Quantum Tool Recognition User manual Quantum - Tool recognition Content Content Introduction 4 General 4 Support 5 Approved areas of use 5 Environment 6 Technical Description 7 System overview 7 Main parts 8 Technical data TRM 9 Technical data HUB 10 Funktion 11 Start using Quantum ToolRec 12 Start the Quantum hub 12 Quantum App 13 Service 20 Maintenance 21 Maintenance schedule 21 Maintenance instructions 21 Recommended spare parts 24 Recycling 24 Quantum - Tool Recognition Introduction Doc-0001374, Rev B Sida 4 Introduction Quantum Tool Recognition is a system for wireless toolrecognition on excavators. This is the only usage intended for this product. All other usages of this machine, without written permission from SVAB, are strictly prohibited. This document gives instructions how to do installation work on a Quantum Tool Recognition system. SVAB reserves the right to change the contents of this instruction at any time without further notice. SVAB develops and produces their products in accordance to european legislation and teh macinery directive 2006/42/EG. The CE marking shows that the system fulfills the directive of electromagnetic compatibility EMC, RoHS and radiodirective RED. This installation instruction shall be used in the technical file which will be the base for the final CE marking of the machine. Therefore, the checklist in this instruction shall be thouroughly performed, completely filled out and signed by responsible fitter. Save this instruction in the technical file. The installation of the system referred to in this document is to be performed by experienced personnel. If there’s unclarities regarding the use, installation, understanding of the system or regarding this document - disengage the installation work and contact the system provider for information. By using common sense you can avoid accidents from happening yourself. This instruction is protected by copyright and may not be reproduced, distributed or altered. Violation of the law may lead to prosecutions and fines, imprisonment or duty to pay compensation to the creator / proprietor. FCC and ISED Changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from any persons and must not be co-located or operating in conjunction with any other antenna or transmitter. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed General Quantum - Tool Recognition Introduction Doc-0001374, Rev B Sida 5 RSS standard This equipment is exempt from the routine RF exposure evaluation requirement of RSS-102. This equipment should be installed and operated with a minimum distance of 20 cm between the antenna and the user or bystanders. This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Ce matériel n’est pas sujet à l’évaluation habituelle d’exposition RF selon RSS102. Ce matériel devrait être installé et exploité en gardant une distance minimale de 20 cm entre l’antenne et l’utilisateur ou lesspectateurs. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. CAN ICES-3 (B)/NMB-3(B) Contact SVAB at: SVAB, Ulvsättersgatan 2SE-694 35 Hallsberg Phone: +46 (0)582 152 30 (main) +46 (0)0582 152 33 (Support) On our website www.svab.se you will find additional information. Support Approved areas of use If you are unsure whether the function is allowed to control, always ask a technician from your system provider. Approved areas of use for Quantum ToolRec: - Tool recognition on excavator - Provide input signal to compatible systems Quantum shall only be used for approved areas of use and functions as mentioned above. SVAB will not take part in injuries or accidents that occurs due to unauthorized use. and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Quantum - Tool Recognition Introduction Do…

Text truncated - open the document above for the full version.

EXTERNAL PHOTOS Project no.: 371810 FCC ID: 2AUTR-963 Page 1 (2) EXTERNAL PHOTOS Project no.: 371810 FCC ID: 2AUTR-963 Page 2 (2)

HUB Model: P-0000963

INTERNAL PHOTOS Project no.: 371810 FCC ID: 2AUTR-963 Page 1 (2) INTERNAL PHOTOS Project no.: 371810 FCC ID: 2AUTR-963 Page 2 (2)

FCC ID: 2AUTR-963 MPE Calculation for FCC Uncontrolled Environment Formula from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Source Based Time Averaged Duty Cycle is 100% in calculation below Maximum peak output power at antenna input terminal:9.60(dBm) Maximum peak output power at antenna input terminal:0.009(W) Maximum antenna gain:3.00(dBi) Maximum antenna gain:1.995(numeric) Prediction distance:20(cm) Prediction frequency:2440(MHz) Time Averaged Duty Cycle100% MPE limit for uncontrolled exposure at prediction frequency:10.00(W/m^2) Power density at prediction frequency:0.0036(mW/cm^2) Power density at prediction frequency:0.036(W/m^2) Maximum allowable antenna gain:27.41(dBi) Margin of Compliance:24.41(dB) 2 4R PG S p =

Report No. 371810-01-R02 Template version: C Nemko Norway Nemko AS, Instituttveien 6, P.O. Box 96 Kjeller, 2027 Kjeller, Norway TEL +47 22 96 03 30 FAX +47 22 96 05 50 EMAIL [email protected] ENTERPRISE NUMBER NO974404532 nemko.com/no Test Report Product Tool Recognition HUB with Bluetooth LE Transceiver Name and address of the applicant SVAB Hydraulik AB Ulvsättersgatan 2 69491 Hallsberg, Sweden Name and address of the manufacturer SVAB Hydraulik AB Ulvsättersgatan 2 69491 Hallsberg, Sweden Model Quantum HUB Rating 12V/24V DC (100mA/55mA, 1.32W) Trademark SVAB Serial number / Additional information Bluetooth Low Energy Tested according to FCC Part 15.247 Frequency Hopping Transmitters / Digital Transmission Systems Industry Canada RSS-247, Issue 2 Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices Order number 371810 Tested in period 2019-07-23 to 2019-07-23 Issue date 2020-12-18 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway CAB Number: FCC: NO0001 ISED: NO0470 An accredited technical test executed under the Norwegian accreditation scheme Prepared by [Frode Sveinsen] Approved by [G.Suhanthakumar] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information contact Nemko. TEST REPORT FCC Part 15.247 Report no.: 371810-01-R02 FCC ID: 2AUTR-963 IC: 25895-963 Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (50) CONTENTS 1 INFORMATION ......................................................................................................................... 3 1.1 Test Item .................................................................................................................................... 3 1.2 Normal test condition ................................................................................................................. 4 1.3 Test Engineer ............................................................................................................................ 4 1.4 Antenna Requirement ................................................................................................................ 4 1.5 Test configuration ...................................................................................................................... 4 1.6 Comments ................................................................................................................................. 4 2 TEST REPORT SUMMARY ...................................................................................................... 5 2.1 General ...................................................................................................................................... 5 2.2 Test Summary ........................................................................................................................... 6 3 TEST RESULTS ........................................................................................................................ 7 3.1 Occupied Bandwidth (99% BW)................................................................................................. 7 3.2 DTS Bandwidth ........................................................................................................................ 10 3.3 Peak Power Output .................................................................................................................. 13 3.4 Power Spectral Density (PSD) ................................................................................................. 17 3.5 Conducted Emissions at Antenna Connector .......................................................................... 20 3.6 Restricted Bands of operation.................................................................................................. 27 3.7 Radiated Emissions, Band Edge ............................................................................................. 28 3.8 Radiated Emissions, 30 – 1000 MHz ....................................................................................... 30 3.9 Radiated Emissions, 1 – 26 GHz ............................................................................................. 32 4 Measurement Uncertainty ..................................................................................................... 48 5 LIST OF TEST EQUIPMENT................................................................................................... 49 6 BLOCK DIAGRAM .................................................................................................................. 50 6.1 Conducted Tests ...................................................................................................................... 50 6.2 Test Site Radiated Emission .................................................................................................... 50 TEST REPORT FCC Part 15.247 Report no.: 371810-01-R02 FCC ID: 2AUTR-963 IC: 25895-963 Nemko Norway, Instituttveien 6, Kjeller, Norway Page 3 (50) 1 INFORMATION 1.1 Test Item Name SVAB FCC ID 2AUTR-963 ISED ID 25895-963 Model/version Quantum HUB Serial number N/A Hardware identity and/or version V.3.55 Software identity and/or version V.3.2.5 Frequency Range 2402–2480 MHz Number of Channels 40 Operating Modes Bluetooth Low Energy Type of Modulation Digital (Gaussian Frequency Shift Keying) Conducted Output Power 9.1 mW (Peak) Antenna Connector None Number of Antennas 1 Antenna Diversity Supported No Power Supply 12/24 V DC , 100 mA / 55 mA, 1.32W Connections 4x M8 connectors, CAN1, CAN2, I/O and DC Power input Highest Clock Frequency 120 MHz Description of Test Item The tested device is a BT Low Energy Hub. Description Brand Model Regulatory Information Bluetooth Controller Texas Instr…
