2AUCY-V2318Mobile Phone

viv o Mobile Communication Co., Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: October 30, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may concern, vivo Mobile Communication Co., Ltd. certifies that the equipment FCC ID: 2AUCY-V2318 for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. vivo Mobile Communication Co., Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. the applicant is not a named entity or any of its subsidiaries or affiliates. Sincerely, ________________________ Name: Xiang Jianfeng Title: Certification Engineer E-mail: [email protected]

vivo Mobile Communication Co., Ltd. Federal Communications Commission 7435 Oaklan d Mills Road Columbia MD 21046 Ref: Attestation Statements Part 2.911(d)(7) Filing Grantee Code: 2AUCY FRN:0028746295 vivo Mobile Communication Co., Ltd., certifies that, as of the date of the filing of application, SMART LUCKY TECHNOLOGY, INC. is designated as the U.S. agent for the purpose of accepting service of process on behalf of the applicant. The physical U.S. address and email and FRN for the designated agent are: Physical U.S. address: 5890 Pacific Center Blvd., San Diego, California 92121 FRN：0033411711 Email: [email protected] The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The agent accepts the designation by vivo Mobile Communication Co., Ltd. as the U.S. agent to accept service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. Signed by the Applicant Signed by the Agent (if different from the Applicant) Name: Jianfeng Xiang Name: Lei Xu Title: Certification Engineer Title: Secretary Email: [email protected] Email: [email protected] Date: 2023/02/22 Date: 2023/02/22

vivo Mobile Communication Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: (2AUCY-V2318). Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Parts List Operational Description Tune Up software security requirement The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for a period of 180days: External Photos, Internal Photos, Test Setup Photos Manual Test Setup Photos Internal Photos External Photos User Manual Sincerely, (signature) (printed name) xiangjianfeng 2023-12-06

RF_160, Issue 04 vivo Mobile Communication Co., Ltd. Declaration of Authorization We Name: vivo Mobile Communication Co., Ltd. Address: No.1, vivo Road, Chang'an, Dongguan,Guangdong,China City: Dong guan Country: China Declare that: Name Representative of agent: Sherlock Fang Agent Company name: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Address: No.1 Workshop, M-10, Middle Section, Science & Technology Park, City: Shenzhen Country: China is authorized to apply for Certification of the following product(s): Product description: Mobile phone Type designation: V2318 Trademark: vivo FCC ID: 2AUCY-V2318 on our behalf. Sincerely yours, Contact Person: xiangjianfeng Applicant: vivo Mobile Communication Co., Ltd. Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

External photos

E-Label 1. The information that will be displayed on the e-label and information that will remain in the user manual is shown below: Information on E-label In Manual FCC ID number Yes No 15.19 statement (“This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”) No Yes Class A / B Digital Device user manual statements* No Yes Caution to the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment1 No Yes Describe any other FCC regulatory information included in e-label* * If the e-label includes information typically included in the manual then the e-label shall clearly differentiate between information required to be on the device’s surface and information required to be in the manual – refer to KDB 784748 D02 e labelling v02r01. E-label show： B. Access to the required information on the e-label 1. Users are able to access the information in no more than three steps in a device’s menu. The actual steps are: To access the e-label information, in the device, Choose 1: Settings > About phone >Status, No special access codes or permissions are required to go through the above steps beyond enter- ing a userdefined password to protect against unauthorized access to the device. 2. The information is stored on the device, no special accessories or supplemental plug-ins (e.g., a SIM/USIM card) are required to access the information. Yes see E-label photos 3. Users are provided specific instructions on how to access the information. The information to the user is provided in the iPhone Info document. C. Labeling for Importation and Purchasing 1. Products utilizing e-labels are required to have a physical label on the product at the time of importation, marketing and sales. For devices imported in bulk and not packaged individually, a removable adhesive label or, for devices in protective bags, a label on the bags is acceptable for this purpose. Any removable label shall be of a type intended to survive normal shipping and handling and must only be removed by the customer after purchase. For devices imported already in individual packages ready for sale, the information may alternatively be provided on the package. It shall contain: 1. The FCC ID and/or the SDoC logo (if applicable); and 2. Any other information required by specific rule to be provided on the surface of the product unless such information is permitted to be included in the User’s manual or other packaging inserts. The FCC ID and Model number are present on the product packaging、physical label. D. Other considerations 1. The above information must be programmed by the responsible party and the information must be secured in such a manner that third-parties cannot modify it. The e-label information is pre-programmed by the grantee. The user cannot modify the e-label information. 2. All the applicable regulatory information required on the packaging or user instructions must be provided according to the rules even if it is displayed electronically. For example, hearing aid compatibility (HAC) ratings for the phones as specified in 47 C.F.R. § 20.19. Yes, it is provided

Internal photos Antenna Support TX Band Ant 11# GSM850,WCDMA B5,LTE B5/12/13/17/26/28,NR n5/26 Ant 12# UL Interband CA LTE B4,ENDC_LTE B7,NSA NR N7/38/41/66 Ant 13# NR n77/78 Ant 14# GSM1900,WCDMA B2/4,LTE B2/4/7/66/38/41,NR n2/7/66/38/41 Ant 15# NR n77/78 Ant 21# NR n77/78 Ant 22# WiFi 2.4G/5G/BT Ant 23# NR n77/78 Ant 24# NSA N38/41 Ant 25# WiFi 2.4G/5G/BT Ant 31# GSM1900,WCDMA B2/4,LTE B2/4/7/66/38/41,NR n2/7/66/38/41 Ant 41# GSM850,WCDMA B5,LTE B5/12/13/17/26/28,NR n5/26

Report No.: ZEWM2311001675RG01 Part 1_Appendix A Detailed System Check Results 1.System Performance Check System Performance Check 750 MHz Head System Performance Check 835 MHz Head System Performance Check 1750 MHz Head System Performance Check 1900 MHz Head System Performance Check 1950 MHz Head System Performance Check 2450 MHz Head System Performance Check 2600 MHz Head System Performance Check 3500 MHz Head System Performance Check 3700 MHz Head System Performance Check 3900 MHz Head System Performance Check 5250 MHz Head System Performance Check 5600 MHz Head System Performance Check 5750 MHz Head Date: 2023/11/15 System Performance Check 750 MHz Head D750V3-SN 1160 Communication System: D750; Frequency: 750.000 Medium: HSL. Medium parameters used: f= 750.000 MHz; σ= 0.897 S/m; ε r = 41.6 DASY8 Configuration: - Probe: EX3DV4 - SN7838; ConvF(9.75, 9.68, 9.67); Calibrated: 2023/09/11 - Sensor-Surface: 1.4 mm - Electronics: DAE4ip Sn1830; Calibrated: 2023/09/12 - Phantom: Twin-SAM V8.0 (30deg probe tilt); Serial: 2256 - Measurement Software: cDASY8 V16.2.4.2524 Area Scan (90.0 mm x 195.0 mm): Measurement Grid: 15.0 mm x 15.0 mm SAR (1g) = 2.13 W/kg; SAR (10g) = 1.42 W/kg; Zoom Scan (32.0 mm x 32.0 mm x 30.0 mm): Measurement Grid: 8.0 mm x 8.0 mm x 5.0 mm Power Drift = 0.05 dB SAR (1g) = 2.14 W/kg; SAR (10g) = 1.43 W/kg; Date: 2023/11/10 System Performance Check 835 MHz Head D835V2-SN 4d105 Communication System: D835; Frequency: 835.000 Medium: HSL. Medium parameters used: f= 835.000 MHz; σ= 0.911 S/m; ε r = 42.6 DASY8 Configuration: - Probe: EX3DV4 - SN7838; ConvF(9.3, 9.34, 9.27); Calibrated: 2023/09/11 - Sensor-Surface: 1.4 mm - Electronics: DAE4ip Sn1830; Calibrated: 2023/09/12 - Phantom: Twin-SAM V8.0 (30deg probe tilt); Serial: 2256 - Measurement Software: cDASY8 V16.2.4.2524 Area Scan (95.0 mm x 180.0 mm): Measurement Grid: 15.0 mm x 15.0 mm SAR (1g) = 2.50 W/kg; SAR (10g) = 1.64 W/kg; Zoom Scan (32.0 mm x 32.0 mm x 30.0 mm): Measurement Grid: 8.0 mm x 8.0 mm x 5.0 mm Power Drift = 0.04 dB SAR (1g) = 2.52 W/kg; SAR (10g) = 1.68 W/kg; Date: 2023/11/12 Test Laboratory: SGS-SAR Lab System Performance Check 835MHz Head DUT: D835V2; Type: Dipole; Serial: 4d105 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL835;Medium parameters used: f = 835 MHz; σ = 0.904 S/m; ε r = 42.218; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: ES3DV3 - SN3137; ConvF(5.94, 5.94, 5.94); Calibrated: 2023/9/27 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2023/3/17 Phantom: SAM 6; Type: SAM Twin; Serial: 1913 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/d=15mm, Pin=250mW/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 2.30 W/kg Configuration/d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 52.96 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 3.37 W/kg SAR(1 g) = 2.26 W/kg; SAR(10 g) = 1.48 W/kg Maximum value of SAR (measured) = 2.65 W/kg 0 dB = 2.30 W/kg = 3.61 dBW/kg Date: 2023/11/14 Test Laboratory: SGS-SAR Lab System Performance Check 835MHz Head DUT: D835V2; Type: Dipole; Serial: 4d105 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL835;Medium parameters used: f = 835 MHz; σ = 0.906 S/m; ε r = 41.928; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN7620; ConvF(10.73, 10.73, 10.73); Calibrated: 2022/11/20 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2022/12/10 Phantom: SAM 1; Type: SAM; Serial: 1912 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/d=15mm, Pin=250mW/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3.36 W/kg Configuration/d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 52.92 V/m; Power Drift = 0.04 dB Peak SAR (extrapolated) = 4.00 W/kg SAR(1 g) = 2.46 W/kg; SAR(10 g) = 1.59 W/kg Maximum value of SAR (measured) = 3.42 W/kg 0 dB = 3.42 W/kg = 5.34 dBW/kg Date: 2023/11/15 Test Laboratory: SGS-SAR Lab System Performance Check 835MHz Head DUT: D835V2; Type: Dipole; Serial: 4d105 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL835;Medium parameters used: f = 835 MHz; σ = 0.913 S/m; ε r = 43.091; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN7620; ConvF(10.73, 10.73, 10.73); Calibrated: 2022/11/20 Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2022/12/10 Phantom: SAM 1; Type: SAM; Serial: 1912 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/d=15mm, Pin=250mW/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3.06 W/kg Configuration/d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 51.62 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 3.84 W/kg SAR(1 g) = 2.34 W/kg; SAR(10 g) = 1.5 W/kg Maximum value of SAR (measured) = 3.29 W/kg 0 dB = 3.29 W/kg = 5.17 dBW/kg Date: 2023/11/10 Test Laboratory: SGS-SAR Lab System Performance Check 1750MHz Head DUT: D1750V2; Type: Dipole; Serial: 1149 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL1750;Medium parameters used: f = 1750 MHz; σ = 1.37 S/m; ε r = 39.144; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: ES3DV3 - SN3137; ConvF(5.07, 5.07, 5.07); Calibrated: 2023/9/27 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2023/3/17 Phantom: SAM 6; Type: SAM Twin; Serial: 1913 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/d=10mm, Pin=250mW/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 10.5 W/kg Configuration/d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0…

Text truncated - open the document above for the full version.

Report No.: ZEWM2311001675RG01 Part 1_Appendix B Detailed Test Results GSM850 for Head, Body GSM1900 for Head, Body WCDMA Band II for Head, Body WCDMA Band IV for Head, Body & Limbs WCDMA Band V for Head, Body LTE Band 2 for Head, Body & Limbs LTE Band 4 for Head, Body LTE Band 5 for Head, Body LTE Band 7 for Head, Body LTE Band 12 for Head, Body LTE Band 13 for Head, Body LTE Band 26 for Head, Body LTE Band 38 for Head, Body LTE Band 41 for Head, Body LTE Band 66 for Head, Body & Limbs n2 for Head, Body n5 for Head, Body & Limbs n7 for Head, Body & Limbs n26 for Head, Body n41 for Head, Body n66 for Head, Body & Limbs n77 for Head, Body & Limbs n78 for Body WIFI 2.4G for Head, Body WIFI 5G for Head, Body & Limbs BT for Head, Body Date: 2023/11/12 Test Laboratory: SGS-SAR Lab V2318 GSM850 GPRS 4TS 251CH Left cheek Ant11 DUT: V2318; Type: Mobile Phone; Serial: 869975079989417 Communication System: UID 0, GPRS/EGPRS Mode(4up) Communication System (0); Frequency: 848.6 MHz;Duty Cycle: 1:2.07491 Medium: HSL835;Medium parameters used: f = 849 MHz; σ = 0.947 S/m; ε r = 42.384; ρ = 1000 kg/m 3 Phantom section: Left Section DASY 5 Configuration: Probe: ES3DV3 - SN3137; ConvF(5.94, 5.94, 5.94); Calibrated: 2023/9/27 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2023/3/17 Phantom: SAM 6; Type: SAM Twin; Serial: 1913 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/Head/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.519 W/kg Configuration/Head/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.409 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 1.23 W/kg SAR(1 g) = 0.567 W/kg; SAR(10 g) = 0.297 W/kg Maximum value of SAR (measured) = 0.637 W/kg 0 dB = 0.519 W/kg = -2.85 dBW/kg Date: 2023/11/12 Test Laboratory: SGS-SAR Lab V2318 GSM850 GPRS 2TS 190CH Back side 15mm Ant11 DUT: V2318; Type: Mobile Phone; Serial: 869975079989417 Communication System: UID 0, GPRS/EGPRS Mode(2up) Communication System (0); Frequency: 836.6 MHz;Duty Cycle: 1:4.14954 Medium: HSL835;Medium parameters used: f = 837 MHz; σ = 0.939 S/m; ε r = 42.45; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: ES3DV3 - SN3137; ConvF(5.94, 5.94, 5.94); Calibrated: 2023/9/27 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2023/3/17 Phantom: SAM 6; Type: SAM Twin; Serial: 1913 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/Body/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.370 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 9.682 V/m; Power Drift = -0.19 dB Peak SAR (extrapolated) = 0.546 W/kg SAR(1 g) = 0.352 W/kg; SAR(10 g) = 0.222 W/kg Maximum value of SAR (measured) = 0.421 W/kg 0 dB = 0.370 W/kg = -4.32 dBW/kg Date: 2023/11/12 Test Laboratory: SGS-SAR Lab V2318 GSM850 GPRS 4TS 190CH Left side 10mm Ant11 DUT: V2318; Type: Mobile Phone; Serial: 869975079989417 Communication System: UID 0, GPRS/EGPRS Mode(4up) Communication System (0); Frequency: 836.6 MHz;Duty Cycle: 1:2.07491 Medium: HSL835;Medium parameters used: f = 837 MHz; σ = 0.939 S/m; ε r = 42.45; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: ES3DV3 - SN3137; ConvF(5.94, 5.94, 5.94); Calibrated: 2023/9/27 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2023/3/17 Phantom: SAM 6; Type: SAM Twin; Serial: 1913 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/Body/Area Scan (5x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.566 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 23.80 V/m; Power Drift = -0.08 dB Peak SAR (extrapolated) = 0.871 W/kg SAR(1 g) = 0.495 W/kg; SAR(10 g) = 0.277 W/kg Maximum value of SAR (measured) = 0.623 W/kg 0 dB = 0.566 W/kg = -2.47 dBW/kg Date: 2023/11/12 Test Laboratory: SGS-SAR Lab V2318 GSM1900 GPRS 4TS 661CH Right cheek Ant14 DUT: V2318; Type: Mobile Phone; Serial: 869975079989417 Communication System: UID 0, GPRS/EGPRS Mode(4up) Communication System (0); Frequency: 1880 MHz;Duty Cycle: 1:2.07491 Medium: HSL1900;Medium parameters used: f = 1880 MHz; σ = 1.381 S/m; ε r = 40.744; ρ = 1000 kg/m 3 Phantom section: Right Section DASY 5 Configuration: Probe: ES3DV3 - SN3137; ConvF(4.83, 4.83, 4.83); Calibrated: 2023/9/27 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2023/3/17 Phantom: SAM 6; Type: SAM Twin; Serial: 1913 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/Head/Area Scan (8x14x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.505 W/kg Configuration/Head/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 14.28 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 0.960 W/kg SAR(1 g) = 0.477 W/kg; SAR(10 g) = 0.253 W/kg Maximum value of SAR (measured) = 0.589 W/kg 0 dB = 0.505 W/kg = -2.97 dBW/kg Date: 2023/11/12 Test Laboratory: SGS-SAR Lab V2318 GSM1900 GPRS 2TS 661CH Back side 15mm Ant31 DUT: V2318; Type: Mobile Phone; Serial: 869975079989417 Communication System: UID 0, GPRS/EGPRS Mode(2up) Communication System (0); Frequency: 1880 MHz;Duty Cycle: 1:4.14954 Medium: HSL1900;Medium parameters used: f = 1880 MHz; σ = 1.381 S/m; ε r = 40.744; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: ES3DV3 - SN3137; ConvF(4.83, 4.83, 4.83); Calibrated: 2023/9/27 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE4 Sn896; Calibrated: 2023/3/17 Phantom: SAM 6; Type: SAM Twin; Serial: 1913 DASY52 52.10.4(1527); SEMCAD X 14.6.14(7483) Configuration/Body/Area Scan (8x14x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.373 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm…

Text truncated - open the document above for the full version.

Report No.: ZEWM2311001675RG01 Part 1_Appendix C Calibration certificate 1. Dipole D750V3-SN 1160 D835V2-SN 4d105 D1750V2-SN 1149 D1900V2- SN 5d028 D1950V3- SN 1138 D2450V2-SN 733 D2600V2-SN 1125 D3500V2-SN 1082 D3700V2-SN 1046 D3900V2-SN 1026 D5GV2-SN 1165 2. DAE DAE4-SN 702 DAE4-SN 760 DAE4-SN 896 DAE4-SN 1267 DAE4ip -SN 1803 DAE4ip -SN 1830 3. Probe EX3DV4-SN 7620 EX3DV4-SN 7838 EX3DV4-SN 7821 ES3DV3-SN 3137 Report No.: ZEWM2311001675RG01 EX3DV4-SN 3836 EX3DV4-SN 3624

Report No.: ZEWM2311001675RG01 Part 1_Appendix E Conducted RF Output Power Measurement of RF conducted Power 1 Conducted Power of Main Antenna (Ant11) 1.1 Conducted Power of GSM 1.2 Conducted Power of WCDMA 1.3 Conducted Power of LTE 2 Conducted Power of Main Antenna (Ant14) 2.1 Conducted Power of GSM 2.2 Conducted Power of WCDMA 2.3 Conducted Power of LTE 3 Conducted Power of Main Antenna (Ant31) 3.1 Conducted Power of GSM 3.2 Conducted Power of WCDMA 3.3 Conducted Power of LTE 4 Conducted Power of Main Antenna (Ant41) 4.1 Conducted Power of GSM 4.2 Conducted Power of WCDMA 4.3 Conducted Power of LTE 5 Conducted Power of ENDC_LTE 5.1 Conducted Power of LTE (Ant12) 6 Conducted Power of Intra Band LTE Uplink CA 6.1 Conducted Power of LTE Uplink CA (Ant14) 6.2 Conducted Power of LTE Uplink CA (Ant31) 7 Conducted Power of LTE Downlink CA 7.1 Conducted Power of LTE Downlink CA (Ant11) 7.2 Conducted Power of LTE Downlink CA (Ant14) 7.3 Conducted Power of LTE Downlink CA (Ant31) 7.4 Conducted Power of LTE Downlink CA (Ant41) Report No.: ZEWM2311001675RG01 8 Conducted Power of NR Antenna 8.1 Conducted Power of NR Antenna (Ant11) 8.2 Conducted Power of NR Antenna (Ant12) 8.3 Conducted Power of NR Antenna (Ant13) 8.4 Conducted Power of NR Antenna (Ant14) 8.5 Conducted Power of NR Antenna (Ant15) 8.6 Conducted Power of NR Antenna (Ant21) 8.7 Conducted Power of NR Antenna (Ant23) 8.8 Conducted Power of NR Antenna (Ant24) 8.9 Conducted Power of NR Antenna (Ant31) 8.10 Conducted Power of NR Antenna (Ant41) 9 Conducted Power of WiFi and Bluetooth 9.1 Conducted Power of 2.4GWiFi 9.2 Conducted Power of 5GWiFi 9.3 Conducted Power of Bluetooth Note: DSI Trigger Conditions Antenna No. DSI 2 Receiver on standalone All WWAN Ant DSI 3 Receive on simultaneous transmission with WLAN All WWAN Ant DSI 4 Receive off / Sensor on standalone 12#/13#/14#15# Receive off / Sensor off standalone 11#/21#/22#/23#/24#/25#/31#/41# DSI 5 Receiver off/Sensor on simultaneous transmission with WLAN 12#/13#/14#/15# Receiver off/Sensor off simultaneous transmission with WLAN 11#/21#/22#/23#/24#/25#/31#/41# DSI 6 Receiver off/Sensor off simultaneous transmission with WLAN 12#/13#/14#/15# hotspot All WWAN Ant DSI 7 Receiver off/Sensor off Sensor Trigger Distance -1mm 12#/13#/14#/15# Receiver off/Sensor off standalone 12#/13#/14#/15# Report No.: ZEWM2311001675RG01 Measurement of RF conducted Power 1 Conducted Power of Main Antenna (Ant11) 1.1 Conducted Power of GSM GSM 850 DSI 2 Burst Output Power(dBm) Division Factors Frame-Average Output Power(dBm) Channel 128 190 251 Tune up 128 190 251 Tune up GSM(GMSK) GSM 32.68 32.61 32.78 33.60 -9.19 23.49 23.42 23.59 24.41 GPRS (GMSK) 1 TX Slot 32.42 32.59 32.53 33.60 -9.19 23.23 23.40 23.34 24.41 2 TX Slots 29.28 29.55 29.16 30.50 -6.18 23.10 23.37 22.98 24.32 3 TX Slots 27.51 27.82 27.56 28.60 -4.42 23.09 23.40 23.14 24.18 4 TX Slots 26.24 26.45 26.11 27.80 -3.17 23.07 23.28 22.94 24.63 EGPRS (GMSK) 1 TX Slot 32.41 32.34 32.60 33.60 -9.19 23.22 23.15 23.41 24.41 2 TX Slots 29.29 29.35 29.27 30.50 -6.18 23.11 23.17 23.09 24.32 3 TX Slots 27.52 27.66 27.65 28.60 -4.42 23.10 23.24 23.23 24.18 4 TX Slots 26.32 26.30 26.21 27.80 -3.17 23.15 23.13 23.04 24.63 EGPRS (8PSK) 1 TX Slot 27.05 27.13 27.03 28.60 -9.19 17.86 17.94 17.84 19.41 2 TX Slots 25.52 25.75 25.56 26.60 -6.18 19.34 19.57 19.38 20.42 3 TX Slots 23.56 23.59 23.64 24.60 -4.42 19.14 19.17 19.22 20.18 4 TX Slots 21.85 22.10 22.07 23.10 -3.17 18.68 18.93 18.90 19.93 GSM 850 DSI 3 Burst Output Power(dBm) Division Factors Frame-Average Output Power(dBm) Channel 128 190 251 Tune up 128 190 251 Tune up GSM(GMSK) GSM 31.43 31.41 31.50 32.60 -9.19 22.24 22.22 22.31 23.41 GPRS (GMSK) 1 TX Slot 31.34 31.49 31.47 32.60 -9.19 22.15 22.30 22.28 23.41 2 TX Slots 28.16 28.45 28.31 29.50 -6.18 21.98 22.27 22.13 23.32 3 TX Slots 26.65 26.80 26.61 27.60 -4.42 22.23 22.38 22.19 23.18 4 TX Slots 25.12 25.44 25.35 26.80 -3.17 21.95 22.27 22.18 23.63 EGPRS (GMSK) 1 TX Slot 31.30 31.44 31.42 32.60 -9.19 22.11 22.25 22.23 23.41 2 TX Slots 28.15 28.41 28.28 29.50 -6.18 21.97 22.23 22.10 23.32 3 TX Slots 26.65 26.75 26.59 27.60 -4.42 22.23 22.33 22.17 23.18 4 TX Slots 25.17 25.33 25.27 26.80 -3.17 22.00 22.16 22.10 23.63 EGPRS (8PSK) 1 TX Slot 27.05 27.13 27.03 28.60 -9.19 17.86 17.94 17.84 19.41 2 TX Slots 25.52 25.75 25.56 26.60 -6.18 19.34 19.57 19.38 20.42 3 TX Slots 23.56 23.59 23.64 24.60 -4.42 19.14 19.17 19.22 20.18 4 TX Slots 21.85 22.10 22.07 23.10 -3.17 18.68 18.93 18.90 19.93 Report No.: ZEWM2311001675RG01 GSM 850 DSI 4/7 Burst Output Power(dBm) Division Factors Frame-Average Output Power(dBm) Channel 128 190 251 Tune up 128 190 251 Tune up GSM(GMSK) GSM 33.17 33.08 33.23 34.10 -9.19 23.98 23.89 24.04 24.91 GPRS (GMSK) 1 TX Slot 33.16 33.12 33.20 34.10 -9.19 23.97 23.93 24.01 24.91 2 TX Slots 31.16 31.02 30.81 32.10 -6.18 24.98 24.84 24.63 25.92 3 TX Slots 29.42 29.35 29.15 30.10 -4.42 25.00 24.93 24.73 25.68 4 TX Slots 26.97 26.77 27.50 28.60 -3.17 23.80 23.60 24.33 25.43 EGPRS (GMSK) 1 TX Slot 33.19 33.11 33.22 34.10 -9.19 24.00 23.92 24.03 24.91 2 TX Slots 31.14 31.01 30.81 32.10 -6.18 24.96 24.83 24.63 25.92 3 TX Slots 29.45 29.35 29.12 30.10 -4.42 25.03 24.93 24.70 25.68 4 TX Slots 26.99 26.80 27.10 28.60 -3.17 23.82 23.63 23.93 25.43 EGPRS (8PSK) 1 TX Slot 27.05 27.13 27.03 28.60 -9.19 17.86 17.94 17.84 19.41 2 TX Slots 25.52 25.75 25.56 26.60 -6.18 19.34 19.57 19.38 20.42 3 TX Slots 23.56 23.59 23.64 24.60 -4.42 19.14 19.17 19.22 20.18 4 TX Slots 21.85 22.10 22.07 23.10 -3.17 18.68 18.93 18.90 19.93 GSM 850 DSI 5/6 Burst Output Power(dBm) Division Factors Frame-Average Output Power(dBm) Channel 128 190 251 Tune up 128 190 251 Tune up GSM(GMSK) GSM 32.46 32.50 32.57 33.70 -9.19 23.27 23.31 23.38 24.51 GPRS (GMSK) 1 TX Slot 32.48 32.46 32.50 33.70 -9.19 23.29 23.27 23.31 24.51 2 TX Slots 29.55 29.48 29.35 30.60 -6.18 23.37 23.30 23.17 24.42 3 TX Slots 27.59 27.66 27.58 28.70 -4.42 23.17 23.24 23.16 24.28 4 TX Slots 25.95 26.64 26.32 27.90 -3.1…
