2AUI9-GESMRTUCLUnder-cabinet luminaires

Confirm 0821INAC1304REV1 Conecte con la aplicación Alexa: 1.Presione suavemente el ícono de menú ubicado en la parte superior izquierda de la pantalla y seleccione “Skills & Games” (Habilidades y juegos) 2.Presione suavemente el cuadro de búsqueda, teclee “Good Earth Lighting”, seleccione Good Earth Lighting y haga clic en “Enable” (Habilitar) 3.Ingrese su nombre de usuario y su contraseña de Good Earth Smart, y luego presione suavemente “Link Now” (Enlazar ahora) Conecte con la aplicación Google Home: 1. Presione suavemente el ícono de signo más (+) ubicado en la parte superior izquierda de la pantalla y seleccione “Set up device” (Configu rar dispositivo). Luego, presione suavemente “Have something already set up” (Ya tiene algo configurado). 2.Presione suavemente el cuadro de búsqueda, teclee “Good Earth Lighting” y seleccione Good Earth Lighting. 3.Ingrese sus credenciales de nombre de usuario y contraseña de Good Earth Smart y luego presione suavemente “Link Now” (Enlazar ahora) Ejemplos de comandos de voz: “Oye Google, enciende mi luz” “Oye Google, atenúa la luz del gabinete al 50 por ciento.” "Oye Google, ajusta la luz del gabinete a blanca fría." Ejemplos de comandos de voz: “Alexa, enciende mi luz” “Alexa, atenúa la luz del gabinete al 50 por ciento.” "Alexa, ajusta la luz del gabinete a blanca fría." 1 DESCARGA DE LA APLICACIÓN/REGISTRO Busque “Good Earth Lighting” en la tienda App Store® o en Google Play y descargue la aplicación. Una vez que se haya descargado exitosamente, abra la aplicación Good Earth, examine y acepte el acuerdo de privacidad y los términos y condiciones presionando suavemente “Agree” (Aceptar). Regístrese ingresando su dirección de correo electrónico. Ingrese el código de verificación suministrado, enviado por correo electrónico, y cree una contraseña para la cuenta. 2 SELECCIÓN DEL TIPO DE LUZ 3 RESTABLEZCA Y SINCRONICE CON UN DISPOSITIVO INTELIGENTE Descarga y emparejamiento de la aplicación Good Earth: Guía de inicio rápido en 3 pasos fáciles Nota: Solo hay compatibilidad con redes Wi-Fi de 2.4 GHz; puede que sea necesario ajustar el router en el modo de señal de 2.4 G. Asegúrese de que el accesorio para iluminación se coloque muy próximo a la señal de la red Wi-Fi. ESPAÑOL Impreso en China ¿Necesita ayuda? Sírvase visitar nuestro sitio web en: https://goodearthlighting.com/contact-us o llame al Centro de Asistencia al Cliente al 1-800-291-8838, 8:30 a.m.-5 p.m., Hora Central Estándar (CST), de lunes a viernes Good Earth Lighting ® 1400 East Business Center Drive, Ste. 108 Mount Prospect, IL 60056 Good Earth Lighting ® son marcas registradas de Good Earth Lighting, Inc.© 2020 Good Earth Lighting, Inc. App Store es una marca de servicio de Apple Inc. Google Play y Google Home son marcas registradas de Google LLC. Amazon, Alexa y todos los logotipos relacionados son marcas comerciales de Amazon.com, Inc. o afiliados. La marca y los logotipos con la palabra Bluetooth ® son marcas registradas que pertenecen a Bluetooth SIG Inc. y cualquier uso de dichas marcas por Good Earth Lighting Inc.® es bajo licencia. La marca de la palabra y los logotipos Bluetooth ® son marcas registradas pertenecientes a Bluetooth SIG, Inc., y todo uso de dichas marcas por Good Earth Lighting Inc ® es bajo licencia. Wi-Fi® es una marca registrada de Wi-Fi Alliance ® Confirm [email protected] Get Verification Code I Agree to User Agreement and Privacy Policy En la pantalla de inicio, seleccione “Add Device” (Añadir dispositivo) o presione suavemente “+” en la esquina superior derecha para añadir un dispositivo. En la sección Wi-Fi Lighting (Iluminación Wi-Fi), añada manualmente el accesorio para iluminación seleccionando la categoría de luz adecuada entre las opciones presentadas. Para sincronizar exitosamente con un dispositivo inteligente (es decir, un teléfono inteligente, una tableta, etc.), el accesorio para iluminación debe primero estar parpadeando rápidamente en el modo de emparejamiento/reajuste. Presione y mantenga presionado el botón de emparejamiento ubicado en el accesorio para iluminación durante 6 segundos para ingresar al modo de emparejamiento. (Nota: Si tiene múltiples accesorios para iluminación enlazados, puede presionar y mantener presionado el botón de emparejamiento durante 6 segundos para ingresar al modo de emparejamiento para cada accesorio para iluminación). Haga clic en “Confirm” (Confirmar) para añadir un accesorio para iluminación o todos ellos. Seleccione la red Wi-Fi a la que le gustaría que su dispositivo inteligente se conecte e ingrese la contraseña para comenzar a sincronizar el dispositivo (NOTA: Su dispositivo inteligente debe estar conectado a la misma red solo para el proceso de emparejamiento). Una vez que se haya emparejado exitosamente, el accesorio para iluminación dejará de parpadear y la página de control del dispositivo aparecerá en el dispositivo inteligente. Seleccione el dispositivo sincronizado recientemente en la pantalla de inicio para controlar todas las funciones de luz a través de la app inteligente. Confirm Exemples de commandes vocales: « Écoute Google, allume ma lumière » « Écoute, Google, baisse l’intensité de l’éclairage sous le meuble à 50 pour cent. » « Écoute, Google, règle la lumière sous le meuble sur blanc froid. » Connexion avec l’appli Alexa : 1.Tapez sur l’icône Menu, qui est située dans le coin supérieur gauche de l'écran, et sélectionnez « Skills & Games » (Compétences et jeux). 2.Tapez sur le champ de recherche et saisissez « Good Earth Lighting », puis sélectionnez Good Earth Lighting et cliquez sur « Enable » (Activer). 3.Saisissez votre nom d’utilisateur pour Good Earth Smart et votre mot de passe, puis cliquez sur « Link Now » (Se connecter maintenant). Connexion avec l’appli Google Home: 1.Tapez sur l’icône Plus (+), qui est située dans le coin supérieur gauche de l'écran, et sélectionnez « Set up device » (Configurer le dispositif). Puis tapez sur « Have something already set up » (Avoir quelque ch…

Text truncated - open the document above for the full version.

Good Earth Lighting Inc. Add: 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Date: 2021-7-19 FCC ID: 2AUI9-GESMRTUCL Dear Sir/Madam, We, Good Earth Lighting Inc. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only output power is different for these model: Product name: Under-cabinet luminaires Model List: Sincerely, Name/Title： Chris Serak/VP Global openations Company: Good Earth Lighting Inc. Address: 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Phone: 8478081133 Extension: 223 Fax: 8478080838 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021-7-19> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AUI9-GESMRTUCL GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Chris Serak/VP Global openations Company: Good Earth Lighting Inc. Address: 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Phone: 8478081133 Extension: 223 Fax: 8478080838 E-Mail: [email protected]

Good Earth Lighting Inc. 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Date: 2021-7-19 FCC ID: 2AUI9-GESMRTUCL Model Number: GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Good Earth Lighting Inc., declare that this EUT (FCC ID: 2AUI9-GESMRTUCL ) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Chris Serak/VP Global openations Company: Good Earth Lighting Inc. Address: 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Phone: 8478081133 Extension: 223 Fax: 8478080838 E-Mail: [email protected]

Good Earth Lighting Inc. 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-7-19 To whom it may concern: We, Good Earth Lighting Inc. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AUI9-GESMRTUCL including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Chris Serak/VP Global openations Company: Good Earth Lighting Inc. Address: 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Phone: 8478081133 Extension: 223 Fax: 8478080838 E-Mail: [email protected]

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 4 External Photos of the EUT Fig.1 Fig.2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 4 Fig.3 Fig.4 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 4 Fig.5 Fig.6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 4 Fig.7

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 1 LABEL AND LOCATION (Size: L7.0m x 3.0cm) Material: Tagboard Glue: adhesive sticker Font color: Blue Label color: White Label Location Under-cabinet luminaires Model No.: GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 FCC ID: 2AUI9-GESMRTUCL Input: AC 120V, 60Hz, 180mA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 6 Internal Photos of the EUT Fig.1 Fig.2 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 6 Fig.3 Fig.4 BT /WIFI Antenna Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 6 Fig.5 Fig.6 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 6 Fig.7 Fig.8 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 6 Fig.9 Fig.10 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 6 of 6 Fig.11 Fig.12

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 1 of 27 Appendix A RF Test Data for BT V5.0(Conducted Measurement) Product Name: Under-cabinet luminaires Trade Mark: Test Model: GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 Environmental Conditions Temperature: 24.6 C Relative Humidity: 54.1% ATM Pressure: 100.0 kPa Test Engineer: Jay Li Supervised by: Li Huan A.1 Duty Cycle BT LE Test Mode Test Channel Ant Duty Cycle[%] Verdict BT LE 2440 Ant1 100 PASS #im grbble1hchnnav Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 2 of 27 BT 2LE Test Mode Test Channel Ant Duty Cycle[%] Verdict BT LE 2440 Ant1 100 PASS #im grbble1hchnnav Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 3 of 27 A.2 Maximum Conducted Peak Output Power BT LE Mode Channel Conduct Peak Power[dBm] Limit [dBm] Verdict BT LE LCH -0.689 30 PASS BT LE MCH -1.494 30 PASS BT LE HCH -1.74 30 PASS Test Graphs LCH MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 4 of 27 HCH BT 2LE Mode Channel Conduct Peak Power[dBm] Limit [dBm] Verdict BT LE LCH -0.985 30 PASS BT LE MCH -1.835 30 PASS BT LE HCH -2.021 30 PASS Test Graphs LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 5 of 27 MCH HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 6 of 27 A.3 Maximum Power Spectral Density BT LE Mode Channel PSD [dBm/3KHz] Limit [dBm/3KHz] Verdict BT LE LCH -16.769 8 PASS BT LE MCH -17.190 8 PASS BT LE HCH -17.878 8 PASS Test Graphs LCH MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 7 of 27 HCH BT 2LE Mode Channel PSD [dBm/3KHz] Limit [dBm/3KHz] Verdict BT LE LCH -19.733 8 PASS BT LE MCH -20.727 8 PASS BT LE HCH -20.657 8 PASS Test Graphs LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 8 of 27 MCH HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 9 of 27 A.4 6dB Bandwidth BT LE Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict BT LE LCH 0.7071 ≥0.5 PASS BT LE MCH 0.7033 ≥0.5 PASS BT LE HCH 0.6981 ≥0.5 PASS Test Graphs LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 10 of 27 MCH HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 11 of 27 BT 2LE Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict BT LE LCH 1.164 ≥0.5 PASS BT LE MCH 1.234 ≥0.5 PASS BT LE HCH 1.258 ≥0.5 PASS Test Graphs LCH MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 12 of 27 HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 13 of 27 A.5 RF Conducted Spurious Emissions BT LE Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdict BT LE LCH -1.802 -38.129 -21.802 PASS BT LE MCH -2.633 -37.333 -22.633 PASS BT LE HCH -2.81 -37.403 -22.810 PASS BT LE_LCH_Graphs Pref/BT LE/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 14 of 27 Puw/BT LE/LCH BT LE_MCH_Graphs Pref/BT LE/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 15 of 27 Puw/BT LE/MCH BT LE_HCH_Graphs Pref/BT LE/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 16 of 27 Puw/BT LE/HCH BT 2LE Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdict BT LE LCH -2.442 -37.721 -22.442 PASS BT LE MCH -3.25 -37.229 -23.250 PASS BT LE HCH -3.434 -37.809 -23.434 PASS BT LE_LCH_Graphs Pref/BT LE/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 17 of 27 Puw/BT LE/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 18 of 27 BT LE_MCH_Graphs Pref/BT LE/MCH Puw/BT LE/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 19 of 27 BT LE_HCH_Graphs Pref/BT LE/HCH Puw/BT LE/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 20 of 27 A.6 Band-edge for RF Conducted Emissions BT LE Mode Channel Carrier Power[dBm] Max.Spurious Level [dBm] Limit [dBm] Verdict BT LE LCH -1.484 -48.693 -21.48 PASS BT LE HCH -2.547 -48.980 -22.55 PASS Test Graphs LCH HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 21 of 27 BT 2LE Mode Channel Carrier Power[dBm] Max.Spurious Level [dBm] Limit [dBm] Verdict BT LE LCH -3.272 -48.345 -23.27 PASS BT LE HCH -2.862 -48.757 -22.86 PASS Test Graphs LCH HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 22 of 27 A.7 Restrict-band band-edge measurements BT LE Test Mode Test Chann el Ant Freq. Power [dBm] Gain Ground Factor E [dBuV/m] Detector Limit [dBuV/ m] Verdi ct BT LE 2402 Ant1 2310.0 -41.81 2.0 0 55.45 PEAK 74 PASS Ant1 2310.0 -52.49 2.0 0 44.77 AV 54 PASS Ant1 2390.0 -42.90 2.0 0 54.36 PEAK 74 PASS Ant1 2390.0 -52.25 2.0 0 45.01 AV 54 PASS 2480 Ant1 2483.5 -42.65 2.0 0 54.61 PEAK 74 PASS Ant1 2483.5 -51.76 2.0 0 45.50 AV 54 PASS Ant1 2500.0 -41.55 2.0 0 55.71 PEAK 74 PASS Ant1 2500.0 -51.57 2.0 0 45.69 AV 54 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 23 of 27 Restrict-band band-edge measurements_BT LE_2402_Ant1_PEAK Restrict-band band-edge measurements_BT LE_2402_Ant1_AV Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA Page 24 of 27 Re…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 1 of 46 Appendix B RF Test Data for 2.4G WIFI (Conducted Measurement) Product Name: Under-cabinet luminaires Trade Mark: Test Model: GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 Environmental Conditions Temperature: 24.6 C Relative Humidity: 54.1% ATM Pressure: 100.0 kPa Test Engineer: Jay Li Supervised by: Li Huan B.1 Duty Cycle Test Mode Test Channel Ant Duty Cycle[%] Verdict 11B 2437 Ant1 100 PASS 11G 2437 Ant1 100 PASS 11N20SISO 2437 Ant1 100 PASS 11N40SISO 2437 Ant1 100 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 2 of 46 Duty Cycle_11B_2437_Ant1 Duty Cycle_11G_2437_Ant1 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 3 of 46 Duty Cycle_11N20SISO_2437_Ant1 Duty Cycle_11N40SISO_2437_Ant1 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 4 of 46 B.2 Maximum Conducted Output Power Mode Channel Meas.Level [dBm] Limit [dBm] Verdict 11B LCH 16.05 30 PASS MCH 16.04 30 PASS HCH 15.46 30 PASS 11G LCH 17.24 30 PASS MCH 19.24 30 PASS HCH 18.82 30 PASS 11N20SISO LCH 17.22 30 PASS MCH 19.38 30 PASS HCH 18.72 30 PASS 11N40SISO LCH 19.28 30 PASS MCH 19.28 30 PASS HCH 19.11 30 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 5 of 46 B.3 Maximum Power Spectral Density Mode Channel Meas.Level [dBm/3KHz] Limit [dBm/3KHz] Verdict 11B LCH -10.365 8 PASS MCH -10.330 8 PASS HCH -9.678 8 PASS 11G LCH -16.000 8 PASS MCH -12.823 8 PASS HCH -13.030 8 PASS 11N20SISO LCH -15.566 8 PASS MCH -14.237 8 PASS HCH -14.251 8 PASS 11N40SISO LCH -17.447 8 PASS MCH -16.739 8 PASS HCH -14.828 8 PASS Test Graphs 11B/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 6 of 46 11B/MCH 11B/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 7 of 46 11G/LCH 11G/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 8 of 46 11G/HCH 11N20SISO/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 9 of 46 11N20SISO/MCH 11N20SISO/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 10 of 46 11N40SISO/LCH 11N40SISO/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 11 of 46 11N40SISO/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 12 of 46 B.4 6dB Bandwidth Mode Channel 6dB Bandwidth [MHz] Limit [MHz] Verdict 11B LCH 9.114 ≥0.5 PASS MCH 9.591 ≥0.5 PASS HCH 9.123 ≥0.5 PASS 11G LCH 15.47 ≥0.5 PASS MCH 14.27 ≥0.5 PASS HCH 15.77 ≥0.5 PASS 11N20SISO LCH 16.25 ≥0.5 PASS MCH 16.07 ≥0.5 PASS HCH 16.35 ≥0.5 PASS 11N40SISO LCH 35.73 ≥0.5 PASS MCH 35.18 ≥0.5 PASS HCH 35.12 ≥0.5 PASS Test Graphs 11B/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 13 of 46 11B/MCH 11B/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 14 of 46 11G/LCH 11G/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 15 of 46 11G/HCH 11N20SISO/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 16 of 46 11N20SISO/MCH 11N20SISO/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 17 of 46 11N40SISO/LCH 11N40SISO/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 18 of 46 11N40SISO/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 19 of 46 B.5 RF Conducted Spurious Emissions Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdic t 11B LCH 4.27 -38.046 -15.730 PASS MCH 4.276 -38.493 -15.724 PASS HCH 4.268 -37.598 -15.732 PASS 11G LCH -1.072 -38.244 -21.072 PASS MCH 0.857 -37.685 -19.143 PASS HCH 0.632 -37.188 -19.368 PASS 11N20 SISO LCH -0.584 -37.168 -20.584 PASS MCH 1.506 -37.175 -18.494 PASS HCH 0.65 -38.392 -19.350 PASS 11N40 SISO LCH -2.283 -37.701 -22.283 PASS MCH -1.915 -37.351 -21.915 PASS HCH -1.5 -37.145 -21.500 PASS Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 20 of 46 11B_LCH_Graphs Pref/11B/LCH Puw/11B/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 21 of 46 11B_MCH_Graphs Pref/11B/MCH Puw/11B/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 22 of 46 11B_HCH_Graphs Pref/11B/HCH Puw/11B/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 23 of 46 11G_LCH_Graphs Pref/11G/LCH Puw/11G/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 24 of 46 11G_MCH_Graphs Pref/11G/MCH Puw/11G/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 25 of 46 11G_HCH_Graphs Pref/11G/HCH Puw/11G/HCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 26 of 46 11N20SISO_LCH_Graphs Pref/11N20SIS O/LCH Puw/11N20 SISO/LCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 27 of 46 11N20SISO_MCH_Graphs Pref/11N20 SISO/MCH Puw/11N20 SISO/MCH Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEB Page 28 of 46 11N20SISO_HCH_Graphs Pref/11N20 SISO/HCH Puw/11N20 SISO/HCH Shenzhen L…

Text truncated - open the document above for the full version.

Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 35 FCC TEST REPORT For Good Earth Lighting Inc. Under-cabinet luminaires Test Model: GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 Additional Model No.: Please Refer to Page 6 Prepared for : Good Earth Lighting Inc. Address : 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : June 22, 2021 Number of tested samples : 2 Sample No. ： 210527032A-1, 210527032A-2 Serial number : Prototype Date of Test : June 22, 2021 ~ June 30, 2021 Date of Report : July 02, 2021 Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 35 FCC TEST REPORT FCC CFR 47 PART 15 C (15.247) Report Reference No. ................. : LCS210527032AEA Date of Issue ................................... : July 02, 2021 Testing Laboratory Name ............. : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ........................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ........... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .......................... : Good Earth Lighting Inc. Address ........................................... : 1400 East Business Center Drive, Suite 108, MOUNT PROSPECT, Illinois, United States Test Specification Standard .......................................... : FCC CFR 47 PART 15 C (15.247) Test Report Form No. ................... : LCSEMC-1.0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. ........................... : Under-cabinet luminaires Trade Mark .......................................................................................................................................... : Model/ Type reference ........................................................................................................................ : GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 Ratings ................................................................................................................................................ : Input: AC 120V, 60Hz, 180mA Result ............................................ : Positive Compiled by: Supervised by: Approved by: Cherry Chen / Administrators Jin Wang/ Technique principal Gavin Liang/ Manager Shenzhen LCS Compliance Testing Laboratory Ltd. FCC ID: 2AUI9-GESMRTUCL Report No.: LCS210527032AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 35 FCC -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS210527032AEA July 02, 2021 Date of issue Test Model.............................. : GE-SMRT-UCL-30-20W-2765-WH-WFBT-01 EUT......................................... : Under-cabinet luminaires Applicant............................... : Go…

Text truncated - open the document above for the full version.
