2AVFNLCE4121MLTE Indoor CPE

WELCOME GETTING STARTED LED INDICATION INTERFACE AND BUTTON HARDWARE CONNECTION LTE Indoor CPE LCE4121M Quick Start Guide TO THE LTE CPE This document will serve as a quick start guide for LTE indoor device. Carefully read the following safety symbols to help you use your CPE safely and correctly. Additional information Optional methods or shortcuts for an action Potential problems or conventions that need to be specified The figures provided in this document are just for reference only, please prevail in kind. Equipment Appearance The figure is just for reference only, please connect the hardware according to your requirements. Package Contents Please check the package contents before installation: SET UP THE HARDWARE > LTE Indoor CPE > Power Adapter > Quick Start Guide > Ethernet Cable Insert SIM Card If you want to remove the SIM card, please lightly press the SIM card, the SIM card will pop out. Make sure the CPE is turned off before you insert or remove your SIM card. Step 1 Connect the supplied power adapter to the CPE. Step 2 Connect other devices. · You can connect your computer or classic Switch via Ethernet cable to LAN port. If you find any missing or damaged, please contact your local vendor. Otherwise, the CPE and SIM card may be damaged. Please insert your SIM card as following: · You can connect your laptop via Wi-Fi. When you are using the CPE, you can adjust the position and direction of CPE to get stronger LTE signal, you can judge from the LTE signal LED indicator. 1 2 3 4 5 Indicator Status Description Steady on 5G Wi-Fi available Off 5G Wi-Fi unavailable Blinking (500ms interval) Data transmission Blinking (1s interval) Setting up WPS connection Steady on 2.4G Wi-Fi available Off 2.4G Wi-Fi unavailable Blinking (500ms interval) Data transmission Blinking (1s interval) Setting up WPS connection Steady on Internet Available Off Internet Unavailable Blinking (500ms interval) Data transmission Steady on Power on Off No power supply Steady on Display the current LTE network signal, the stronger signal, the more bars on Off No Signal All SIGNAL LED Blinking (1s interval） Searching network of LTE Blinking one by one Firmware upgrade Interface & button Description DC IN DC power input port LAN1 LAN2/WAN Connect computer, switches (non-Poe devices) or other LAN devices RESET Press 1s to reboot device. Press 5s and more, CPE will restore to factory mode. You will lose user defined settings once you reset CPE. So, be cautious to click Reset Button. SIM USIM Slot WPS Quick set up for Wi-Fi connection or Mesh link 1 POWER Indicator 4 5G WiFi Indicator 7 Reset Button 2 Internet Indicator 5 Signal Indicator 8 WPS 3 2.4G WiFi Indicator 6 LAN1,LAN2/WAN Port 9 Power Port * SETUP CPE LTE SETTING WI-FI SETTING MESH SETUP FCC Compliance Statements Login the Web Management Page Use a browser to log into the web management page to configure and manage the CPE. Step 1 Connect the CPE properly. You can connect to device via Ethernet cable or Wi-Fi . Step 2 Launch Internet Explorer, enters http://192.168.1.1 in the address bar, and presses Enter. Step 3 Enter the user name and password, and login. IP address You can login to the web management page after the password is verified. Step 1 Connect the CPE properly. Step 2 Login to the web management page. Step 3 Choose Network → LTE Setting. Step 4 Set Connect Method. The default configuration are Auto connect and scan full band, if you want to connect the LTE network accord your requirement, you can set the Connect Method as Manual, and just scan some specified band. Step 1 Connect the CPE properly. Step 2 Login the web management page. Step 3 Chose Settings →Wi-Fi →WLAN Setting. Step 4 In the Setting area, modify the SSID, such as “Xlink-router”. Step 5 To ensure your data safety, it is recommended that you change the default Wi-Fi password. Step 6 Click Submit to save the configurations. LCE4121M is controller, and LCE4121S is agent. Step 1 Make sure all the devices is under manufacture status. Step 2 Power on the LCE4121S and LCE4121M. Login to CPE Web via “192.168.1.1”, visit “SETTINGS > Wi-Fi > Mesh” and enable Mesh. Set LCE4121M as controller, LCE4121S as Agent. Reboot them before next step. Step 3 Push WPS button on both Controller & Agent devices, and wi-fi led start blinking. When the mesh is established, the led will turn to stead on. FAQs Can not access to WebUI? • Make sure device work as controller mode. Reset the factory to make sure it work under controller. How to setup mesh network manually? • Press controller’s and agent’s WPS button to setup manually. Dose it can setup mesh with other brand’s router? • No.. The CPE fails to search for the wireless network. • Check that the power adapter is connected properly. • Check that the CPE is placed in an open area that is far away from obstructions, such as concrete or wooden walls. Check that the CPE is placed far away from household electrical appliances that generate strong electromagnetic field, such as microwave ovens, refrigerators, and satellite dishes. This product has reached the standard of shipment inspection. Notice Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase. Leax Arkivator Telecom USA Inc. reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation. I IP address This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Cla…
