2AVNP-PSR-9536-APublic Safety Repeater

User’s manual PSR-9536-A PSR-9536-B V01 - 2 - User’s manual_v01 Update history Document version Date Editor Description V01 2020-01-28 Jake Kim Draft - 3 - User’s manual_v01 Contents 1. Introduction.............................................................................................................................................. - 13 - 1.1 Features................................................................................................................................................... - 13 - 1.2 Outlook ................................................................................................................................................ - 14 - 1.2.1 PSR .................................................................................................................................................... - 14 - 1.3 System RF block diagram .................................................................................................................... - 15 - 1.4 Frequency diagram ........................................................................................................................ - 16 - 2. System overview.......................................................................................................................................... - 17 - 2.1 Interior ............................................................................................................................................... - 17 - 2.1.1 PSU ................................................................................................................................................... - 18 - 2.1.2 RRFU ................................................................................................................................................. - 18 - 2.1.3 MUX ................................................................................................................................................. - 18 - 2.1.4 PA ...................................................................................................................................................... - 18 - 2.1.5 Carrier board .................................................................................................................................. - 18 - 2.1.6 DTU ................................................................................................................................................... - 18 - 2.2 External Interface ................................................................................................................................. - 19 - 2.2.1 AC INPUT .................................................................................................................................... - 20 - 2.2.2 EXTERNAL NFPA ALARM ................................................................................................... - 20 - 2.2.3 NAMEPLATE WITH UL MARK .......................................................................................... - 21 - 2.2.4 ETHERNET .................................................................................................................................. - 22 - 2.2.5 BLUETOOTH ANT ................................................................................................................... - 22 - 2.2.6 BACKUP BATTERY .................................................................................................................. - 23 - 2.2.7 RF port ......................................................................................................................................... - 24 - 2.2.8 Grounding .................................................................................................................................. - 24 - 2.3 Function features .................................................................................................................................. - 25 - - 4 - User’s manual_v01 2.3.1 ICS ..................................................................................................................................................... - 25 - 2.3.2 Isolation measurement ............................................................................................................... - 25 - 2.3.3 Antenna monitoring ................................................................................................................. - 26 - 2.3.4 Single / Dual band ..................................................................................................................... - 26 - 2.3.5 Channel filter .............................................................................................................................. - 27 - 2.3.6 Spectrum analyzing .................................................................................................................. - 27 - 2.3.7 External backup battery monitoring .................................................................................... - 27 - 3. INSTALLATION ........................................................................................................................................ - 28 - 3.1 Outdoor Installation ............................................................................................................................ - 28 - 3.2 Indoor Installation ................................................................................................................................ - 28 - 3.3 Cable Installation Planning ................................................................................................................ - 28 - 3.4 Mounting and Installation ............................................................................................................ - 29 - 4. Connecting WEB GUI .................................................................................................................................. - 30 - 4.1 Recommended specs to client ....................…

Text truncated - open the document above for the full version.

TJ INNOVATION.LTD 2018, Sambo Techno-tower 122, Jomaru-ro385beon-gil, Bucheon-si, Korea DATE: Feb. 13, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Subject: Letter for Warning Label Message FCC ID: 2AVNP-PSR-9536-A To Whom It May Concern: Warning label messages will be also shown in online and point-of-sale marketing materials and on outside packaging of device per KDB 935210 D02 Signal Boosters Certification v04r02 in Section V clause (g). Best Regards Company Name: TJ INNOVATION.LTD Contact Name / Title: Hyung Gyu Kim, Manager

Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Agent Authorization Letter Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 2.3 Fixed Typo “Agent” 11/09/2017 QM TJ INNOVATION.LTD HACS-F004 FCC Agent Authorization Letter Rev : 2.3 DATE: Feb.13, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To whom it may concern: Subject : FCC Agent Authorization Letter for FCC ID: 2AVNP-PSR-9536-A We, the undersigned, hereby authorize HCT CO., LTD. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by HCT CO., LTD. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). We recognize that we are still responsible for the terms and conditions outlined in the HCT America Client Services Agreement. This authorization is valid until further written notice from the applicant. Sincerely, Signed by: Company Name: TJ INNOVATION.LTD Contact Name / Title: Hyung Gyu Kim, Manager

Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Confidentiality Request Letter Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 3.0 Updated LTC and STC Confidentiality table 11/09/2017 QM TJ INNOVATION.LTD HACS-F003 FCC Confidentiality Request Letter Rev : 3.0 DATE: Feb.13, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD SUBJECT: Request for Confidentiality for FCC ID: 2AVNP-PSR-9536-A We hereby request confidential treatment of the information accompanying this application as outlined below: LONG-TERM AND SHORT-TERM CONFIDENTIAL LIST LONG-TERM CONFIDENTIAL Exhibit Description 1 Block Diagram 2 Operational Description 3 Parts List & Tune up procedure 4 Schematics SHORT-TERM CONFIDENTIAL (180 DAYS) 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signed by: Company Name: TJ INNOVATION.LTD Contact Name / Title: Hyung Gyu Kim, Manager TJ INNOVATION.LTD HACS-F003 FCC Confidentiality Request Letter Rev : 3.0

FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 7 EXTERNAL PHOTOGRAPHS FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 7 ■ EXTERNAL PHOTO( Top ) FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 7 ■ EXTERNAL PHOTO( Bottom ) FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 7 ■ EXTERNAL PHOTO( Left ) FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 7 ■ EXTERNAL PHOTO( Right ) FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 7 ■ EXTERNAL PHOTO( Front ) FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 7 ■ EXTERNAL PHOTO( Rear ) 12345 6 78910 1 AC input port 2 NFPA alarm port 3 Nameplate 4 Ethernet 5 Reserved 6 Backup battery port 7 Donor antenna port 8 Donor coupling port 9 Service antenna port 10 Service coupling port

FCC/IC label & location (Class A) Model : PSR9536A_HV01 FCC ID : 2AVNP-PSR-9536-A IC : 25851-PSR9536A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Part 90 Signal booster This is A 90.219 CLASS A DEVICE WARNING:This is NOT a CONSUMER device. It is designed for installation by an installer approved by an ISED licensee. You MUST have an ISED LICENCE or the express consent of an ISED licensee to operate this device. ② ③ ① ④

FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 5 INTERNAL PHOTOGRAPHS FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 5 ■ Main view Actual view 1 2 3 4 5 6 7 PSU PSR-RFU PSR-Carrier Board PSR-DTU PSR-enclosure PSR-harness (not described in the picture) PSR-PLL (installed inside RFU) Integrated All-in-one module 1 2 3 4 5 6 7 PSU PSR-RFU PSR-Carrier Board PSR-DTU PSR-enclosure PSR-harness (not described in the picture) PSR-PLL (installed inside RFU) Integrated All-in-one module Design drawing  PSU : Power Supply Unit  PLL : Phase Locked Loop module inside RFU  RFU : RF Unit  DTU : Digital Unit FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 5 ■ PSU [PSU] TOP VIEW [PSU] INNER VIEW 1 [PSU] FRONT VIEW AC switch 2 AC input terminal 3 Alarm LED display 4 DC output terminal 5 Battery switch 6 Battery input terminal 123456 FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 5 ■ RFU [RFU] TOP VIEW 1 DC-DC conversion unit 2 PLL 3 Uplink PA unit 4 Multiplexer_Donor 5 Donor ANT port 6 Donor coupling port 12 34 56 [RFU] FRONT VIEW [RFU] REAR VIEW 8 9 10 7 56810 11 7 Downlink PA unit (PS700) 8 Service ANT port 9 Downlink PA unit (PS800) 10 Service coupling port 11 DC input port FCC ID: 2AVNP-PSR-9536-A, IC: 25851-PSR9536A HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 5 ■ Carrier board & DTU 1 DC input port 2 RF port for modem 3 Dry contact port 4 Door alarm port 5 Backup battery port 6 RF port (reserved) 7 RF port (reserved) 8 USIM port 1 2 3 4 5 6 7 8 1 UL DAC 2 DL ADC 3 UL ADC 4 DL DAC 5 FPGA (bottom side) 6 REF CLK_10MHz 7 DEBUG port Carrier boardDTU Carrier boardDTU 123456 7

HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 On your side TEST REPORT FCC MPE Test for PSR-9536-A Certification APPLICANT TJ innovation Co., Ltd. REPORT NO. HCT-RF-2002-FC002-R1 DATE OF ISSUE February 20, 2020 Report No. HCT-RF-2002-FC002-R1 F-TP22-03 (Rev. 02) Page 3 of 6 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of IssueDescription 0 February 12, 2020Initial Release 1 February 20, 2020Revised antenna gain. The result shown in this test report refer only to the sample(s) tested unless otherwise stated. The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules under normal use and maintenance. Report No. HCT-RF-2002-FC002-R1 F-TP22-03 (Rev. 02) Page 4 of 6 RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 1.34 - 30 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 30 - 300 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 300 - 1500 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 1500 - 100.000 ̆ ̆ ̆ ̆ ̆ ̆ 614 824/f 27.5 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ 1.63 2.19/f 0.073 ̆ ̆ ̆ ̆ ̆ ̆ ̆ ̆ *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Report No. HCT-RF-2002-FC002-R1 F-TP22-03 (Rev. 02) Page 5 of 6 - PS700 ˊ(Uplink) Max Peak output Power at antenna input terminal 31.00 dBm Max Peak output Power at antenna input terminal 1258.93 mW Prediction distance 40.00 cm Prediction frequency 769.003125 MHz Antenna Gain(typical) 5.900 dBi Antenna Gain(numeric) 3.890 - Power density at prediction frequency( S) 0.2436 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5127 mW/cm 2 - PS700 ˊ (Downlink) Max Peak output Power at antenna input terminal 34.00 dBm Max Peak output Power at antenna input terminal 2511.89 mW Prediction distance 40.00 cm Prediction frequency 799.003125 MHz Antenna Gain(typical) 2.900 dBi Antenna Gain(numeric) 1.950 - Power density at prediction frequency( S) 0.2436 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5327 mW/cm 2 Report No. HCT-RF-2002-FC002-R1 F-TP22-03 (Rev. 02) Page 6 of 6 - PS800 ˊ (Uplink) Max Peak output Power at antenna input terminal 31.00 dBm Max Peak output Power at antenna input terminal 1258.93 mW Prediction distance 40.00 cm Prediction frequency 851.003125 MHz Antenna Gain(typical) 5.900 dBi Antenna Gain(numeric) 3.890 - Power density at prediction frequency( S) 0.2436 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5673 mW/cm 2 - PS800 ˊ(Downlink) Max Peak output Power at antenna input terminal 34.00 dBm Max Peak output Power at antenna input terminal 2511.89 mW Prediction distance 40.00 cm Prediction frequency 806.003125 MHz Antenna Gain(typical) 2.900 dBi Antenna Gain(numeric) 1.950 - Power density at prediction frequency( S) 0.2436 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.5373 mW/cm 2

HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 634 6300 F ax. +82 31 645 6401 On your side FCC Test for PSR-9536-A Certification APPLICANT TJ innovation Co., Ltd. REPORT NO. HCT-RF-2002-FC001-R2 DATE OF ISSUE February 27, 2020 Report No. HCT-RF-2002-FC001-R2 Page 3 of 77 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 February 12, 2020 Initial Release 1 February 20, 2020 Revised antenna peak gain on page 5. 2 February 27, 2020 Revised uplink and downlink frequency on page 5, page 7 The result shown in this test report refer only to the sample(s) tested unless otherwise stated. The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules under normal use and maintenance. Report No. HCT-RF-2002-FC001-R2 Page 4 of 77 CONTENTS 1. GENERAL INFORMATION 5 1.1. APPLICANT INFORMATION 5 1.2. PRODUCT INFORMATION 5 1.3. TEST INFORMATION 5 2. TEST STANDARDS 6 3. TEST SPECIFICATIONS 7 3.1. ADDITIONAL DESCRIPTIONS ABOUT TEST 7 3.2. MEASUREMENTUNCERTAINTY 9 3.3. STANDARDS ENVIRONMENTAL TEST CONDITIONS 9 3.4. TEST DIAGRAMS 10 4. TEST EQUIPMENTS 11 5. TEST RESULT 12 5.1. AGC THRESHOLD 12 5.2. OUT-OF-BAND REJECTION 14 5.3. OCCUPIED BANDWIDTH 18 5.4. INPUT-VERSUS-OUTPUT SIGNAL COMPARISON 40 5.5. INPUT/OUTPUT POWER AND AMPLIFIER/BOOSTER GAIN 53 5.6. NOISE FIGURE 57 5.7. OUT-OF-BAND/OUT-OF-BLOCK EMISSIONS AND SPURIOUS EMISSIONS 59 5.8. RADIATED SPURIOUS EMISSIONS 74 6. Annex A_EUT AND TEST SETUP PHOTO 77 Report No. HCT-RF-2002-FC001-R2 Page 5 of 77 1. GENERAL INFORMATION 1.1. APPLICANT INFORMATION Company Name TJ innovation Co., Ltd. Company Address 2018, Sambo Techno-tower 122, Jomaru-ro 385beon-gil, Bucheon-si, Gyeonggi-do, Korea 1.2. PRODUCT INFORMATION EUT Type Public Safety Repeater (PSR-9536) EUT Serial Number PSR-9536-A-2002-0001 Power Supply Input : (110 ~ 240) Vac or DC +30.3V, +6.2V Output(Voltage, Current) : 30.3V/3.9A, 10A DC rating: 177W Frequency Range PS700: 799 MHz ~ 805 MHz(Uplink), 769 MHz ~ 775 MHz(Downlink) PS800: 806 MHz ~ 816 MHz(Uplink), 851 MHz ~ 861 MHz(Downlink) Tx Output Power Uplink : 30 dBm / Downlink : 33 dBm Antenna Peak Gain Downlink (service side) : Omni antenna, Gain: 2.9dBi Uplink (donor side) : Panel antenna, Gain: 5.9dBi 1.3. TEST INFORMATION FCC Rule Parts Part 2, Part 90 Measurement Standards KDB 935210 D05 v01r03, ANSI C63.26-2015 Test Location HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA Report No. HCT-RF-2002-FC001-R2 Page 6 of 77 2. TEST STANDARDS The following tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 2, 90. Description Reference AGC threshold KDB 935210 D05 v01r03 3.2 KDB 935210 D05 v01r03 4.2 Out-of-band rejection KDB 935210 D05 v01r03 3.3 KDB 935210 D05 v01r03 4.3 Occupied Bandwidth §2.1049 §90.219(e)(4)(ii) Input-versus-output signal comparison §90.210, §90.219(e)(4)(iii) Input/output power and amplifier/booster gain §2.1046, §90.219, §90.541, §90.635 Noise figure §90.219(e)(2) Emission masks Out-of-band/out-of-block emissions and spurious emissions §2.1051, §90.219(e)(3) Spurious emissions radiated §2.1053 Report No. HCT-RF-2002-FC001-R2 Page 7 of 77 3. TEST SPECIFICATIONS 3.1. ADDITIONAL DESCRIPTIONS ABOUT TEST Except for the following cases, EUT was tested under normal operating conditions. : Out-of-band rejection test requires maximum gain condition without AGC : Noise figure test requires any AGC circuitry be disabled over the duration of the measurement. This EUT is supported power supply both of AC and DC. Test results are only attached worst cases. The test was generally based on the method of KDB 935210 D05 v01r03 and only followed ANSI C63.26-2015 if there was no test method in KDB standard. EUT was tested with following modulated signals provide by applicant. Band Name Link Frequency Tested signals PS700 Uplink (799 ~ 805) MHz P25 Phase 1, P25 Phase 2, TETRA Downlink (769 ~ 775) MHz PS800 Uplink (806 ~ 816) MHz P25 Phase 1, P25 Phase 2, TETRA Downlink (851 ~ 861) MHz Below channels greater than 25 kHz in EUT specification are not tested because it could consist of a combination of P25 Phase 1, P25 Phase 2 and TETRA signals. Channelizing P25 Phase 1 combinations P25 Phase 2 combinations TETRA combinations 50 kHz n = 4 n = 8 n = 2 75 kHz n = 6 n = 12 n = 3 The frequency stability measurement has been omitted in accordance with section 3.7 of KDB 935210 D05 v01r03. : It can be confirmed through input-versus-output spectrum test that EUT does not alter the input signal. The tests results included actual loss value for attenuator and cable combination as shown in the table below. : Input Path Correction factor table Frequency (MHz) Factor (dB) Frequency (MHz) Factor (dB) 600 0.723 850 0.756 700 0.763 900 0.728 750 0.756 1 000 0.739 800 0.795 1 050 0.703 Report No. HCT-RF-2002-FC001-R2 Page 8 of 77 : Output Path Correction factor table Frequency (MHz) Factor (dB) Frequency (MHz) Factor (dB) 30 29.772 1500 31.413 50 29.780 2000 31.603 100 29.858 2500 31.931 150 29.939 3000 32.272 200 30.053 3500 32.387 250 30.195 4000 32.685 300 30.409 4500 32.517 350 30.491 5000 32.662 400 30.536 5500 33.296 450 30.532 6000 33.361 500 30.682 6500 34.388 550 30.602 7000 33.551 600 30.773 7500 33.924 650 30.819 8000 33.681 700 30.855 8500 33.775 750 30.842 9000 34.452 800 30.878 850 30.890 900 30.890 950 30.947 1000 30.920 Report No. HCT-RF-2002-FC001-R2 Page 9 of 77 3.2. MEASUREMENTUNCERTAINTY Description Refere…

Text truncated - open the document above for the full version.

Report No. HCT-RF-2002-FC001-R2 Page 52 of 77 Input / PS800 / P25 Phase 1 / Downlink / Mask D 3 dB above the AGC threshold Output / PS800 / P25 Phase 1 / Downlink / Mask D Report No. HCT-RF-2002-FC001-R2 Page 53 of 77 5.5. INPUT/OUTPUT POWER AND AMPLIFIER/BOOSTER GAIN Test Requirement: §2.1046 Measurements required: RF power output. (a) For transmitters other than single sideband, independent sideband and controlled carrier radiotelephone, power output shall be measured at the RF output terminals when the transmitter is adjusted in accordance with the tune-up procedure to give the values of current and voltage on the circuit elements specified in §2.1033(c)(8). The electrical characteristics of the radio frequency load attached to the output terminals when this test is made shall be stated. (b) For single sideband, independent sideband, and single channel, controlled carrier radiotelephone transmitters the procedure specified in paragraph (a) of this section shall be employed and, in addition, the transmitter shall be modulated during the test as specified and applicable in § 2.1046 (b) (1-5). In all tests, the input level of the modulating signal shall be such as to develop rated peak envelope power or carrier power, as appropriate, for the transmitter. (c) For measurements conducted pursuant to paragraphs (a) and (b) of this section, all calculations and methods used by the applicant for determining carrier power or peak envelope power, as appropriate, on the basis of measured power in the radio frequency load attached to the transmitter output terminals shall be shown. Under the test conditions specified, no components of the emission spectrum shall exceed the limits specified in the applicable rule parts as necessary for meeting occupied bandwidth or emission limitations. §90.219 Use of signal boosters. (e) Device Specifications. In addition to the general rules for equipment certification in §90.203(a)(2) and part 2, subpart J of this chapter, a signal booster must also meet the rules in this paragraph. (1) The output power capability of a signal booster must be designed for deployments providing a radiated power not exceeding 5 Watts ERP for each retransmitted channel. §90.541 Transmitting power and antenna height limits. The transmitting power and antenna height of base, mobile, portable and control stations operating in the 769-775 MHz and 799-805 MHz frequency bands must not exceed the maximum limits in this section. Power limits are listed in effective radiated power (ERP). (a) The transmitting power and antenna height of base stations must not exceed the limits given in paragraph (a) of §90.635. Report No. HCT-RF-2002-FC001-R2 Page 54 of 77 §90.635 Limitations on power and antenna height. (a) The effective radiated power and antenna height for base stations may not exceed 1 kilowatt (30 dBw) and 304 m. (1,000 ft.) above average terrain (AAT), respectively, or the equivalent thereof as determined from the Table. These are maximum values, and applicants will be required to justify power levels and antenna heights requested. TableˋEquivalent Power and Antenna Heights for Base Stations in the 851-869 MHz and 935-940 MHz Bands Which Have a Requirement for a 32 km (20 mi) Service Area Radius Antenna height (ATT) meters (feet) Effective radiated power (watts) Above 1,372 (4,500) 65 Above 1,220 (4,000) to 1,372 (4,500) 70 Above 1,067 (3,500) to 1,220 (4,000) 75 A…
