2AUZVCMS505Card Reader(CMS505)

Thank you for choosing TOP VME . CMS505 Card Reader User Guide Content 1. Product Introduction ...............................................................................................1 1-1. Overview ............................................................................................................................1 1-2. Features ..............................................................................................................................1 2. Product Specifications .............................................................................................2 2-1. General Specifications ..................................................................................................2 2-2. Electronic Specifications ..............................................................................................2 2-3. Machine Specifications ................................................................................................2 3. Product content .........................................................................................................2 4. Product Dimension ...................................................................................................3 5. Installation Instructions ..........................................................................................4 5-1. Board description ...........................................................................................................4 5-2. iron plate description ....................................................................................................5 6. Application ...................................................................................................................6 7. Wiring ............................................................................................................................7 8. Function Description ................................................................................................15 8-1. Setting and Display ........................................................................................................15 8-2. Setting ................................................................................................................................15 8-2-1. GAME ........................................................................................................................16 8-2-2. Signal .........................................................................................................................16 8-2-3. System .......................................................................................................................16 8-3. Function Modes ..............................................................................................................17 9. Troubleshooting ........................................................................................................18 1 CMS505 1. Product Introduction 1-1. Overview The card management system can save labor costs, and reduce auditing stress. All top-ups and cash settlements are completed at the cash register to avoid unnecessary cash handling. This solves the problem of miscalculation and difference between the cash and computer accounts of other branches, and decrease the time cost of checking and reconciling. Easy to install and use, no need for network cable connection between devices. Information is using and transferring by the memory of the CPU. Without the computer management, each host can work independently. After using the system management, the accounts are clearer, the handover is simple, it is easy to check and manage at any time, and improve the work efficiency of the playground. All game cards can be transferred between players, and the venue does not need to be recovered, but can be stored, refunded and deposited. Applicable to all: game machine, machines with the functions of opening points, returning coins, and issuing lottery tickets. 1-2. Features • Card Information High security • Compatible with various game consoles • Multiple devices can be connected in real time ★ Avaliable type for contact card(ISO 7816) & non-contact card(RFID) 2 Card Reader 2. Product Specifications 2-1. General Specifications Communication Interface RS232/PULSE Card type Contact card(ISO 7816)、non-contact card (Mifare1 S70) Installation siteIndoors 2-2. Electronic Specifications Input power+12V DC Power Consumption Standby:1.5~1.6W Working:2.3W Max.:2.5W Temperature Range (° C) Ambient: 0~60 Storage:-10~80 Humidity:20~70%RH(no condensation) 2-3. Machine Specifications Weight229 ±12g Dimension133 x 92 x 75 mm Screen Size1.8 Inch Screen 3. Product content MainCMS 505( non-contact card ) Accessories Manual*1 Wires (Check page...) Screw set CMS100H Adapter board(Optional) Metal Frame Sticker (Purchase) Metal Frame (Purchase) 3 CMS505 4. Product Dimension 133.1 5.24 92.23.63 51 2.008 51 2.008 117.3 4.618 115.9 4.563 84.13.311 84.13.311 75.12.957 36.51.437 4 .157 4 Card Reader 5. Installation Instructions 5-1. Board description 1. Dig holes according to the recommended shape and size. 2. Put the CMS505 into the iron frame according to the direction shown in the figure, and lock the nut. Nuts CMS505 Metal Frame 105.64.157 136 5.354 110 4.331 105.64.157 136.6 5.378 136.6 5.378 6 .236 孔*4 20 .78720 .787 20 .78720 .787 94 3.701 94 3.701 5 CMS505 3. Put the CMS505 into the board according to the direction shown in the figure and lock the nut. 5-2. iron plate description 1. Put the CMS505 into the stud on the iron plate according to the direction shown in the figure, and lock the nut to complete. Nuts CMS505 CMS505 Iron Plate Nuts board 6 Card Reader 6. Application 7 CMS505 7. Wiring ConnectorInterfaceVoltageUseWirePag. J2Power+12V DCPower CableWEL-R7U028 WEL- R7U02 Power+12V DC Power Extension CU-R961-19 CN4 RS232/ UART Data Transfer WEL-R7U06 (Purchase) 10 CN4USB/UARTData Transfer 2WIR-CP2102N-00 (Purchase) 11 J4 PULSE/ HOPPER Data T…
