2AVKZRM68-51BRADAR Module

Rev 1/26/2023 Smart Radar System, Inc. 3rd Floor, Fine Venture Bldg, 41 Seongnam-daero 925gil, Bundang-gu, Seongnam-si, South Korea 13496 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 09-26-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AVKZRM68-51B [Smart Radar System, Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Smart Radar System, Inc.] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Sincerely, Jaecheol Ahn Rev 1/26/2023 Smart Radar System, Inc. 3rd Floor, Fine Venture Bldg, 41 Seongnam-daero 925gil, Bundang-gu, Seongnam-si, South Korea 13496 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 09-26-2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AVKZRM68-51B [Smart Radar System, Inc.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Jaecheol Ahn

Smart Radar System, Inc. 3rd Floor, Fine Venture Bldg, 41 Seongnam-daero 925gil, Bundang-gu, Seongnam-si, South Korea 13496 MODULAR APPROVAL LETTER Date: 09/26/2024 FCC ID: 2AVKZRM68-51B Modular Approval Requirement Answers (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. Y (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. Y (iii) The modular transmitter must have its own power supply regulation. Y (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y (v) The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in § 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see § 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see § 15.31(i)). Y (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. Y (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y (viii) Radio frequency devices operating under the provisions of this part are subject to the radio frequency radiation exposure requirements specified in §§ 1.1307(b), 1.1310, 2.1091, and 2.1093 of this chapter, as appropriate. Applications for equipment authorization of modular transmitters under this section must contain a statement confirming compliance with these requirements. The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Technical information showing the basis for this statement must be submitted to the Commission upon request. Y Sincerely, Contact Name: Jaecheol Ahn Title: Leader of Hardware Development Team

Smart Radar System, Inc. 3rd Floor, Fine Venture Bldg, 41 Seongnam-daero 925gil, Bundang-gu, Seongnam-si, South Korea 13496 Date: 09/26/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Request of Confidentiality FCC ID: 2AVKZRM68-51B To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Smart Radar System, Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Smart Radar System, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description 5 NA SHORT-TERM 6 Internal Photos 7 External Photos 8 Test-Setup Photos 9 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Contact Name: Jaecheol Ahn Title: Leader of Hardware Development Team

Smart Radar System, Inc. 3rd Floor, Fine Venture Bldg, 41 Seongnam-daero 925gil, Bundang-gu, Seongnam-si, South Korea 13496 Date: 09/26/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of Dt&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: 2AVKZRM68-51B including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of Dt&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Smart Radar System, Inc.. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Contact Name: Jaecheol Ahn Title: Leader of Hardware Development Team

Sample Label & Location FCC ID: 2AVKZRM68-51B FCC ID: 2AVKZRM68-51B Note: FCC ID will be engrave d on the back of module.

FCC ID: RF feature(Mode) Max Target EIRP (dBm) Maximum EIRP (mW) Maximum power density (mW/cm 2 ) Requirement (mW/cm 2 ) FMCW Radar 60 000.0 ~ 62 000.0 14.00 25.119 0.005 0 1.000 0 ~~~~~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averaging time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2 .19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : R= Distance to the center of the radiation of the antenna(20cm) Part 1.1310▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) The exposure condition of this device is compliant with FCC The EUT w ill only be us ed with a separation of 20 centimeters o r greater between the antenna and the body of the user. The MPE sample calculation for this exposure is shown below. EIRP / ( 4 R 2 π ) 25.119 S= Maximum power density(mW/cm 2 ) 0.005 EIRP= Equivalent Isotropic Radiated Power(mW) 2AVKZRM68-51B MPE Calculation Regulation(s): Part 1.1310, Part 2.1091Method: KDB447498 D01v06 Frequency range (MHz) Note: Please refer to the operation description for Max Target power.

Report No.: DRTFCC2409-0113 FCC ID: 2AVKZRM68-51B This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-245(02)240927 Pages: 2 / 28 Test Report Version Test Report No. Date Description Revised By Reviewed By DRTFCC2409-0113 Sep. 27 2024 Initial issue Seokho Han JaeJin Lee Report No.: DRTFCC2409-0113 FCC ID: 2AVKZRM68-51B This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-245(02)240927 Pages: 3 / 28 Table of Contents 1. General Information ................................................................................. 4 1.1. Description of EUT............................................................................................................. 4 1.2. Declaration by the applicant / manufacturer .................................................................... 5 1.3. Testing Laboratory ............................................................................................................. 5 1.4. Testing Environment ......................................................................................................... 5 1.5. Measurement Uncertainty ................................................................................................. 5 1.6. Test Equipment List ........................................................................................................... 6 2. Test Methodology ..................................................................................... 8 2.1. EUT configuration .............................................................................................................. 8 2.2. EUT exercise ...................................................................................................................... 8 2.3. General test procedures .................................................................................................... 8 2.4. Instrument Calibration ....................................................................................................... 8 2.5. Description of test modes ................................................................................................. 8 3. Antenna Requirements ............................................................................ 9 4. Summary of Test Results ....................................................................... 10 5. Test Results ............................................................................................ 11 5.1. Occupied Bandwidth (99%) ............................................................................................. 11 5.2. Equivalent Isotropic Radiated Power ............................................................................. 13 5.3. Unwanted emissions ....................................................................................................... 17 5.4. Frequency stability .......................................................................................................... 23 5.5. AC line conducted emissions ......................................................................................... 25 APPENDIX I ................................................................................................. 28 Report No.: DRTFCC2409-0113 FCC ID: 2AVKZRM68-51B This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-245(02)240927 Pages: 4 / 28 1. General Information 1.1. Description of EUT FCC Equipment Class Part 15 Field Disturbance Sensor (FDS) Product RADAR Module Model Name RM68-51 Add Model Name - Serial Number No Specified Power Supply DC 5 V Frequency Range 60 ~ 62 GHz Max. RF Output Power (EIRP) 11.74 dBm (0.0149W) Modulation Type FMCW Antenna Specification Antenna type: Patch Antenna Antenna gain(Max): 7.1 dBi RADAR CERTIFICATION OPTIONS ☐ a. Any terrestrial radar transmitting in the 57-71 GHz frequency band can be certified under §15.255(c)(2) with a peak conducted output power limit of -10 dBm and a peak EIRP limit of 10 dBm. ☐ b. Any terrestrial radar transmitting within the 61.0-61.5 GHz ISM band segment, with a maximum EIRP output of 40 dBm (average) and 43 dBm (peak), can be certified under the §15.255(c)(2)(v) rules. ☐ c. Radars intended for operation onboard unmanned aircraft in the 60.0-64.0 GHz band segment can be certified under §15.255(b)(3) with a peak EIRP limit of 20 dBm and a required off-time of at least 16.5 milliseconds within any contiguous 33.0 millisecond interval. ☐ d. Terrestrial, including vehicular (in-cabin) radar devices in the 57.0-59.4 GHz band segment, can be certified under §15.255(c)(2)(i), with peak EIRP limits of 20 dBm for indoor operation and 30 dBm for outdoor operation. ☐ e. All terrestrial radar within the 57.0-61.56 GHz band segment can be certified under §15.255(c)(2)(ii), with a peak EIRP limit of 3 dBm with no off-time requirement, or 20 dBm with a corresponding off-time requirement of 16.5 milliseconds within any 33.0-millisecond interval. ☒ f. Any terrestrial radar operating within the 57.0-64.0 GHz band segment can be certified under §15.255(c)(2)(iii)(A), with a peak EIRP limit of 14 dBm and a corresponding off-time requirement of 25.5 milliseconds within any 33.0-millisecond interval. ☐ g. Permanent or temporary fixed radar intended solely for outdoor or other than in-cabin vehicular applications can be certified under §15.255(c)(2)(iii)(B) with a peak EIRP limit of 20 dBm and a corresponding off-time requirement of 16.5 milliseconds within any contiguous 33.0 millisecond interval. ☐ h. Pulsed radar applications with a maximum pulse duration of 6 nanoseconds and transmitting within the 57-64 GHz band segment can be certified under §15.255(c)(3), with an average EIRP limit of 13 dBm, a peak EIRP limit of 33 dBm, and a transmit duty cycle limit of 10%; in addition, the average integrated EIRP within the 61.5-64.0 GHz band must not exceed 5 dBm in any 0.…

Text truncated - open the document above for the full version.

Antenna Specifications for Radar Module 1. General Specifications Items Specifications Antenna Type Patch Antenna Frequency Band 60 ~ 64 GHz VSWR 2.0 manx. Gain 7.1 dBi 2. VSWR & Radiation Pattern S11 & VSWR Axis of Radiation Pattern Radiation Pattern - 3D
