2AUCY-V2027MOBILE PHONE

vivo Mobile Communication Co., Ltd.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Sep 17, 2020
Application Purpose: Original Equipment
Date of Application: Sep 17, 2020
Equipment Note: MOBILE PHONE
Company: vivo Mobile Communication Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

vivo Mobile Communication Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (2AUCY-V2027). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Parts List Operational Description Tune Up The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (signature) :xiang jianfeng (printed name)

Cover Letter(s)

vivo Mobile Communication Co., Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for (2AUCY-V2027) To Whom It May Concern: We, the undersigned, hereby authorize Jim Huang at SGS-CSTC Standards Technical Services Ltd on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by SGS-CSTC Standards Technical Services Ltd on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Signature: Print name:xiang jianfeng

Cover Letter(s)

Amendment Letter TIMCO Engineering, Inc. This is to request report update for FCC ID: 2AUCY-V2027, The Major change filed under this application and the relevant report numbers are as below: Original report number New report number Revise content ZR/2020/8001706 ZR/2020/8001706-01 1.Modify data conversion error of antenna height in radiated emission. 2. Update equipment list in section 3. 3. Updated Support Units, Test facility and Test Location in section 1.1, 1.2, and 1.3 Sincerely, (signature) (printed name) Simon Ling

External Photos

1 Photographs - EUT external Photographs Test model No.: V2027

Internal Photos

1 Photographs - EUT internal Test model No.: V2027

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. Xi’an Branch Report No.: ZR/2020/8001706 Page: 1 of 19 TEST REPORT Application No: ZR/2020/80017 Applicant: vivo Mobile Communication Co., Ltd. Address of Applicant #283,BBK Road,Wusha,Chang'An，DongGuan City，China Manufacturer: vivo Mobile Communication Co., Ltd. Address of Manufacturer: #283,BBK Road,Wusha,Chang'An，DongGuan City，China EUT Description: Mobile phone Model No.: V2027 Trade Mark: vivo FCC ID: 2AUCY-V2027 Standard(s) : 47 CFR Part 15, Subpart B Date of Receipt: 2020/8/7 Date of Test: 2020/8/7 to 2020/8/30 Date of Issue: 2020/8/31 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Xi’an Branch Report No.: ZR/2020/8001706 Page: 2 of 19 Revision Record Version Chapter Date Modifier Remark 01 2020/8/31 Original SGS-CSTC Standards Technical Services Co., Ltd. Xi’an Branch Report No.: ZR/2020/8001706 Page: 3 of 19 Test Summary Emission Part Item Standard Method Requirement Result Conducted Emissions at Mains Terminals (150kHz-30MHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Radiated Emissions (30MHz-1GHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Radiated Emissions (above 1GHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Internal Source Upper Frequency Below 1.705MHz 30MHz 1.705MHz to 108MHz 1GHz 108MHz to 500MHz 2GHz 500MHz to 1GHz 5GHz Above 1GHz 5th harmonic of the highest frequency or 40GHz, whichever is lower Checked By Test By David Chen Daniel Wang Reviewer Project Engineer SGS-CSTC Standards Technical Services Co., Ltd. Xi’an Branch Report No.: ZR/2020/8001706 Page: 4 of 19 Contents 1 GENERAL INFORMATION......................................................................................................................... 5 1.1 DESCRIPTION OF SUPPORT UNITS ............................................................................................................ 7 1.2 TEST LOCATION ..................................................................................................................................... 7 1.3 TEST FACILITY ....................................................................................................................................... 7 1.4 DEVIATION FROM STANDARDS ................................................................................................................. 7 1.5 ABNORMALITIES FROM STANDARD CONDITIONS ......................................................................................... 7 2 EMISSION TEST RESULTS ....................................................................................................................... 8 2.1 CONDUCTED EMISSIONS AT MAINS TERMINALS (150KHZ-30MHZ)............................................................... 8 2.1.1 E.U.T. Operation ........................................................................................................................... 8 2.1.2 Test Setup Diagram ...................................................................................................................... 8 2.1.3 Measurement Data ....................................................................................................................... 8 2.2 RADIATED EMISSIONS (30MHZ-1GHZ) ................................................................................................... 11 2.1.4 E.U.T. Operation ......................................................................................................................... 11 2.1.5 Test Setup Diagram .................................................................................................................... 11 2.1.6 Measurement Data ..................................................................................................................... 11 2.3 RADIATED EMISSIONS (ABOVE 1GHZ) ..................................................................................................... 14 2.1.7 E.U.T. Operation ......................................................................................................................... 14 2.1.8 Test Setup Diagram .................................................................................................................... 14 2.1.9 Measurement Data ..................................................................................................................... 14 3 EQUIPMENT LIST .................................................................................................................................... 17 4 MEASUREMENT UNCERTAINTY ............................................................................................................ 18 5 PHOTOGRAPHS ...................................................................................................................................... 19 5.1 TEST SETUP ........................................................................................................................................ 19 5.2 EUT CONSTRUCTIONAL DETAILS (EUT PHOTOS) .................................................................................... 19 SGS-CSTC Standards Technical Services Co., Ltd. Xi’an Branch Report No.: ZR/2020/8001706 Page: 5 of 19 1 General Information Product Name: Mobile phone Model No.(EUT): V2027 Trade Mark: vivo Hardware Version: MP_0.1 Software Version: PD2034EF_EX_A_3.2.4 Frequency Bands: Band Tx (MHz) Rx (MHz) GSM850 824~849 869~894 GSM1900 1850~1910 1930~1990 WCDMA Band II 1850~1910 1930~1990 WCDMA Band IV 1710~1755 2110~2155 WCDMA Band V 824~849 869~894 LTE Band 2 1850~1910 1930~1990 LTE Band 4 1710~1755 2110~2155 LTE Band 5 824~849 869~894 LTE Band 7 2500~2570 2620~2690 LTE Band 38 2570~2620 2570~2620 LTE Band 41 2535~2655 2535~2655 Wi-Fi 2.4G 2412~2472 2412~2472 Bluetooth 2402~2480 2402~2480 Wi-Fi 5G 5150~5850 5150~5850 FM / 88~108 GNSS / 1559~1610 Accessory: Accessory Equipment Manufacturer/trademark Model Specification A…

Text truncated - open the document above for the full version.

Test Report

SGS-CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD. Report No.: ZR/2020/8001706-01 Page: 1 of 19 Authorized Signature: Simon Ling Wireless Laboratory Manager TEST REPORT Application No: ZR/2020/80017 Applicant: vivo Mobile Communication Co., Ltd. Address of Applicant #283,BBK Road,Wusha,Chang'An，DongGuan City，China Manufacturer: vivo Mobile Communication Co., Ltd. Address of Manufacturer: #283,BBK Road,Wusha,Chang'An，DongGuan City，China EUT Description: Mobile phone Model No.: V2027 Trade Mark: vivo FCC ID: 2AUCY-V2027 Standard(s) : 47 CFR Part 15, Subpart B Date of Receipt: 2020/8/7 Date of Test: 2020/8/7 to 2020/8/30 Date of Issue: 2021/8/19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD. Report No.: ZR/2020/8001706-01 Page: 2 of 19 Revision Record Version Chapter Date Modifier Remark 01 2020/8/31 Original 02 2021/5/26 Leah Chen 1. Modify data conversion error of antenna height 2. Updated equipment list 03 2021/8/19 Leah Chen 1. Updated Support Units, Test facility and Test Location Authorized for issue by: Prepared By (Leah Chen) / Engineer Checked By (Daniel Wang) /Reviewer SGS-CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD. Report No.: ZR/2020/8001706-01 Page: 3 of 19 Test Summary Emission Part Item Standard Method Requirement Result Conducted Emissions at Mains Terminals (150kHz-30MHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Radiated Emissions (30MHz-1GHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Radiated Emissions (above 1GHz) 47 CFR Part 15, Subpart B ANSI C63.4:2014 Class B Pass Internal Source Upper Frequency Below 1.705MHz 30MHz 1.705MHz to 108MHz 1GHz 108MHz to 500MHz 2GHz 500MHz to 1GHz 5GHz Above 1GHz 5th harmonic of the highest frequency or 40GHz, whichever is lower SGS-CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD. Report No.: ZR/2020/8001706-01 Page: 4 of 19 Contents 1 GENERAL INFORMATION .................................................................................................................. 5 1.1 DESCRIPTION OF SUPPORT UNITS .................................................................................................... 7 1.2 TEST LOCATION ............................................................................................................................. 7 1.3 TEST FACILITY ............................................................................................................................... 7 1.4 DEVIATION FROM STANDARDS ......................................................................................................... 7 1.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 7 2 EMISSION TEST RESULTS................................................................................................................. 8 2.1 CONDUCTED EMISSIONS AT MAINS TERMINALS (150KHZ-30MHZ) ....................................................... 8 2.1.1 E.U.T. Operation ...................................................................................................................... 8 2.1.2 Test Setup Diagram ................................................................................................................. 8 2.1.3 Measurement Data................................................................................................................... 8 2.2 RADIATED EMISSIONS (30MHZ-1GHZ) ............................................................................................11 2.1.4 E.U.T. Operation .....................................................................................................................11 2.1.5 Test Setup Diagram ................................................................................................................11 2.1.6 Measurement Data..................................................................................................................11 2.3 RADIATED EMISSIONS (ABOVE 1GHZ) ..............................................................................................14 2.1.7 E.U.T. Operation .....................................................................................................................14 2.1.8 Test Setup Diagram ................................................................................................................14 2.1.9 Measurement Data..................................................................................................................14 3 EQUIPMENT LIST ..............................................................................................................................17 4 MEASUREMENT UNCERTAINTY.......................................................................................................18 5 PHOTOGRAPHS ................................................................................................................................19 5.1 TEST SETUP .................................................................................................................................19 5.2 EUT CONSTRUCTIONAL DETAILS (EUT PHOTOS) .............................................................................19 SGS-CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD. Report No.: ZR/2020/8001706-01 Page: 5 of 19 1 General Information Product Name: Mobile phone Model No.(EUT): V2027 Trade Mark: vivo Hardware Version: MP_0.1 Software Version: PD2034EF_EX_A_3.2.4 Frequency Bands: Band Tx (MHz) Rx (MHz) GSM850 824~849 869~894 GSM1900 1850~1910 1930~1990 WCDMA Band II 1850~1910 1930~1990 WCDMA Band IV 1710~1755 2110~2155 WCDMA Band V 824~849 869~894 LTE Band 2 1850~1910 1930~1990 LTE Band 4 1710~1755 2110~2155 LTE Band 5 824~849 869~894 LTE Band 7 2500~2570 2620~2690 LTE Band 38 2570~2620 2570~2620 LTE Band 41 2535~2655 2535~2655 Wi-Fi 2.4G 2412~2472 2412~2472 Bluetooth 2402~2480 2402~2480 Wi-Fi 5G 5150~5850 5150~5850…

Text truncated - open the document above for the full version.

Test Setup Photos

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 5 Appendix A Photographs of Set-Up for ZR/2020/80017 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 5 1 Photographs – RF Test model No.: V2027 1.1 Setup for AC Power Line Conducted Emissions below 30MHz（Test Location: SGS-CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD.） SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 5 1.2 Setup for Unwanted Emissions that fall Outside of the Restricted Bands(Radiated) and Unwanted Emissions in the Restricted Bands (Radiated) below 1GHz（Test Location: SGS- CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD.） SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 5 1.3 Setup for Unwanted Emissions that fall Outside of the Restricted Bands(Radiated) and Unwanted Emissions in the Restricted Bands (Radiated) above 1GHz（Test Location: SGS- CSTC STANDARDS TECHNICAL SERVICES (XI 'AN) CO., LTD.） SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 5 1.4 Setup for DFS（Test Location: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch）
