2AW63TL-AH7037 inch HD wireless video door phone

(3)Indoor display ON/Off operation Drill 4 holes on wall to fix mount bracket Secure the bracket on wall with screws Fix camera on the bracket Turn on: For first time use, use USB charger to power supply the display, it will be turned on automatically. ( Or in power suply status Press and hold the on/off button for around 10 seconds till the screen is on.) Turn off: Press and hold the on/off button for around 10 seconds till the screen shut off. 1.Press on display go to main menu , use arrow button to select“About”then press to confirm.Select“Reset Setting”and confirm，then use arrow button and to input the default password 1234 to reset the display to factory setting. 3.Use the arrow button and button to input the default password 1234 on indoor display,it sounds“di di di ”and go to pairing mode, screen showing“pairing” 4.Then use pin to fast press the pair hole button three times on outdoor camera, the green light bright, and it sounds“di di di ”go to pairing mode 5.Both indoor display and outdoor camera sound“duan”to prompt pair successfully, display showing “pair success” 6.If pairing failed, will sound “dada”, display showing “pairing failed”, have to do the above operations again. Fix screw on the left side to secure the camera 2 43 4.Fast press the outdoor camera pair hole button three times, it sounds "di di di" Lock wiring diagram Caution: 1.Please wire the lock with the Unlock module as per the diagram, then connect to electricity power supply . Connect the holes to the terminal board and fix the screws Press and hold one end of the terminal block and connect the wires to the ports Press and hold the other end of the terminal,regardless of positive and negative, connect the cable of the external power supply to the port. 1.Put the wiring board into the corresponding AC/DC hole on the back of the video doorbell, and then fix the screws. 2.Use the matching push-type quick-connect terminal, keep one end pressed down, insert the wires of the terminal block individually and release. 3.The other end also remains pressed down to connect to the external power supply, regardless of positive and negative pole, just connect to the terminal then release. Please note that the external power supply AC: 8-24V, DC: 8-36V. 2.Long press the pair button on unlock module for around 5 seconds till the red light tinkle 3.Indoor display in monitoring status, press the unlock button to open lock, the lock is unlocked and the unlock module will sound“di”, prompt pairing successfully. After pairing successfully, you can set the unlock time, default unlock time is 1 second. Press one time the button on the unlock module, , red indicator light slowly twinkle three times, set unlock time 3 seconds. Press one time again the button on the unloik module, indicator light slowly twinkle five times, set unlocktime 5 seconds. Press the button one time again, indicator light slowly twinkle eight times, set unlock time 8 seconds. 1.Press button to go the main menu. 3 1.Press button on display go to the main menu. 3.Usearrow button and button to input the default password 1234 2. Click after selecting "Pair" menu . Lock wiring diagram Precautions AC/DC wiring instruction Main technical parameters Trouble shooting Main technical parameters AC/DC wiring instruction 131415 7 7 8 8 9 9 10 12 13 13 14 14 2.After reset the indoor display, go to main menu and select“Pair”and press enter to“ Pair”menu 2 Select "monitor time" in the main menu, press to confirm and go to“ monitor time“interface. USB power cablewiring board mounting screws unlock box (optional) push-type quick- connect terminal display display Caution: The indoor display and outdoor camera is paired in factory, no need to pair again. If the unit can not monitor or call or no signal , please contact your after sales service to confirm before following the below operation. 1. Press go to main menu. 2.After going to volume setting interface, use arrow button to adjust the volume and press to confirm. display display module Screen brightness can be directly adjusted by pressing up/down arrow button on the display.Press the no the display to directly enter the event playback interface; on the monitoring interface, press the up/down arrow button to set the volume and brightness. There are language Settings, IE cardcapacity, system upgrade andmore functions waiting for you to experience. display Unlock module power supply Unlock module power supply Unlock module power supply 1. Press the go to main menu, select “motion detection”, press go to motion detection setting menu. 1. Press go to main menu. Indoor display Display size Outdoor camera Power consumption Battery capacity Pixel Electricity power supply Camera angle Night light Standby 285uA Working 250mA DC5V 5000mAh 1080P DC8-36V, AC 8-24V 160° 850nm infrared lamp Two way intercom PIR motion detection 433Mhz wireless unlock Working temperature Size Ye s Ye s Ye s -20°C ~ -60° 14.4*5.1*3.5cm Power supply 7 inch Power supply Battery capacity DC 5V 2000mAh Working current Two way intercom Auto video record video playback:Yes 800mA Ye s Ye s Ye s Max support 64G Screen resolution Working temperature Size 1280* 800 -20°C ~ -60°C 18.1*13.2*2.0cm TF card The unlock module already paired with the device in factory, no need to pair again. If prompt not paired please confirm with your after sales service and refer the below operation. call button PIR camera pairing button loudspeaker USB charge port AC/DC X. XI. Contents XI microphone 7 inch display outd oor cameraUSB cablemanual Adapter FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: Thi…

Text truncated - open the document above for the full version.

Dongguan Tianluo Electronic Technology Co.,Ltd Agent Authorization Company: Dongguan Tianluo Electronic Technology Co.,Ltd Address: 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan,Guangdong, China Product Name: 7 inch HD wireless video door phone Trade Mark: N/A Model Number(s): TL-AH703 FCC ID: 2AW63TL-AH703 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022-11-04 Name: Deng Long Title: Manager Company: Dongguan Tianluo Electronic Technology Co.,Ltd

Dongguan Tianluo Electronic Technology Co.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022-11-04 Subject; Request for Confidentiality FCC ID: 2AW63TL-AH703 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM Software Security Requirements In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name / Title: Deng Long / Manager Company: Dongguan Tianluo Electronic Technology Co.,Ltd Address: 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan,Guangdong, China Phone: 86-769-83198302 Fax: 86-769-83198302 E-Mail: [email protected]

FCC ID: 2AW63TL-AH703 Fig. 1 Fig. 2 FCC ID: 2AW63TL-AH703 Fig. 3 Fig. 4 FCC ID: 2AW63TL-AH703 Fig. 5 Fig. 6 FCC ID: 2AW63TL-AH703 Fig. 7 Fig. 8 FCC ID: 2AW63TL-AH703 Fig. 9 Fig. 10 FCC ID: 2AW63TL-AH703 Fig. 11

_____________________________________________________________________________________________________ LABEL AND LOCATION (Size: L3.00cm x 2.00cm) Label Location

FCC ID: 2AW63TL-AH703 Fig. 1 Fig. 2 FCC ID: 2AW63TL-AH703 Fig. 3 Fig. 4 SRD Antenna FCC ID: 2AW63TL-AH703 Fig. 5 Fig. 6 433.92MHz(RX) Antenna 433.92MHz(RX) Module FCC ID: 2AW63TL-AH703 Fig. 7 Fig. 8 FCC ID: 2AW63TL-AH703 Fig. 9 Fig. 10 FCC ID: 2AW63TL-AH703 Fig. 11 Fig. 12 FCC ID: 2AW63TL-AH703 Fig. 13 Fig. 14

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong RF Exposure evaluation Report Reference No...................... : FCC ID. ............................................ : GTS20220907011-1-7 2AW63TL-AH703 Compiled by ( position+printed name+signature) . : File administrators Peter Xiao Supervised by ( position+printed name+signature) . : Test Engineer Jenny Zeng Approved by ( position+printed name+signature) . : Manager Jason Hu Date of issue .................................... : Oct.13, 2022 Representative Laboratory Name . : Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Dongguan Tianluo Electronic Technology Co.,Ltd Address ............................................ : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan, Guangdong, China Test specification ........................... : Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ...................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : 7 inch HD wireless video door phone Trade Mark ....................................... : N/A Manufacturer .................................... : Dongguan Tianluo Electronic Technology Co.,Ltd Model/Type reference ...................... : TL-AH703 Listed Models .................................. : N/A Hardware Version ............................ : N/A Software Version .............................. : N/A Rating ............................................... : DC 3.7V by battery Recharged by DC 5.0V Result ............................................... : PASS Report No.: GTS20220907011-1-7 Page 2 of 11 T E S T R E P O R T Test Report No. : GTS20220907011-1-7 Oct.13, 2022 ______________________________________________________________________________________________ Date of issue Equipment under Test : 7 inch HD wireless video door phone Model /Type : TL-AH703 Listed model : N/A Applicant : Dongguan Tianluo Electronic Technology Co.,Ltd Address : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan, Guangdong, China Manufacturer : Dongguan Tianluo Electronic Technology Co.,Ltd Address : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20220907011-1-7 Page 3 of 11 Contents 1. SUMMARY ................................................................................................................................................................. 4 1.1 EUT CONFIGURATION ........................................................................................................................................................ 4 1.2 PRODUCT DESCRIPTION ..................................................................................................................................................... 4 2. TEST ENVIRONMENT ................................................................................................................................................. 5 2.1 ADDRESS OF THE TEST LABORATORY ..................................................................................................................................... 5 2.2 TEST FACILITY .................................................................................................................................................................. 5 2.3 ENVIRONMENTAL CONDITIONS ............................................................................................................................................ 5 2.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY .................................................................................................................. 5 3. METHOD OF MEASUREMENT .................................................................................................................................... 6 3.1 APPLICABLE STANDARD ...................................................................................................................................................... 6 3.2 REQUIREMENT ................................................................................................................................................................. 6 3.3 LIMIT ............................................................................................................................................................................. 6 3.4 MPE CALCULATION METHOD ............................................................................................................................................. 7 3.5 ANTENNA INFORMATION .................................................................................................................................................…

Text truncated - open the document above for the full version.

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ................. : FCC ID. ....................................... : GTS20220907011-1-6 2AW63TL-AH703 Compiled by ( position+printed name+signature): File administrators Peter Xiao Supervised by ( position+printed name+signature): Test Engineer Jenny Zeng Approved by ( position+printed name+signature): Manager Jason Hu Date of issue ................................. : Oct.13, 2022 Representative Laboratory Name ....................................................... : Shenzhen Global Test Service Co.,Ltd. Address ......................................... : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong,China Applicant’s name ......................... : Dongguan Tianluo Electronic Technology Co.,Ltd Address ......................................... : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan, Guangdong, China Test specification ........................ : Standard ........................................ : FCC Part 15.247 TRF Originator .............................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................. : 7 inch HD wireless video door phone Trade Mark .................................... : N/A Manufacturer ................................. : Dongguan Tianluo Electronic Technology Co.,Ltd Model/Type reference ................... : TL-AH703 Listed Models .............................. : N/A Hardware Version ........................ : N/A Software Version ........................... : N/A Rating ............................................ : DC 3.7V by battery Recharged by DC 5.0V Result ............................................ : PASS Report No.: GTS20220907011-1-6 Page 2 of 43 T E S T R E P O R T Test Report No. : GTS20220907011-1-6 Oct.13, 2022 ______________________________________________________________________________________________ Date of issue Equipment under Test : 7 inch HD wireless video door phone Model /Type : TL-AH703 Listed model : N/A Applicant : Dongguan Tianluo Electronic Technology Co.,Ltd Address : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan, Guangdong, China Manufacturer : Dongguan Tianluo Electronic Technology Co.,Ltd Address : 201room, Block 4, Longchang Science Park, No. 26, Hantang Street, Dongcheng District,Dongguan, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20220907011-1-6 Page 3 of 43 Contents 1. TEST STANDARDS ......................................................................................................................................... 4 2. SUMMARY ....................................................................................................................................................... 5 2.1. General Remarks ................................................................................................................................... 5 2.2. Product Description ................................................................................................................................ 5 2.3. Equipment Under Test ........................................................................................................................... 6 2.4. Short description of the Equipment under Test (EUT) ........................................................................... 6 2.5. EUT operation mode .............................................................................................................................. 6 2.6. Block Diagram of Test Setup ................................................................................................................. 7 2.7. EUT Exercise Software .......................................................................................................................... 7 2.8. Special Accessories ............................................................................................................................... 7 2.9. External I/O Cable .................................................................................................................................. 7 2.10. Related Submittal(s) / Grant (s) ........................................................................................................... 7 2.11. Modifications ........................................................................................................................................ 7 3. TEST ENVIRONMENT ..................................................................................................................................... 8 3.1. Address of the test laboratory ................................................................................................................ 8 3.2. Test Facility ............................................................................................................................................ 8 3.3. E…

Text truncated - open the document above for the full version.

FCC ID: 2AW63TL-AH703 _______________________________________________________________________________________________ Page 1 of 2 1. TEST SETUP PHOTOGRAPHS 1.1. Photo of Radiated Emissions Measurement Fig. 1 Fig. 2 FCC ID: 2AW63TL-AH703 _______________________________________________________________________________________________ Page 2 of 2 Photo of Conducted Emission Measurement Fig.3
