2ATVI-P200Wireless Mini Projector

User Manual Wireless Mini Projector P200 Power ON/OFF Forward Towards back volume+ volume- Return Focus Infrared receiver This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device must operate with a minimum distance of 20 cm between the radiator and user body. FCC Statement

Shenzhen Suichen Technology Co., Ltd. Add: Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Tel: 86-18123895780 Fax: 86-18123895780 Date: 2020-09-03 Dear Sir/Madam, We, Shenzhen Suichen Technology Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: FCC ID: 2ATVI-P200 Product name: Wireless Mini Projector Model No.: P200, P200PLUS, P302, P302PLUS, P201, P201PLUS Sincerely, Name: Shumin Yang Company: Shenzhen Suichen Technology Co., Ltd. Address: Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Phone: 86-18123895780 Fax: 86-18123895780 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: Sep. 03, 2020 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2ATVI-P200 P200, P200PLUS, P302, P302PLUS, P201, P201PLUS For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Shumin Yang Company: Shenzhen Suichen Technology Co., Ltd. Address: Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Phone: 86-18123895780 Fax: 86-18123895780 E-Mail: [email protected]

Shenzhen Suichen Technology Co., Ltd. Add: Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Tel: 86-18123895780 Fax: 86-18123895780 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/3/2020 To whom it may concern: We, Shenzhen Suichen Technology Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2ATVI-P200 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Shumin Yang Company: Shenzhen Suichen Technology Co., Ltd. Address: Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Phone: 86-18123895780 Fax: 86-18123895780 E-Mail: [email protected]

Shenzhen Suichen Technology Co., Ltd. Add: Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Tel: 86-18123895780 Fax: 86-18123895780 Date: 2020/09/03 FCC ID: 2ATVI-P200 Model Number: P200, P200PLUS, P302, P302PLUS, P201, P201PLUS To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Shenzhen Suichen Technology Co., Ltd. declare that this EUT (FCC ID: 2ATVI-P200) doesn’t have Ad Hoc mode function on“non-US/Canada frequencies”. Inaddition.The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name: Shumin Yang Company: Shenzhen Suichen Technology Co., Ltd. Address: Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Phone: 86-18123895780 Fax: 86-18123895780 E-Mail: [email protected]

FCC ID: 2ATVI-P200 FCC ID: 2ATVI-P200 FCC ID: 2ATVI-P200

FCC ID: 2ATVI-P200

FCC ID: 2ATVI-P200 WIFI Antenna BT Antenna FCC ID: 2ATVI-P200 FCC ID: 2ATVI-P200 FCC ID: 2ATVI-P200

RF Exposure evaluation FCC ID: 2ATVI-P200 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information P200 can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna Identification in Internal photos Antenna type and antenna number Operate frequency band Maximum antenna gain Antenna 0 2.4G/5G Wifi Chain 0 FPC antenna 2.4GHz – 2.5 GHz 5.1GHz – 5.8 GHz 2.00 dBi Antenna 1 2.4G/5G Wifi Chain 1 FPC antenna 2.4GHz – 2.5 GHz 5.1GHz – 5.8 GHz 2.00 dBi Antenna 2 Bluetooth FPC antenna 2.4GHz – 2.5 GHz 2.00 dBi 5. Manufacturing Tolerance Bluetooth GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 0.0 1.0 2.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 0.0 1.0 2.0 Tolerance ±(dB) 1.0 1.0 1.0 8-DPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 0.0 1.0 2.0 Tolerance ±(dB) 1.0 1.0 1.0 BLE GFSK Channel Channel 0 Channel 19 Channel 39 Target (dBm) -1.0 -1.0 -1.0 Tolerance ±(dB) 1.0 1.0 1.0 2.4GHz WLAN IEEE 802.11b (Peak) Frequency (MHz) Antenna 0 Antenna 1 2412 2437 2462 2412 2437 2462 Target (dBm) 16.0 16.0 16.0 16.0 16.0 16.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11g (Peak) Frequency (MHz) Antenna 0 Antenna 1 2412 2437 2462 2412 2437 2462 Target (dBm) 14.0 14.0 14.0 14.0 14.0 14.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT20 (Peak) Frequency (MHz) Antenna 0 Antenna 1 2412 2437 2462 2412 2437 2462 Target (dBm) 13.0 13.0 13.0 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT40 (Peak) Frequency (MHz) Antenna 0 Antenna 1 2422 2437 2452 2422 2437 2452 Target (dBm) 12.0 12.0 12.0 12.0 12.0 12.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 5GHz WLAN Band 1 IEEE 802.11a (Average) Frequency (MHz) Antenna 0 Antenna 1 5180 5200 5240 5180 5200 5240 Target (dBm) 13.0 12.0 12.0 13.0 12.0 12.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT20 (Average) Frequency (MHz) Antenna 0 Antenna 1 5180 5200 5240 5180 5200 5240 Target (dBm) 7.0 7.0 7.0 7.0 7.0 7.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT20 (Average) Frequency (MHz) Antenna 0 Antenna 1 5180 5200 5240 5180 5200 5240 Target (dBm) 7.0 7.0 7.0 7.0 7.0 7.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT40 (Average) Frequency (MHz) Antenna 0 Antenna 1 5190 5230 5190 5230 Target (dBm) 7.0 7.0 7.0 7.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT40 (Average) Frequency (MHz) Antenna 0 Antenna 1 5190 5230 5190 5230 Target (dBm) 7.0 7.0 7.0 7.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT80 (Average) Frequency (MHz) Antenna 0 Antenna 1 5210 5210 Target (dBm) 7.0 7.0 Tolerance ± (dB) 1.0 1.0 5GHz WLAN Band 3 IEEE 802.11a (Average) Frequency (MHz) Antenna 0 Antenna 1 5745 5785 5825 5745 5785 5825 Target (dBm) 15.0 14.0 13.0 15.0 14.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT20 (Average) Frequency (MHz) Antenna 0 Antenna 1 5745 5785 5825 5745 5785 5825 Target (dBm) 13.0 13.0 13.0 13.0 13.0 13.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT20 (Average) Frequency (MHz) Antenna 0 Antenna 1 5745 5785 5825 5745 5785 5825 Target (dBm) 12.0 12.0 12.0 12.0 12.0 12.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 1.0 1.0 IEEE 802.11n HT40 (Average) Frequency (MHz) Antenna 0 Antenna 1 5755 5795 5755 5795 Target (dBm) 13.0 12.0 13.0 12.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT40 (Average) Frequency (MHz) Antenna 0 Antenna 1 5755 5795 5755 5795 Target (dBm) 13.0 12.0 13.0 12.0 Tolerance ± (dB) 1.0 1.0 1.0 1.0 IEEE 802.11ac VHT80 (Average) Frequency (MHz) Antenna 0 Antenna 1 5775 5775 Target (dBm) 12.0 12.0 Tolerance ± (dB) 1.0 1.0 6. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 2dBi, the RF power density can be obtained. Bluetooth Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) Duty Cycle MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW GFSK 3.00 1.9953 2.00 1.5849 100% 0.00063 1.0000 π/4DQPSK 3.00 1.9953 2.00 1.5849 100% 0.00063 1.0000 8-DPSK 3.00 1.9953 2.00 1.5849 100% 0.00063 1.0000 BLE GFSK 0.00 1.0000 2.00 1.5849 100% 0.00032 1.0000 2.4GHz WLAN Antenna 0 Modulation Typ…

Text truncated - open the document above for the full version.

      !"#$%&'()!( * !"%+,,,')-'.) !,./-(0/1.!/ %2"%3( *4( .-56!% 75  *8'*',88 ' (-9%3( *5'7-.//-%: ** *+(;-.(<-%75/ =5/ %1' *! *     >?@A BCDE?@A  F AF?GA   >?@A BCHIJ  AK ALM N >OPQ  HRHRRCHSRRTUBUCUB H@ VOU?HRR ,8W()/!X9 YW;(-( ZW.( -/! 8/Z;(* -'./[N  \()/!8( (;-.-.;](889^ *  7'W/.0(;/!X9 YW;(-( ZW.( -/! 8/Z;(* -'./[N  _/;-` *( //.#. _   #WW.0/!X9 YW;(-( ZW.( -/! 8/Z;(* -'./[N  a */.]; b'  +-/c(;;'/N]' /"%dd AK     eM fQ     ghhijkkllllllllllllllllllllllllllllllllllllllllllllm  !"#$%&'()!( * !"%+,,,')-'.)  !,./-(0/ 1.!/ %2"%3( *4( .-56!%75 *8'*',88' (-9% 3( *5'7-.//-%: ** *+(;-.(<-%75/ =5/ %1' *! *%,5(  noopqrstuvwtsxyN z   {e  #!!./;;N 68d#%d|\%}' ; *&'()!( *%_(. "-5.!%_( ~  <88' (-9%75-';-.//-%\'-( !(;-.(<-%75/ 5/ %,5(    KL  Q 7- !.!N >? BCHIJ _6\€.(*( -.N75/ =5/ 1)X)_/;-7/.0(</,%:-! a;-/._6\N+-/!d$d     @{   _5(;W'X)(<-( 89X/./W.!'</!( 5)/.( W.-c.  <88/.<()W'.W;/;;) *;-5/ 75/ =5 / 1)X)_/;-7/.0(</,%:-!(;<‚ )/!*/!;<W9.(*5- /. !;'.</c-5/8-/.() 75/ =5 / 1)X)_/;-7/.0(</,%:-!-‚/; ./;W ;(X()(-9c. !()) -;;'8/)(X()(-9c.!8*/; ./;')-( *c.8-5/./!/.~;( -/.W./--( c-5/./W.!'</!8-/.()!'/-(-;W)</8/ - !< -/4-  f K Q ^(./)/;;a( (3.ƒ/<-. _.!/a.‚N |# a 'c<-'./.N 75/ =5/ 7'(<5/ _/<5 )*9,%:-! a!/)|_9W/./c/./ </N 3d :(;-/!a!/);N 3d3:„7%3…d%3…d3:„7%3d%3d3:„7 a!')-( _9W/N,,†|+777%€\+a €W/.-( \./‡'/ <9N\.8d$dd$ˆdab= 6-( *N d‰ …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…

Text truncated - open the document above for the full version.

     !"#$ %&'(%&')  *+,(*+,(  *+,-*+,-  *+((*+((         !"##"# $"!" %&'&()**+,-.'&/01/2345261/7237897:57&;(.'&/1&031;32376<97'/6<7;295=49/1>12'??(=4/5?'27/ /7@1;716 4<79'21&>A237BC<407923'216<94/5;7/63'??.7'2?7'62D*/E.7?4023'21&237 )**+,-.'&/01/2301231&237.'&/23'2;4&2'1&623731>3762?7@7?48237/76197/<4079A.'67/4&712379'& BC;4&/ 5;27/49'9'/1'27/=7'6597=7&2A<94@1/7/23'223729'&6=12279/7=4&629'276;4=<?1'&;70123237 <7'+;4 &/5;27/<4079?1=126F%823729'&6=12279;4=<?1760123237;4&/5;27/<4079?1=126.'67/4&23756748 9442G=7 '&G6:5'97'@79'>1&>4@79'21=71&279@'?A'6<79=1227/5&/79H7;214&I.JIKJ48L)MFDNO'&/BHHMFNINJA 237'227& 5'214&97:5197/63'??.7K*/E1&627'/48D*/EFP227&5'214&.7?40237>7&79'?817?/6297&>23?1=126 6<7;1817/ 1&L)MFD*QI'J'&/BHHGR7&'97&4297:5197/F  # S  T4&&7; 223729'&6=12279452<52246<7;295='&'?(-79561&>'?40?466BC;'.?7A'&/6722376<7;295='&'?(-79 24BEU V)**+,-AWEUVK**+,-A<7'+/727;249A'&/='X34?/FY7'6597=7&26521?1-1&>2376767221&>'97 ='/748 2371&G.'&/978797&;7?7@7?A.'&/7/>7'&/452G48G.'&/7=16614&6F  #Z "" [\]  H^[T]B\Y P_P`ab[B   # #c# ]7=<79'2597DDFde,5=1/12(Mfg ]762[&>1&779Y44&]'&T4&81>59'214&6U`P_DFNR B7='9+h]37=7'6597=7&2897:57&;(9'&>716894=K*Y,-24237)*233'9=4&1;4823785&/'=7&2'? 897:57&; (F]37?40762A=1//?7'&/31>3762;3'&&7?6'9727627/24@7918(2376<5914567=16614&6'&/.'&/'>7 =7'6597 =7&2/'2'F  ]762<?4 2'684??406h       !"#  !"#$  %&'&(&)*&%&'&(&)*&  +,-./0+1./+,-./0+1./  +1./0231./+1./0231./        !"#!"  $%&%'%()%$%&%'%()%  *+,-./*0-.*+,-./*0-.  *0-./120-.*0-./120-.        !" !  #$%$&$'($#$%$&$'($  )*+,-.)/,-)*+,-.)/,-  )/,-.01/,-)/,-.01/,-        !"#$! !"#$!%  &'(')'*'&'(')'*'  +,-./0+1./+,-./0+1./  +1./0231./+1./0231./        !"#$%" !"#&$%"'  ()*)+) ,)()*)+) ,)  -./012-301-./012-301  -301245301-301245301        !"#$%!& !"#$%!'  ()*)+),)()*)+),)  -./012-301-./012-301  -301245301-301245301        !!"#$! !!"#$%  &'(')'*+'&'(')'*+'  ,-./01,2/0,-./01,2/0  ,2/01342/0,2/01342/0        !" !  #$%$&$'($#$%$&$'($  )*+,-.)/,-)*+,-.)/,-  )/,-.01/,-)/,-.01/,-        !" !  #$%$&$'($#$%$&$'($  )*+,-.)/,-)*+,-.)/,-  )/,-.01/,-)/,-.01/,-        !"#$! !"#$!%  &'(')'*'&'(')'*'  +,-./0+1./+,-./0+1./  +1./0231./+1./0231./        !"#$%" !"#&$%"'  ()*)+) ,)()*)+) ,)   -./012-301-./012-301  -301245301-301245301

      !"#$%!& !"#$%!'  ()*)+),)()*)+),)  -./012-301-./012-301  -301245301-301245301       !"#$%&"'($)*+(#,&-%."".("/ 0&1 2345116  789:;<=>8>?8@A?B:;<=>8>?8  234511   789:;<=>8>?8@A?B:;<=>8>?8  234511CDE43F  789:;<=>8>?8@A?B:;<=>8>?8       !"#$  %&'()*+,&,-&./-0()*+,&,-&  12 3   %&'()*+,&,-&./-0()*+,&,-&  4   %&'()*+,&,-&./-0()*+,&,-&       !"#$  %&'()*+,&,-&./-0()*+,&,-&   !"#1$   %&'()*+,&,-&./-0()*+,&,-&         !!"#$"  % "!&#'##!%(((% # )   *+,+-.+ -,/+01203,0-/2450116.3.4,7+.3-/.+482.-50-+/0+-.++0/-5.2-50+-50-982+,45.36:-5. 2.4;/+4 ,61.;02-:450116.84.3<,-5-5.3.=,>.?@5.84./90;.2A0+.+-1:0--0>5.30+-.++0/2/90+0+-.++0 -50-84. 408+,B8.>/8;1,+7-/-5.,+-.+-,/+01203,0-/2C-5.A0+890>-82.2A0:3.4,7+-5.8+,-4/-50-062/D.+ 0+-.++0 >0+6.2.;10>.36:-5.84.2C68--5.84./904-0+30230+-.++0E0>D/2.1.>-2,>01>/++.>-/2,4 ;2/5,6,-. 3 %(((% " $( # F#GFGFHG   I,JK:4-. A4/;.20-,+7,+-5.LMNNOLMPQ?RSTU60+3-50-,484.3.V>184,=.1:9/29,V.3?W/,+-O-/O;/,+-/;.20-,/+4 A0:.A ;1/:-20+4A,--,+70+-.++04<,-53,2.>-,/+0170,+72.0-.2-50+X3Y,;2/=,3.3-5.A0V,A8A>/+38>-.3 /8-;8-; /<.2/9-5.,+-.+-,/+01203,0-/2,42.38>.36:Z3Y9/2.=.2:Q3Y-50--5.3,2.>-,/+0170,+/9-5. 0+-.++0 .V>..34X3Y,? [["   @5.A0V ,A8A70,+/90+-.++0<04L3Y,9/2L?M\TU]^_^?                                                               !  "#$%##& '( "#$%##&

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20200528006-1-5-4 2ATVI-P200 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : June 18, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Suichen Technology Co., Ltd. Address ............................................ : Room 12A01,12/F,Yunsong Building,Tairan 8th road,Tian'an community,Shatou street, Futian district, ShenZhen, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Wireless Mini Projector Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Suichen Technology Co., Ltd. Model/Type reference....................... : P200 Listed Models .................................. : P200PLUS, P302, P302PLUS, P201, P201PLUS Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2402-2480MHz Rating ............................................... : 12V3A Result................................................ : PASS Report No.: GTS20200528006-1-5-4 Page 2 of 30 T E S T R E P O R T Test Report No. : GTS20200528006-1-5-4 June 18, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Wireless Mini Projector Model /Type : P200 Listed Models : P200PLUS, P302, P302PLUS, P201, P201PLUS Applicant : Shenzhen Suichen Technology Co., Ltd. Address : Ro…

Text truncated - open the document above for the full version.
