2AVZW0PAT5200GENESIS with Bluetooth

EN GENESIS SERIES IOS Android Bluetooth All the specific ac�ons and contents are only for reference, please make the object as the standard, and in this manual are subject to change without no�ce. Table of contents Safety and Precau�ons --------------------------------- 14 Contents --------------------------------- 14 Feature Loca�ons --------------------------------- 15 Tracer Module Se�ngs --------------------------------- 16 Keys of Tac. Torch or Laser --------------------------------- 19 APP opera�on instruc�ons --------------------------------- 20 Charging Instruc�ons --------------------------------- 24 Intelligent Power Control --------------------------------- 25 Self-Test Mode --------------------------------- 25 Specifica�ons --------------------------------- 26 Warranty --------------------------------- 26 To avoid the risk of high voltage circuit electrical shock, do not disassemble Genesis. Do not look into the gun barrel to avoid accidental discharge of BB gun which can lead to bodily harm or disability. Charge the ba�ery at least every 2 months when the tracer is not used to avoid completely discharging the ba�ery. The defect of completely discharging the ba�ery is not covered by Does not support Gel BBs. Safety and Precau�ons Contents 2 M Moun�ng Base x1 User Manual x1 Type C Charging Cable x1 Allen Key x1 EN •GENESIS •Moun�ng Base Feature Loca�ons Detach KeyManual Key Tighten Ratchet Perpetual Se�ng Key Flame Mode Key Power/Tracer Se�ng Key Horizontal Calibra�on Hole Ver�cal Calibra�on Hole Power Indicate Light Flame LED Tac�cal Torch Func�on Reserved Hole Type C Charging Port Perpetual Se�ng Key 1. Tracer Se�ng Key: •Click the Tracer Set. Key to power-on / off. (On : a long beep/ Off : long and short beep) •Long-press Tracer Set. Key for 6 sec. to switch to the tracer modes. The list of alert as follows: Tracer Module Se�ngs Standard Tracer Mode - each shot of tracer BBs gets emblazed Sniper Tracer Mode is available on APP only. Note 1 & Note 2 Turn off tracer func�on Note 3 Beep Once Beep Twice Beep Three Warning tone Illustra�on Func�ons (Default se�ngs: Standard Tracer Mode) Automa�cally recall last se�ngs Note 1: In Sniper Tracer Mode, the flame effect turns inac�vated to avoid ge�ng sniper exposed. Note 2: The details of the sniper mode are set by the APP, as shown in the red frame area as shown below. Note 3: When both tracer and flame func�on are off, the Quark K will automa�cally turned off a�er 1 min. (Genesis will back to default se�ngs a�er restart.) Tracer EN 2. Flame Mode Key: Click the Key for once to switch to the next mode, there are 5 modes in total, and loops in the following sequence: Func�on and LED Mode Mono Flame The flame LED renders the beam/flame with the switched color The flame LED flashes the color of the mode switched Bifrost The flame Led renders the flame with the rainbow-colors and emblaze the BBs track into rainbow-colored beams. The flame LED flashes white for twice with two beeps. Mul�layer 1. The flame LED renders the mul�layer beam with the set colors 2. The 7 layers is the maximum for Mul�layer mode The flame LED flashes white for four �mes with four beeps. Dynamic Genesis changes the flame color for once in every 0.5 second during shoo�ng. When the shoo�ng is paused, the flame color se�ngs stay at the last changed color un�l the next shot. The 7 colors is the aximum for Dynamic Rainbow mode The flame LED flashes white for three �mes with three beeps. Off Click the Flame mode key again and go back to Mono flame mode 5 Beep for Flame func�on off. Remarks EN Note 1 : When tracer mode is on and using tracer BBs, the flame color will be blended by fluorescence Note 2: Colors and layers of flamer se�ng by APP, as shown below: Note 3 : When both tracer and flame func�on are off, the Genesis will automa�cally turned off a�er 1 min. (Genesis will back to default se�ngs a�er restart.) Keys of Tac. Torch or Laser Manual Key Perpetual Se�ng Key 1. Perpetual Torch Key • Toggle Perpetual Torch Key to the right to switch on Perpetual Torch func�on. Toggle the same key to the le� to switch off Perpetual Torch func�on. • When the Perpetual Torch func�on is ON, push and hold on / release the Manual Key to ac�vate / deac�vate the Strobe func�on. 2. Manual Key: • Tac. Torch Control: Hold on / release the key to switch the Tac�cal Torch between ON/OFF. • Laser Control: Quickly push Manual Key for 3 �mes to switch the Laser ON/OFF. • Tracer Control: Hold on Manual Key for more than 3 seconds to switch the tracer ON/OFF. APP opera�on instruc�ons 1. Install AceSo� APP to connect: A. Turn on the Genesis Tracer B. Scan the QR code below to download APP Reminder: A�er downloading APP by using Android system, the system will display the informa�on 【Will you permit “AceSo�” to access the loca�on informa�on of this device?】and 【”AceSo�” requests to ac�vate Bluetooth func�on】. Please click 【Permit】. AceSoft Android AceSoft IOS AceSoft Will you permit “AceSoft” to access the location information of this device? Permit ”AceSoft” requests to activate Bluetooth function. Permit EN 2. Make sure the mobile device Bluetooth ac�vated, then run the App, the app displays the following picture. and click the Tracer Se�ng Key to connect the mobile device. 3. Select the func�on to detail se�ng EN Dynamic 4. Tap to check the instruc�ons in "Tracer" "Flamer" "Chronograph" func�on pages Ammo 1 3.0mm 0.1g Charging Instruc�ons 2. Power/Tracer Indicator Light breaths during charging, and goes off when charging is completed. Breathing light reflects progress of charging: 1. Charge the Genesis with a Type C cable for at least 4 hours on the first use to ensure best performance of the ba�ery. 3. Genesis switches ON/OFF automa�cally when the charging cable gets plugged/unplugged. Type C Charging cable USB power Red: 0% ~ 30% Orange: 30% ~ 60% Green: 80% ~ 99% EN 1. Genesis enter sleep mode while idle for over 5 minutes and awake by 2. Low Ba�ery Force Power Off: the indicator LED flas…

Text truncated - open the document above for the full version.

Acetk Corp LTD. PHOENIX TESTLAB GmbH Date: 2023-02-01 Product Certification Department Koenigswinkel 10 32825 Blomberg Germany Attestation Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Acetk Corp LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Acetk Corp LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: FCC ID: 2AVZW0PAT5200 If you have any questions, please feel free to contact me Eric Chang CEO ___________________________ Signatory (signature of the applicant)

Acetk Corp LTD. 9F., No. 116, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221, Taiwan (R.O.C.) Date: 2023/2/24 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AVZW0PAT5200 US Agent – Attestation Statement / Part 2.911(d)(7) Acetk Corp LTD. certifies, that as of 2023/2/24 we have designated FCC US Agent, LLC to accept service of process on our behalf for FCC ID: 2AVZW0PAT5200 Acetk Corp LTD. , accepts to maintain an agent of service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- related administrative or judicial proceeding involving the equipment, whichever is later. FCC US Agent, LLC, accepts as of the date of the filing of this application, the obligation of being the designated agent for the purpose of accepting service of process on behalf of Acetk Corp LTD. for FCC ID: 2AVZW0PAT5200 Designated Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, Company: Acetk Corp LTD. Designated Agent: FCC US Agent, LLC Company Representative: Eric Chang Designated Agent Representative: Tim Payne Signature: Signature:

Acetk Corp LTD. Long/Short-term Confidentiality Request PHOENIX TESTLAB GmbH Date: 21 February 2023 Product Certification Königswinkel 10 D 32825 Blomberg FCC ID: 2AVZW0PAT5200 To Whom It May Concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby request long-term confidential treatment of information accompanying this application as outlined below: ☒ Schematics ☐ Parts List ☒ Block Diagram ☒ BOM ☒ Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentiality) withheld from the public disclosure ☐ for an initial period of days ☐ until: ☐ not applicable ☐ External Photos ☐ Test Setup Photos ☐ Internal Photos ☐ Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. If you have any questions, please feel free to contact me. Yours sincerely, Signatory Eric Chang CEO

Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 1 of 4 Attachment 2：EUT Detailed Photographs Photo 1 Model Name：GENESIS Photo 2 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 2 of 4 Photo 3 Model Name：GENESIS Photo 4 Model Name：GENESIS Antenna Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 3 of 4 Photo 5 Model Name：GENESIS Photo 6 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 4 of 4 Photo 7 Model Name：GENESIS --- END ---

Label &Label location Product name: GENESIS Model name: GENESIS FCC ID : 2AVZW0PAT5200 Height: 1.6 mm Width: 21 mm :4.3mm silk screen printing and gravure printing

Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 1 of 12 Attachment 2：EUT Detailed Photographs Photo 1 Model Name：GENESIS Photo 2 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 2 of 12 Photo 3 Model Name：GENESIS Photo 4 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 3 of 12 Photo 5 Model Name：GENESIS Photo 6 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 4 of 12 Photo 7 Model Name：GENESIS Photo 8 Model Name：GENESIS Module Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 5 of 12 Photo 9 Model Name：GENESIS Photo 10 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 6 of 12 Photo 11 Model Name：GENESIS Photo 12 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 7 of 12 Photo 13 Model Name：GENESIS Photo 14 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 8 of 12 Photo 15 Model Name：GENESIS Photo 16 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 9 of 12 Photo 17 Model Name：GENESIS Photo 18 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 10 of 12 Photo 19 Model Name：GENESIS Photo 20 Model Name：GENESIS Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 11 of 12 Photo 21 Model Name：GENESIS Photo 22 Model Name：GENESIS The original position of the antenna. Refer to photo 4 of the Attachment 2 EUT Detailed Photographs (External). Report No: WD-RF-R-220419-A0 WD-RF-R-220419-B0 Page 12 of 12 Photo 23 Model Name：GENESIS Photo 24 Model Name：GENESIS --- END --- Antenna

Report No: WD-RF-R-220419-B0 Page 1 of 10 FCC MPE Evaluation Report Report No: WD-RF-R-220419-B0 Product Name : GENESIS Model Name : GENESIS FCC ID : 2AVZW0PAT5200 Applicant : Acetk Corp LTD. Received Date : Nov. 11, 2022 Tested Date : Jan. 05, 2023 ~ Jan. 11, 2023 Applicable Standard : 47 CFR FCC Part 2.1091 47 CFR FCC Part 1.1310 KDB 447498 D01 OET Bulletin 65 Supplement C Wendell Industrial Co., Ltd Wendell EMC & RF Laboratory Caution: This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment. Please note that the measurement uncertainty are provided for informational purpose only and are not used in determining the Pass/Fail results. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of Wendell Industrial Co., Ltd.. Report No: WD-RF-R-220419-B0 Page 2 of 10 Test Report Issued Date: January 13, 2023 Project No.: 22Q112202 Product Name GENESIS Trade Mark Model Name GENESIS FCC ID 2AVZW0PAT5200 Applicant Acetk Corp LTD. Manufacturer Acetk Corp LTD. EUT Rated Voltage Battery 3.6V & DC 5V EUT Test Voltage Battery 3.6V & AC 120V / 50Hz EUT Supports Radios Application Bluetooth LE Applicable Standard 47 CFR FCC Part 2.1091 47 CFR FCC Part 1.1310 KDB 447498 D01 OET Bulletin 65 Supplement C RF Evaluation 0.00013 mW/cm 2 Test Result Complied Documented : ( Specialist / Emma Lu ) Technical Engineer : ( Section Manager / Jack Chang ) Approved : ( Project Manager / Gary Wu ) Report No: WD-RF-R-220419-B0 Page 3 of 10 Table of Contents Document Revision History ................................................................................................................. 4 Reference Testing Standard ................................................................................................................. 5 1 Generation Information .............................................................................................................. 6 1.1 Applicant .................................................................................................................................... 6 1.2 Manufacturer ............................................................................................................................. 6 1.3 Description of Equipment under Test ...................................................................................... 6 1.4 Test Facility ................................................................................................................................ 7 2 Mobile device Assessment Procedure ......................................................................................... 8 3 RF Exposure Assessment ............................................................................................................. 8 4 Limit Requirement ...................................................................................................................... 9 5 Test Results ................................................................................................................................. 10 Report No: WD-RF-R-220419-B0 Page 4 of 10 Document Revision History Report No. Issue date Description WD-RF-R-220419-B0 January 13, 2023 Initial report Report No: WD-RF-R-220419-B0 Page 5 of 10 Reference Testing Standard Standard Description Version 47 CFR FCC Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. -- 47 CFR FCC Part 1.1310 Radiofrequency radiation exposure limits. -- KDB 447498 D01 RF Exposure procedures and equipment authorization policies for mobile and portable devices. V06 OET Bulletin 65 Supplement C Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields. Edition 01-01 Report No: WD-RF-R-220419-B0 Page 6 of 10 1 Generation Information 1.1 Applicant Acetk Corp LTD. 9F., No. 116, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221, Taiwan 1.2 Manufacturer Acetk Corp LTD. 9F., No. 116, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221, Taiwan 1.3 Description of Equipment under Test Product Name GENESIS Model No. GENESIS FCC ID 2AVZW0PAT5200 Frequency Range 2402 ~ 2480 MHz Antenna Information Refer to the table “Antenna List” The above equipment was tested by Wendell EMC & RF Laboratory For compliance with the requirements set forth in 47 CFR § 2.1091 / 47 CFR § 1.1310. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties Antenna List No. Manufacturer Model No. Antenna Type Peak Gain 1 Acetek C-5TP 2P4G PCB Antenna 0.26 dBi for 2.4GHz Report No: WD-RF-R-220419-B0 Page 7 of 10 1.4 Te s t Facility Items Required (IEC 60068-1) Temperature (°C) 15-35 Humidity (% RH) 25-75 Barometric pressure (mbar) 860-1060 Description: Accredited by TAF Accredited Number: 2965 Issued by: Wendell Industrial Co., Ltd Lab Address: 6F/6F-1, No.188, Baoqiao Rd., Xindian Dist., New Taipei City 23145, Taiwan (R.O.C) Test Lab: Wendell EMC & RF Laboratory Test Location: 1F., No. 119, Wugong 3rd Rd., Wugu Dist., New Taipei City 248, Taiwan (R.O.C.) Designation Number: TW0025 Test Firm Registration Number: 665221 Report No: WD-RF-R-220419-B0 Page 8 of 10 2 Mobile device Assessment Procedure In 47 CFR § 2.1091, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is …
