2AW56-EZ4G4G phone

Product Name: 4G phone Brand Name: Snapfon Model Name: Snapfon ez4G Manufacturer: Ying Tai Electronics Co., Ltd Snapfon ez4G User Manual 1 Contents 1.Introduction Thank you for choosing this 4G mobile phone which support GPS, WIFI. With this user manual, you can understand the operation of this phone and enjoy its perfect function and simple operation. Besides basic call, messaging and phonebook function, you will also learn other features, such as FM radio, alarm, calendar, and calculator to make your work and life more convenient. 2.Functions 2.1 Keys Insert the figure. 2 2.2 Function of keys Insert the figure. 2.3 Battery The battery in a newly purchased phone has about 50% charge up. You 3 will get the best battery performance after the first three fully charging & discharging cycles. 2.4 Charging the battery The remaining battery level is indicated by the battery icon at the upper right of the display screen. When the battery level is very low, the mobile phone will prompt “Battery low” on screen. A charging animation will be shown on screen while the battery is being charged up. When the charging completes, the animation will disappear. 2.5 Installing the SIM cards and the battery The battery in a newly purchased phone has about 50% charge up. You will get the best battery performance after the first three fully charging & discharging cycles.  Press and hold the END key to switch off the mobile phone.  Lift the back cover above the battery from the bottom gap to remove it.  Lift the battery buckle outward from upside gap to remove it.  Insert SIM card into the SIM card slot carefully with the index corner aligned to the shape of the SIM card slot. Please ensure the SIM is fully inserted and tight.  Align the metal contacts of the battery with the metal contacts of the phone compartment. Press the battery down until it locks into place. 3. Menu 3.1 Contacts The Contacts page offers management functions. It allows you to view the 4 list of contacts and related details, make a call or send an SMS/MMS to a certain contact, and share the contact. -Create new contact: Edit the new contact info. You can choose to store the contact to phone or USIM. -Delete all: You can choose to delete all contacts in your SIM card or cell phone. -Sub Setting menu: You can edit my info, Default account for new contacts, phonetic name, Import, Export. 3.2 Call History All calls/Missed calls Enter the call records, will display the all calls and missed calls list. Press the Options key: - Call Call the record number. - Create new contact To save new contact information - Send a message Send text message to the number -Add to a contact Add to new contacts or Add to existed contacts - Delete Delete the number. -Block number You will no longer receive calls from this number -Call details Date and duration time -Clear call history Will delete all calls from history Sub Setting Menu -General select ringstone, vibrate or not, dial pad tones, dial number voice, incoming call. -Calling accounts make calls with SIM1/SIM2 card -Call blocking You won’t receive calls or texts from blocked numbers. -Voicemail 3.3 Messaging 5 The phone supports SMS sending. Press left-soft key, you can see below options: New message Edit text message . Press # to change input method: R9, 123, abc, Abc, ABC. Search Search messages via keywords. Delete all threads All threads will be deleted. Delete thread Delete the selected messages. Settings You can configure SMS Enabled, Text message(SMS), Multimedia message(MMS), Notifications, General. Cell Broadcast You can change the Alert settings using the settings menu option. Voice messages You can send and receive voice messages 3.4 Settings 3.4.1 Network & Internet You can choose to open/close WIFI, Hotspot & tethering, select its mobile network, SIM cards, Airplane mode. 6 3.4.2 Connected devices You can connect other devices via Bluetooth or USB, when Bluetooth is turned on, your device can communicate with other nearby Bluetooth devices. ON/OFF: Enable or disable bluetooth. Device name: To rename Bluetooth device. Received files: To check the transfer history Pair new device: To search and pair for nearby bluetooth devices. 3.4.3 APP & notifications You can check recently opened apps, To set its notifications, App permissions, etc. 3.4.4 battery You can see the battery level, Power management, App usage since full charge. 3.4.5 Display Allows you to configure the brightness, main menu style, wallpaper, sleep duration, and display size. 3.4.6 Sound Allows you to regulate the media volume, Alarm volume, Ring volume, select vibrate for calls or not, phone ringstone, default notification sound, default alarm sound, and other sounds and vibrations. 3.4.7 Storage You can check its device storage and portable storage 3.4.8 Security & Location Enter the "Security & location" menu, you can set the device security and 7 Privacy to avoid unauthorized use. -screen lock: choose screen lock -location: Enable or disable location -Show passwords: display characters briefly as you type -SIM card lock: lock SIM card, require PIN to use phone. User & Accounts You could add accounts info for owner, Ex. Whatsapp, Facebook. Let apps refresh data automatically. System -Language & Input: You can choose the language & Input modes. The phone supports many different languages. Set the current language type, then menu and interface refresh for the corresponding language. After entering, you can choose different input methods to edit at any editing interface. -Date &Time: In this menu, you can change the phone time and date settings. -Reset options: Restore you phone to the factory or default settings through this option. You need to input your phone code (default is 1122) for this operation. All data will be deleted when your phone is restored to its factory settings. -About phone: Show its basic infos. 3.5 Multimedia Camera Before using Camera, make sure you have inserted a memory card. The photos will be saved…

Text truncated - open the document above for the full version.

Excellus Communications, LLC Agent Authorization Company: Excellus Communications, LLC Address: 27298 Wetland Road, Suite 101 Harrisburg, SD 57032 USA Product Name: 4G phone Model Number(s): Snapfon ez4G Product Description: 4G phone FCC ID: 2AW56-EZ4G We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-11-02 Name: Dan Strandell Title: General Manager Company: Excellus Communications, LLC

Excellus Communications, LLC Authorization Letter We, (the approval holder) Company name Excellus Communications, LLC Addresss 27298 Wetland Road, Suite 101 Harrisburg, SD 57032 USA declare that the following representative (agent): Name (person) Bovey Yang Company name Shenzhen STS Test Services Co., Ltd. Addresss 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Nemko for product certification below Product Description 4G phone Type or Model(s) Snapfon ez4G Brand Name Snapfon FCC ID 2AW56-EZ4G Attestation: Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) USA 2020/11/02 Dan Strandell General Manager

Excellus Communications, LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-11-02 Subject; Request for Confidentiality FCC ID: 2AW56-EZ4G To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune-up Procedure Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Dan Strandell Title: General Manager

Page 1 of 4 Report No.: STS2009191 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 4 Report No.: STS2009191 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2009191 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2009191 Photo 7 FM Antenna

FCC Label

Page 1 of 9 Report No.: STS2009191 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 LTE RX Antenna BT/WIFI/GPS Antenna GSM/WCDMA/LTE Antenna Page 2 of 9 Report No.: STS2009191 Photo 3 Photo 4 T-Coil Page 3 of 9 Report No.: STS2009191 Photo 5 Photo 6 Page 4 of 9 Report No.: STS2009191 Photo 7 Photo 8 Page 5 of 9 Report No.: STS2009191 Photo 9 Photo 10 Page 6 of 9 Report No.: STS2009191 Photo 11 Photo 12 Page 7 of 9 Report No.: STS2009191 Photo 13 Photo 14 Page 8 of 9 Report No.: STS2009191 Photo 15 Photo 16 Page 9 of 9 Report No.: STS2009191 Photo 17 Photo 18

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.: STS2009191W03 Issued for Excellus Communications, LLC 27298 Wetland Road, Suite 101 Harrisburg, SD 57032 USA Product Name: 4G phone Brand Name: Snapfon Model Name: Snapfon ez4G Series Model: N/A FCC ID: 2AW56-EZ4G Test Standard: FCC Part 15.247 S T L A B S Page 2 of 76 Report No.: STS2009191W03 TEST RESULT CERTIFICATION Applicant’s Name ................... : Excellus Communications, LLC Address .................................. : 27298 Wetland Road, Suite 101 Harrisburg, SD 57032 USA Manufacturer's Name ............. : Ying Tai Electronics Co., Ltd Address .................................. : ROOM 803, CHEVALIER HOUSE 45-51 CHATHAM ROAD SOUTH, TSIM SHA TSUI, KOWLOON, HONG KONG Product Description Product Name ........................ : 4G phone Brand Name ......................... : Snapfon Model Name ........................... : Snapfon ez4G Series Model .......................... : N/A Test Standards ....................... : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ................................ : Date of receipt of test item .......... : 07 Sept. 2020 Date (s) of performance of tests . : 07 Sept. 2020 ~ 26 Oct. 2020 Date of Issue .............................. : 26 Oct. 2020 Test Result .................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory: (Vita Li) Page 3 of 76 Report No.: STS2009191W03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.6 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 14 2.7 EQUIPMENTS LIST 15 3. EMC EMISSION TEST 17 3.1 CONDUCTED EMISSION MEASUREMENT 17 3.2 RADIATED EMISSION MEASUREMENT 21 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 33 4.1 LIMIT 33 4.2 TEST PROCEDURE 33 4.3 TEST SETUP 34 4.4 EUT OPERATION CONDITIONS 34 4.5 TEST RESULTS 35 5. NUMBER OF HOPPING CHANNEL 50 5.1 LIMIT 50 5.2 TEST PROCEDURE 50 5.3 TEST SETUP 50 5.4 EUT OPERATION CONDITIONS 50 5.5 TEST RESULTS 51 6. AVERAGE TIME OF OCCUPANCY 52 6.1 LIMIT 52 6.2 TEST PROCEDURE 52 6.3 TEST SETUP 52 6.4 EUT OPERATION CONDITIONS 52 6.5 TEST RESULTS 53 7. HOPPING CHANNEL SEPARATION MEASUREMEN 59 Page 4 of 76 Report No.: STS2009191W03 Table of Contents Page 7.1 LIMIT 59 7.2 TEST PROCEDURE 59 7.3 TEST SETUP 59 7.4 EUT OPERATION CONDITIONS 59 7.5 TEST RESULTS 60 8. BANDWIDTH TEST 66 8.1 LIMIT 66 8.2 TEST PROCEDURE 66 8.3 TEST SETUP 66 8.4 EUT OPERATION CONDITIONS 66 8.5 TEST RESULTS 67 9. OUTPUT POWER TEST 73 9.1 LIMIT 73 9.2 TEST PROCEDURE 73 9.3 TEST SETUP 73 9.4 EUT OPERATION CONDITIONS 73 9.5 TEST RESULTS 74 10. ANTENNA REQUIREMENT 75 10.1 STANDARD REQUIREMENT 75 10.2 EUT ANTENNA 75 Page 5 of 76 Report No.: STS2009191W03 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 26 Oct. 2020 STS2009191W03 ALL Initial Issue Page 6 of 76 Report No.: STS2009191W03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 76 Report No.: STS2009191W03 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.68dB 2 Unwanted Emissions, conducted ±2.988dB 3 All emissions, radiated 30-1GHz ±5.6dB 4 All emissions, radiated 1G-6GHz ±5.5dB 5 All emissions, radiated>6G ±5.8dB 6 Conducted Emission (9KHz-150KHz) ±3.37dB 7 Conducted Emission (150KHz-30MHz) ±3.83dB Page 8 of 76 Report No.: STS2009191W03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name 4G phone Trade Name Snapfon Model Name Snapfon ez4G Series Model N/A Model Difference N/A Channel List Please refer to the Note 2. Bluetooth …

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2AW56-EZ4G DSS&DTS Setup photo Model name: Snapfon ez4G DSS&DTS conduction DSS&DTS radiation L Page 2 of 2 FCC ID: 2AW56-EZ4G DSS&DTS radiation H
