0 2450.0 2460.0 2470.0 2480.0 2490.0 2500.0 Gain (dBi) 3.15 2.84 2.11 1.42 1.64 1. 66 2.18 2.32 1.84 1.54 1.24 Efficiency (%) 81.97 75.78 71.35 71.54 75.99 78.52 82.92 81.57 73.26 66.35 65.78 2400.0MHz H+V, Eff: 82.0%Back View2400.0MHz Total(E1-XZ), Max= 1.90dBi2400.0MHz Total(E2-YZ), Max= 2.22dBiTotal(H-XY), Max= 2.85dBi, CirD=3.19 2.85 1.01 -0.84 -2.68 -4.52 -6.36 -8.2 -10.05 -11.89 -13.73 -15.57 -17.41 -19.26 -21.1 -22.94 -24.78 -26.62 -28.47 2410.0MHz H+V, Eff: 75.8%Back View2410.0MHz Total(E1-XZ), Max= 1.36dBi2410.0MHz Total(E2-YZ), Max= 1.94dBiTotal(H-XY), Max= 2.64dBi, CirD=3.71 2.64 0.8 -1.04 -2.88 -4.73 -6.57 -8.41 -10.25 -12.1 -13.94 -15.78 -17.62 -19.46 -21.31 -23.15 -24.99 -26.83 -28.67 2420.0MHz H+V, Eff: 71.3%Back View2420.0MHz Total(E1-XZ), Max= 0.88dBi2420.0MHz Total(E2-YZ), Max= 1.69dBiTotal(H-XY), Max= 1.91dBi, CirD=3.40 1.91 0.06 -1.78 -3.62 -5.46 -7.31 -9.15 -10.99 -12.83 -14.67 -16.52 -18.36 -20.2 -22.04 -23.88 -25.73 -27.57 -29.41 2430.0MHz H+V, Eff: 71.5%Back View2430.0MHz Total(E1-XZ), Max= 0.76dBi2430.0MHz Total(E2-YZ), Max= 1.42dBiTotal(H-XY), Max= 1.03dBi, CirD=2.61 1.42 -0.42 -2.26 -4.1 -5.94 -7.79 -9.63 -11.47 -13.31 -15.16 -17 -18.84 -20.68 -22.52 -24.37 -26.21 -28.05 -29.89 2440.0MHz H+V, Eff: 76.0%Back View2440.0MHz Total(E1-XZ), Max= 1.14dBi2440.0MHz Total(E2-YZ), Max= 1.64dBiTotal(H-XY), Max= 1.13dBi, CirD=2.23 1.64 -0.21 -2.05 -3.89 -5.73 -7.58 -9.42 -11.26 -13.1 -14.94 -16.79 -18.63 -20.47 -22.31 -24.15 -26 -27.84 -29.68 2450.0MHz H+V, Eff: 78.5%Back View2450.0MHz Total(E1-XZ), Max= 1.48dBi2450.0MHz Total(E2-YZ), Max= 1.57dBiTotal(H-XY), Max= 1.56dBi, CirD=2.24 1.66 -0.18 -2.03 -3.87 -5.71 -7.55 -9.4 -11.24 -13.08 -14.92 -16.76 -18.61 -20.45 -22.29 -24.13 -25.97 -27.82 -29.66 2460.0MHz H+V, Eff: 82.9%Back View2460.0MHz Total(E1-XZ), Max= 1.76dBi2460.0MHz Total(E2-YZ), Max= 1.88dBiTotal(H-XY), Max= 2.18dBi, CirD=2.61 2.18 0.34 -1.51 -3.35 -5.19 -7.03 -8.87 -10.72 -12.56 -14.4 -16.24 -18.08 -19.93 -21.77 -23.61 -25.45 -27.29 -29.14 2470.0MHz H+V, Eff: 81.6%Back View2470.0MHz Total(E1-XZ), Max= 1.82dBi2470.0MHz Total(E2-YZ), Max= 2.32dBiTotal(H-XY), Max= 2.28dBi, CirD=3.49 2.32 0.48 -1.36 -3.2 -5.04 -6.89 -8.73 -10.57 -12.41 -14.25 -16.1 -17.94 -19.78 -21.62 -23.47 -25.31 -27.15 -28.99 2480.0MHz H+V, Eff: 73.3%Back View2480.0MHz Total(E1-XZ), Max= 1.18dBi2480.0MHz Total(E2-YZ), Max= 1.66dBiTotal(H-XY), Max= 1.84dBi, CirD=4.34 1.84 -0.01 -1.85 -3.69 -5.53 -7.38 -9.22 -11.06 -12.9 -14.74 -16.59 -18.43 -20.27 -22.11 -23.95 -25.8 -27.64 -29.48 2490.0MHz H+V, Eff: 66.4%Back View2490.0MHz Total(E1-XZ), Max= 0.24dBi2490.0MHz Total(E2-YZ), Max= 0.55dBiTotal(H-XY), Max= 0.74dBi, CirD=3.73 0.74 -1.1 -2.94 -4.79 -6.63 -8.47 -10.31 -12.15 -14 -15.84 -17.68 -19.52 -21.37 -23.21 -25.05 -26.89 -28.73 -30.58 2500.0MHz H+V, Eff: 65.8%Back View2500.0MHz Total(E1-XZ), Max= -0.29dBi2500.0MHz Total(E2-YZ), Max= 0.44dBiTotal(H-XY), Max= 0.17dBi, CirD=2.17 0.74 -1.1 -2.95 -4.79 -6.63 -8.47 -10.31 -12.16 -14 -15.84 -17.68 -19.52 -21.37 -23.21 -25.05 -26.89 -28.73 -30.58

Page 1 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A RF Test Data for Zigbee(Conducted Measurement) Product Name: Gateway Test Model: Z120 Environmental Conditions Temperature: 23.8 C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Nick Peng Supervised by: Ling Zhu Page 2 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT ZIGB 2405 Ant1 1.328 0.5 Pass NVNT ZIGB 2440 Ant1 1.411 0.5 Pass NVNT ZIGB 2480 Ant1 1.324 0.5 Pass Page 3 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs -6dB Bandwidth NVNT ZIGB 2405MHz Ant1 -6dB Bandwidth NVNT ZIGB 2440MHz Ant1 Page 4 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT ZIGB 2480MHz Ant1 Page 5 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.2 Maximum Conducted Output Power Condition Mode Frequency (MHz) Antenna Total Power (dBm) Limit (dBm) Verdict NVNT ZIGB 2405 Ant1 -0.82 30 Pass NVNT ZIGB 2440 Ant1 -0.68 30 Pass NVNT ZIGB 2480 Ant1 -0.64 30 Pass Page 6 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs Power NVNT ZIGB 2405MHz Ant1 Power NVNT ZIGB 2440MHz Ant1 Page 7 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Power NVNT ZIGB 2480MHz Ant1 Page 8 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Total PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT ZIGB 2405 Ant1 -12.96 8 Pass NVNT ZIGB 2440 Ant1 -11.76 8 Pass NVNT ZIGB 2480 Ant1 -13.02 8 Pass Page 9 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs PSD NVNT ZIGB 2405MHz Ant1 PSD NVNT ZIGB 2440MHz Ant1 Page 10 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity PSD NVNT ZIGB 2480MHz Ant1 Page 11 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.4 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT ZIGB 2405 Ant1 -55.29 -20 Pass NVNT ZIGB 2480 Ant1 -55.79 -20 Pass Page 12 of 23 FCC ID: 2ATQ2-CEGW02 Report No.: LCSA071823127EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs Band Edge NVNT ZIGB 2405MHz Ant1 Ref Band Edge NVNT ZIGB 2405MHz Ant1 Emission Page 13 of …
