2ATU8-X15TWS

Instruction Manual X15 Indicator Light Full Power No Power Charging Contacts Battery Indicator Connect Before Use Reset Please read the instructions before use English Wipe and dry charging contacts if earbuds can’t be charge. ！ 2.After open the phone Bluetooth, Click the <X15> to Pairing 1.Take out the earbuds (Earbuds auto power on) Bluetooth Device nameK30 > If earbuds has any connection or function problems, please reset the earbuds 1. Delete the BT pairing information on the phone. 2. Take the earbuds into the charging case to charge. 3. Take out the earbuds and wait for 20 seconds. (If the above operation does not work, please try again) Operation X2 2S Switch SongAdjust Volume X1 X1: Click Once X2: Click 2 times Play /Pause - + Bluetooth Device name Available Devices X15 Nova7 > PairingCharging Flashing No LightRed Connected X1 Answer/Hang up Power on/off （When no conected） 2S 2S： Press and hold for 2 seconds 5S Reject Call X3 Voice Assistant Siri 1. Fully charge the earbuds and charging case. 2. Choose the right angle and eartips. S M L Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.

BESING TECHNOLOGY (SHENZHEN) CO., LTD Agent Authorization Company: BESING TECHNOLOGY (SHENZHEN) CO., LTD Address: 2F, Block 1, Tianxin Resident Group Industrial Park, Shangwu Community, Shiyan Street, Baoan District , Shenzhen, China Product Name: TWS Model Number(s): X15, X08 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Date: Feb. 21, 2022 Signature: Name:Ali Deng Title: manager Company: BESING TECHNOLOGY (SHENZHEN) CO., LTD

BESING TECHNOLOGY (SHENZHEN) CO., LTD Date: Feb. 21, 2022 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2ATU8-X15 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Ali Deng Title: manager

FCC ID: 2ATU8-X15 BESING TECHNOLOGY (SHENZHEN) CO., LTD Model Confirmation Letter We, (BESING TECHNOLOGY (SHENZHEN) CO., LTD) certify the product: TWS, models: X15, X08 Their electrical circuit design, layout, components used and internal wiring are identical, only appearance color is different Signiture: Grantee Contact: Ali Deng Company Name: BESING TECHNOLOGY (SHENZHEN) CO., LTD Date: 2022-2-21

Label place Size：5*15mm Sample： FCC ID:2ATU8-X15

charging case Battery ANT TWS Battery

FCC ID: 2ATU8-X15 RF Exposure Evaluation According to KDB 447498 and part 2.1093，Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz) ] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where f (GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Here, EDR-worst mode and channel Mode Channel Max Power (dBm) Tune up tolerance (dBm) Maximum tune-up (dBm) (mW) π/4-DQPSK Highest -1.67 -2±1 -1 0.794 BLE-worst mode and channel Mode Channel Max Power (dBm) Tune up tolerance (dBm) Maximum tune-up (dBm) (mW) BLE Middle -2.34 -2±1 -1 0.794 Mode Maxtune-up Power (dBm) Max tune-up Power (mW) Frequency (MHz) Min. distance (mm) Calc. thresholds limit π/4-DQPSK -1 0.794 2480 < 5mm 0.250 3.0 BLE -1 0.794 2440 < 5mm 0.248 3.0 So a SAR test is not required

Project No.: ZKT-220216L0690-01 Page 1 of 61 FCC TEST REPORT FCC ID: 2ATU8-X15 Report Number. ............................... : ZKT-220216L0690-01 Date of Test ................................................ : Feb. 10, 2022 – Feb. 21, 2022 Date of issue .................................... : Feb. 21, 2022 Total number of pages ..................... : 61 Test Result ..................................... : PASS Testing Laboratory. .......................... : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ............................ : BESING TECHNOLOGY (SHENZHEN) CO., LTD Address .......................................... : 2F, Block 1, Tianxin Resident Group Industrial Park, Shangwu Community, Shiyan Street, Baoan District, Shenzhen, China Manufacturer's name ..................... : BESING TECHNOLOGY (SHENZHEN) CO., LTD Address .......................................... : 2F, Block 1, Tianxin Resident Group Industrial Park, Shangwu Community, Shiyan Street, Baoan District, Shenzhen, China Test specification: Standard .......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 ANSI C63.10:2013 KDB558074 D0115.247 Meas Guidance v 05r02 Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-112_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2020-01-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................... : TWS Trademark ...................................... : N/A Model/Type reference ...................... : X15, X08 Ratings ............................................. : DC 3.7V from battery Project No.: ZKT-220216L0690-01 Page 2 of 61 Testing procedure and testing location: Testing Laboratory .................................. : Shenzhen ZKT Technology Co., Ltd. Address 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Tested by (name + signature) .................... : Reviewer (name + signature) ..................... : Approved (name + signature) .................... : Project No.: ZKT-220216L0690-01 Page 3 of 61 Table of Contents Page 1. VERSION .............................................................. 5 2. TEST SUMMARY ........................................................ 6 2.1 TEST FACILITY ......................................................... 6 2.2 MEASUREMENT UNCERTAINTY.......................................... 7 3. GENERAL INFORMATION ............................................... 8 3.1 GENERAL DESCRIPTION OF EUT ........................................ 8 3.2 Test Setup Configuration .................................................. 9 3.3 Support Equipment ....................................................... 9 3.4 Test Mode ............................................................. 10 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS ................................ 11 4. EMC EMISSION TEST .................................................. 12 4.1 Conducted emissions .................................................... 12 4.1.1 POWER LINE CONDUCTED EMISSION Limits ........................... 12 4.1.2 TEST PROCEDURE ................................................... 12 4.1.3 DEVIATION FROM TEST STANDARD ................................... 12 4.1.4 TEST SETUP ......................................................... 13 4.1.5 EUT OPERATING CONDITIONS ........................................ 13 4.1.6 Test Result ........................................................... 14 4.2 Radiated emissions ..................................................... 16 4.2.1 Radiated Emission Limits ............................................... 16 4.2.2 TEST PROCEDURE ................................................... 16 4.2.3 DEVIATION FROM TEST STANDARD ................................... 17 4.2.4 TEST SETUP ......................................................... 17 4.2.5 EUT OPERATING CONDITIONS ........................................ 18 4.2.6 TEST RESULTS ...................................................... 19 5. RADIATED BAND EMISSION MEASUREMENT ............................ 27 5.1 Test Requirement: ...................................................... 27 5.2 TEST PROCEDURE .................................................... 27 5.3 DEVIATION FROM TEST STANDARD .................................... 28 5.4 TEST SETUP .......................................................... 28 5.5 EUT OPERATING CONDITIONS ......................................... 28 5.6 TEST RESULT ......................................................... 29 6. CONDUCTED BAND EDGE AND SPURIOUS EMISSION .................... 30 6.1 Limit ................................................................... 30 6.2 Test Setup ............................................................. 30 6.3 Test procedure ......................................................... 30 6.4 DEVIATION FROM STANDARD .......................................... 30 6.5 Test Result ............................................................. 30 7. 20DB BANDWIDTH ..................................................... 41 7.1 Test Setup ............................................................. 41 7.2 Limit ................................................................... 41 Project No.: ZKT-2…
