2ATQIWXSmart Phone

1 User Guide Product Name：Smart Phone Brand Nam e: Wings Mobile Model Name ： WX Manufacture ：COOSEA GROUP (HK) COMPANY LIMITED 2 Contents I. CAUTIONS ON MOBILE PHONE USE ............................................................................................................... 4 1.1 INTERFERENCE ......................................................................................................................................... 4 1.2 REASONABLE USE .................................................................................................................................... 4 1.3 QUALIFIED MAINTENANCE SERVICE .......................................................................................................... 4 1.4 WATER-RESISTANCE................................................................................................................................. 4 1.5 EMERGENCY CALLS .................................................................................................................................. 4 2 PRECAUTIONS FOR USE OF BATTERY ........................................................................................................... 4 3 CAUTIONS FOR CHILDREN............................................................................................................................ 5 II. KEYS AND PARTS ........................................................................................................................................ 6 III. START TO USE ........................................................................................................................................... 7 3.1 TO INSERT SIM CARD(S): ........................................................................................................................ 7 3.2 CHARGE THE BATTERY ............................................................................................................................. 9 IV. BASIC FUNCTIONS ..................................................................................................................................... 9 1. LOCK AND UNLOCK THE SCREEN ................................................................................................................ 9 2. MAKE IT YOURS .........................................................................................................................................11 3 3. SWITCH TO RECENTLY USED APPLICATION ...............................................................................................17 4. MAKE A CALL ............................................................................................................................................17 5. CALL LOG ..................................................................................................................................................19 6. ANSWERING PHONE CALLS AND REJECTION ..............................................................................................20 7. ADD A CONTACT ........................................................................................................................................21 8. SEND AND RECEIVE MESSAGE(S) ..............................................................................................................22 9. BROWSER THE WEB ..................................................................................................................................24 10. ENJOY MUSIC ..........................................................................................................................................24 11. DOWNLOAD APPLICATIONS FROM PLAY STORE .......................................................................................25 12. MANAGE APPLICATIONS ..........................................................................................................................25 13. APPLICATIONS & UTILITIES .............................................................................................................27 14. SETTINGS ................................................................................................................................................27 V. TECHNICAL INFORMATION .........................................................................................................................32 4 I. Cautions on mobile phone use 1.1 Interference All phones may be interfered, which affect phone calls. 1.2 Reasonable use Use only in the normal position. Do not touch the antenna area unnecessarily. 1.3 Qualified maintenance service Only qualified personnel may install or repair this product. 1.4 Water-resistance Your device is non water-resistant. Keep it dry. 1.5 Emergency calls Ensure the phone is switched on and in service. Enter the emergency number and press the Dialer icon. 2 Precautions for use of battery 2.1 Do not dispose of batteries near or in a fire to avoid dangers. 2.2 Do not dispose of batteries in the garbage. Dispose of batteries to assigned battery recycling center. 5 3 Cautions for children Keep your device out the reach of children in case of accidental injury caused by incorrect use of the device as toys. 6 II. Keys and parts 7  1. SIM Tray  2. Main Mic  3. Audio Jack  4. Type-C jack  5. Speaker  6. Receiver  7. Front camera  8. Light sensor  9. P-sensor  10. Volume key  11. Power key  12. Rear camera  13.Flashlight  14.Fingerprint  15.Sub-Mic III. Start to use 3.1 To insert SIM card(S): Insert the SIM card correctly in the card slot(s) (See figure below), suggest switch off the phone when you insert SIM card. Insert the Micro SD card into the slot with the correct direction (See figure below), suggest switch off the phone when you insert SIM card. Note: Use only compatible memory cards with this device. Incompatible memory cards may damage the card or the device and corrupt the data stored in the card. 8 9 3.2 Charge the battery During charging, the battery indicator on the phone is …

Text truncated - open the document above for the full version.

Wings Mobile Telecom SL TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.09.09 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, Wings Mobile Telecom SL hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Antonio Milio Signature:

Chip Declaration Letter We Wings Mobile Telecom SL state: Product： Smart Phone Model Name： WX FCC ID: 2ATQIWX These requirements are met by way of the operation of the chip setup. 15.247 (g) and (h) (g) Frequency hopping spread spectrum systems are not required to employ all available hopping channels during each transmission. However, the system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this section should the transmitter be presented with a continuous data (or information) stream. In addition, a system employing short transmission bursts must comply with the definition of a frequency hopping system and must distribute its transmissions over the minimum number of hopping channels specified in this section. (h) The incorporation of intelligence within a frequency hopping spread spectrum system that permits the system to recognize other users within the spectrum band so that it individually and independently chooses and adapts its hopsets to avoid hopping on occupied channels is permitted. The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. Signatory Date 2020-04-16 Signature Name: Antonio Milio Title: Manager Company: Wings Mobile Telecom SL Address: c/Beethoven 15, piso 4, Barcelona, Spain

Wings Mobile Telecom SL TCBJ FORM-4 Issued by: TCB Administrator Revision 6 12/06/10 2020.09.09 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Smart Phone / WX /FCC ID: 2ATQIWX) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description • Tune up Procedure • Part List • SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. required to be submitted with this application be permanently withheld from public review. Please contact me if there is any information you may need. Sincerely, Name: Antonio Milio Signature:

Page 1 of 6 Report No.: STS2007302 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 6 Report No.: STS2007302 Photo 3 Photo 4 Page 3 of 6 Report No.: STS2007302 Photo 5 Photo 6 Page 4 of 6 Report No.: STS2007302 Photo 7 Photo 8 FM Antenna Page 5 of 6 Report No.: STS2007302 Photo 9 Photo 10 Page 6 of 6 Report No.: STS2007302 Photo 11

FCC Label Smart Phone Model name: WX FCC ID: 2ATQIWX This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 7 Report No.: STS2007302 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 NFC Antenna LTE RX Antenna GSM/WCDMA/LTE Antenna BT/WIFI/GPS Antenna Page 2 of 7 Report No.: STS2007302 Photo 3 Photo 4 Page 3 of 7 Report No.: STS2007302 Photo 5 Photo 6 Page 4 of 7 Report No.: STS2007302 Photo 7 Photo 8 Page 5 of 7 Report No.: STS2007302 Photo 9 Photo 10 Page 6 of 7 Report No.: STS2007302 Photo 11 Photo 12 Page 7 of 7 Report No.: STS2007302 Photo 13

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2007302W13 Issued for Wings Mobile Telecom SL c/Beethoven 15, piso 4, Barcelona, Spain Product Name: Smart Phone Brand Name: Wings Mobile Model Name: WX Series Model: N/A FCC ID: 2ATQIWX Test Standard: FCC Part 15.247 S T L A B S Page 2 of 73 Report No.: STS2007302W13 TEST RESULT CERTIFICATION Applicant’s Name ................... : Wings Mobile Telecom SL Address .................................. : c/Beethoven 15, piso 4, Barcelona, Spain Manufacture's Name .............. : COOSEA GROUP (HK) COMPANY LIMITED Address .................................. : UNIT 5-6 16/F MULTIFIELD PLAZA 3-7A PRAT AVENUE TSIMSHATSUI KL Product Description Product Name ........................ : Smart Phone Brand Name ......................... : Wings Mobile Model Name ........................... : WX Series Model .......................... : N/A Test Standards ....................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ................................ : Date of receipt of test item .......... : 05 Feb. 2020 Date (s) of performance of tests . : 26 Feb. 2020 ~ 20 Mar. 2020 Date of Issue .............................. : 22 July 2020 Test Result .................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory: (Vita Li) Page 3 of 73 Report No.: STS2007302W13 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 10 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 30 4.1 LIMIT 30 4.2 TEST PROCEDURE 30 4.3 TEST SETUP 30 4.4 EUT OPERATION CONDITIONS 30 4.5 TEST RESULTS 31 5. NUMBER OF HOPPING CHANNEL 46 5.1 LIMIT 46 5.2 TEST PROCEDURE 46 5.3 TEST SETUP 46 5.4 EUT OPERATION CONDITIONS 46 5.5 TEST RESULTS 47 6. AVERAGE TIME OF OCCUPANCY 48 6.1 LIMIT 48 6.2 TEST PROCEDURE 48 6.3 TEST SETUP 48 6.4 EUT OPERATION CONDITIONS 48 6.5 TEST RESULTS 49 7. HOPPING CHANNEL SEPARATION MEASUREMEN 55 7.1 LIMIT 55 Page 4 of 73 Report No.: STS2007302W13 Table of Contents Page 7.2 TEST PROCEDURE 55 7.3 TEST SETUP 55 7.4 EUT OPERATION CONDITIONS 55 7.5 TEST RESULTS 56 8. BANDWIDTH TEST 62 8.1 LIMIT 62 8.2 TEST PROCEDURE 62 8.3 TEST SETUP 62 8.4 EUT OPERATION CONDITIONS 62 8.5 TEST RESULTS 63 9. OUTPUT POWER TEST 69 9.1 LIMIT 69 9.2 TEST PROCEDURE 69 9.3 TEST SETUP 70 9.4 EUT OPERATION CONDITIONS 70 9.5 TEST RESULTS 71 10. ANTENNA REQUIREMENT 72 10.1 STANDARD REQUIREMENT 72 10.2 EUT ANTENNA 72 Page 5 of 73 Report No.: STS2007302W13 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 20 Mar. 2020 STS2002185W13 ALL Initial Issue 00 01 Apr. 2020 STS2003175W13 ALL Updated Model name, Series model, Appearance, Software version number and FCC ID. 00 22 July 2020 STS2007302W13 ALL Update Brand Name Page 6 of 73 Report No.: STS2007302W13 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(iii) Number of Hopping Frequency PASS -- 15.247(a)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 73 Report No.: STS2007302W13 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±6.7dB 4 All emissions, radiated 1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±4.43dB 7 Conducted Emission (150KHz-30MHz) ±5dB Page 8 of 73 Report No.: STS2007302W13 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Smart Phone Trade Name Wings Mobile Model Name WX Series Model N/A Model Difference N/A Channe…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2ATQIWX DSS&DTS&U-NII&DXX Setup photo Model name: WX DSS&DTS&U-NII&DXX conduction DSS&DTS&U-NII&DXX radiation L Page 2 of 2 FCC ID: 2ATQIWX DSS&DTS&U-NII radiation H DXX Loop antenna
