2ATQIW7Smart Phone

1 User Guide Product Name：Smart Phone Brand Name : Wings Mobile Model Name ： W7, WX Manufacture ：COOSEA GROUP (HK) COMPANY LIMITED 2 Contents I. CAUTIONS ON MOBILE PHONE USE ............................................................................................................... 4 1.1 INTERFERENCE ......................................................................................................................................... 4 1.2 REASONABLE USE .................................................................................................................................... 4 1.3 QUALIFIED MAINTENANCE SERVICE .......................................................................................................... 4 1.4 WATER-RESISTANCE................................................................................................................................. 4 1.5 EMERGENCY CALLS .................................................................................................................................. 4 2 PRECAUTIONS FOR USE OF BATTERY ........................................................................................................... 4 3 CAUTIONS FOR CHILDREN............................................................................................................................ 5 II. KEYS AND PARTS ........................................................................................................................................ 6 III. START TO USE ........................................................................................................................................... 7 3.1 TO INSERT SIM CARD(S): ........................................................................................................................ 7 3.2 CHARGE THE BATTERY ............................................................................................................................. 9 IV. BASIC FUNCTIONS ..................................................................................................................................... 9 1. LOCK AND UNLOCK THE SCREEN ................................................................................................................ 9 2. MAKE IT YOURS .........................................................................................................................................11 3 3. SWITCH TO RECENTLY USED APPLICATION ...............................................................................................17 4. MAKE A CALL ............................................................................................................................................17 5. CALL LOG ..................................................................................................................................................19 6. ANSWERING PHONE CALLS AND REJECTION ..............................................................................................20 7. ADD A CONTACT ........................................................................................................................................21 8. SEND AND RECEIVE MESSAGE(S) ..............................................................................................................22 9. BROWSER THE WEB ..................................................................................................................................24 10. ENJOY MUSIC ..........................................................................................................................................24 11. DOWNLOAD APPLICATIONS FROM PLAY STORE .......................................................................................25 12. MANAGE APPLICATIONS ..........................................................................................................................25 13. APPLICATIONS & UTILITIES .............................................................................................................27 14. SETTINGS ................................................................................................................................................27 V. TECHNICAL INFORMATION .........................................................................................................................32 4 I. Cautions on mobile phone use 1.1 Interference All phones may be interfered, which affect phone calls. 1.2 Reasonable use Use only in the normal position. Do not touch the antenna area unnecessarily. 1.3 Qualified maintenance service Only qualified personnel may install or repair this product. 1.4 Water-resistance Your device is non water-resistant. Keep it dry. 1.5 Emergency calls Ensure the phone is switched on and in service. Enter the emergency number and press the Dialer icon. 2 Precautions for use of battery 2.1 Do not dispose of batteries near or in a fire to avoid dangers. 2.2 Do not dispose of batteries in the garbage. Dispose of batteries to assigned battery recycling center. 5 3 Cautions for children Keep your device out the reach of children in case of accidental injury caused by incorrect use of the device as toys. 6 II. Keys and parts 7  1. SIM Tray  2. Main Mic  3. Audio Jack  4. Type-C jack  5. Speaker  6. Receiver  7. Front camera  8. Light sensor  9. P-sensor  10. Volume key  11. Power key  12. Rear camera  13.Flashlight  14.Fingerprint  15.Sub-Mic III. Start to use 3.1 To insert SIM card(S): Insert the SIM card correctly in the card slot(s) (See figure below), suggest switch off the phone when you insert SIM card. Insert the Micro SD card into the slot with the correct direction (See figure below), suggest switch off the phone when you insert SIM card. Note: Use only compatible memory cards with this device. Incompatible memory cards may damage the card or the device and corrupt the data stored in the card. 8 9 3.2 Charge the battery During charging, the battery indicator on the phone…

Text truncated - open the document above for the full version.

Wings Mobile Telecom SL TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.09.09 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, Wings Mobile Telecom SL hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Antonio Milio Signature:

Differences Description We Wings Mobile Telecom SL state: Product： Smart Phone Model Name： W7, WX Trade Name: Wings Mobile FCC ID: 2ATQIW7 The electrical circuit design, layout, components used and internal wiring for above models are identical, Only different in model name and Software Version number. Model Name Software version number W7 K6307Q4WS.FHDJ.P0.ANASAPA9DATJDFTL.0103_1159.V3.04 WX K6307Q4WS-WX.FHDJ.P0.ANASAPA9DATJDFTL.0103_1327.V3.04 Signatory Date 2020-09-09 Signature Name: Antonio Milio Title: Manager Company: Wings Mobile Telecom SL Address: c/Beethoven 15, piso 4, Barcelona, Spain

Wings Mobile Telecom SL TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.09.09 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Smart Phone / W7,WX /FCC ID: 2ATQIW7) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description • Tune up Procedure • Part List • SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Antonio Milio Signature:

Page 1 of 6 Report No.: STS2007301 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 6 Report No.: STS2007301 Photo 3 Photo 4 Page 3 of 6 Report No.: STS2007301 Photo 5 Photo 6 Page 4 of 6 Report No.: STS2007301 Photo 7 Photo 8 FM Antenna Page 5 of 6 Report No.: STS2007301 Photo 9 Photo 10 Page 6 of 6 Report No.: STS2007301 Photo 11

FCC Label Smart Phone Model name: W7 FCC ID: 2ATQIW7 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 7 Report No.: STS2007301 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 NFC Antenna LTE RX Antenna GSM/WCDMA/LTE Antenna BT/WIFI/GPS Antenna Page 2 of 7 Report No.: STS2007301 Photo 3 Photo 4 Page 3 of 7 Report No.: STS2007301 Photo 5 Photo 6 Page 4 of 7 Report No.: STS2007301 Photo 7 Photo 8 Page 5 of 7 Report No.: STS2007301 Photo 9 Photo 10 Page 6 of 7 Report No.: STS2007301 Photo 11 Photo 12 Page 7 of 7 Report No.: STS2007301 Photo 13

W7_SAR Setup photo Right Touch Right Tilt Left Touch Left Tilt Front side(separation distance is 10mm) Back side(separation distance is 10mm) Left Edge(separation distance is 10mm) Right Edge(separation distance is 10mm) Top Edge(separation distance is 10mm) Bottom Edge(separation distance is 10mm)

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] S T L A B S Testing Engineer : (Aaron Bu) Technical Manager : (Jason Lu) Authorized Signatory : (Vita Li) SAR Dipole Performance Measurement Report EUT Type： SAR Validation Dipole and Waveguide Model Name： DIP 0G835-332, DIP 1G800-329, DIP 1G900-333, DIP 2G450-335, DIP 2G600-336, WAG32 Brand Name: SATIMO Test Conclusion： Pass Test Date： 14 Aug. 2019~16 Aug. 2019 Date of Issue： 17 Aug. 2019 ISSUED BY Shenzhen STS Test Services Co., Ltd. 1. Equipment List Kind of Equipment Manufacturer Type No. Serial No. Last Calibration Calibrated Until PC Acer N/A N/A N/A N/A E-Field Probe MVG SSE5 SN 14/16 EP309 2018.12.13 2019.12.12 Dielectric Probe Kit MVG SCLMP SN 32/14 OCPG67 2018.12.01 2019.11.30 Phantom1 MVG SAM SN 32/14 SAM115 N/A N/A Phantom2 MVG SAM SN 32/14 SAM116 N/A N/A Attenuator Agilent 99899 DC-18GHz N/A N/A Directional coupler Narda 4226-20 3305 N/A N/A Network Analyzer Agilent 8753ES US38432810 2019.10.11 2020.10.10 Multi Meter Keithley Multi Meter 2000 4050073 2019.10.11 2020.10.10 Signal Generator Agilent N5182A MY50140530 2019.10.09 2020.10.08 Power Amplifier DESAY ZHL-42W 9638 2019.10.09 2020.10.08 Power Meter R&S NRP 100510 2019.10.16 2020.10.15 Power Sensor R&S NRP-Z11 101919 2019.10.12 2020.10.11 Power Sensor Agilent E9301A MY41497725 2019.10.12 2020.10.11 Temperature hygrometer SuWei SW-108 N/A 2019.10.13 2020.10.12 ISSUED BY Shenzhen STS Test Services Co., Ltd. 2.<Justification of the extended calibration> Referring to KDB 865664 D01, if dipoles are verified in return loss<-20dB, (within 20% of prior calibration),and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head 835 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -28.11 - 51.6 - 2018.08.15 -27.05 -3.77 54.69 3.09 2019.08.14 -26.41 -2.37 52.62 -2.07 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 835MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Body 835 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -23.87 - 49.0 - 2018.08.15 -22.21 -6.95 52.59 3.59 2019.08.14 -24.25 9.19 52.65 0.06 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Body 835MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Head 1800 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -29.51 - 46.7 - 2018.08.16 -25.32 -14.2 45.24 -1.46 2019.08.15 -26.39 4.23 44.94 -0.30 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 1800 MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Body 1800 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -24.59 - 48.8 - 2018.08.16 -24.95 1.46 45.42 -3.38 2019.08.15 -26.77 7.29 46.31 0.79 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Body 1800 MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Head 1900 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -23.68 - 51.2 - 2018.08.16 -25.00 5.57 47.12 -4.08 2019.08.15 -23.79 -4.84 48.62 1.50 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 1900 MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Body 1900 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -20.22 - 48.8 - 2018.08.16 -23.26 15.03 47.11 -1.79 2019.08.15 -24.15 3.83 48.71 1.60 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Body 1900 MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Head 2450 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -26.00 - 46.1 - 2018.08.16 -29.56 13.69 47.53 1.43 2019.08.16 -28.39 -3.96 48.46 0.93 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Head 2450 MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Body 2450 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -32.75 - 48.8 - 2018.08.16 -31.06 -5.16 45.61 -3.19 2019.08.16 -30.52 -1.74 46.33 0.72 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. <Dipole Verification Data> Body 2450 MHz ISSUED BY Shenzhen STS Test Services Co., Ltd. Head 2600 MHz Date of Measurement Return Loss (dB) Delta (%) Impedance Delta(ohm) 2017.08.15 -34.35 - 50.2 - 2018.08.16 -31.25 -9.02 53.76 3.56 2019.08.16 -31.54 0.93 53.82 0.06 The return loss is <-20dB, within 20% of prior calibration; the impedanc…
