2AVIT-TW205True Wireless Earbuds

Earfun Technology (HK) Limited

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Aug 05, 2024
Application Purpose: Original Equipment
Date of Application: Aug 05, 2024
Equipment Note: True Wireless Earbuds
Frequency Range: 2402.00000000 - 2480.00000000
Company: Earfun Technology (HK) Limited
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

EarFun Air Life True Wireless Earbuds 01 10 19 29 39 48 中文（繁體） 57 中文（简体） Polski 01 2. How to Fit 1. EarFun Audio App No Forced Registration. Easy to Use. Multi-Band Equalizer, Multipoint Devices Management. Customizable Touch Controls, Game Mode. Firmware Update, Find Headphones, and More. Download the EarFun Audio app for an enhanced experience. Please update your earbuds firmware to the latest version via the EarFun Audio App for the best user experience. If earbuds can't connect to the app, reinstall or update the app in the app store. Download on the Download on the Note: 1. Please choose the suitable ear tip for the best sound and secure fit. 2. Select the left or right earbud and insert to the corresponding ear. 3. Rotate the earbud back and forth for the ear tip to create a comfortable seal. 1. Choose the best-sized ear tip 3. Rotate2. Insert S XS M L EN 3. Pairing Your Earbuds Remove the insulating film Put back in and close the lid Open to take out both earbuds Activate Bluetooth and connect EarFun Air Life 123 12 4 2. Connect to a New Device Unpair from the old device Search on the new device and connect Option A 1. First-time Pairing with Device 02 EarFun Air Life EarFun Air Life Option B 03 x3 Tap triple (L and R) 12 Search on the new device and connect Power on and put on, triple tap on BOTH earbuds to pair EarFun Air Life x8s Press for 8s (L/R) Power on and put on, press BOTH earbuds for 8s *Until hearing the prompt tone "pairing" 4. Reset and Reconnecting 1 23 Delete the previous Bluetooth record EarFun Air Life OTHER DEVICE EarFun Air Life EarFun Air Life Disconnect Bluetooth EarFun Air Life Reactivate Bluetooth to reconnect 5. Touch Controls Playing music Play/Pause Tap twice (L/R) Next track Tap triple (R) Volume up Tap once (R) Previous track Tap triple (L) Volume down Tap once (L) LR x2 x3 x1 x3 x3 x1 Hands free conversation Answer and transfer two calls Tap triple (L/R) Answer/End a call Tap twice (L/R) Reject a call Tap and hold for 2s (L/R) Tap and hold for 2s (L/R) Voice assistant Activate the voice assistant Game Mode: Please enable in EarFun Audio app 04 6. Battery level 7. Specifications Green70% - 100% White30% - 70% Orange 5% - 30% No LED Indicating <5% Please charge LEDs flashes lowly Charging GreenCharging complete 60mAh x 2(earbuds); 380mAh(charging case) 1.5 hours(for earbuds) 2 hours(for charging case via USB-C) 61.8mm x 25.7mm x 46.9mm 38g 2.402GHz-2.480GHzBluetooth frequency Bluetooth profileA2DP, AVRCP, HFP, HSP V5.4 Bluetooth transmitted power Battery capacity Charging time Playtime(varies by volume level and audio content) Dimensions Weight Bluetooth version <7dBm (for EU) Up to 11 hours, Totally 35 hours with the charging case 05 LED 8. Troubleshooting 06 Q: The earbuds are turning on, but fail to connect to my device? A: To connect your earbuds to your device, please remove the insulating films on both earbudsand check that Bluetooth is enabled. If the earbuds still don’t connect, try resetting them or contact us for assistance. Q: What to do if the earbuds are uncomfortable to wear? A: Select the appropriate size of eartips, then correctly wear the earbuds. Q: What to do if the other person cannot hear clearly during a call? A: Please adjust the position of the earbuds to ensure that the voice microphone is pointing towards the direction of the speaker's voice. Ensure the Bluetooth device uses the earbud's microphone for calls. Q: What to do if the earbuds fail to connect to the app? A: Ensure Bluetooth connection and Location permissions are enabled for the app. These permissions do not involve any privacy information. You can also download the latest version of the app or uninstall and reinstall it if needed. Q: What to do if the audio quality does not meet your expectations? A: We suggest personalizing your audio settings according to your preferences in the EarFun Audio app's EQ settings. Q: Why is the connection not stable and cuts out intermittently? A: Please check for any objects obstructing the earbuds and the Bluetooth device, and avoid any potential radio or WiFi interference. While the earbuds have a maximum range of 49 feet (15m) without obstacles, the actual range may vary depending on usage the environment. Q: Is the charging case waterproof? A: No, the earbuds are sweat and waterproof, but the charging case is not. Customer Service For FAQS and more information: Please send an email to: [email protected] www.myearfun.com Q: What to do if one earbud is silent or has low volume? A: If the earbud's LED is lit, carefully clean the dirt from the speak mesh using a toothpick or cotton swab dipped in alcohol. Try to reset the two earbuds and reconnect. If the issue persists, please contact us for assistance. Other trademarks and trade names are those of their respective owners. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Earfun Technology (HK) Limited is under license. BLUETOOTH FCC Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. RF Exposure Compliance Risk of explosion if the battery is replaced by an incorrect type Disposal of a battery into fire or a hot even, or mechanically crushing or cutting of a battery, that can result in an explosion; Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. CAUTION To prevent possible hearing damage, do not listen at high volume levels for long periods. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found …

Text truncated - open the document above for the full version.

Attestation Statements

Earfun Technology (HK) Limited Covered Equipment Certification Attestation Letter 7/31/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AVIT-TW205 Earfun Technology (HK) Limited (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Signed: Printed name: Rocky Deng Title: Engineer Company Name: Earfun Technology (HK) Limited Date: 7/31/2024

Attestation Statements

Earfun Technology (HK) Limited * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 7/31/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AVIT-TW205 Applicant of FRN: 0029085636 Per section 2.911(d)(7) of the FCC rules, Earfun Technology (HK) Limited (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: EARFUN, INC FCC Registration Number (FRN): 0033640855 Physical U.S. Company Address: 8605 SANTA MONICA BLVD #79525 WEST HOLLYWOOD, CA 90069-4109 Contact Person: ZILI WANG Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Signed: Printed name: Rocky Deng Printed name: ZILI WANG Title: Engineer Title: CEO Company Name: Earfun Technology (HK) Limited Company Name: EARFUN, INC Date: 7/31/2024 Date: 7/31/2024

Attestation Statements

Cover Letter(s)

Earfun Technology (HK) Limited DATE : 2024.07.31 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint EST Technology Co., Ltd. Address: Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Earfun Technology (HK) Limited Address: FLAT/RM A 9F,SILVERCORP INTERNATIONAL TOWER, 707-713 NATHAN ROAD MONGKOK KL, HONG KONG (Applicant Name and address) <Signature> Name: Rocky Deng Title: Engineer Company: Earfun Technology (HK) Limited

Cover Letter(s)

Earfun Technology (HK) Limited DATE : 2024.07.31 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AVIT-TW205 Product Name: True Wireless Earbuds Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Rocky Deng Title: Engineer Company: Earfun Technology (HK) Limited

External Photos

External photos M/N: TW205 External photos M/N: TW205 External photos M/N: TW205 External photos M/N: TW205

Internal Photos

Internal photos M/N: TW205 Internal photos M/N: TW205 Internal photos M/N: TW205 Internal photos M/N: TW205

RF Exposure Info

Page 1 of 3 Report No. ESTE-R2407070 FCC RF EXPOSURE REPORT Earfun Technology (HK) Limited True Wireless Earbuds Model Number: TW205 FCC ID: 2AVIT-TW205 Applicant: Earfun Technology (HK) Limited Address: FLAT/RM A 9F, SILVERCORP INTERNATIONAL TOWER 707-713 NATHAN ROAD MONGK OK KL, HONG KONG Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2407070 Date of Test: Jul. 01, 2024~ Jul. 12, 2024 Date of Report: Jul. 13, 2024 Page 2 of 3 Report No. ESTE-R2407070 1. Applicable Standards FCC Part 2(Section 2.1093) FCC KDB 447498 D04 Interim General RF Exposure Guidance v01 2. Exposure Evaluation of Portable or Mobile Devices Human exposure to RF emissions from portable devices (47 CFR §2.1093), as defined by the FCC, must be evaluated with respect to the FCC-adopted limits for SAR. Evaluation of mobile devices, as defined by the FCC, may also be performed with respect to SAR limits, but in such cases it is usually simpler and more cost-effective to evaluate compliance with respect to field strength or power density limits. For certain devices that are designed to be used in both mobile and portable configurations similar to those described in 47 CFR §2.1091(d)(4), such as certain desktop phones and wireless modem modules, compliance for mobile configurations is also satisfied when the same device is evaluated for SAR compliance in portable configurations. The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 300 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Page 3 of 3 Report No. ESTE-R2407070 3. Evaluation Results Left earbud: Mode CH Peak output Power （dBm） Antenna Gain (dBi) effective radiated power （dBm） Target power (dBm) Max. Target power (mW) SAR Test Exemption Limit (mW) GFSK 2402 -3.25 2.48 -2.92 -2±1 0.794 2.72 2441 -2.35 2.48 -2.02 -2±1 0.794 2.72 2480 -0.9 2.48 -0.57 0±1 1.259 2.72 π/4- DQPSK 2402 -2.48 2.48 -2.15 -2±1 0.794 2.72 2441 -1.58 2.48 -1.25 -1±1 1.000 2.72 2480 -0.1 2.48 0.23 0±1 1.259 2.72 BLE 1M 2402 -3.27 2.48 -2.94 -2±1 0.794 2.72 2440 -2.29 2.48 -1.96 -1±1 1.000 2.72 2480 -0.76 2.48 -0.43 0±1 1.259 2.72 BLE 2M 2402 -3.01 2.48 -2.68 -2±1 0.794 2.72 2440 -2.03 2.48 -1.7 -1±1 1.000 2.72 2480 -0.56 2.48 -0.23 0±1 1.259 2.72 Right earbud: Mode CH Peak output Power （dBm） Antenna Gain (dBi) effective radiated power （dBm） Target power (dBm) Max. Target power (mW) SAR Test Exemption Limit (mW) GFSK 2402 -1.54 2.48 -1.21 -1±1 1.000 2.72 2441 -0.78 2.48 -0.45 0±1 1.259 2.72 2480 0.37 2.48 0.7 0±1 1.259 2.72 π/4- DQPSK 2402 -0.75 2.48 -0.42 0±1 1.259 2.72 2441 -0.02 2.48 0.31 0±1 1.259 2.72 2480 1.18 2.48 1.51 1±1 1.585 2.72 BLE 1M 2402 -1.77 2.48 -1.44 -1±1 1.000 2.72 2440 -1.01 2.48 -0.68 0±1 1.259 2.72 2480 0.18 2.48 0.51 0±1 1.259 2.72 BLE 2M 2402 -1.62 2.48 -1.29 -1±1 1.000 2.72 2440 -0.68 2.48 -0.35 0±1 1.259 2.72 2480 0.56 2.48 0.89 0±1 1.259 2.72 Note: 1. Limited=3060*(0.5/20)^x, x=-log(60/(3060*√f)). 2. We choose f=2.48GHz (Highest frequency operate at bluetooth) to calculate MPE limit as higher frequency will have lower MPE limits. 3. SAR Test Exclusion Thresholds is 2.72mW for separation distance 5mm. Therefore, SAR test is not required. End of Test Report

Test Report

Page 1 of 106 Report No. ESTE-R2407068 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Earfun Technology (HK) Limited True Wireless Earbuds Model Number: TW205 FCC ID: 2AVIT-TW205 Applicant : Earfun Technology (HK) Limited Address: FLAT/RM A 9F, SILVERCORP INTERNATIONAL TOWER 707-713 NATHAN ROAD MONGK OK KL, HONG KONG Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2407068 Date of Test: Jul. 01, 2024~ Jul. 12, 2024 Date of Report: Jul. 13, 2024 Page 2 of 106 Report No. ESTE-R2407068 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION .......................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................... 5 1.1. Description of Device (EUT) ............................................................................................................ 5 1.2. Antenna Information ......................................................................................................................... 5 1.3. Information of RF Cable ................................................................................................................... 5 2. SUMMARY OF TEST ........................................................................................................................... 6 2.1. Summary of test result ..................................................................................................................... 6 2.2. Test Facilities ..................................................................................................................................... 7 2.3. Measurement uncertainty ................................................................................................................ 8 2.4. Assistant equipment used for test .................................................................................................. 8 2.5. Block Diagram ................................................................................................................................... 8 2.6. Test mode .......................................................................................................................................... 9 2.7. Channel List ..................................................................................................................................... 10 2.8. Power Setting of Test Software .................................................................................................... 10 2.9. Test Equipment ............................................................................................................................... 11 3. MAXIMUM PEAK OUTPUT POWER ................................................................................................... 12 3.1. Limit ................................................................................................................................................... 12 3.2. Test Setup ........................................................................................................................................ 12 3.3. Spectrum Analyzer Setting ............................................................................................................ 12 3.4. Test Procedure ................................................................................................................................ 12 3.5. Test Result ....................................................................................................................................... 12 4. 20 DB BANDWIDTH ......................................................................................................................... 13 4.1. Limit ................................................................................................................................................... 13 4.2. Test Setup ........................................................................................................................................ 13 4.3. Spectrum Analyzer Setting ............................................................................................................ 13 4.4. Test Procedure ................................................................................................................................ 13 4.5. Test Result ....................................................................................................................................... 13 5. CARRIER FREQUENCY SEPARATION .............................................................................................. 14 5.1. Limit ................................................................................................................................................... 14 5.2. Test Setup ........................................................................................................................................ 14 5.3. Spectrum Analyzer Setting ............................................................................................................ 14 5.4. Test Procedure ................................................................................................................................ 14 5.5. Test Result ....................................................................................................................................... 14 6. NUMBER OF HOPPING CHANNEL ................................................................................................... 15 6.1. Limit ................................................................................................................................................... 15 6.2. Test Setup ........................................................................................................................................ 1…

Text truncated - open the document above for the full version.

Test Report

Page 88 of 106 Report No. ESTE-R2407068 Appendix F: Band edge measurements Test Result Test Mode Antenna ChName Frequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 Low 2402 -2.01 -38.8 ≤-22.01 PASS DH5 Ant1 High 2480 -0.25 -42.83 ≤-20.25 PASS DH5 Ant1 Low Hop_2402 -2.79 -39.93 ≤-22.79 PASS DH5 Ant1 High Hop_2480 0.04 -44.35 ≤-19.96 PASS 2DH5 Ant1 Low 2402 -1.92 -39.49 ≤-21.92 PASS 2DH5 Ant1 High 2480 -0.06 -43.54 ≤-20.06 PASS 2DH5 Ant1 Low Hop_2402 -5.06 -41.09 ≤-25.06 PASS 2DH5 Ant1 High Hop_2480 0.05 -50.1 ≤-19.95 PASS Page 89 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2480-PASS DH5-Ant1-Hop_2402-PASS Page 90 of 106 Report No. ESTE-R2407068 DH5-Ant1-Hop_2480-PASS 2DH5-Ant1-2402-PASS 2DH5-Ant1-2480-PASS Page 91 of 106 Report No. ESTE-R2407068 2DH5-Ant1-Hop_2402-PASS 2DH5-Ant1-Hop_2480-PASS Page 92 of 106 Report No. ESTE-R2407068 Appendix G: Conducted Spurious Emission Test Result Test Mode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 30~26500 -2.01 -42.61 ≤-22.01 PASS DH5 Ant1 2441 30~26500 -1.81 -43.31 ≤-21.81 PASS DH5 Ant1 2480 30~26500 -0.25 -43.17 ≤-20.25 PASS 2DH5 Ant1 2402 30~26500 -1.92 -43.31 ≤-21.92 PASS 2DH5 Ant1 2441 30~26500 -1.21 -43.15 ≤-21.21 PASS 2DH5 Ant1 2480 30~26500 -0.06 -43.1 ≤-20.06 PASS Page 93 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402-30~26500-PASS DH5-Ant1-2441-30~26500-PASS DH5-Ant1-2480-30~26500-PASS Page 94 of 106 Report No. ESTE-R2407068 2DH5-Ant1-2402-30~26500-PASS 2DH5-Ant1-2441-30~26500-PASS 2DH5-Ant1-2480-30~26500-PASS Page 95 of 106 Report No. ESTE-R2407068 Appendix H: Reference level measurement Test Result Test Mode Antenna Freq(MHz) Max.Point[MHz] Result[dBm] DH5 Ant1 2402 2402.17 -2.01 DH5 Ant1 2441 2441.00 -1.81 DH5 Ant1 2480 2479.99 -0.25 2DH5 Ant1 2402 2401.84 -1.92 2DH5 Ant1 2441 2440.85 -1.21 2DH5 Ant1 2480 2479.85 -0.06 Page 96 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS DH5-Ant1-2480-PASS Page 97 of 106 Report No. ESTE-R2407068 2DH5-Ant1-2402-PASS 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Page 98 of 106 Report No. ESTE-R2407068 13. TEST SETUP PHOTO Radiated Test (Below 1GHz) Radiated Test (Above 1GHz) Page 99 of 106 Report No. ESTE-R2407068 14. EUT PHOTO External Photos M/N: TW205 Page 100 of 106 Report No. ESTE-R2407068 External Photos M/N: TW205 Page 101 of 106 Report No. ESTE-R2407068 External Photos M/N: TW205 Page 102 of 106 Report No. ESTE-R2407068 External Photos M/N: TW205 Page 103 of 106 Report No. ESTE-R2407068 Internal Photos M/N: TW205 Page 104 of 106 Report No. ESTE-R2407068 Internal Photos M/N: TW205 Bluetooth Antenna Page 105 of 106 Report No. ESTE-R2407068 Internal Photos M/N: TW205 Page 106 of 106 Report No. ESTE-R2407068 Internal Photos M/N: TW205 End of Test Report

Test Report

深圳市朋伴兴业科技有限公司 PAGE1 OF5 产品规格承认书 SPECIFICATIONS 客户: CUSTOMER: 产品名称: DESCRIPTION:双极天线客户型号: CUSTOMERPARTNo: 产品型号: OURMODELNO:PBX2012MA07 日期: DATE: 确认签字,盖章后请返回承认书一份 PLEASERETRUVTOUSONECOPYOF“SPECIFICATIONFORAPPROVAL” WITYYOURAPPROVEDSIGNATURES 核准审核刘飞制作刘小美客户确认签章(APPROVEDSIGNATURE) 深圳市朋伴兴业科技有限公司 PAGE2 OF5 PBX2012MA07Specification OperatingTemp.:-40°C~+85°C 1.FEATURES: ●Lightweight,compact ●Widebandwidth,lowcost ●Built-inantennawithhighgain 2.APPLICATIONS: ●Bluetooth,WirelessLAN,MobileTV ●HomeRFsystem,etc 3.PRODUCTIDENTIFICATION 201 221 (1)(2)(3) (1)Producttype:MultilayerchipAntenna (2)ExternalDimensions(L×W)(mm):2.0*1.2 4.SHAPEANDDIMENSIONS: SHAPEANDDIMENSIONS UNLESSOTHERSPECIFIEDTOLERANCESON： X＝ ± X.X＝ ± X.XX＝ ANGLES＝ ± HOLEDIA＝ ± 深圳市朋伴兴业科技有限公司 SCALE：N/AUNIT：mm THISDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-21Specification DOCUMENT NO. 2012 SPECREV. P1 HIPC 深圳市朋伴兴业科技有限公司 PAGE3 OF5 TERINAL-CONFIGURATION EVALUATIONBOARD APPLICATIONGUIDE UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝±HOLEDIA＝± 深圳市朋伴兴业科技有限公司 SCALE：N/AUNIT：mm THISDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-21Specification DOCUMENT NO. 2012 SPECREV. P1 深圳市朋伴兴业科技有限公司 PAGE4 OF5 5.SPECIFICATIONS: *Testcondition:Testboardsize98*65mm Matchingcircuit:Pimatchingcircuitwillberequired 6.ElectricalCharacteristics: VSWR MarkFrequencyVSWR 12400MHz3.04 22450MHz1.15 32500MHz2.57 ITEMSPECIFICATION FrequencyBand2400MHz～2483MHz VSWRLessthan3 PolarizationLinear *PeakGain2.48dBiTyp. *PeakEfficiency72.6%Typ. Impedance50ΩTyp. UNLESSOTHERSPECIFIEDTOLERANCESON： X＝ ± X.X＝ ± X.XX＝ ANGLES＝ ± HOLEDIA＝ ± 深圳市朋伴兴业科技有限公司 SCALE：N/AUNIT：mm THISDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-21Specification DOCUMENT NO. 2012 SPECREV. P1 MarkFrequencyVSWR 12400MHz3.04 2 2450MHz1.15 3 2500MHz2.57 深圳市朋伴兴业科技有限公司 PAGE5 OF5 RadiationPattern TheGainpatternismeasuredinINPAQ’sFAR-fieldchamber.DUTisplacedonthetableof rotator,astandardhornantennaandVectorNetworkAnalyzerisusedtocollectdata. ◎3DGainPattern(2400MHz) ◎ 2DGainPattern(2400MHz) UNLESSOTHERSPECIFIEDTOLERANCESON： X＝±X.X＝±X.XX＝ ANGLES＝±HOLEDIA＝± 深圳市朋伴兴业科技有限公司 SCALE：N/AUNIT：mm THISDRAWINGSANDSPECIFICATIONSARETHEPROPERTYOFPBXY TECHNOLOGYLimitedANDSHALLNOTBEREPRODUCEDORUSEDAS THEBASISFORTHEMANUFACTUREORSALEOFAPPARATUSOR DEVICESWITHOUTPERMISSION DRAWNBY:SeraCHECKEDBY:XD DESIGNEDBY:SeraAPPROVEDBY:XD TITLE：CHIP2450-21Specification DOCUMENT NO. 2012 SPECREV. P1

Test Report

Page 66 of 106 Report No. ESTE-R2407068 Appendix G: Conducted Spurious Emission Test Result Test Mode Antenna Frequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5 Ant1 2402 30~26500 -3.89 -43.3 ≤-23.89 PASS DH5 Ant1 2441 30~26500 -3.01 -43.15 ≤-23.01 PASS DH5 Ant1 2480 30~26500 -1.36 -43.68 ≤-21.36 PASS 2DH5 Ant1 2402 30~26500 -3.79 -43.2 ≤-23.79 PASS 2DH5 Ant1 2441 30~26500 -2.89 -43.47 ≤-22.89 PASS 2DH5 Ant1 2480 30~26500 -1.24 -42.45 ≤-21.24 PASS Page 67 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402-30~26500-PASS DH5-Ant1-2441-30~26500-PASS DH5-Ant1-2480-30~26500-PASS Page 68 of 106 Report No. ESTE-R2407068 2DH5-Ant1-2402-30~26500-PASS 2DH5-Ant1-2441-30~26500-PASS 2DH5-Ant1-2480-30~26500-PASS Page 69 of 106 Report No. ESTE-R2407068 Appendix H: Reference level measurement Test Result Test Mode Antenna Freq(MHz) Max.Point[MHz] Result[dBm] DH5 Ant1 2402 2401.84 -3.89 DH5 Ant1 2441 2440.99 -3.01 DH5 Ant1 2480 2480.17 -1.36 2DH5 Ant1 2402 2401.85 -3.79 2DH5 Ant1 2441 2440.85 -2.89 2DH5 Ant1 2480 2479.84 -1.24 Page 70 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS DH5-Ant1-2480-PASS Page 71 of 106 Report No. ESTE-R2407068 2DH5-Ant1-2402-PASS 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Page 72 of 106 Report No. ESTE-R2407068 12.2.Test Result For Right Earbud Appendix A: 20dB Emission Bandwidth Test Result Test Mode Antenna Frequency[MHz] 20db EBW[MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict DH5 Ant1 2402 0.939 2401.538 2402.477 --- --- DH5 Ant1 2441 0.948 2440.538 2441.486 --- --- DH5 Ant1 2480 0.945 2479.541 2480.486 --- --- 2DH5 Ant1 2402 1.305 2401.349 2402.654 --- --- 2DH5 Ant1 2441 1.299 2440.352 2441.651 --- --- 2DH5 Ant1 2480 1.272 2479.373 2480.645 --- --- Page 73 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402 DH5-Ant1-2441 DH5-Ant1-2480 Page 74 of 106 Report No. ESTE-R2407068 2DH5-Ant1-2402 2DH5-Ant1-2441 2DH5-Ant1-2480 Page 75 of 106 Report No. ESTE-R2407068 Appendix B: Maximum conducted output power Test Result Peak Test Mode Antenna Frequency[MHz] Conducted Peak Powert[dBm] Conducted Limit[dBm] Verdict DH5 Ant1 2402 -1.54 ≤20.97 PASS DH5 Ant1 2441 -0.78 ≤20.97 PASS DH5 Ant1 2480 0.37 ≤20.97 PASS 2DH5 Ant1 2402 -0.75 ≤20.97 PASS 2DH5 Ant1 2441 -0.02 ≤20.97 PASS 2DH5 Ant1 2480 1.18 ≤20.97 PASS Page 76 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS DH5-Ant1-2480-PASS Page 77 of 106 Report No. ESTE-R2407068 2DH5-Ant1-2402-PASS 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Page 78 of 106 Report No. ESTE-R2407068 Appendix C: Carrier frequency separation Test Result Test Mode Antenna Frequency[MHz] Result[MHz] Limit[MHz] Verdict DH5 Ant1 2402 1.038 ≥0.948 PASS DH5 Ant1 2441 0.972 ≥0.948 PASS DH5 Ant1 2480 0.984 ≥0.948 PASS 2DH5 Ant1 2402 1.137 ≥0.870 PASS 2DH5 Ant1 2441 0.999 ≥0.870 PASS 2DH5 Ant1 2480 1.005 ≥0.870 PASS Page 79 of 106 Report No. ESTE-R2407068 Test Graphs DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS DH5-Ant1-2480-PASS Page 80 of 106 Report No. ESTE-R2407068 2DH5-Ant1-2402-PASS 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS Page 81 of 106 Report No. ESTE-R2407068 Appendix D: Time of occupancy Test Result Test Mode Antenna Frequency[MHz] BurstWidth [ms] TotalHops [Num] Result[s] Limit[s] Verdict DH1 Ant1 Hop 0.377 319 0.12 ≤0.4 PASS DH3 Ant1 Hop 1.620 160 0.259 ≤0.4 PASS DH5 Ant1 Hop 2.870 125 0.359 ≤0.4 PASS 2DH1 Ant1 Hop 0.388 319 0.124 ≤0.4 PASS 2DH3 Ant1 Hop 1.630 158 0.258 ≤0.4 PASS 2DH5 Ant1 Hop 2.870 98 0.281 ≤0.4 PASS P…

Text truncated - open the document above for the full version.
