2AW63-ML-002Battery Powered Smart Video Doorbell

DongGuan Tianluo Electronic Technology Co.,Ltd August 05, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AW63-ML-002 Product Name: Battery Powered Smart Video Doorbell Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name：Long Deng Title：Manager Company： DongGuan Tianluo Electronic Technology Co.,Ltd

DongGuan Tianluo Electronic Technology Co.,Ltd August 05, 2020: Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Flux Compliance Service Laboratory 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with DongGuan Tianluo Electronic Technology Co.,Ltd 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District, Dongguan, Guangdong (Applicant Name and address) <Signature> Name：Long Deng Title：Manager Company： DongGuan Tianluo Electronic Technology Co.,Ltd

Page 1 of 3 Report No.:FCS202008019W01 External photos Photo 1 Photo 2 Page 2 of 3 Report No.:FCS202008019W01 Photo 3 Photo 4 Page 3 of 3 Report No.:FCS202008019W01 Photo 5 Photo 6

Page 1 of 4 Report No.:FCS202008019W01 Internal photos Photo 1 Antenna Photo 2 Page 2 of 4 Report No.:FCS202008019W01 Photo 3 Photo 4 Page 3 of 4 Report No.:FCS202008019W01 Photo 5 Photo 6 Page 4 of 4 Report No.:FCS202008019W01 Photo 7 Photo 8

FCC Test Report Report No: FCS202009019W01 Issued for Applicant: DongGuan Tianluo Electronic Technology Co.,Ltd Address: 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District, Dongguan, Guangdong Product Name: Battery Powered Smart Video Doorbell Brand Name: NA Model Name: Acebell-ML-001 Series Model: NA FCC ID: 2AW63-ML-002 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page 2 of 33 Report No.: FCS202008019W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : DongGuan Tianluo Electronic Technology Co.,Ltd Address .................................. : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District, Dongguan, Guangdong Manufacture's Name .............. : DongGuan Tianluo Electronic Technology Co.,Ltd Address .................................. : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District, Dongguan, Guangdong Product Description Product Name ........................ : Battery Powered Smart Video Doorbell Model Name ........................... : Acebell-ML-001 Test Standards ....................... : FCC Rules and Regulations Part 15 Subpart C, Section 249 Test Procedure ....................... : ANSI C63.10:2013 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ................................ : Date (s) of performance of tests . : 22 July, 2020 ~ 05 August, 2020 Date of Issue .............................. : 05 August, 2020 Test Result .................................. : Pass Tested by : (Chris Chen) Reviewed by : (Jack Chen) Approved by : ( Andy yue) Page 3 of 33 Report No.: FCS202008019W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.4 EQUIPMENTS LIST 11 3 CONDUCTED EMISSION MEASUREMENT 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 13 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 16 4.3 TEST SETUP 18 4.4 TEST RESULTS 19 5. BAND EDGE TEST 24 5.1 LIMIT 24 5.2 TEST PROCEDURE 24 5.3 TEST SETUP 25 5.4 TEST RESULTS 26 6. 20 DB BANDWIDTH TEST 30 6.1 LIMIT 30 6.2 TEST PROCEDURE 30 6.3 TEST SETUP 30 6.4 TEST RESULTS 31 7. ANTENNA REQUIREMENT 33 7.1 STANDARD REQUIREMENT 33 7.2 EUT ANTENNA 33 Page 4 of 33 Report No.: FCS202008019W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Revision History Rev. Issue Date Effect Page Contents 00 05 August, 2020 All Initial Issue Page 5 of 33 Report No.: FCS202008019W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1. SUMMARY OF TEST RESULTS FCC Part 15.249,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.205(a), 15.209(a), 15.249(a), 15.249(c) Radiated Spurious Emission PASS -- 15.209 Field strength of fundamental PASS 15.249(d) Band Edge Emission PASS -- 15.215(c) 20dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) All tests are according to ANSI C63.10-2013 Page 6 of 33 Report No.: FCS202008019W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1.1 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.71dB 2 Unwanted Emissions, conducted ±2.98 dB 3 Conducted Emission (9KHz-150KHz) ±4.13 dB 4 Conducted Emission (150KHz-30MHz) ±4.74 dB 5 All emissions,radiated(<1G) 30MHz-1000MHz ±3.2 dB 6 All emissions,radiated (1GHz -18GHz) ±3.66 dB 7 All emissions,radiated (18GHz -40GHz) ±4.31 dB Page 7 of 33 Report No.: FCS202008019W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Battery Powered Smart Video Doorbell Trade Name NA Model Name Acebell-ML-001 Ser…
