2AVSB-IC-10AQWireless car charger

Specifications Input: DC 9V/2.5A,5V/2A Output: 15W Max Product Standard: Qi2 Product Dimension: 59.3*30.2*59.3 mm Product Material: ABS+PC+Tempered Glass Charging Distance: 10mm Charging Efficiency: 80% IC-10AQ 15W产品说明书 User Manual Product Features Product Operating Guide Attention 1.Please do not vigorously extrude or collide. 2.Please do not dismantle or put it into fire or water when the product is power on,to avoid short circuit or leakage. 3.Please do not use it in severely high temperature,high humidity or corrosive environment,to avoid damage to the circuit leakage. 4.Please do not put the magnetic strip or chip card (Such as ID card,bankcard etc.)on the charging pad to avoid to cause magneticcard lose efficacy. 5.Please do not put the metal (Such as coin etc.) on the charging pad when charging,to avoid damage from heating. Charging Head Angle Pivot Knob 尺寸：280*100mm 双面印刷 材质：128克铜版纸 Vent Clip 1. Built-in magnet and wireless charging transmitter coil, placing the magnetic phone will automatically adsorption and start wireless charging. 2. Standby mode: The RGB light runnning three laps and it keeps green. 3. Charging mode: the ice blue breathing light keeps flashing. 4. FOD function: when put metal or magnet objects on the charger, the ice blue light will flash for reminding.the wireless charging stops working 5. Perfect protective function based on over-voltage, over-current, over-temperature and short-circuit protection. 1. Please make sure the product connect to the power before using. 2. The green light keeps on if connected with power. 3. The ice blue light will flashes and the product stop charging when the current is too large or there is foreign object. Do not wireless charging the phone if similar situation happened. 4. Please purchase the wireless receiver module or case separately (Not included in the product) if your phone do not support wireless charging. Type-C Charging Port Charging area for phone Product Parts Description Fast wireless charging requires QC or PD adapters. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC RF exposure statement: The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance between 20cm the radiator your body. Model:IC-10AQ FCC ID:2AVSB-IC-AQ Manufacturer:Shenzhen Mgctech Co.,Ltd. Address: 201 ,Bldg.C, No.12, Fusheng RoadPinghu Fuchengao Street, Longgang District,Shenzhen,China .518111. Wireless Car Charger

ShenzhenMgctechCo.,Ltd. Address：401,Bldg.14,No.48-12,FuchengaoRd.,PinghuStreet,LonggangDistrict,Shenzhen, China Date:2025-12-03 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:2AVSB-IC-10AQ FRN:0029269446 (“ShenzhenMgctechCo.,Ltd.”)certifiesthat,asofthedateofthefilingoftheapplication, GOLDENVICTORYINTERNATIONALTRADINGCOLTDisourdesignatedU.S.agentfor serviceofprocessfortheabovereferencedFCCID.(“ShenzhenMgctechCo.,Ltd.”)accepts tomaintainanagentfornolessthanoneyearafterthegranteehasterminatedallmarketing andimportationortheconclusionofanyCommission-relatedproceedinginvolvingthe equipment. GOLDENVICTORYINTERNATIONALTRADINGCOLTDaccepts,asofthedateofthefiling oftheapplication,theobligationofthedesignatedU.S.agentforserviceofprocessforthe abovereferencedFCCID. DesignatedU.S.AgentInformation: Name:GOLDENVICTORYINTERNATIONALTRADINGCOLTD Address:11016THSTREETSUITE1400DENVER,CO80202UnitedStates FRN：0036377570 ContactPerson:LeonHowar Tel.:(337)255-0461 Email:[email protected] Sincerely, Signedonbehalfof（ShenzhenMgctech Co.,Ltd.） SignedonbehalfofGOLDENVICTORY INTERNATIONALTRADINGCOLTD Name:CiciHuangName:LeonHowar Title:OverseasSalesManagerTitle:Manager Date:2025-12-03Date:2025-12-03

Rev1/26/2023 (ShenzhenMgctechCo.,Ltd.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:12-3-2025 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2AVSB-IC-10AQ (“ShenzhenMgctechCo.,Ltd.”)certifiesthattheequipmentforwhichauthorizationissoughtisnot “covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903of theFCCrules. (“ShenzhenMgctechCo.,Ltd.”)certifiesthattheequipmentforwhichauthorizationissoughtdoesnot includecybersecurityoranti-virussoftwareproducedorprovidedbyKasperskyLab,Inc.oranyofits successorsandassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyofits successorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446 D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, (Applicantsignature): (Applicantprintedname):CiciHuang Rev1/26/2023 (ShenzhenMgctechCo.,Ltd.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:12-3-2025 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2AVSB-IC-10AQ (“ShenzhenMgctechCo.,Ltd.”)certifiesthat,asofthedateofthefilingoftheapplication,Shenzhen MgctechCo.,Ltd.isnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, (Applicantsignature): (Applicantprintedname):CiciHuang

承 认 书 SPECIFICATION FOR APPROVAL 客户名称（CUSTOM 客户料号（CUSTOMER P/N） Shenzhen Lijing Technology Co., Ltd. : 品名（DESCRIPTION) : DATE:2024-3-26 规格（SPECIFICATION) ：G43.5 Slotting + Magnetic Coil + Small M REV.NO.:A0 Note： 深 圳 市 鸿 日 昇 威 科 技 有 限 公 司 HRSW ELECTRONICS CO.,LTD ADD：深圳市龙华新区观澜环观中路48号1栋2楼 No. 2, 2nd Floor, Building 1, Guanwan Ring Guan Middle Road, Longhua New District, Shenzhen City TEL：15112254520 FAX：+86-0755-28015170 page:1/2 SPECIFICATION FOR APPROVAL 1.MECHANICAL DIMENSION (UNIT:mm) 2.SCHEMATICS: 备注：1.加20MM小磁片 2. 加背胶 Note: 1. Add 20mm small magnetic sheet 2. Add adhesive backing ADC HEB 42.5±0.57±20.8±0.052.1MAX3±220.5±0.3 3.WINDING： STE P START-FINISHWIRE TYPETURNSTAPE REMAR K N1S-F热风线(Hot air line)⌀0.08*80mm 2UEW11TS (Ref) 4.ELECTRICAL SPECIFICATION: ITEMLDCR TES T CON 线圈加磁 Coil with magnet S-F 100KHz,0.25V AT 25°C SPEC7.9uH±10% 58mΩ Max 5.BILF OF MATERIAL： NO.ITEMMATERIAL SPECIFICATIONMANUFACTURER SGS NO. 1Hot air line Hot air line: 0.08 * 80 strands NANJINGJINNINGCO,LTD 2 Lead-free tin rodLead-free tin rod QIAODO 3 magnetic sheet ⌀42.5*0.8TAIYI CO.,LTD 4 glue Yellow glue 9999LIANCHENG CO.,LTD 5 high-temperature 8mm high-temperature adhesive tapeCUDAK CO.,LTD HRSW ELECTRONICS CO.,LTD PART NO TITLE G42.5 sl DRAWN B G42.5 slotting + magnetic coil + small magnet + glue 7MM YCHECKED BY APPROVED BY adhesive tape page:2/2

ShenzhenMgctechCo.,Ltd. Date:December3,2025 ProductModelNumber:IC-10AQ,EV15MAQ,EV15MDQ,IC-10BQ, IC-10CQ,IC-20AQ,carmincharger FCCID:2AVSB-IC-10AQ Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C. CanadaV5J5K5toactonourbehalfonallmattersconcerningtheabove namedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformation relatedtotheapprovalprojecttotheappliedcertificationbodyandtothe notificationentitiesandtodiscussanyissuesconcerningtheapproval application.AnyandallactscarriedoutbyQAILaboratoriesLtd.onour behalfshallhavethesameeffectasactsofourown. By: ContactListedonFCCWesbite Title:OverseasSalesManager Email:[email protected] Telephone:0755-28266187 Onbehalfof:ShenzhenMgctechCo.,Ltd.

ShenzhenMgctechCo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:December3,2025 Subject;RequestforConfidentiality FCCID:2AVSB-IC-10AQ ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SoftwareSecurityRequirementsforUNIIdevices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:CiciHuang Title:OverseasSalesManager

ShenzhenMgctechCo.,Ltd. ModelDifference Date:2025-12-03 Productdescription:Wirelesscarcharger Modelname:IC-10AQ,EV15MAQ,EV15MDQ,IC-10BQ,IC-10CQ,IC-20AQ, carmincharger FCCID:2AVSB-IC-10AQ IC-10AQistestedmodel,othermodelsarederivativemodels.Themodelsare identicalincircuit,onlydifferentonthemodelnames.SothetestdataofIC-10AQ canrepresenttheremainingmodels. Client’ssignature: Client’sname/title:CiciHuang/OverseasSalesManager Contactinformation/address:401,Bldg.14,No.48-12,FuchengaoRd.,Pinghu Street,LonggangDistrict,Shenzhen,China

FCCID:2AVSB-IC-10AQ EUTPHOTO(ExternalPhotos) FCCID:2AVSB-IC-10AQ FCCID:2AVSB-IC-10AQ ※※※※※ENDOFREPORT※※※※※

39.2mm 43.9mm 59.3mm M o d e l : I C - 1 0 A Q F C C I D : 2 A V S B - I C - 1 0 A Q W i r e l e s s C a r C h a r g e r I n p u t : D C 9 V / 2 . 5 A , 5 V / 2 A O u t p u t : 1 5 W M a x M a d e i n C h i n a M o d e l : I C - 1 0 A Q F C C I D : 2 A V S B - I C - 1 0 A Q W i r e l e s s C a r C h a r g e r I n p u t : D C 9 V / 2 . 5 A , 5 V / 2 A O u t p u t : 1 5 W M a x M a d e i n C h i n a

FCCID:2AVSB-IC-10AQ EUTPHOTOS(InternalPhotos) FCCID:2AVSB-IC-10AQ FCCID:2AVSB-IC-10AQ CoilAntenna FCCID:2AVSB-IC-10AQ FCCID:2AVSB-IC-10AQ ※※※※※ENDOFREPORT※※※※※

ProjectNo.:ZHT-251110131W01-2 Page 1 of 9 RFExposureEvaluation FCCID:2AVSB-IC-10AQ ReportNo........................:ZHT-251110131W01-2 Product............................: Wirelesscarcharger Trademark.......................: / Model(s)...........................:IC-10AQ EV15MAQ,EV15MDQ,IC-10BQ,IC-10CQ,IC-20AQ,carmincharger ModelDifference..............:IC-10AQistestedmodel,othermodelsarederivativemodels.Themodels areidenticalincircuit,onlydifferentonthemodelnames.Sothetestdata ofIC-10AQcanrepresenttheremainingmodels. Applicant..........................:ShenzhenMgctechCo.,Ltd. Address............................:401,Bldg.14,No.48-12,FuchengaoRd.,PinghuStreet,Longgang District,Shenzhen,China Manufacturer....................:ShenzhenMgctechCo.,Ltd. Address............................:401,Bldg.14,No.48-12,FuchengaoRd.,PinghuStreet,Longgang District,Shenzhen,China Preparedby......................:GuangdongZhonghanTestingTechnologyCo.,Ltd. Address............................:Room104/201,Building1,YibaolaiIndustrialPark,Qiaotou,Fuhai Subdistrict,Bao'anDistrict,Shenzhen,Guangdong,China DateofReceipt................:Nov.10,2025 DateofTest(s)..................:Nov.10,2025toNov.24,2025 DateofIssue....................:Nov.24,2025 TestStandard(s)..............: KDB680106D01WirelessPowerTransferv04 Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. PreparedbyReviewedby:Approvedby: LeonLi/EngineerBaretWu/DirectorLeviLee/Manager Note:ThisdevicedescribedabovehasbeentestedbyZHT,andthetestresultsshowthattheequipment undertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport.Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofZHT, thisdocumentmaybealteredorrevisedbyZHT,personalonly,andshallbenotedintherevisionofthe document. ProjectNo.:ZHT-251110131W01-2 Page 2 of 9 TableofContentsPage 1.GENERALINFORMATION................................................................................................................................3 1.1.GENERALDESCRIPTIONOFEUT.......................................................................................................3 1.2.TestModes.............................................................................................................................................4 1.3.Auxiliaryequipment................................................................................................................................4 2.RFEXPOSURETEST........................................................................................................................................5 2.1.MeasuringStandard...............................................................................................................................5 2.2.Requirements..........................................................................................................................................5 2.3.Limits.......................................................................................................................................................5 2.4.TestSetup...............................................................................................................................................6 2.5.TestProcedure.......................................................................................................................................7 2.6.MEASUREMENTUNCERTAINTY.........................................................................................................7 2.7.TestInstrumentslist................................................................................................................................8 2.8.TestResult..............................................................................................................................................8 2.9.TestPhotos.............................................................................................................................................9 ProjectNo.:ZHT-251110131W01-2 Page 3 of 9 1.GENERALINFORMATION 1.1.GENERALDESCRIPTIONOFEUT ProductName:Wirelesscarcharger TestModelNo.: IC-10AQ Hardwareversion:V1.0 Softwareversion:V1.0 OperationFrequency: 115-205KHz,360KHz Modulationtype:ASK AntennaType:CoilAntenna Antennagain:0dBi RatingsInput:9V2.5A,5V2A Output:15WMax Remark:Theantennagainisprovidedbythecustomer,ifthedataprovidedbythecustomerisnotaccurate, GuangdongZhonghanTestingTechnologyCo.,Ltd.doesnotassumeanyresponsibility. ProjectNo.:ZHT-251110131W01-2 Page 4 of 9 1.2.TESTMODES TestModes: Mode1 ACAdapter+Wirelesschargingload(MPPProtocol:BatteryStatus:≤1%) Mode2 ACAdapter+Wirelesschargingload(MPPProtocol:BatteryStatus:50%) Mode3 ACAdapter+Wirelesschargingload(MPPProtocol:BatteryStatus:≥98%) Mode4 ACAdapter+Wirelesschargingload(EPPProtocol:BatteryStatus:≤1%) Mode5 ACAdapter+Wirelesschargingload(EPPProtocol:BatteryStatus:50%) Mode6 ACAdapter+Wirelesschargingload(EPPProtocol:BatteryStatus:≥98%) Mode7 Standby Note:Allmodesweretested,onlytheworst-casewasrecordedinthereport.Mode1istheworstmode. 1.3.AUXILIARYEQUIPMENT Auxiliaryequipment ItemEquipmentMfr/BrandModel/TypeNo.SeriesNo.Note E-1 ACAdapter HuizhouJinhuIndustrial DevelopmentCo.,Ltd. VCBAJACH /AE E-2MobilephoneXiaomiXiaomi13/AE E-3MobilephoneAppleInc.iPhone15Pro/AE ProjectNo.:ZHT-251110131W01-2 Page 5 of 9 2.RFEXPOSURETEST 2.1.MEASURINGSTANDARD KDB680106D01WirelessPowerTransferv04 2.2.REQUIREMENTS Accordingtotheitem5ofKDB680106D01v04: Inductivewirelesspowertransferapplicationsthatmeetallofthefollowingrequirementsareexcludedfrom submittinganRFexposureevaluation. Requirementsofsection3ofKDB680106D01Yes/NoDescription MobileDeviceandPortableDeviceConfigurationsYesMobileDevice EquipmentAuthorizationProceduresforDevicesOperatingat FrequenciesBelow4MHz Yes Thedeviceoperateinthe frequencyrange: 115-205KHz,360KHz RFExposurecompliancemaybeensuredonlyforaminimum conditionsatsmallerdistancescanstillbeconsidered unlikely.separationdistancethatisgreaterthan2…

Text truncated - open the document above for the full version.

ProjectNo.:ZHT-251110131W01-1 Page 1 of 22 Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. PreparedbyReviewedby:Approvedby: LeonLi/EngineerBaretWu/DirectorLeviLee/Manager Note:ThisdevicedescribedabovehasbeentestedbyZHT,andthetestresultsshowthattheequipment undertest(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport.Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofZHT, thisdocumentmaybealteredorrevisedbyZHT,personalonly,andshallbenotedintherevisionofthe document. FCCTESTREPORT FCCID:2AVSB-IC-10AQ ReportNo........................:ZHT-251110131W01-1 Product............................:Wirelesscarcharger Trademark.......................:/ Model(s)...........................:IC-10AQ EV15MAQ,EV15MDQ,IC-10BQ,IC-10CQ,IC-20AQ,carmincharger ModelDifference..............:IC-10AQistestedmodel,othermodelsarederivativemodels.Themodels areidenticalincircuit,onlydifferentonthemodelnames.Sothetestdataof IC-10AQcanrepresenttheremainingmodels. Applicant..........................:ShenzhenMgctechCo.,Ltd. Address............................:401,Bldg.14,No.48-12,FuchengaoRd.,PinghuStreet,LonggangDistrict, Shenzhen,China Manufacturer....................:ShenzhenMgctechCo.,Ltd. Address............................:401,Bldg.14,No.48-12,FuchengaoRd.,PinghuStreet,LonggangDistrict, Shenzhen,China Preparedby.....................:GuangdongZhonghanTestingTechnologyCo.,Ltd. Address............................:Room104/201,Building1,YibaolaiIndustrialPark,Qiaotou,Fuhai Subdistrict,Bao'anDistrict,Shenzhen,Guangdong,China DateofReceipt................:Nov.10,2025 DateofTest(s)................:Nov.10,2025toNov.24,2025 DateofIssue....................:Nov.24,2025 Standard .......................................... ::FCCCFRTitle47Part15SubpartC Testprocedure................................::/ ProjectNo.:ZHT-251110131W01-1 Page 2 of 22 TABLEOFCONTENTS 1.TESTSUMMARY......................................................................................................................................3 2.GENERALINFORMATION......................................................................................................................4 2.1GENERALDESCRIPTIONOFEUT...................................................................................................4 2.2Testmode...........................................................................................................................................4 2.3BlockDiagramofEUTConfiguration..................................................................................................5 2.4TestConditions...................................................................................................................................6 2.5DescriptionOfSupportUnits(ConductedMode)...............................................................................6 3.TAESTFACILITYANDTESTINSTRUMENTUSED..............................................................................7 3.1TESTFACILITY..................................................................................................................................7 3.2EQUIPMENTSLISTFORALLTESTITEMS.....................................................................................7 3.3TESTINGSOFTWARE.......................................................................................................................8 4.CONDUCTEDEMISSIONTEST............................................................................................................10 4.1CONDUCTEDEMISSIONMEASUREMENT...................................................................................10 4.1.1POWERLINECONDUCTEDEMISSIONLimits...........................................................................10 4.1.2TESTPROCEDURE......................................................................................................................10 4.1.3DEVIATIONFROMTESTSTANDARD.........................................................................................10 4.1.4TESTSETUP.................................................................................................................................11 4.1.5EUTOPERATINGCONDITIONS..................................................................................................11 4.1.6TestResult.....................................................................................................................................12 5.RADIATEDEMISSIONMEASUREMENT..............................................................................................14 5.1RadiatedEmissionLimits..................................................................................................................14 5.2AnechoicChamberTestSetupDiagram..........................................................................................15 5.3TestProcedure.................................................................................................................................15 5.4DEVIATIONFROMTESTSTANDARD............................................................................................15 5.5TestResult........................................................................................................................................16 6.BANDWIDTHTEST................................................................................................................................19 7.ANTENNAREQUIREMENT...................................................................................................................21 8.TESTSETUPPHOTO............................................................................................................................22 9.EUTCONSTRUCTIONALDETAILS......................................................................................................22 ProjectNo.:ZHT-251110131W01-1 Page 3 of 22 1.TESTSUMMARY TestItemSectioninCFR47Result Antennarequirement15.203Pass ACPowerLineConductedEmis…

Text truncated - open the document above for the full version.

FCCID:2AVSB-IC-10AQ EUTTESTPHOTOS FCCID:2AVSB-IC-10AQ ※※※※※ENDOFREPORT※※※※※
