2AVQ6-HY0025Homey Pro (Early 2023)

Athom B.V.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 20, 2023
Application Purpose: Original Equipment
Date of Application: Jul 18, 2023
Equipment Note: Homey Pro (Early 2023)
Frequency Range: 2405.00000000 - 2480.00000000
Company: Athom B.V.
Country: Netherlands

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Welcome home. Quick Start Guide Welcome home. Let us help you quickly set up Homey Pro, so you can explore and start having fun right away. Let Homey Pro be the center of your home Consider the position of Homey Pro well, as the place in your home affects its performance. To control Infrared devices, Homey Pro requires to have a direct line of sight with the device. Avoid exposing Homey Pro to direct sunlight for optimal performance. Lass Homey Pro zum Mittelpunkt deines Heims werden Überlege dir die Position von Homey Pro gut, denn der Platz in deinem Heim beeinfl usst seine Leistung. Um Infrarotgeräte zu steuern, muss sich Homey Pro in Sichtweite zum Gerät befi nden. Für optimale Leistung von Homey Pro, Sonneneinstrahlung vermeiden. DE Deja que Homey Pro sea el centro de la casa Piensa bien en qué lugar de la casa vas a colocar el Homey Pro, ya que su posición afectará a su funcionamiento. Para controlar dispositivos de infrarrojos, no puede haber ningún obstáculo entre ellos y el Homey Pro. Evita exponer Homey Pro a la luz solar directa para un rendimiento óptimo. ES Mettez Homey Pro au cœur de votre maison Réfl échissez bien à la position de votre Homey Pro, car son emplacement dans votre maison a un impact sur sa performance. Pour commander des appareils à infrarouge, il ne doit pas y avoir d’obstacle entre Homey Pro et l’appareil. Pour une performance optimale de Homey Pro, évitez la lumière directe du soleil. FR Position in your home Give Homey Pro a little space Homey Pro performs best when it’s free and not obstructed by its direct environment. Placing objects on top of Homey Pro might reduce performance (e.g. blocking Infrared signals). Gib Homey Pro etwas Platz Die beste Leistung erbringt Homey Pro in Freiheit und ohne Behinderung durch die direkte Umgebung. Das Positionieren von Objekten auf Homey Pro kann die Leistung beeinträchtigen (z.B. Blockieren von Infrarotsignalen). DE Deja espacio al Homey Pro Homey Pro funciona mejor cuando está en un entorno abierto y no tiene obstáculos a su alrededor. Si se colocan objetos encima del Homey Pro, podrían reducir su rendimiento (por ejemplo, bloqueando las señales infrarrojas). ES Donnez un peu d’espace à Homey Pro Homey Pro fonctionne mieux quand il est dans un endroit dégagé et non obstrué par son environnement direct. Placer des objets sur Homey Pro peut dégrader sa performance (par exemple en bloquant les signaux infrarouges). FR Surrounding Plug the USB-C cable into Homey Pro and the adapter Connect Homey Pro to your power socket and Homey Pro will automatically turn on. The LED ring will turn white to confi rm Homey Pro is starting. Verbinde das USB-Kabel mit Homey Pro und dem Adapter Verbinde Homey Pro mit der Steckdose und warte auf das automatische Einschalten. Der LED-Ring wird weiß, um zu bestätigen, dass Homey Pro funktioniert. DE Enchufa el cable USB al Homey Pro y al adaptador Conecta el Homey Pro al enchufe de red: el dispositivo se encenderá automáticamente. El anillo LED se volverá de color blanco para confi rmar que el Homey Pro está en funcionamiento. ES Branchez le câble USB à Homey Pro et à l’adaptateur Connectez Homey Pro à votre prise de courant et Homey s’allumera automatiquement. L’anneau LED s’allumera en blanc pour confi rmer que Homey Pro fonctionne. FR Installing Homey Pro Download the Homey app Go to https://setup.homey.app or scan the QR code on the back of this guide. After installing and creating your account, we’ll guide you through the setup process on your phone. Lade die Homey-App herunter Gehe zu https://setup. homey.app oder scanne den QR-Code auf der Rückseite dieses Leitfadens. Nach der Installation und Erstellung deines Kontos führen wir dich auf deinem Telefon durch den Einrichtungsvorgang. DE Descarga la aplicación de Homey Ve a https://setup.homey.app o escanea el código QR del reverso de esta guía. Cuando hayas instalado la aplicación y creado tu cuenta, te guiaremos por el proceso de configuración a través del teléfono. ES Télécharger l’appli Homey Rendez-vous sur https://setup. homey.app ou scannez le code QR au dos de ce guide. Après avoir installé l’appli et avoir créé votre compte, nous vous guiderons à travers les étapes de configuration sur votre téléphone. FR Get the Homey app Safety and handling Important safety information Handle Homey Pro with care. It contains sensitive electronic components, and can be damaged, impair functionality, or cause injury if dropped, burned, punctured, crushed, disassembled, or if exposed to excessive heat or liquid or to environments having high concentrations of industrial chemicals, including near evaporating liquifi ed gasses. Don’t use a damaged Homey Pro. Power supply Only use Homey Pro with an adapter that is compliant with applicable country regulations and safety standards, including the International Standard for Safety of Information Technology Equipment (IEC 62368-1), with a minimal output rating of 5V/2A (10W). Powering Homey Pro with other power adapters that may not meet applicable safety standards could pose a risk of death or injury. Using damaged cables or adapters, or a moist environment, can cause fi re, electric shock, injury, or damage to Homey Pro or other property. Prolonged heat exposure Avoid prolonged skin contact with the device, power adapter, charging cable or connector when plugged into a power source, as it may cause discomfort or injury. Medical device interference Homey Pro contains components and radios that emit electromagnetic fi elds. These electromagnetic fi elds should not, but may possibly interfere with pacemakers, defi brillators, or other medical devices. Maintain a safe distance of separation between your medical device and Homey Pro. Consult your physician and medical device manufacturer for information specifi c to your medical device, including radio immunity. Stop using Homey Pro if you suspect it might be interfering with your medical device. Support For support and troubleshooting information, and …

Text truncated - open the document above for the full version.

Attestation Statements

COMPANY LETTERHEAD Covered Equipment Certification Attestation Letter 6/13/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AVQ6-HY0025 Athom B.V. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Athom B.V. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Emile Nijssen Title: Creative Director Company Name: Athom B.V. Date: 6/13/2023

Attestation Statements

COMPANY LETTERHEAD * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 6/27/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AVQ6HY0025 Per section 2.911(d)(7) of the FCC rules, Athom B.V. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Federal Registration Number (FRN): 0033401829 Company Name: EMCTEK Physical U.S. Company Address: 11788 Big Canyon Ln, San Diego, CA 92131 USA Agent name: Fang Liu Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: OR Agent Signed: Signed: Signed: Printed name: Emile Nijssen Printed name: Fang Liu Title: Creative Director Title: Director Company Name: Athom B.V. Company Name: EMCTEK Date: 6/13/2023 Date: 6/27/2023 FCC ID: 2AVQ6-HY0025

Cover Letter(s)

COMPANY LETTERHEAD July 13, 2023 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: 2AVQ6-HY0025 Pursuant to Sections 0.457(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request permanent confidential treatment of exhibits identified as such in the table below and request they are permanently withheld from public review based on the documents containing trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. We also request short-term confidentiality on certain exhibits until the intended date of marketing as outlined below. We request the exhibits be withheld from public view for a period of 180 days. We attest marketing of the product will only commence after the period of short-term confidentiality expires, or if marketing is to commence before the requested number of days listed above, the grantee will inform Nemko to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. Exhibit Type of Confidentiality Requested Block Diagrams ☒ Permanent ☐ Short Term External Photos ------------------ ☒ Short Term Internal Photos ☐ Permanent* ☒ Short Term Operation Description ☒ Permanent ☐ Short Term Parts List & Placement/BOM ☐ Permanent ☐ Short Term Tune-Up Procedure ☐ Permanent ☐ Short Term Schematic Diagrams ☒ Permanent ☐ Short Term Test Setup Photos ------------------ ☒ Short Term User’s Manual ☐ Permanent* ☒ Short Term The asterisked items (*) require further information to be provided in this justification letter before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. Note: any documents held under the Short-Term confidentiality will automatically become public after the requested time if an appropriate extension request has not been received. Any exhibits (i.e., schematic diagrams) that may have already been requested to have “Permanent” confidentiality as shown above need not be repeated under Short-Term confidentiality request. Sincerely, Signed: Printed name: Emile Nijssen Title: Creative Director Company Name: Athom B.V.

RF Exposure Info

CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel: +86-755-27521059 Fax: +86-755-27521011 http://www.sz-ctc.org.cn CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn Maximum Permissible Exposure Evaluation FCC ID: 2AVQ6-HY0025 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) EUT Specification Product Name: Smart home hub Trade Mark: Homey Pro Model/Type reference: HY0025 Listed Model(s): / Frequency band (Operating) BT: 2.402GHz ~ 2.480GHz 2.4G WiFi: 2.412GHz ~ 2.462GHz 5G WiFi: 5.150GHz ~ 5.350GHz, 5.470GHz ~ 5.850GHz Zigbee: 2.405GHz ~ 2.480GHz Z-Wave LR: 912MHz, 920MHz Z-Wave: 908.42MHz, 916MHz Device category Portable (<5mm separation) Mobile (>20cm separation) Fixed (>20cm separation) Others ___ Exposure classification Occupational/Controlled exposure (S=5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversity Single antenna Multiple antenna Tx diversity Rx diversity Tx/Rx diversity Antenna gain (Max) BT / 2.4G WiFi: 3.5dBi 5G WiFi: 2.5dBi Zigbee: 1dBi Z-Wave LR / Z-Wave: 2dBi Evaluation applied MPE Evaluation SAR Evaluation Page 2 of 3 Report No.: CTC20222084E10 CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500 -- -- F/300 6 1500-100000 -- -- 5 6 (B) Limits for General Population/Uncontrol Exposures 300-1500 -- -- F/1500 6 1500-100000 -- -- 1 30 Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout= output power to antenna in mW G= gain of antenna in linear scale Pi= 3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Zigbee - Worst case Type Frequency (MHz) Max. Measured Power (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/cm 2 ) Power density Limit (mW/cm 2 ) OQPSK 2480 6.76 7.00 1 0.00126 1 Z-Wave LR - Worst case Type Frequency (MHz) Max. Measured Power (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/cm 2 ) Power density Limit (mW/cm 2 ) OQPSK 912 0.20 0.50 2 0.00035 0.6 Z-Wave - Worst case Type Frequency (MHz) Max. Measured Power (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/cm 2 ) Power density Limit (mW/cm 2 ) FSK/GFSK 908.42 -0.16 0.00 2 0.00032 0.6 Page 3 of 3 Report No.: CTC20222084E10 CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn BT - Worst case Type Frequency (MHz) Max. Measured Power (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/cm 2 ) Power density Limit (mW/cm 2 ) GFSK 2440 4.71 5.00 3.5 0.00141 1 2.4G WiFi - Worst case Type Frequency (MHz) Max. Measured Power (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/cm 2 ) Power density Limit (mW/cm 2 ) 802.11 g 2437 15.37 15.50 3.5 0.01580 1 5G WiFi - Worst case Type Frequency (MHz) Max. Measured Power (dBm) Max. Tune up Power (dBm) Antenna Gain (dBi) Power density at 20cm (mW/cm 2 ) Power density Limit (mW/cm 2 ) 802.11 n(HT40) 5670 18.22 18.50 2.5 0.02505 1 Zigbee, Z-Wave, BT, WiFi can transmit simultaneously. Type Frequency (MHz) Power density at 20cm (mW/cm 2 ) Total Power density at 20cm Power density Limit Zigbee 2480 0.00126 0.02830 1 Z-Wave LR 912 0.00035 BT 2440 0.00141 WiFi 5670 0.02505 Note: 1. Calculate by Worst-case mode 2. Max. Tune Up Power by Manufacturer's Declaration, and Max. Tune Up Power is used to calculate. 3. For a more detailed features description, please refer to the RF Test Report. **********************THE END**********************

Test Report

NOTE:ThisdocumentisissuedbyShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,thetestreportshallnotbereproducedexceptin fullwithoutpriorwrittenpermissionofthecompany.Thetestresultsapplyonlytotheparticularsample(s)testedandtothespecifictestscarried outwhichisavailableonrequestforvalidationandinformationconfirmedatourwebsite. MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page1of 17 REPORTNo.：SZ23040110E01 TESTREPORT APPLICANT:AthomB.V. PRODUCTNAME:Smarthomehub MODELNAME:HY0025 TRADENAME:HomeyPro BRANDNAME:N/A STANDARD(S):IEEEStd149-2021 RECEIPTDATE:2023-04-07 TESTDATE:2023-04-10 ISSUEDATE:2023-07-10 Editedby: FangJinshan(Rapporteur) Approvedby: ChiShide(Supervisor) MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page2of17 REPORTNo.：SZ23040110E01 DIRECTORY 1.TechnicalInformation ·········································································································3 1.1.ApplicantandManufacturerInformation ······································································3 1.2.EquipmentUnderTest(EUT)Description····································································3 2.TestResults··························································································································4 2.1.AppliedReferenceDocuments·······················································································4 2.2.TestConditions·················································································································4 2.3.MeasurementUncertainty·······························································································4 2.4.TestResultslists··············································································································5 AnnexATestSetupPhotos···································································································6 AnnexBFigures ······················································································································7 1.2DRadiationPattern ·············································································································7 2.3DRadiationPattern ···········································································································10 AnnexCEUTPhotos ············································································································13 AnnexDGeneralInformation ······························································································17 1.1IdentificationoftheResponsibleTestingLaboratory··············································17 1.2IdentificationoftheResponsibleTestingLocation··················································17 1.3TestEquipmentsUtilized·······························································································17 ChangeHistory VersionDateReasonforchange 1.02023-07-10Firstedition MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page3of17 REPORTNo.：SZ23040110E01 1.TechnicalInformation Note:Providebyapplicant. 1.1.ApplicantandManufacturerInformation Applicant: AthomB.V. ApplicantAddress: OudeMarkt9b,7511GAEnschede,Netherlands. Manufacturer: AthomB.V. ManufacturerAddress: OudeMarkt9b,7511GAEnschede,Netherlands. 1.2.EquipmentUnderTest(EUT)Description WirelessTypeN/A FrequencyN/A IMEIN/A SampleNo.1# MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page4of17 REPORTNo.：SZ23040110E01 2.TestResults 2.1.AppliedReferenceDocuments Leadingreferencedocumentsfortesting: No.IdentityDocumentTitle 1IEEEStd149-2021 IEEERecommendedPracticeforAntenna Measurements 2.2.TestConditions TestEnvironmentConditions ： RelativeHumidity(%):25-75 Temperature(°C):10-30 2.3.MeasurementUncertainty Theuncertaintyiscalculatedusingthemethodssuggestedinthe"GuidetotheExpressionof UncertaintyinMeasurement"(GUM)publishedbyISO.Whenthetestresultisacriticalvalue,we willusethemeasurementuncertaintygivethejudgmentresultbasedonthe95%Confidence intervals. MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page5of17 REPORTNo.：SZ23040110E01 2.4.TestResultslists 2.4.1.EfficiencyandGain Z-WAVEAntenna Frequency (MHz) Efficiency(%) Gain(dBi) 86810.9-4.8 870 10.9-4.8 890 11.9-4.3 90014.0-3.8 91016.1-3.5 914 16.9-3.3 920 18.2-3.2 92218.6-3.2 92318.9-3.2 ZigbeeAntenna Frequency (MHz) Efficiency(%) Gain(dBi) 240033.31.0 241031.60.8 2420 30.20.6 243028.30.3 244028.20.3 245027.60.2 2460 26.60.1 247025.80.1 248024.7-0.1 249024.1-0.2 2500 24.1-0.1 MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page6of17 REPORTNo.：SZ23040110E01 AnnexATestSetupPhotos MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE…

Text truncated - open the document above for the full version.

Test Report

CTC Laboratories, Inc. $CNAS$ 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China Tel : +86-0755-27521059 Fax: +86-0755-27521011 http://www.sz-ctc.org.cn TEST REPORT Report No. ··························: CTC20222084E07 FCC ID.................................: 2AVQ6-HY0025 IC........................................: 25905-HY0025 Applicant····························: Athom B.V. Address·······························: Oude Markt 9b, 7511GA Enschede, Netherlands. Manufacturer························: Athom B.V. Address·······························: Oude Markt 9b, 7511GA Enschede, Netherlands. Product Name······················: Smart home hub Trade Mark···························: Homey Pro Model/Type reference·············: HY0025 Listed Model(s) ·····················: / Standard·····························: FCC CFR Title 47 Part 15 Subpart C Section 15.247 RSS-247 Issue 2 Date of receipt of test sample...: Nov. 16, 2022 Date of testing.......................: Nov. 16, 2022 to Apr. 23, 2023 Date of issue.........................: May 19, 2023 Result.................................: PASS Compiled by: (Printed name+signature) Jim Jiang Supervised by: (Printed name+signature) Eric Zhang Approved by: (Printed name+signature) Totti Zhao $英文检测章$ $Totti$ This test report may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CTC. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CTC within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. The test report merely correspond to the test sample. Page 2 of 41 Report No.: CTC20222084E07 CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn Table of Contents Page 1. TEST SUMMARY ..........................................................................................................................................................3 1.1. TEST STANDARDS .............................................................................................................................................................3 1.2. REPORT VERSION ............................................................................................................................................................3 1.3. TEST DESCRIPTION ...........................................................................................................................................................3 1.4. TEST FACILITY .................................................................................................................................................................4 1.5. MEASUREMENT UNCERTAINTY ...........................................................................................................................................4 1.6. ENVIRONMENTAL CONDITIONS ...........................................................................................................................................5 2. GENERAL INFORMATION .............................................................................................................................................6 2.1. CLIENT INFORMATION ......................................................................................................................................................6 2.2. GENERAL DESCRIPTION OF EUT .........................................................................................................................................6 2.3. ACCESSORY EQUIPMENT INFORMATION ...............................................................................................................................7 2.4. OPERATION STATE ...........................................................................................................................................................8 2.5. MEASUREMENT INSTRUMENTS LIST ....................................................................................................................................9 3. TEST ITEM AND RESULTS ........................................................................................................................................... 11 3.1. CONDUCTED EMISSION ...................................................................................................................................................11 3.2. RADIATED EMISSION ......................................................................................................................................................14 3.3. BAND EDGE EMISSIONS (RADIATED) .................................................................................................................................22 3.4. BAND EDGE AND SPURIOUS EMISSIONS (CONDUCTED) ......................................................................................................... 27 3.5. DTS BANDWIDTH ..........................................................................................................................................................33 3.6. PEAK OUTPUT POWER ...................................................................................................................................................36 3.7. POWER SPECTRAL DENSITY ...........................................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Emile Nijssen(Creative Director)

[email protected]0640923136Fax: 0640923136

Test Firm

CTC Laboratories, Inc.Totti Zhao

[email protected]+8675527521059

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
3	15C	2.40 GHz - 2.48 GHz	4.74 mW

Confidentiality

Long Term

Grant Notes

Output power is conducted. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance.
