2AUF7RF-N6201UHF Reader Module

RF-N6201 Operation Manual Contents 1 Demo Instruction .........................................................................................................................4 2 Demo Applicating Environment ...................................................................................................4 3 Demo Version ..............................................................................................................................4 4 Demo Operation ..........................................................................................................................4 4.1 Connect Reader .................................................................................................................4 4.1.1 RS232 Communication Connection ........................................................................5 4.1.2 RS485 Communication Connection ........................................................................6 4.1.3 TCP Client Communication Connection ..................................................................8 4.2 Data Displaying Area .........................................................................................................9 4.2.1 Read EPC .............................................................................................................. 10 4.2.2 Read TID ............................................................................................................... 11 4.2.3 Custom Read ........................................................................................................ 11 4.2.4 Stop ...................................................................................................................... 16 4.3 Write Data ....................................................................................................................... 16 4.3.1 Write EPC Data ..................................................................................................... 16 4.3.2 Write User Data .................................................................................................... 17 4.3.3 Custom Tag Operation .......................................................................................... 17 4.4 Device Configuration ....................................................................................................... 23 4.4.1 RS232 Parameter .................................................................................................. 24 4.4.2 RS485 Parameter .................................................................................................. 25 4.4.3 Ethernet Parameter .............................................................................................. 26 4.4.4 Reader Time ......................................................................................................... 29 4.4.5 Reader MAC ......................................................................................................... 31 4.4.6 TCP Server/Client Mode ....................................................................................... 31 4.5 GPI/O Configuration ........................................................................................................ 34 4.5.1 GPO Configuration ............................................................................................... 35 4.5.2 GPI State Get ........................................................................................................ 36 4.5.3 GPI Operation Configuration ................................................................................ 37 4.6 RFID Configuration .......................................................................................................... 40 4.6.1 EPC Baseband Parameter ..................................................................................... 41 4.6.2 Power Configuration for Antenna Port ................................................................. 42 4.6.3 Auto-idleness Configuration ................................................................................. 42 4.6.4 Tag Filtering .......................................................................................................... 43 4.6.5 Hopping Frequency Management ........................................................................44 4.7 Other Configurations ....................................................................................................... 47 4.7.1 Wiegand Communication Parameter Configuration ............................................. 47 4.7.2 Buzzer Control ...................................................................................................... 48 4.7.3 EAS Alarm ............................................................................................................. 49 4.8 Tools ................................................................................................................................ 50 4.8.1 Restart .................................................................................................................. 50 4.8.2 Restore Factory Setting ........................................................................................ 52 4.8.3 Data Export .......................................................................................................... 53 4.8.4 Upgrade ................................................................................................................ 54 4.8.5 Custom Command ................................................................................................ 57 4.8.6 Device Info ........................................................................................................... 58 4.8.7 Devices Search ..................................................................................................... 60 2.7 Label and compliance information ............................................................................ 67 2.9 Additional testing, Part 15 Subpart B dis…

Text truncated - open the document above for the full version.

(Shenzhen Nation RFID Technology Co., Ltd.) (August 17, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2AUF7RF-N6201) [Shenzhen Nation RFID Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Lijun Xia (Shenzhen Nation RFID Technology Co., Ltd.) (August 17, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2AUF7RF-N6201) [Shenzhen Nation RFID Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Lijun Xia

< Shenzhen Nation RFID Technology Co., Ltd.> Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 Company name: Shenzhen Nation RFID Technology Co., Ltd. FCC ID: 2AUF7RF-N6201 Gentlemen, In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Certification Guide v02’. FCC ID: 2AUF7RF-N6201 has been examined against the following requirements. Items to be covered by Single modular transmitters. Requirement per 15.212 and KDB 996369 D01 ‘Modular Certification Guide v02 Explanation from Grantee 1. The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly YES 2. The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal YES 3. The module must contain power supply regulation on the module YES 4. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) YES 5. The module must demonstrate compliance in a stand- alone configuration YES 6. The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) YES 7. The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee YES 8. The module must comply with RF exposure requirements YES Name: Lijun Xia Title: Engineering Manager Signature of applicant Date: 2023.08.17

Shenzhen Nation RFID Technology Co., Ltd. (August 17, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (UHF Reader Module / RF-N6201 / FCC ID: 2AUF7RF-N6201) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☒ Internal Photos ☐ NOTE 1 ☒ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: Lijun Xia Title: Engineering Manager

Shenzhen Nation RFID Technology Co., Ltd. (August 17, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Lijun Xia Title: Engineering Manager

External Photos ANT

FCC ID LABEL: Label Location:

Internal Photos

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2AUF7RF-N6201 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation Channel Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result RFID LCH 22±1 23 199.526 2 4.256 (6.29dBi) 0.169 1 Pass RFID MCH 21±1 22 158.489 3 4.256 (6.29dBi) 0.13426 1 Pass RFID HCH 19±1 20 100 4.256 (6.29dBi) 0.0847 1 Pass

BRA-02 antenna product manual Product model BRA-02 type antenna Functions and features of the product Electrical performance: Universal antennas suitable for UHF band RFID applications have the characteristics of high gain and low standing wave. Mechanical properties: beautiful and small appearance, using waterproof ring and silicone double waterproof design, shell with stiffener design, suitable for various harsh environments. Main uses and scope of application BRA-02 antenna can be easily used in UHF band RFID occasions such as access control, warehousing, logistics, and retail Performance indicators Frequency range： ： 902MHz～928MHz VSWR：≤1.3:1 Gain： 6.29dBi H-side HPBW： 90° E-side HPBW： 90° Polarization： Circular polarization humidity： 5%～95% Input impedance： 50 Ω Mechanical indicators Size ： 128mm×128mm×20mm Weight： 0.3kg(without support) Materials： Engineering plastics ASA, aluminum Aluminum color: milky white Protection level: IP67 Operating temperature: -40°C~+ 85°C Storage temperature: -40°C~+ 85°C Figure 1 Actual BRA-02 antenna Installation The BRA-02 antenna can be mounted on a steel frame structure or pillar through its own bracket or user-equipped bracket, and connected to the reader by a coaxial line. The antenna can be installed horizontally or vertically, depending on the mounting orientation of the bracket, and the inclination angle of the antenna can be adjusted according to the actual situation after installation。 The antenna bracket is an option and can be selected according to the customer's needs. Antenna size: Antenna Frequency: VSWR test diagram of BRA-02 antenna Antenna pattern BRA-02 (two-dimensional pattern, gain display greater than 6 dBic) Antenna performance diagram Manufacturer: Shenzhen Nation RFID Technology Co., Ltd. Address: No. 527-531, 5th floor, 5A, Shenzhen Software Industrial Base, Haitian 2nd Rd, Nanshan District, Shenzhen, Guangdong, P.R.China 518057.
