WARRANTY Wireless Charging Stand User Manual 1. The power of all devices should not exceed rated power of this power strip, such as hair dryers or steam irons. 2. Do not covers the power strip with anything to prevent overheat. 3. Do not use it in humid environment. 4. Do not disassemble or modify it by yourself. 1. The power cable on this strip is flexible enough to let it settle in place on the desk, and the 4 anti-slip rubber footpads at the bottom keep from slipping and sliding. 2. Hidden Blue LED indicator doesn’t disturb you when sleeping and let you know your phone is charging wirelessly. 3. The switch can completely shut off electronics when not in use, helping to conserve energy. 4. In order to help you to better organize the extension cord we offer you a fastening cable tie as a gift just want you to be happy with our product. 5.Transmits charging power straight through even heavy-protection phone cases (5mm). NOTE: Magnetic or metal attachments and other foreign objects will interfere with charging. WARRANTY MADE IN CHINA 1. Wireless Charger 2. 2 USB Port 3. Type-C Port 4. AC Socket OVERVIEW 5. LED Indicator 6. ON/OFF Switch 7. Non-Slip Pads 8. Heat Dissipation Holes FEATURES SAFETY COMPATIBILITY 3. 5W Standard Charge Mode: All Qi-enabled phones and devices Pixel 3 / Pixel 3XL (The phone's screen will display the message: Charging slowly) SPECIFICATION Power Strip with Fast Wireless Charger Model: W88 Interface: 2 Outlets & 3 USB Ports AC Output: Power Input: USB Total Output: Type-C Output: Wireless Charger Output: 5V1A/7.5V1A/9V1.1A Material: Fire-resistant ABS shell Cable Length: 5 feet Dimension: 4.96 * 3.43 * 4.25 in USB Power Strip 5 6 2 1 3 4 7 8 1. 10W Fast Charge Mode: Samsung Galaxy S10 / S9+ / S9 / S8 / S8+ / S7 edge / S7 / S6 edge+ Samsung Note 10 / Note 9 / Note 8 / Note 7 AC110V-240V 1250W (Max) 1250 PD18W 12V1.5A/9V2A/5V2.4A Desktop Power Strip 260.00 mm 90.00 mm Ensure that all products to be of thehighest quality in material,craftsmanshipand services for 18 months from the date of purchase. We will replace any product found to be defective due to manufacturer flaws based Refunds are available within the first 30 days after purchase. AC110V-240V 50/60Hz 110V-240 3-in-1 wireless charging station This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. During the operation of device a distance of 15 cm surrounding the device and 20 cm above the top surface of the device must be respected. FCC StatementFCC Statement

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: Mar. 15, 2021 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AU7V-W88 W88 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Juno Li Company: Shenzhen Xinjiawei Technology Co.Ltd Address: 1st Floor,Office Building,No.17,Hongbai Indu.Zone No. 1 Chuangye Road,Shilongzi,Baoan District ,Shenzhen, China Phone: +86-15302677830 Fax: +86-0755-23096962 E-Mail: [email protected]

Shenzhen Xinjiawei Technology Co.Ltd 1st Floor,Office Building,No.17,Hongbai Indu.Zone No. 1 Chuangye Road,Shilongzi,Baoan District ,Shenzhen, China Tel: +86-15302677830 Fax: +86-0755-23096962 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 03/15/2021 To whom it may concern: We, Shenzhen Xinjiawei Technology Co.Ltd the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AU7V-W88 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Juno Li Company: Shenzhen Xinjiawei Technology Co.Ltd Address: 1st Floor,Office Building,No.17,Hongbai Indu.Zone No. 1 Chuangye Road,Shilongzi,Baoan District ,Shenzhen, China Phone: +86-15302677830 Fax: +86-0755-23096962 E-Mail: [email protected]

FCC ID: 2AU7V-W88

FCC ID: 2AU7V-W88 Antenna

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20200324013-1-3-2 2AU7V-W88 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Mar. 14, 2021 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Xinjiawei Technology Co.Ltd Address ............................................ : 1st Floor,Office Building,No.17,Hongbai Indu.Zone No. 1 Chuangye Road,Shilongzi,Baoan District ,Shenzhen, China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Multi-ChargingStation Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Xinjiawei Technology Co.Ltd Model/Type reference....................... : W88 Listed Models .................................. : N/A Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : AC110-240V,50/60Hz Result................................................ : PASS Report No.: GTS20200324013-1-3-2 Page 2 of 11 T E S T R E P O R T Test Report No. : GTS20200324013-1-3-2 Mar. 14, 2021 ____________________________________________________________________________________ Date of issue Equipment under Test : Multi-ChargingStation Model /Type : W88 Listed Models : N/A Applicant : Shenzhen Xinjiawei Technology Co.Ltd Address : 1st Floor,Office Building,No.17,Hongbai Indu.Zone No. 1 Chuangye Road,Shilongzi,Baoan District ,Shenzhen, China Manufacturer : Shenzhen Xinjiawei Technology Co.Ltd Address : 1st Floor,Office Building,No.17,Hongbai Indu.Zone No. 1 Chuangye Road,Shilongzi,Baoan District ,Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200324013-1-3-2 Page 3 of 11 Contents 1 S U M M A R Y ............................................................................ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Special Accessories 4 1.5 Modifications 4 2 T E S T E N V I R O N M E N T .............................................................. 5 2.1 Address of the test laboratory 5 2.2 Test Facility 5 2.3 Environmental conditions 5 2.4 Summary of measurement results 6 2.5 Statement of the measurement uncertainty 6 2.6 Equipments Used during the Test 6 3 T E S T C O N D I T I O N S A N D RE S U L T S ............................................. 7 3.1 Applicable Standard 7 3.2 Limit 7 3.3 Test Setup 7 3.4 Measurement Procedure 8 3.5 Test Result of E and H field Strength 8 3.6 Equipment Approval Considerations 10 3.7 Conclusion 10 4 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 11 Report No.: GTS20200324013-1-3-2 Page 4 of 11 1 SUM M A R Y 1.1 General Remarks Date of receipt of test sample : Mar. 05, 2021 Testing commenced on : Mar. 07, 2021 Testing concluded on : Mar. 14, 2021 1.2 Product Description Product Name: Multi-ChargingStation Model/Type reference: W88 Power supply: AC110-240V,50/60Hz Hardware version: XJW_W88_IP6809_2Coil_V1.0 Software version: V1.0 Test samples ID: GTS20200324013-1-3# Wireless Charger Antenna Type Coil Antenna Antenna Gain 0dBi Operation frequency 110KHz~205KHz Modulation Type ASK 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Modes: Mode 1 EUT Powered on + Mobile Phone (Battery Status: <1%) Record Mode 2 EUT Powered on + Mobile Phone (Battery Status: <50%) Record Mode 3 EUT Powered on + Mobile Phone (Battery Status:100%) Record Note: All test modes were pre-tested, but we only recorded the worst case in this report. 1.4 Special Accessories Follow auxiliary equipment(s) test with EUT that provided by the manufacturer or laboratory is listed as follow: Description Manufacturer Model Technical Parameters Certificate Provided by / / / / / / / / / / / / / / / / / / 1.5 Modifications No modifications were implemented to meet testing criteria. Report No.: GTS20200324013-1-3-2 Page 5 of 11 2 T E S T E N V I R O N M E N T 2.1 Address of the test laboratory Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen,…
