2AVKP-BF-A30battery wifi camera

FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the follow ing two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, inc luding interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentia l installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televis ion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technic ian for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be insta lled and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna.

SHENZHEN BOVISION TECHNOLOGY CO.,LTD. Model Difference Product description: battery wifi camera Model name: BF-A30 BF-A10, BF-A10W, BF-A10B, BF-A30W, BF-A30B, BF-S30, BF-X30, BF-W30, SC-MU72, SC-MS72, A10, A103 Trade Name: N/A FCC ID: 2AVKP-BF-A30 All the model are the same circuit and RF module, only for model name. Regards Sincerely Client’s signature: Client’s name / title : Wang Zhi (Manager) Contact information / address: 2nd floor, building G, no. 8, shangxue industrial park, bantian street, longgang district, shenzhen,China

C5266091_X8_Ed.1 1/1 Letter of Authorization <SHENZHEN BOVISION TECHNOLOGY CO.,LTD.> Company:SHENZHEN BOVISION TECHNOLOGY CO.,LTD. Address:2nd floor, building G, no. 8, shangxue industrialpark, bantian street, longgang district,shenzhen,China Product Name:battery wifi camera Model Number:BF-A30 BF-A10, BF-A10W, BF-A10B, BF-A30W, BF-A30B, BF-S30, BF-X30, BF-W30, SC-MU72, SC-MS72, A10, A103 FCC Identifier:2AVKP-BF-A30 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: WangZhi Date: 2021-07-07 Title: Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 <SHENZHEN BOVISION TECHNOLOGY CO.,LTD.> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-07-07 Subject: Request for Confidentiality FCC ID:2AVKP-BF-A30 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Wang Zhi Title:Manager

EUT PHOTO(External Photos)

Label and label location battery wifi camera FCC ID:2AVKP-BF-A30

EUT PHOTO(Internal Photos) ※※※※※※※※※※ END OF REPORT WIFI ANT

FCC ID:2AVKP-BF-A30 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation 2.4G WIFI mode Channel Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 9.121 8.17 0.001625 1.0 PASS 802.11g 8.471 7.03 0.001399 1.0 PASS 802.11n(HT20) 8.517 7.11 0.001414 1.0 PASS 802.11n(HT40) 7.832 6.07 0.001208 1.0 PASS Remark: antenna gain=0dBi

ProjectNo.:ZKT-2106252933E Page 1 of 56 FCCTESTREPORT FCCID:2AVKP-BF-A30 ReportNumber...................................:ZKT-2106252933E DateofTest.......................................................:Jun.08,2021toJul.05,2021 Dateofissue.........................................:Jul.05,2021 Totalnumberofpages .......................... 56 TestResult ............................................ : PASS TestingLaboratory............................: ShenzhenZKTTechnologyCo.,Ltd. Address...............................................: 1/F,No.101,BuildingB,No.6,TangweiCommunityIndustrial Avenue,FuhaiStreet,Bao'anDistrict,Shenzhen,China Applicant'sname.............................: SHENZHENBOVISIONTECHNOLOGYCO.,LTD. Address...............................................: 2ndfloor,buildingG,no.8,shangxueindustrialpark,bantianstreet, longgangdistrict,Shenzhen,China Manufacturer'sname......................: SHENZHENBOVISIONTECHNOLOGYCO.,LTD. Address...............................................: 2ndfloor,buildingG,no.8,shangxueindustrialpark,bantianstreet, longgangdistrict,Shenzhen,China Testspecification: Standard ................................................ : FCCCFRTitle47Part15SubpartCSection15.247 ANSIC63.10:2013 Testprocedure.....................................: / Non-standardtestmethod................:N/A TestReportFormNo. ....................... : TRF-EL-110_V0 TestReportForm(s)Originator ..... : ZKTTesting MasterTRF ........................................ : Dated:2020-01-06 ThisdevicedescribedabovehasbeentestedbyZKT,andthetestresultsshowthattheequipmentunder test(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofZKT,thisdocumentmay bealteredorrevisedbyZKT,personalonly,andshallbenotedintherevisionofthedocument. Productname ..................................... :batterywificamera Trademark...........................................: N/A Model/Typereference ......................... :BF-A30 BF-A10,BF-A10W,BF-A10B,BF-A30W,BF-A30B,BF-S30, BF-X30,BF-W30,SC-MU72,SC-MS72,A10,A103 Ratings .................................................. :Input:DC5VorDC3.6VBattery ProjectNo.:ZKT-2106252933E Page 2 of 56 Testingprocedureandtestinglocation: TestingLaboratory.......................................:ShenzhenZKTTechnologyCo.,Ltd. Address ............................................................ :1/F,No.101,BuildingB,No.6,TangweiCommunity IndustrialAvenue,FuhaiStreet,Bao'anDistrict, Shenzhen,China AlenHe Testedby(name+signature).......................: JoeLiu Reviewer(name+signature).......................: LakeXie Approved(name+signature).......................: ProjectNo.:ZKT-2106252933E Page 3 of 56 TableofContents Page 1.VERSION5 2.SUMMARYOFTESTRESULTS6 2.1TESTFACILITY7 2.2MEASUREMENTUNCERTAINTY7 3.GENERALINFORMATION8 3.1GENERALDESCRIPTIONOFEUT8 3.2DESCRIPTIONOFTESTMODES9 3.3BLOCKDIGRAMSHOWINGTHECONFIGURATIONOFSYSTEMTESTED9 3.4DESCRIPTIONOFSUPPORTUNITS(CONDUCTEDMODE)10 3.5EQUIPMENTSLISTFORALLTESTITEMS11 4.EMCEMISSIONTEST12 4.1CONDUCTEDEMISSIONMEASUREMENT12 4.1.1POWERLINECONDUCTEDEMISSIONLIMITS12 4.1.2TESTPROCEDURE12 4.1.3DEVIATIONFROMTESTSTANDARD12 4.1.4TESTSETUP13 4.1.5EUTOPERATINGCONDITIONS13 4.1.6TESTRESULT14 4.2RADIATEDEMISSIONMEASUREMENT16 4.2.1RADIATEDEMISSIONLIMITS16 4.2.2TESTPROCEDURE16 4.2.3DEVIATIONFROMTESTSTANDARD17 4.2.4TESTSETUP17 4.2.5EUTOPERATINGCONDITIONS18 4.2.6TESTRESULTS18 5.RADIATEDBANDEMISSIONMEASUREMENT29 5.1TESTREQUIREMENT:29 5.2TESTPROCEDURE29 5.3DEVIATIONFROMTESTSTANDARD29 5.4TESTSETUP30 5.5EUTOPERATINGCONDITIONS30 5.6TESTRESULT31 6.POWERSPECTRALDENSITYTEST33 6.1APPLIEDPROCEDURES/LIMIT33 6.2TESTPROCEDURE33 6.3DEVIATIONFROMSTANDARD33 6.4TESTSETUP33 6.5EUTOPERATIONCONDITIONS33 ProjectNo.:ZKT-2106252933E Page 4 of 56 6.6TESTRESULT34 7.CHANNELBANDWIDTH&99%OCCUPYBANDWIDTH42 7.1APPLIEDPROCEDURES/LIMIT42 7.2TESTPROCEDURE42 7.3DEVIATIONFROMSTANDARD42 7.4TESTSETUP42 7.5EUTOPERATIONCONDITIONS42 7.6TESTRESULT43 8.PEAKOUTPUTPOWERTEST46 8.1APPLIEDPROCEDURES/LIMIT46 8.2TESTPROCEDURE46 8.3DEVIATIONFROMSTANDARD46 8.4TESTSETUP46 8.5EUTOPERATIONCONDITIONS46 8.6TESTRESULT47 9.CONDUCTEDBANDEDGEANDSPURIOUSEMISSION48 9.1APPLICABLESTANDARD48 9.2TESTPROCEDURE48 9.3DEVIATIONFROMSTANDARD48 9.4TESTSETUP48 9.5EUTOPERATIONCONDITIONS48 9.6TESTRESULTS48 10.ANTENNAREQUIREMENT55 11.TESTSETUPPHOTO56 12.EUTCONSTRUCTIONALDETAILS56 ProjectNo.:ZKT-2106252933E Page 5 of 56 1.VERSION ReportNo.VersionDescriptionApproved ZKT-2106252933ERev.01InitialissueofreportJul.05,2021 ProjectNo.:ZKT-2106252933E Page 6 of 56 2.SUMMARYOFTESTRESULTS Testproceduresaccordingtothetechnicalstandards: FCCPart15(15.247),SubpartC Standard Section TestItemResultRemark FCCpart15.203/15.247 (c) AntennarequirementPASS FCCpart15.207ACPowerLineConductedEmissionPASS FCCpart15.247(b)(3)ConductedPeakOutputPowerPASS FCCpart15.247(a)(2)ChannelBandwidth&99%OCBPASS FCCpart15.247(e)PowerSpectralDensityPASS FCCpart15.247(d)BandEdgePASS FCCpart15.205/15.209SpuriousEmissionPASS NOTE: (1)”N/A”denotestestisnotapplicableinthisTestReport ProjectNo.:ZKT-2106252933E Page 7 of 56 2.1TESTFACILITY ShenzhenZKTTechnologyCo.,Ltd. Add.:1/F,No.101,BuildingB,No.6,TangweiCommunityIndustrialAvenue,FuhaiStreet,Bao'an District,Shenzhen,China FCCTestFirmRegistrationNumber:692225 DesignationNumber:CN1299 ICRegisteredNo.:27033 2.2MEASUREMENTUNCERTAINTY Thereporteduncertaintyofmeasurementy±U，whereexpendeduncertaintyUisbasedonastandard uncertaintymultipliedbyacoveragefactorofk=2 ， providingalevelofconfidenceofapproximately95 %。 No.ItemUncertainty 1ConductedEmissionTest±1.38dB 2RFpowerconducted±0.16dB 3Spuriousemissionsconducted±0.21dB 4Allemissionsradiated(<1G)±4.68dB 5Allemissionsradiated(>1G)±4.89dB 6Temperature±0.5°C 7Humidity±2% ProjectNo.:ZKT-2106252933E Page 8 of 56 3.GENERALINFORMATION 3.1GENERALDESCRIPTIONOFEUT ProductName: batterywificamera ModelNo.: BF-A30 BF-A10,BF-A10W,BF-A10B,BF-A30W,BF-A30B,BF-S30, BF-X30,BF-W30,SC-MU72,SC-MS72,A10,…

Text truncated - open the document above for the full version.

ProjectNo.:ZKT-2106252933E Page 41 of 56 TXCH06 TXCH09 ProjectNo.:ZKT-2106252933E Page 42 of 56 7.CHANNELBANDWIDTH&99%OCCUPYBANDWIDTH TestRequirement:FCCPart15CSection15.247(a)(2) TestMethod:KDB558074D0115.247MeasGuidancev05r02 7.1APPLIEDPROCEDURES/LIMIT FCCPart15(15.247),SubpartC SectionTestItemLimit FrequencyRange (MHz) Result 15.247(a)(2)Bandwidth >=500KHz (6dBbandwidth) 2400-2483.5PASS 7.2TESTPROCEDURE 1.SetRBW=100kHz. 2.Setthevideobandwidth(VBW)≥3xRBW. 3.Detector=Peak. 4.Tracemode=maxhold. 5.Sweep=autocouple. 6.Allowthetracetostabilize. 7.Measurethemaximumwidthoftheemissionthatisconstrainedbythefrequenciesassociatedwiththe twooutermostamplitudepoints(upperandlowerfrequencies)thatareattenuatedby6dBrelativetothe maximumlevelmeasuredinthefundamentalemission. 7.3DEVIATIONFROMSTANDARD Nodeviation. 7.4TESTSETUP 7.5EUTOPERATIONCONDITIONS TheEUTtestedsystemwasconfiguredasthestatementsof2.4Unlessotherwiseaspecialoperating conditionisspecifiedinthefollowsduringthetesting. ProjectNo.:ZKT-2106252933E Page 43 of 56 7.6TESTRESULT Temperature： 26°C RelativeHumidity： 54% Pressure： 101kPa TestVoltage： DC12V TestMode ： TXbMode TestCH -6dBOccupyBandwidth(MHz) 802.11b802.11g802.11n(HT20) 802.11n(HT 40) Limit(KHz)Result Lowest8.22416.29015.02035.060 >500Pass Middle7.68815.34013.45035.080 Highest7.77015.15016.09035.070 TestCH 99%OccupyBandwidth(MHz) Result 802.11b802.11g802.11n(HT20)802.11n(HT40) Lowest12.56716.35017.54335.790 PassMiddle12.45816.33817.54235.852 Highest12.49216.35917.54035.896 ProjectNo.:ZKT-2106252933E Page 44 of 56 Testplotasfollows: 802.11b802.11g Lowestchannel Middlechannel Highestchannel ProjectNo.:ZKT-2106252933E Page 45 of 56 802.11n20802.11n40 Lowestchannel Middlechannel Highestchannel ProjectNo.:ZKT-2106252933E Page 46 of 56 8.PEAKOUTPUTPOWERTEST TestRequirement:FCCPart15CSection15.247(b)(3) TestMethod:KDB558074D0115.247MeasGuidancev05r02 8.1APPLIEDPROCEDURES/LIMIT FCCPart15(15.247),SubpartC SectionTestItemLimit FrequencyRange (MHz) Result 15.247(b)(3) PeakOutput Power 1wattor30dBm2400-2483.5PASS 8.2TESTPROCEDURE a. TheEUTwasdirectlyconnectedtothePowermeter 8.3DEVIATIONFROMSTANDARD Nodeviation. 8.4TESTSETUP 8.5EUTOPERATIONCONDITIONS TheEUTtestedsystemwasconfiguredasthestatementsof2.4Unlessotherwiseaspecialoperating conditionisspecifiedinthefollowsduringthetesting. ProjectNo.:ZKT-2106252933E Page 47 of 56 8.6TESTRESULT Temperature ： 26°C RelativeHumidity ： 54% Pressure： 101kPa TestVoltage： DC12V TestCH PeakOutputPower(dBm) Limit(dBm)Result 802.11b802.11g802.11n(HT20)802.11n(HT40) Lowest9.0248.4718.501 7.832 30.00Pass Middle9.1218.3218.517 7.541 Highest9.1108.2938.3897.652 ProjectNo.:ZKT-2106252933E Page 48 of 56 9.CONDUCTEDBANDEDGEANDSPURIOUSEMISSION TestRequirement:FCCPart15CSection15.247(d) TestMethod:KDB558074D0115.247MeasGuidancev05r02 9.1APPLICABLESTANDARD inany100kHzbandwidthoutsidethefrequencybandsinwhichthespreadspectrumintentionalradiatorin operating,theradiofrequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dBbelow thatinthe100kHzbandwidthwithinthebandthatcontainsthehighestlevelofthedesiredpower,Inaddition, radiatedemissionswhichfallintherestrictedbands,asdefinedin§15.205(a),mustalsocomplywiththe radiatedemissionlimitsspecifiedin15.209(a). 9.2TESTPROCEDURE Usingthefollowingspectrumanalyzersetting: A)SettheRBW=100KHz. B)SettheVBW=300KHz. C)Sweeptime=autocouple. D)Detectorfunction=peak. E)Tracemode=maxhold. F)Allowtracetofullystabilize. 9.3DEVIATIONFROMSTANDARD Nodeviation. 9.4TESTSETUP 9.5EUTOPERATIONCONDITIONS TheEUTtestedsystemwasconfiguredasthestatementsof2.4Unlessotherwiseaspecialoperating conditionisspecifiedinthefollowsduringthetesting. 9.6TESTRESULTS ProjectNo.:ZKT-2106252933E Page 49 of 56 Testplotasfollows: Testmode:802.11b LowestchannelHighestchannel Testmode:802.11g LowestchannelHighestchannel ProjectNo.:ZKT-2106252933E Page 50 of 56 Testmode:802.11n(HT20) LowestchannelHighestchannel Testmode:802.11n(HT40) LowestchannelHighestchannel ProjectNo.:ZKT-2106252933E Page 51 of 56 Testplotasfollows: 802.11b Lowestchannel Middlechannel Highestchannel ProjectNo.:ZKT-2106252933E Page 52 of 56 802.11g Lowestchannel Middlechannel Highestchannel ProjectNo.:ZKT-2106252933E Page 53 of 56 802.11n(HT20) Lowestchannel Middlechannel Highestchannel ProjectNo.:ZKT-2106252933E Page 54 of 56 802.11n(HT40) Lowestchannel Middlechannel Highestchannel ProjectNo.:ZKT-2106252933E Page 55 of 56 10.ANTENNAREQUIREMENT Standardrequirement: FCCPart15CSection15.203/247(c) 15.203requirement: Anintentionalradiatorshallbedesignedtoensurethatnoantennaotherthanthatfurnishedbytheresponsiblepartyshall beusedwiththedevice.Theuseofapermanentlyattachedantennaorofanantennathatusesauniquecouplingtothe intentionalradiator,themanufacturermaydesigntheunitsothatabrokenantennacanbereplacedbytheuser,butthe useofastandardantennajackorelectricalconnectorisprohibited. 15.247(c)(1)(i)requirement: (i)Systemsoperatinginthe2400-2483.5MHzbandthatisusedexclusivelyforfixed.Point-to-pointoperationsmay employtransmittingantennaswithdirectionalgaingreaterthan6dBiprovidedthemaximumconductedoutputpowerof theintentionalradiatorisreducedby1dBforevery3dBthatthedirectionalgainoftheantennaexceeds6dBi. EUTAntenna: TheantennaisFPCBAntenna,thebestcasegainoftheantennais0dBi,referencetotheappendixIIfordetails ProjectNo.:ZKT-2106252933E Page 56 of 56 11.TESTSETUPPHOTO ReferencetotheappendixIfordetails. 12.EUTCONSTRUCTIONALDETAILS ReferencetotheappendixIIfordetails. ※※※※※ENDOFREPORT※※※※※

EUT TEST PHOTO
