2AVY81088-24GRC TOYS, RC ROBOTS

Guangdong Amwell Toys Industry Co., Ltd

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Dec 22, 2022
Application Purpose: Original Equipment
Date of Application: Dec 22, 2022
Equipment Note: RC TOYS, RC ROBOTS
Frequency Range: 2407.00000000 - 2477.00000000
Company: Guangdong Amwell Toys Industry Co., Ltd
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic DevelopmentCanada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L' appareil ne doit pas produire de brouillage; (2) L' appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d' en compromettre le fonctionnement. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Cover Letter(s)

Guangdong Amwell Toys Industry Co., Ltd Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Agent Authorization Company: Guangdong Amwell Toys Industry Co., Ltd Address: Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Product Name: RC TOYS, RC ROBOTS Model Number(s): 1088, 09-039, 09-139, 09-839, 09-939, 2048, 2049, 2056A, 2059, 2069, 2079, 2089, 2099, 3086A, 2088, 3088, 4088, 5088, 6088, 7088, 8088, 9088, 8080A, 9090A, 3066A, 3066B, 3066C, 18081, 18082, 18083, 18011, 18012, 8801, 8802, 8803, 8804, 8805, 303554, 303555, 303558, 303559, NX01, 2101, 6601 Product Description: RC TOYS, RC ROBOTS We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Oct. 26, 2022 Name: DUQUN YANG Title: General Manager Company: Guangdong Amwell Toys Industry Co., Ltd

Cover Letter(s)

Guangdong Amwell Toys Industry Co., Ltd Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Oct. 26, 2022 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: 2AVY81088-24G Models: 1088, 09-039, 09-139, 09-839, 09-939, 2048, 2049, 2056A, 2059, 2069, 2079, 2089, 2099, 3086A, 2088, 3088, 4088, 5088, 6088, 7088, 8088, 9088, 8080A, 9090A, 3066A, 3066B, 3066C, 18081, 18082, 18083, 18011, 18012, 8801, 8802, 8803, 8804, 8805, 303554, 303555, 303558, 303559, NX01, 2101, 6601 To Whom It May Concern: We, The Guangdong Amwell Toys Industry Co., Ltd hereby declare that the model : 1088 is identical with the model : 09-039, 09-139, 09-839, 09-939, 2048, 2049, 2056A, 2059, 2069, 2079, 2089, 2099, 3086A, 2088, 3088, 4088, 5088, 6088, 7088, 8088, 9088, 8080A, 9090A, 3066A, 3066B, 3066C, 18081, 18082, 18083, 18011, 18012, 8801, 8802, 8803, 8804, 8805, 303554, 303555, 303558, 303559, NX01, 2101, 6601, except the model names and the color of appearance. Except for the different above, no other modification is performed. Sincerely, Guangdong Amwell Toys Industry Co., Ltd Signature: Guangdong Amwell Toys Industry Co., Ltd Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China [DUQUN YANG, General Manager]

External Photos

Report No.: AGC09272220903AP02 Page 1 of 4 EXTERNAL PHOTOS All VIEW-1 OF EUT All VIEW-2 OF EUT Report No.: AGC09272220903AP02 Page 2 of 4 TOP VIEW OF EUT BOTTOM VIEW OF EUT Report No.: AGC09272220903AP02 Page 3 of 4 FRONT VIEW OF EUT BACK VIEW OF EUT Report No.: AGC09272220903AP02 Page 4 of 4 LEFT VIEW OF EUT RIGHT VIEW OF EUT ****************************************End of Report****************************************

External Photos

ID Label/Location Info

FCC ID Label Location 10mm*10mm FCC ID: 2AVY81088-24G

Internal Photos

Report No.: AGC09272220903AP02 Page 1 of 3 INTERNAL PHOTOS OPEN VIEW OF EUT (FIGURE 1) OPEN VIEW OF EUT (FIGURE 2) Report No.: AGC09272220903AP02 Page 2 of 3 ANTENNA CLOSE-UP PHOTO-1 INTERNAL VIEW OF EUT (FIGURE 1) Antenna (32mm) Report No.: AGC09272220903AP02 Page 3 of 3 INTERNAL VIEW OF EUT (FIGURE 2) ****************************************End of Report****************************************

Internal Photos

Test Report

Page 1 of 32 FCC Test Report Report No.: AGC09272220903FE03 FCC ID : 2AVY81088-24G APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : RC TOYS, RC ROBOTS BRAND NAME : N/A MODEL NAME : Please see the page 6. APPLICANT : Guangdong Amwell Toys Industry Co., Ltd DATE OF ISSUE : Oct. 25, 2022 STANDARD(S) TEST PROCEDURE(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC09272220903FE03 Page 2 of 32 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Oct. 25, 2022 Valid Initial Release Report No.: AGC09272220903FE03 Page 3 of 32 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCY .......................................................................................................... 7 3. MEASUREMENT UNCERTAINTY ................................................................................................................... 8 4. DESCRIPTION OF TEST MODES ................................................................................................................... 9 5. SYSTEM TEST CONFIGURATION ................................................................................................................ 10 5.1. CONFIGURATION OF EUT SYSTEM ...................................................................................................... 10 5.2 EQUIPMENT USED IN TESTED SYSTEM ............................................................................................... 10 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 10 6. TEST FACILITY .............................................................................................................................................. 11 7. RADIATED EMISSION ................................................................................................................................... 12 7.1TEST LIMIT ................................................................................................................................................ 12 7.2. MEASUREMENT PROCEDURE ............................................................................................................. 13 7.3. TEST SETUP............................................................................................................................................ 15 7.4. TEST RESULT .......................................................................................................................................... 16 8. BAND EDGE EMISSION ................................................................................................................................ 22 8.1TEST LIMIT ................................................................................................................................................ 22 8.2. MEASUREMENT PROCEDURE ............................................................................................................. 22 8.3 TEST SETUP............................................................................................................................................. 22 8.4 TEST RESULT ........................................................................................................................................... 22 9. 20DB BANDWIDTH ........................................................................................................................................ 27 9.1. MEASUREMENT PROCEDURE ............................................................................................................. 27 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 27 9.3. MEASUREMENT RESULTS .................................................................................................................... 28 10. FCC LINE CONDUCTED EMISSION TEST ................................................................................................ 30 10.1. LIMITS OF LINE CONDUCTED EMISSION TEST ................................................................................ 30 Report No.: AGC09272220903FE03 Page 4 of 32 10.2. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST .............................................................. 30 10.3. PRELIMINARY PROCEDURE OF LINE CONDUCTED EMISSION TEST ........................................... 31 10.4. FINAL PROCEDURE OF LINE CONDUCTED EMISSION TEST .......................................................... 31 10.5. TEST RESULT OF LINE CONDUCTED EMISSION TEST .................................................................... 31 APPENDIX A: PHOTOGRAPHS OF TEST SETUP .......................................................................................... 32 APPENDIX B: PHOTOGRAPHS OF THE EUT ................................................................................................. 32 Report No.: AGC09272220903FE03 Page 5 of 32 1. VERIFICATION OF CONFORMITY Applicant Guangdong Amwell Toys Industry Co., Ltd Address Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Manufacturer Guangdong Amwell Toys Industry Co., Ltd Address Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Factory Guangdong Amwell Toys Industry Co., Ltd Address Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Product Designation RC TOYS, RC ROBOTS Brand Name N/A Test Model 1088 Series Mode…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 15 Antenna Test Report Report No.: AGC09272221202PA01 PRODUCT DESIGNATION : RC TOYS,RC ROBOTS BRAND NAME : N/A MODEL NAME : 1088, 09-039, 09-139, 09-839, 09-939, 2048, 2049, 2056A, 2059, 2069, 2079, 2089, 2099, 3086A, 2088, 3088, 4088, 5088, 6088, 7088, 8088, 9088, 8080A, 9090A, 3066A, 3066B, 3066C, 18081, 18082, 18083, 18011, 18012, 8801, 8802, 8803, 8804, 8805, 303554, 303555, 303558, 303559, NX01, 2101, 6601 APPLICANT : Guangdong Amwell Toys Industry Co., Ltd DATE OF ISSUE : Dec. 12, 2022 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC09272221202PA01 Page 2 of 15 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Dec. 12, 2022 Valid Initial release Report No.: AGC09272221202PA01 Page 3 of 15 TABLE OF CONTENTS 1. PRODUCT INFORMATON ...................................................................................................................... 4 2. TEST FACILITY ....................................................................................................................................... 5 3. TEST EQUIPMENT LIST ......................................................................................................................... 5 4. MEASUREMENT UNCERTAINTY .......................................................................................................... 5 5. TEST SUMMARY LIST ............................................................................................................................ 5 6. TEST SETUP ........................................................................................................................................... 6 7. TEST RESULTS ....................................................................................................................................... 7 7.1. VSWR ................................................................................................................................................ 7 7.2. GAIN AND EFFICIENCY ................................................................................................................... 8 7.3. RADIATION PATTERN ...................................................................................................................... 9 APPENDIX A: PHOTOGRAPHS OF TEST SETUP ................................................................................. 11 APPENDIX B: PHOTOGRAPHS OF EUT ................................................................................................ 12 Report No.: AGC09272221202PA01 Page 4 of 15 1. PRODUCT INFORMATON General information Applicant Guangdong Amwell Toys Industry Co., Ltd Address Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Manufacturer Guangdong Amwell Toys Industry Co., Ltd Address Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Factory Guangdong Amwell Toys Industry Co., Ltd Address Xingda Industrial Park, Fengxiang, Chenghai, Shantou City, Guangdong Province, China Product Designation RC TOYS,RC ROBOTS Brand Name N/A Test Model 1088 Series Model 09-039, 09-139, 09-839, 09-939, 2048, 2049, 2056A, 2059, 2069, 2079, 2089, 2099, 3086A, 2088, 3088, 4088, 5088, 6088, 7088, 8088, 9088, 8080A, 9090A, 3066A, 3066B, 3066C, 18081, 18082, 18083, 18011, 18012, 8801, 8802, 8803, 8804, 8805, 303554, 303555, 303558, 303559, NX01, 2101, 6601 Difference Description All the series models are the same as the test model except for the model names and the color of appearance. Date of receipt of test item Dec.07, 2022 Date of test Dec.09, 2022 Report Template AGCRT-ER-PA/V1.0 Technical information Frequency Range 2400-2500MHz Test Frequencies 2400MHz, 2410MHz, 2420MHz, 2430MHz, 2440MHz, 2450MHz, 2460MHz, 2470MHz, 2480MHz, 2490MHz, 2500MHz Antenna Type Wire antenna Dimensions 32mm Impedance 50Ω Maximum test values Gain: 2.200dBi; Efficiency: 26.944%; VSWR: 1.178:1 The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. The test results of this report relate only to the tested sample identified in this report. Prepared By Alan Duan (Project Engineer) Dec.12, 2022 Reviewed By Calvin Liu (Reviewer) Oct. 12, 2022 Approved By Max Zhang (Authorized Officer) Oct. 12, 2022 Report No.: AGC09272221202PA01 Page 5 of 15 2. TEST FACILITY 3. TEST EQUIPMENT LIST Equipment Manufacturer Model Cal. Date Cal. Due ANTENNA MEASUREMENT SYSTEM ETS-Lindgren AMS-8600 Nov. 26, 2022 Nov. 25, 2023 Network Analyzer R&S 101443 Oct. 15, 2022 Oct. 14, 2023 Test software ETS-Lindgren EMQuest (Ver V1.12) N/A N/A 4. MEASUREMENT UNCERTAINTY The uncertainty is calculated using the methods suggested in the “Guide to the Expression of Uncertainty in measurement” (GUM) published by CISPR and ANSI. - Uncertainty of VSWR, Uc = ±1.5dB - Uncertainty of Gain, Uc = ±0.8dB 5. TEST SUMMARY LIST NO. Test item Remark 1 VSWR -- 2 Gain and efficiency -- 3 Radiation pattern -- Test Site Attestation of Global Compliance (Shenzhen) Co., Ltd Location 1-2/F, Building 19, Junfeng Industrial Park, Chongqing Road, Heping Community, Fuhai Street, Bao'an District, Shenzhen, Guangdong, China Report No.: AGC09272221202PA01 Page 6 of 15 6. TEST SETUP Report No.: AGC09272221202PA01 Page 7 of 15 7. TEST RESULTS 7.1. VSWR Frequency(MHz) VSWR 2402 1.168:1 2410 1.178:1 2450 1.163:1 2480 1.107:1 Report No.: AGC09272221202PA01 Page 8 of 15 7.2. GAIN AND EFFICIENCY Frequency(MHz) Efficiency(dB) Efficiency(%) Gain(dBi) 2400 -5.924 25.560 1.550 2410 -6.863 20.590 0.346 2420 -7.437 18.039 -0.251 2430 -6.831 20.742 0.588 2440 -5.736 26.691 1.892 2450 -5.442 28.557 2.200 2460 -5.695 26.944 1.841 2470 -6.047 24.845 1.465 2480 -5.795 26.332 1.572 2490 -5.872 25.865 1.327 2500 -5.737 26.684 1.575 Report No.: AGC09272221202PA01 Page 9 of 15 7.3. RADIATION PATTERN 2D POLAR RADIATION PATTERN FREQUENCY=2400MHZ FREQUENCY=2450MHZ FREQUENCY=2500MHZ Report No.: AGC09272221202PA01 Page 10 of 15 3D RADIATION PATTERN FREQUENCY…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: AGC09272220903AP01 Page 1 of 2 TEST SETUP PHOTOS RADIATED EMISSION TEST SETUP BELOW 1GHz RADIATED EMISSION TEST SETUP ABOVE 1GHz Report No.: AGC09272220903AP01 Page 2 of 2 RF CONDUCTED TEST SETUP ****************************************End of Report*************************************
