Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Custos BVS User Manual Ver:0.1.3 Custos BVS - Ball Valve Servo Technology for Humanity User Manual Model: BVSLWU FCC ID: 2AUZXBVSLWU Model: BVSLWU FCC ID: 2AUZXBVSLWU Model: BVSLWU FCC ID: 2AUZXBVSLWU Custos BVS User Manual Ver:0.1.3 Page 2 Thank you for choosing our products. Custos provide whole solution to prevent water damage. product information ü Utility/insurance driven vertical market ü LoRaWAN Class-C compliant ü Act as Actuator & sensor device ü Nationwide deployment capable ü Smart battery box “Optional accessory” ü Outdoor power adapter ü 10-year warranty ü IP66 waterproof rating Custos BVS User Manual Ver:0.1.3 Page 3 What's in the box The Custos BVS snaps over the existing water main valve and will automatically stop the water supply when a leak is detected. The Remote Sensor connects to either the Valve Controller or any Leak Detector to monitor hard to reach areas for leaks. The Power Supply is a standard 12V power supply, and it is required to power up the Valve Controller. Custos BVS User Manual Ver:0.1.3 Page 4 Understanding the Custos BVS Clamp s Fork Tou c h Switch Custos BVS User Manual Ver:0.1.3 Page 5 Custos BVS Set-up instructions Custos BVS User Manual Ver:0.1.3 Page 6 ① Close your valve Valve should open/close easily by hand, without the use of a ny tools. The valve handle should be perpendicular to the pipe, which means the valve is closed. Custos BVS User Manual Ver:0.1.3 Page 7 ② Align the fork with the valve handle Custos BVS User Manual Ver:0.1.3 Page 8 ③ Push down the Custos BVS onto your valve Custos BVS User Manual Ver:0.1.3 Page 9 ④ Tighten clamps while holding the Custos BVS down Custos BVS User Manual Ver:0.1.3 Page 10 ⑤ Check if the Custos BVS is facing the right direction Custos BVS User Manual Ver:0.1.3 Page 11 ⑥ Check if the Fork is aligned with the valve handle correctly Custos BVS User Manual Ver:0.1.3 Page 12 ⑦ Plug the Remote Sensor Probe into the Custos BVS Custos BVS User Manual Ver:0.1.3 Page 13 ⑧ Connect the power supply to the Custos BVS and plug it into an outlet Custos BVS User Manual Ver:0.1.3 Page 14 Contact us if you have any questions Website: http://www.ubitech.hk/ E-mail: [email protected] FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. *RF warning for Mobile device: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
UBITECH LIMITED Agent Authorization Company: UBITECH LIMITED Address: Unit 12, 7/F Block A, Hi-Tech Industrial Centre, 5-21 Pak Tin Par Street, Tsuen Wan, NT, Hong Kong Product Name: Wireless Ball Valve Servo Model Number(s): BVSLWU, BVSULU Product Description: Wireless Ball Valve Servo We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/05/26 Name: C.K.Sze Title: CEO Company: UBITECH LIMITED
UBITECH LIMITED Authorization Letter We, (the approval holder) Company name UBITECH LIMITED Addresss Unit 12, 7/F Block A, Hi-Tech Industrial Centre, 5-21 Pak Tin Par Street, Tsuen Wan, NT, Hong Kong declare that the following representative (agent): Name (person) Bovey Yang Company name Shenzhen STS Test Services Co., Ltd. Addresss 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Micom Labs for product certification below Product Description Wireless Ball Valve Servo Type or Model(s) BVSLWU, BVSULU Tradename or Brand(s) Custos FCC ID 2AUZXBVSLWU Attestation: City: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Hong Kong 2020/05/26 C.K.Sze CEO
Differences Description We UBITECH LIMITED Company state: Product: Wireless Ball Valve Servo Model Name: BVSLWU, BVSULU Trade Name: Custos FCC ID: 2AUZXBVSLWU The electrical circuit design, layout, components used and internal wiring for above models are identical, only different in model name. Signatory Date: 2020-05-26 Signature Name: C.K.Sze Title: CEO Company: UBITECH LIMITED Address: Unit 12, 7/F Block A, Hi-Tech Industrial Centre, 5-21 Pak Tin Par Street, Tsuen Wan, NT, Hong Kong
UBITECH LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/05/26 Subject; Request for Confidentiality FCC ID: 2AUZXBVSLWU To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR UBITECH LIMITED For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: C.K.Sze Title: CEO
Page 1 of 5 Report No.: STS1910031 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: BVSLWU Photo 1 Photo 2 Page 2 of 5 Report No.: STS1910031 Photo 3 Photo 4 Page 3 of 5 Report No.: STS1910031 Photo 5 Photo 6 Page 4 of 5 Report No.: STS1910031 Photo 7 Photo 8 Page 5 of 5 Report No.: STS1910031 Photo 9
Label Size: 25*50mm, used paster. Wireless Ball Valve Servo Model name: BVSLWU FCC ID: 2AUZXBVSLWU This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Size: 25*50mm, used paster. Wireless Ball Valve Servo Model name: BVSULU FCC ID: 2AUZXBVSLWU This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 1 of 4 Report No.: STS1910031 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: BVSLWU Photo 1 Photo 2 Page 2 of 4 Report No.: STS1910031 Photo 3 Photo 4 Page 3 of 4 Report No.: STS1910031 Photo 5 Photo 6 Antenna Page 4 of 4 Report No.: STS1910031 Photo 7
RF Exposure Report FCC-ID: 2AUZXBVSLWU RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) F= Frequency in MHz Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. EUT Operation condition EUT was enabled to transmit and receive at lowest, middle and highest channels. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. 902.3-914.9MHz Mode Lora Detector Maximun Transmitter Power Peak 14±1dBm ANT Gain (G) Antenna gain: -2dBi (gain of antenna in linear scale=0.63) LORA0.63902.3 1531.620.0040 0.602 Power Density (mW/cm²) Limit (mW/cm²) ANT Gain(gain of antenna in linear scale) Protocol Channel Frequenc y (MHz) Output Power to Antenna (dBm) Output Power to Antenna (mW)
Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1910031W01 Issued for UBITECH LIMITED Unit 12, 7F Block A, Hi-Tech Industrial Centre 5-21 Pak Tin Par Street, Tsuen Wan, NT, Hong Kong Product Name: Wireless Ball Valve Servo Brand Name: Custos Model Name: BVSLWU Series Model: BVSULU FCC ID: 2AUZXBVSLWU Test Standard: FCC Part 15.247 S T L A B S Page 2 of 50 Report No.: STS1910031W01 TEST RESULT CERTIFICATION Applicant’s Name ................... : UBITECH LIMITED Address .................................. : Unit 12, 7F Block A, Hi-Tech Industrial Centre 5-21 Pak Tin Par Street, Tsuen Wan, NT, Hong Kong Manufacture's Name .............. : Yong Chao Plastic Technology Co., LTD Address .................................. : No.8, Mingzhu 2 Road, shebei Village, Huangjiang Town, Dongguan City, Guangdong Province, P.R. China Product Description Product Name ........................ : Wireless Ball Valve Servo Brand Name ......................... : Custos Model Name ........................... : BVSLWU Series Model .......................... : BVSULU Test Standards ....................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................... : Date of receipt of test item ......... : 16 Oct. 2019 Date (s) of performance of tests : 16 Oct. 2019 ~ 02 June 2020 Date of Issue ............................. : 02 June 2020 Test Result ................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sunday Hu) Authorized Signatory : (Vita Li) Page 3 of 50 Report No.: STS1910031W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 12 2.6 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 30 4.1 LIMIT 30 4.2 TEST PROCEDURE 30 4.3 TEST SETUP 30 4.4 EUT OPERATION CONDITIONS 30 4.5 TEST RESULTS 31 5. NUMBER OF HOPPING CHANNEL 36 5.1 LIMIT 36 5.2 TEST PROCEDURE 36 5.3 TEST SETUP 36 5.4 EUT OPERATION CONDITIONS 36 5.5 TEST RESULTS 37 6. AVERAGE TIME OF OCCUPANCY 38 6.1 LIMIT 38 6.2 TEST PROCEDURE 38 6.3 TEST SETUP 38 6.4 EUT OPERATION CONDITIONS 38 6.5 TEST RESULTS 39 7. HOPPING CHANNEL SEPARATION MEASUREMEN 41 7.1 LIMIT 41 7.2 TEST PROCEDURE 41 Page 4 of 50 Report No.: STS1910031W01 Table of Contents Page 7.3 TEST SETUP 41 7.4 EUT OPERATION CONDITIONS 41 7.5 TEST RESULTS 42 8. BANDWIDTH TEST 44 8.1 LIMIT 44 8.2 TEST PROCEDURE 44 8.3 TEST SETUP 44 8.4 EUT OPERATION CONDITIONS 44 8.5 TEST RESULTS 45 9. OUTPUT POWER TEST 47 9.1 LIMIT 47 9.2 TEST PROCEDURE 47 9.3 TEST SETUP 47 9.4 EUT OPERATION CONDITIONS 47 9.5 TEST RESULTS 48 10. ANTENNA REQUIREMENT 49 10.1 STANDARD REQUIREMENT 49 10.2 EUT ANTENNA 49 Page 5 of 50 Report No.: STS1910031W01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 02 June 2020 STS1910031W01 ALL Initial Issue Page 6 of 50 Report No.: STS1910031W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(b)(2) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(i) Number of Hopping Frequency PASS -- 15.247(a)(1)(i) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 50 Report No.: STS1910031W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±6.7dB 4 All emissions, radiated 1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±4.43dB 7 Conducted Emission (150KHz-30MHz) ±5dB Page 8 of 50 Report No.: STS1910031W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Wireless Ball Valve Servo Trade Name Custos Model Name BVSLWU Series Model BVSULU Model Difference Only different in model name. Channel List Please ref…
Text truncated - open the document above for the full version.
Page 1 of 2 FCC ID: 2AUZXBVSLWU DSS Setup photo Model name: BVSLWU DSS conduction DSS radiation L Page 2 of 2 FCC ID: 2AUZXBVSLWU DSS radiation H
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 902.3 MHz - 914.9 MHz | 27.35 mW |

Wireless Water Detector
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Wireless Water Detector
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Z-Wave Intelligent Ball Valve Servo
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
