2AUPG-Q-668Emergency Two Way Radios

9 1 Q-668 2 Function Setting 1. Power on/off--Press and hold power button around 3 seconds to turn on/off. 2. Channel Setting--Press MENU button once to enter channel setting(backlight light up, channel code flashing). Press +/- button to select channel and press PTT button to confirm and exit. USA frequency FRS CH01-CH22 Remark: GMRS :CH 1--CH7;CH15--CH22. FRS:CH8--CH14 1 2 3 4 5 6 7 8 9 10 11 462.5625 462.5875 462.6125 462.6375 462.6625 462.6875 462.7125 467.5625 467.5875 467.6125 467.6375 12 13 14 15 16 17 18 19 20 21 22 467.6625 467.6875 467.7125 462.5500 462.5750 467.6000 467.6250 462.6500 462.6750 462.7000 462.7250 Ch. Freq(MHz) Ch. Freq(MHz) 3 3. Code setting--Press MENU button twice to enter encryption code setting. OF means no code, your walkie talkie could hear or be heard by strangers on the same channel. 01 code is 67Hz, 39-99 is DCS code, CTCSS 01-38 code. Other walkie talkies could talk with you with the same channel and code. Freq. ChCh Freq. ChCh Freq.Freq. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 67.0 71.9 74.4 77.0 79.7 82.5 85.4 88.5 91.5 94.8 97.4 100.0 103.5 107.2 110.9 114.8 118.8 123.0 127.3 131.8 136.5 141.3 146.2 151.4 156.7 162.2 167.9 173.8 179.9 186.2 192.8 203.5 210.7 218.1 225.7 233.6 241.8 250.3 4 DCS CODE 39 40 41 42 43 44 45 46 47 48 023 025 026 031 032 043 047 051 054 065 49 50 51 52 53 54 55 56 57 58 071 072 073 074 114 115 116 125 131 132 59 60 61 62 63 64 65 66 67 68 134 143 152 155 156 162 165 172 174 205 69 70 71 72 73 74 75 76 77 78 223 226 243 244 245 251 261 263 265 271 79 80 81 82 83 84 85 86 87 88 306 311 315 331 343 346 351 364 365 371 89 90 91 92 93 94 95 96 97 98 411 412 413 423 431 432 445 464 465 466 99503 5 4. VOX Function--Press MENU button 3 times to enter the voice-activated function selection. OF means no VOX, you need to press PTT while speaking. 01,02,03 means sound sensitive option, from weak to strong. You don't need to press PTT while speaking. 5. Call Tone--Press MENU button 4 times to enter call tone selection. There are 10 tones. Press +/- to select what you like. 6. Button Sound--Press MENU button 5 times to enter button tone setting. There are ON/OF options. ON means there is a tone when press a button. OF means it is silence when press a button. 7. Send-Message Alert Tone--Press MENU button 6 times to enter alert tone setting. There are ON/OF options. ON means there is a tone when you send message to other devices. OF means it is silence when sending a message. 8. Exit Menu--Press MENU button 7 times to exit setting. FM function Under standby mode, Press WX/FM button twice to enter FM mode. Press MENU button to search radio station automatically, it will stop when it gained. Also, you can press CALL or SCAN button to increase or decrease the frequency. Press +/- to adjust its volume. 6 Charging 1. When the battery is low, please charge it with 5V/1A adapter inserted input charging port. Usually, it will be fully charged about 4 hours. Flashing blue light means charging; stable blue light means fully charged. 2. As a power bank to charge other devices--insert its output port with USB cable to connect the other device, a red light flashing means charging. The red light will be turn off when the other device is fully charged. Hand-Crank Generator If it is out of power, hand generator can be temporarily activated to generate power. Theoretically, shaking the handle 3 minutes could power around 6 minutes lighting or listening to 5 minutes radio with low volume. Weather Function In the walkie-talkie state, press the button FM/WX once to enter the weather mode. The horn sound is white noise "rustling" now. Each channel will have corresponding sound. Under air forecast, it can't receive walkie-talkie frequency. Weather forecast frequency table Switching frequency: Press the CALL/ SCAN keys to set the frequency (CH1--CH10) 7 Weather forecast 1050Hz mode In WX mode, an icon appears, press the MENU button to set OFF/ON. When set to ON, the weather forecast mode is silent, no rustling noise. Then, it can receive both the walkie-talkie signal and the predetermined weather channel at the same time. SOS 1. Alertor Press and hold CALL button 3 seconds, the machine will beep "Woo...woo", which is conducive for outdoor search and rescue. 2. Flashlight Press the flashlight button once to have a strong light, press it twice to have weak light. press it three times to exit. 3. Strobe light Press and hold flashlight button 3 seconds, the flashlight will be strobe. In case of being attacked in the wild, this function can make the others’ eyes blindness for a short time--time for you to escape. CH CH2 CH3 CH4 CH5 163.275MHz 162.550MHz 162.400MHz 162.475MHz 162.425MHz CH CH7 CH8 CH9 CH10 162.450MHz 162.500MHz 162.525MHz 161.650MHz 161.775MHz 1 6 8 Button function description Press once to enter menu setting. Press and hold 3 seconds to lock/unlock the keyboard. MENU Name Description Short press CALL the walkie talkie will have a call tone, and other walkie talkies will receive a call. Under Weather/FM mode, press it to increase channels. SCAN Press it once to enter scan function. Under Weather/FM mode, press it to decrease channels. 1. Under standby mode, press it to decrease the volume. 2. under Menu function mode, press it to select. On the top of the head, press and hold around 3 second to turn on/turn off. Press and hold this button to talk 1.Under standby mode, press it to increase the volume. 2.Under Menu function mode, press it to select. On/Off Flashlight Volume Plus & Minus PTT Solar Panel Flashlight switch Channel Plus & Minus Charging port Headphone port Menu WX/FM Multi-function Walkie Talkies Call Strong light: Press the flashlight button once Weak light: press it twice Strobe light: Press and hold it 3 seconds. Turn off: press it three times Plug headphone(2.5mm, excluded) into the socket to enjoy headphone time. Press it once, Weather forecast mode Press it twice, FM mod…

Text truncated - open the document above for the full version.

Report No.: CHTEW22070012 Page: 27 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 7. EXTERANAL AND INTERNAL PHOTOS 7.1. EXTERANAL PHOTOS Report No.: CHTEW22070012 Page: 28 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01)

Report No.: CHTEW22070012 Page: 29 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 7.2. INTERNAL PHOTOS Report No.: CHTEW22070012 Page: 30 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) Report No.: CHTEW22070012 Page: 31 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 8. APPENDIX REPORT

Page: 1 of 25 TEST REPORT Report No. ...................................... : CHTEW22070003 Report vertification: Project No. ...................................... : SHT2206065002EW FCC ID ............................................. : 2AUPG-Q-668 Applicant’s name ........................... : Shenzhen Crony Electronic Technology Co., Ltd. Address ............................................. : 2201, Huichao Technology Building, Jinhai Road, Yantian Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong Test item description .................... : Emergency Two Way Radios Trade Mark ....................................... : QNIGLO Model/Type reference ....................... : Q-668 Listed Model(s) ................................. : Q-668 Plus Standard ......................................... : FCC 47 CFR Part2.1093 IEEE Std C95.1, 1999 Edition IEEE 1528: 2013 Date of receipt of test sample.........: Jun.27, 2022 Date of testing.............................: Jun.28, 2022- Jul.01, 2022 Date of issue...............................: Jul.04, 2022 Result .................. ........................: PASS Compiled by ( position+printed name+signature) .. : File administrators: Fanghui Zhu Supervised by ( position+printed name+signature) .. : Test Engineer: Weiyang Xiang Approved by ( position+printed name+signature) .. : Manager: Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW22070003 Page: 2 of 25 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2021-12) Contents 1. Statement of Compliance 3 2. Test Standards and Report version 4 2.1. Test Standards 4 2.2. Report version 4 3. Summary 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Test frequency list 6 3.5. Testing Laboratory Information 7 3.6. Environmental conditions 7 4. Equipments Used during the Test 8 5. Measurement Uncertainty 9 6. SAR Measurements System Configuration 10 6.1. SAR Measurement Set-up 10 6.2. DASY5 E-field Probe System 11 6.3. Phantoms 12 6.4. Device Holder 12 7. SAR Test Procedure 13 7.1. Scanning Procedure 13 7.2. Data Storage and Evaluation 15 8. Position of the wireless device in relation to the phantom 17 8.1. Front-of-face 17 8.2. Body Position 17 9. Dielectric Property Measurements & System Check 18 9.1. Tissue Dielectric Parameters 18 9.2. SAR System Validation 19 9.3. System Check 20 10. SAR Exposure Limits 23 11. Radiated Power Measurement Results and Tune-up 24 12. SAR Measurement Results 24 13. Test Setup Photos 25 14. External and Internal Photos of the EUT 25 Report No.: CHTEW22070003 Page: 3 of 25 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2021-12) 1. Statement of Compliance Maximum Reported SAR (W/kg @1g) RF Exposure Conditions FRS Head(Dist.= 25mm) 0.071 Body-worn(Dist.= 0mm) 0.097 Note: 1. This device is in compliance with Specific Absorption Rate (SAR) for general population/uncontrolled exposure limits (1.6 W/kg@1g) specified in FCC 47 CFR part 2 (2.1093) and IEEE Std C95.1, 2. This device had been tested in accordance with the measurement methods and procedures specified in IEEE 1528 and FCC KDB publications. Report No.: CHTEW22070003 Page: 4 of 25 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2021-12) 2. Test Standards and Report version 2.1. Test Standards The tests were performed according to following standards: FCC 47 Part 2.1093: Radiofrequency Radiation Exposure Evaluation:Portable Devices IEEE Std C95.1, 1999 Edition: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. FCC published RF exposure KDB procedures: KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04: SAR Measurement Requirements for 100 MHz to 6 GHz KDB 865664 D02 RF Exposure Reporting v01r02: RF Exposure Compliance Reporting and Documentation Considerations KDB 447498 D04 Interim General RF Exposure Guidance v01: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies TCB workshop: April, 2019; Page 19, Tissue Simulating Liquids (TSL) 2.2. Report version Revision No. Date of issue Description N/A 2022-07-04 Original Report No.: CHTEW22070003 Page: 5 of 25 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2021-12) 3. Summary 3.1. Client Information Applicant: Shenzhen Crony Electronic Technology Co., Ltd. Address: 2201, Huichao Technology Building, Jinhai Road, Yantian Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong Manufacturer: Shenzhen Crony Electronic Technology Co., Ltd. Address: 2201, Huichao Technology Building, Jinhai Road, Yantian Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong 3.2. Product Description Main unit Name of EUT: Emergency Two Way Radios Trade Mark: QNIGLO Model No.: Q-668 Listed Model(s): Q-668 Plus Power supply: DC…

Text truncated - open the document above for the full version.

Page: 1 of 31 TEST REPORT Report No. ...................................... : CHTEW22070012 Report Verification: Project No.................................： SHT2206065001EW FCC ID ............................................. : 2AUPG-Q-668 Applicant’s name ........................... : Shenzhen Crony Electronic Technology Co., Ltd. Address ............................................. : 2201, Huichao Technology Building, Jinhai Road, Yantian Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong Test item description .................... : Emergency Two Way Radios Trade Mark ....................................... : QNIGLO Model/Type reference ....................... : Q-668 Listed Model(s) ................................. : Q-668 Plus Standard ......................................... : FCC CFR Title 47 Part 95 Subpart B Date of receipt of test sample..........: Jun.27, 2022 Date of testing.............................: Jun.28, 2022- Jul.01, 2022 Date of issue...............................: Jul.04, 2022 Result .................. ........................: PASS Compiled by ( position+printed name+signature) .. : File administrators: Fanghui Zhu Supervised by (Position+Printed name+Signature): Project Engineer Caspar Chen Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW22070012 Page: 2 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Test mode 7 4.3. Support unit used in test configuration and system 8 4.4. Testing environmental condition 9 4.5. Measurement uncertainty 9 4.6. Equipment Used during the Test 10 5. TEST CONDITIONS AND RESULTS 12 5.1. Transmit Power(ERP) 12 5.2. Occupied Bandwidth 13 5.3. Emission Mask 14 5.4. Modulation Limit 15 5.5. Audio Frequency Response 16 5.6. Audio Low Pass Filter Response 18 5.7. Frequency stability VS Temperature 19 5.8. Frequency stability VS Voltage 20 5.9. Transmit Radiated Spurious Emission 21 6. TEST SETUP PHOTOS 25 7. EXTERANAL AND INTERNAL PHOTOS 27 7.1. EXTERANAL PHOTOS 27 7.2. INTERNAL PHOTOS 29 8. APPENDIX REPORT 31 Report No.: CHTEW22070012 Page: 3 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC Rules Part 95: PERSONAL RADIO SERVICES ‒ FCC Rules Part 2: Frequency allocations and radio treaty matters; General rules and regulations ‒ ANSI C63.26-2013: American National Standard for Compliance Testing of Transmitters Used in Licensed Radio Services ‒ ANSI C63.4-2014: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz 1.2. Report version Revision No. Date of issue Description N/A 2022-07-04 Original Report No.: CHTEW22070012 Page: 4 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result 5.1 Transmit Power(ERP) Part 95.567 Part 2.1046(a) PASS 5.2 Occupied Bandwidth Part 95.573 Part 2.1049 PASS 5.3 Emission Mask Part 95.579(a)(1)(2)(3) Part 2.1049 PASS 5.4 Modulation Limit Part 95.575 Part 2.1047(b) PASS 5.5 Audio Frequency Response Part 95.575 Part 2.1047(a) PASS 5.6 Audio Low Pass Filter Response Part 95.575 Part 2.1047(a) PASS 5.7 Frequency Stability V.S. Temperature Part 95.565 Part 2.1055 PASS 5.8 Frequency Stability V.S. Voltage Part 95.565 Part 2.1055 PASS 5.9 Transmit Radiated Spurious Emission Part 95.579(a)(3) Part 2.1053 PASS Note: ‒ The measurement uncertainty is not included in the test result. Report No.: CHTEW22070012 Page: 5 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 3. SUMMARY 3.1. Client Information Applicant: Shenzhen Crony Electronic Technology Co., Ltd. Address: 2201, Huichao Technology Building, Jinhai Road, Yantian Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong Manufacturer: Shenzhen Crony Electronic Technology Co., Ltd. Address: 2201, Huichao Technology Building, Jinhai Road, Yantian Community, Xixiang Street, Bao'an District, Shenzhen, Guangdong 3.2. Product Description Main unit Name of EUT: Emergency Two Way Radios Trade Mark: QNIGLO Model No.: Q-668 Listed Model(s): Q-668 Plus Power supply: DC 3.7V from Rechargeable Li-ion battery Hardware version: 01V03 Software version: 01V01 3.3. Radio Specification Description Support Frequency Range: CH01~CH07: 462.5625MHz~ 462.7125MHz CH08~CH14: 467.5625MHz~ 467.7125MHz CH15~CH22: 462.5500MHz~ 462.7250MHz Modulation Type: FM Emission Designator: * 1 11K0F3E Antenna Type: built-in Antenna Gain: 1dBi Note: (1) …

Text truncated - open the document above for the full version.

Report No.: CHTEW22070012 Page: 25 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01) 6. TEST SETUP PHOTOS Report No.: CHTEW22070012 Page: 26 of 31 Issued: 2022-07-04 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V03 (2021-01)
