2AU8X-SMPA-R1305GAMD R1305G Player

SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 SMPA-R1305G PLAYER User Manual 2021 December SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 1、Product Overview SMPA-R1305G PLAYERI is a smart player box that supports Windows and Linux operating systems. Customers can develop their own under this system. (for detailed configuration, please refer to the product configuration parameter table of SMPA-R1305G Player box). Customers can use the player box to provide multimedia content of the display through documents or network Figure 1、Product interface diagram： 2、Boot up 1）、Connecting power supply Connect the 12V / 5A power adapter of the accessory to the power socket, connect the DC anti disconnection connector of the adapter to the DC12V socket of the equipment, and tighten the nut; 2）、Key switch and status indication Press the power button to turn on the device, power is always on green. Hold down the power button for 8 to 10 seconds, the system shuts down and the power is always bright red. SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 3、Instructions 1）、External display： The player box HDMI out is connected with the external display HDMI in through the HDMI cable to realize the display interface output; The external device can input interface data through the player box HDMI in, and the player box can synchronously output the display interface from the HDMI out to the external display. (The HDMI in is option) Figure 2: display desktop 2）. External USB device: In the state of connected external display device, USB mouse and USB keyboard can be connected through USB2.0 and USB3.0 ports to realize interface switching, data input and output and other functions. The function of copying or loading data files of external storage devices such as USB flash disk can be realized. SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 Figure 3: USB insertion display in Explorer 3）. Wired, wireless networking and WiFi functions: The player box can be connected to the network through RJ45 port and wifi antenna for network data transmission. Figure 4: wired and wireless networking setting interface entrance SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 Figure 5: Bluetooth setting interface entry 4）. Audio transmission: The player box can transmit audio with external player equipment through aux port. Figure 6: sound adjustment SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 5）. Serial communication: The external equipment can realize the RS232 serial communication function through the COM port of the player box. 6). Extended switch machine: (it needs to be refitted professionally, temporarily omitted, you can contact the manufacturer) 7). Equipment reset: in case of equipment crash, the device can be forced to restart by pressing reset hidden button. 4. firmware upgrade: The player box is equipped with the best firmware at the factory. Customers need to contact Scala if they have firmware requirements. 5. packing configuration 1. Player box host, 1pcs; 2. 12V / 5A adapter, 1pcs; 3. HDMI transfer line, 1pcs; 4. Install screw pack, 1pcs; SCALA Digital Technology(Ningbo) Co., Ltd. Address: No. 7 Hong Da Road , Jiang Bei District, Ning Bo,Zhe Jiang Tel: +1 610 363 3350 Fax: +1 610 363 4010 Website:https://scala-china.com/ SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 R PLAYER Product configuration parameters Spec Date: 3 JAN, 2021 Product Descriptions Spec Date: 10th September, 2019 Scala SMPA Playeryer Hardware & OS OS SUPPORT window10，Linux-Ubuntu APU AMD RYZEN EMBEDDED R1305G or R1505G Graphics AMD Vega GPU with up to 3 Compute Units Memory 8GB DDR4-2400 SO-DIMM Dual channel,Max 32GB Network RTL8111H SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 Interface 1 x DC input[with anti-loose mechanism], 4 x USB3.0 2xAudio Jack (Front-L/R + ,Aux-In) 1 x HDMI Output (HDMI 2.0，up to 2160@60fps , support HDCP) 1x HDMI IN (PCIE, 1080P, Option) or 2nd 1G Ethernet 1x Power button 1 x 1G Ethernet 1 x Mic 1XDB9 for RS232 2X SIM socket (Inside the machine) 1X RJ11 for Tethered Power Button & LED Indicator Port 1X Reset Button SSD 128GB NVME SSD， Max 2T WIFI WiFi 2.4GHz/5GHz Dual-Band Support 802.11a/b/g/n/ac Bluetooth Bluetooth 4.0 standard including Bluetooth 4.0 Low Energy (BLE) Expansion Slots 1xM.2 M key (2280) for starage ,1xM.2 E key for HDMI Capture or 2nd Ethernet， 1xMini pcie for 4G, 1x M.2 E key(2230) for WIFI, 2x SODIMM sockets for memory Power Power input by adapter DC12V,5A Power input by POE NA General information Storage Temp (-15 -- 65 degree) Working Temp (0 -- 40 degree) Storage/Worki ng Humidity (10 -- 90﹪ ) Dimension 180X281X35mm Net Weight 1.81KG SCALA Digital Technology (Ningbo) Co., LTD Version：V1.1 FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving ant…

Text truncated - open the document above for the full version.

SCALA Digital Technology (Ningbo) Co., LTD Agent Authorization Company: SCALA Digital Technology (Ningbo) Co., LTD Address: No. 7 Hong Da Road, Hong Tang Industrial Zone A, Jiang Bei District, Ning Bo City, China Product Name: AMD R1305G Player Trade Mark: SCALA Model Number: SMPA-R1305G FCC ID: 2AU8X-SMPA-R1305G We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-01-18 Name: Lingling Liu Title: Coo Assistant Company: SCALA Digital Technology (Ningbo) Co., LTD

SCALA Digital Technology (Ningbo) Co., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-01-18 Subject; Request for Confidentiality FCC ID: 2AU8X-SMPA-R1305G To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Declaration of Software Security Requirements For U-NII Devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Lingling Liu Title: Coo Assistant

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 5 External Photos of the EUT Fig. 1 Fig. 2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 5 Fig. 3 Fig. 4 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 5 Fig. 5 Fig. 6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 5 Fig. 7 Fig. 8 BT&WIFI Antenna0 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 5 Fig. 9 Fig. 10 WIFI Antenna1

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 LABEL AND LOCATION (Size: L4cm x 3cm) Label Location AMD R1305G Player Model: SMPA-R1305G FCC ID: 2AU8X-SMPA-R1305G Caution:This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 9 Internal Photos of the EUT Fig. 1 Fig. 2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 9 Fig. 3 Fig. 4 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 9 Fig. 5 Fig. 6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 9 Fig. 7 Fig. 8 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 9 Fig. 9 Fig. 10 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 6 of 9 Fig. 11 Fig. 12 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 7 of 9 Fig. 13 Fig. 14 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 8 of 9 Fig. 15 Fig. 16 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 9 of 9 Fig. 17 Fig. 18

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 11 Maximum Permissible Exposure Report 1. Product Information FCC ID: 2AU8X-SMPA-R1305G Product name AMD R1305G Player Test Model SMPA-R1305G Power supply Input: 12V5.0A For AC Adapter Input: 100-240V~, 50/60Hz, 1.3A Adapter Output: 12V5.0A, 60.0W Operation frequency 2402MHz ~ 2480MHz 2412MHz ~ 2462MHz 5180-5240MHz 5745MHz-5825MHz Antenna Type Antenna0: External Antenna Antenna1: PCB Antenna Antenna Gain 2.0dBi(Max) Hardware version V1.X Software version / Channel Number 79 channels for Bluetooth V4.0(DSS) 40 channels for Bluetooth V4.0 (DTS) 11 Channels for 20MHz bandwidth (2412~2462MHz) 7 Channels for 40MHz bandwidth (2422~2452MHz) 4 Channels for 20MHz bandwidth(5180MHz-5240MHz) 2 channels for 40MHz bandwidth(5190MHz~5230MHz) 1 channels for 80MHz bandwidth(5210MHz) 5 channels for 20MHz bandwidth(5745MHz-5825MHz) 2 channels for 40MHz bandwidth(5755MHz~5795MHz) 1 channels for 80MHz bandwidth(5775MHz) Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Devices 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 11 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: Mobile Devices 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information ES-D4 can only use antennas certificated as follows provided by manufacturer; Antenna type and antenna number Operate frequency band Maximum antenna gain Notes External Antenna0 PCB Antenna1 2402MHz ~ 2480MHz 2412MHz ~ 2462MHz 5180-5240MHz 5745MHz-5825MHz 2 dBi BT WiFi Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 11 6. Conducted Power [BT Max Conducted Power] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 4.38 39 2441 4.62 78 2480 3.99 π/4DQPSK 0 2402 6.08 39 2441 6.24 78 2480 6.37 8DPSK 0 2402 6.9 19 2441 6.8 39 2480 6.88 [BLE Max Conducted Power] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) BLE_1M 0 2402 5.71 19 2440 5.59 39 2480 5.49 BLE_2M 0 2402 5.82 19 2440 5.7 39 2480 5.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AU8X-SMPA-R1305G This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 11 [2.4GWIFI Max Conducted Power] Mode Channel Frequency (MHz) Ant 0 Max Conducted Power(dBm) Ant 1 Max Conducted Power(dBm) 11B 1 2412 15.74 16.19 6 2437 15.65 16.06 11 2462 15.39 15.9…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 1 Appendix B RF Test Data for BLE (Conducted Measurement) Product Name: AMD R1305G Player Test Model: SMPA-R1305G Environmental Conditions Temperature: 23.5 C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Bill Zhu Supervised by: Li Huan Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 2 B.1 6dB Bandwidth Test Result TestMode Antenna Channel DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict BLE_1M Ant1 2402 0.656 2401.672 2402.328 0.5 PASS 2440 0.656 2439.672 2440.328 0.5 PASS 2480 0.652 2479.672 2480.324 0.5 PASS BLE_2M Ant1 2402 1.112 2401.448 2402.560 0.5 PASS 2440 1.116 2439.444 2440.560 0.5 PASS 2480 1.112 2479.448 2480.560 0.5 PASS Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 3 BLE_1M_Ant1_2480 BLE_2M_Ant1_2402 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 4 BLE_2M_Ant1_2440 BLE_2M_Ant1_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 5 B.2 Maximum conducted output power Test Result TestMode Antenna Channel Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 5.71 ≤30 PASS 2440 5.59 ≤30 PASS 2480 5.49 ≤30 PASS BLE_2M Ant1 2402 5.82 ≤30 PASS 2440 5.7 ≤30 PASS 2480 5.6 ≤30 PASS Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 6 BLE_1M_Ant1_2480 BLE_2M_Ant1_2402 BLE_2M_Ant1_2440 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 7 BLE_2M_Ant1_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 8 B.3 Maximum power spectral density Test Result TestMode Antenna Channel Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict BLE_1M Ant1 2402 -10.85 ≤8.00 PASS 2440 -10.36 ≤8.00 PASS 2480 -9.96 ≤8.00 PASS BLE_2M Ant1 2402 -11.66 ≤8.00 PASS 2440 -12.11 ≤8.00 PASS 2480 -12.83 ≤8.00 PASS Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 9 BLE_1M_Ant1_2480 BLE_2M_Ant1_2402 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 10 BLE_2M_Ant1_2440 BLE_2M_Ant1_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 11 B.4 Band edge measurements Test Result TestMode Antenna ChName Channel RefLevel[dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 Low 2402 5.67 -47.94 ≤-14.33 PASS High 2480 5.53 -46.92 ≤-14.47 PASS BLE_2M Ant1 Low 2402 5.63 -27.42 ≤-14.37 PASS High 2480 5.50 -47.82 ≤-14.5 PASS Test Graphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 BLE_2M_Ant1_Low_2402 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 12 BLE_2M_Ant1_High_2480 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 13 B.5 Conducted Spurious Emission Test Result TestMode Antenna Channel FreqRange [MHz] RefLevel [dBm] Result[dBm] Limit[dBm] Verdict BLE_1M Ant1 2402 Reference 5.61 5.61 --- PASS 30~1000 5.61 -60.21 ≤-14.39 PASS 1000~26500 5.61 -46.26 ≤-14.39 PASS 2440 Reference 5.26 5.26 --- PASS 30~1000 5.26 -60.99 ≤-14.74 PASS 1000~26500 5.26 -45.45 ≤-14.74 PASS 2480 Reference 5.23 5.23 --- PASS 30~1000 5.23 -60.72 ≤-14.77 PASS 1000~26500 5.23 -45.43 ≤-14.77 PASS BLE_2M Ant1 2402 Reference 5.60 5.60 --- PASS 30~1000 5.60 -60.31 ≤-14.4 PASS 1000~26500 5.60 -46.04 ≤-14.4 PASS 2440 Reference 5.48 5.48 --- PASS 30~1000 5.48 -60.45 ≤-14.52 PASS 1000~26500 5.48 -46.49 ≤-14.52 PASS 2480 Reference 5.38 5.38 --- PASS 30~1000 5.38 -60.04 ≤-14.62 PASS 1000~26500 5.38 -45.9 ≤-14.62 PASS Test Graphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 14 BLE_1M_Ant1_2402_1000~26500 BLE_1M_Ant1_2440_0~Reference Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 15 BLE_1M_Ant1_2440_30~1000 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 16 BLE_1M_Ant1_2480_30~1000 BLE_1M_Ant1_2480_1000~26500 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 17 BLE_2M_Ant1_2402_0~Reference BLE_2M_Ant1_2402_30~1000 BLE_2M_Ant1_2402_1000~26500 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 18 BLE_2M_Ant1_2440_0~Reference BLE_2M_Ant1_2440_30~1000 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 19 BLE_2M_Ant1_2440_1000~26500 BLE_2M_Ant1_2480_0~Reference BLE_2M_Ant1_2480_30~1000 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 20 BLE_2M_Ant1_2480_1000~26500 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 21 B.6 Duty Cycle Test Result TestMode Antenna Channel ON Time [ms] Period [ms] X DC [%] xFactor Limit Verdict BLE_1M Ant1 2402 2.14 2.50 0.8560 85.60 0.68 --- --- 2440 2.14 2.50 0.8560 85.60 0.68 --- --- 2480 2.14 2.50 0.8560 85.60 0.68 --- --- BLE_2M Ant1 2402 1.08 1.87 0.5775 57.75 2.38 --- --- 2440 1.08 1.88 0.5745 57.45 2.41 --- --- 2480 1.08 1.88 0.5745 57.45 2.41 --- --- Test Graphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 22 BLE_1M_Ant1_2480 BLE_2M_Ant1_2402 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEB 23 BLE_2M_Ant1_2440 BL…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 1 Appendix C RF Test Data for 2.4G WIFI (Conducted Measurement) Product Name: AMD R1305G Player Test Model: SMPA-R1305G Environmental Conditions Temperature: 23.5 C Relative Humidity: 52.2% ATM Pressure: 100.0 kPa Test Engineer: Bill Zhu Supervised by: Li Huan Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 2 C.1 6dB Bandwidth Test Result TestMode Antenna Channel DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant0 2412 10.120 2406.920 2417.040 0.5 PASS 2437 10.120 2431.920 2442.040 0.5 PASS 2462 10.120 2456.920 2467.040 0.5 PASS 11G Ant0 2412 16.360 2403.800 2420.160 0.5 PASS 2437 16.360 2428.800 2445.160 0.5 PASS 2462 16.360 2453.800 2470.160 0.5 PASS 11N20SISO Ant0 2412 17.560 2403.200 2420.760 0.5 PASS 2437 17.600 2428.200 2445.800 0.5 PASS 2462 17.560 2453.200 2470.760 0.5 PASS 11N40SISO Ant0 2422 36.320 2403.840 2440.160 0.5 PASS 2437 36.320 2418.840 2455.160 0.5 PASS 2452 36.320 2433.840 2470.160 0.5 PASS Test Graphs 11B_Ant0_2412 11B_Ant0_2437 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 3 11B_Ant0_2462 11G_Ant0_2412 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 4 11G_Ant0_2437 11G_Ant0_2462 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 5 11N20SISO_Ant0_2412 11N20SISO_Ant0_2437 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 6 11N20SISO_Ant0_2462 11N40SISO_Ant0_2422 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 7 11N40SISO_Ant0_2437 11N40SISO_Ant0_2452 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 8 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 9 TestMode Antenna Channel DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.120 2406.920 2417.040 0.5 PASS 2437 10.120 2431.920 2442.040 0.5 PASS 2462 10.120 2456.920 2467.040 0.5 PASS 11G Ant1 2412 16.360 2403.800 2420.160 0.5 PASS 2437 16.360 2428.800 2445.160 0.5 PASS 2462 16.360 2453.800 2470.160 0.5 PASS 11N20SISO Ant1 2412 17.560 2403.200 2420.760 0.5 PASS 2437 17.560 2428.200 2445.760 0.5 PASS 2462 17.560 2453.200 2470.760 0.5 PASS 11N40SISO Ant1 2422 36.320 2403.840 2440.160 0.5 PASS 2437 36.320 2418.840 2455.160 0.5 PASS 2452 36.320 2433.840 2470.160 0.5 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 10 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 11 11G_Ant1_2412 11G_Ant1_2437 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 12 11G_Ant1_2462 11N20SISO_Ant1_2412 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 13 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 14 11N40SISO_Ant1_2422 11N40SISO_Ant1_2437 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 15 11N40SISO_Ant1_2452 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 16 C.2 Maximum conducted output power Test Result Mode Channel Peak Power [dBm] Limit [dBm] Verdict Ant 0 Ant 1 Sum 11B 2412 15.74 16.19 / ≤30 PASS 2437 15.65 16.06 / ≤30 PASS 2462 15.39 15.92 / ≤30 PASS 11G 2412 14.17 14.87 / ≤30 PASS 2437 13.92 14.52 / ≤30 PASS 2462 13.86 14.42 / ≤30 PASS 11N20 2412 14.17 14.84 17.53 ≤30 PASS 2437 13.87 14.61 17.27 ≤30 PASS 2462 13.88 14.51 17.22 ≤30 PASS 11N40 2422 14.19 14.93 17.59 ≤30 PASS 2437 13.93 14.64 17.31 ≤30 PASS 2452 13.43 14.59 17.06 ≤30 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AU8X-SMPA-R1305G Report No.: LCS211220030AEC 17 C.3 Maximum power spectral density Test Result TestMode Antenna Channel Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant0 2412 -18.19 ≤8.00 PASS 2437 -18.33 ≤8.00 PASS 2462 -18.46 ≤8.00 PASS 11G Ant0 2412 -21.9 ≤8.00 PASS 2437 -22.28 ≤8.00 PASS 2462 -22.33 ≤8.00 PASS 11N20SISO Ant0 2412 -22.29 ≤8.00 PASS 2437 -21.35 ≤8.00 PASS 2462 -22.42 ≤8.00 PASS 11N40SISO Ant0 2422 -22.27 ≤8.00 PASS 2437 -23.06 ≤8.00 PASS 2452 -22.21 ≤8.00 PASS TestMode Antenna Channel Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -17.69 ≤8.00 PASS 2437 -17.86 ≤8.00 PASS 2462 -18.07 ≤8.00 PASS 11G Ant1 2412 -21.42 ≤8.00 PASS 2437 -21.74 ≤8.00 PASS 2462 -21.7 ≤8.00 PASS 11N20SISO Ant1 2412 -20.35 ≤8.00 PASS 2437 -20.71 ≤8.00 PASS 2462 -20.74 ≤8.00 PASS 11N40SISO Ant1 2422 -22.58 ≤8.00 PASS 2437 -23.15 ≤8.00 PASS 2452 -22.71 ≤8.00 PASS MIMO Mode Channel MIMO PSD [dBm/3KHz] Limit [dBm/3KHz] Verdict Ant 0 Ant 1 Sum 11N20 2412 -22.29 -20.35 -18.20 8 PASS 2437 -21.35 -20.71 -18.01 8 PASS 2462 -22.42 -20.74 -18.49 8 PASS 11N40 2422 -22.27 -22.58 -19.41 8 PASS 2437 -23.06 -…

Text truncated - open the document above for the full version.
