2AW6Y-CAM20Shelf Camera v2.0

Shelf Camera V2.0 Device Model: 2019-01 Operating manual Contents Specifications ................................................................................................................................................ 3 Power supply ............................................................................................................................................. 3 Wi-Fi .......................................................................................................................................................... 3 Camera module ......................................................................................................................................... 3 Operating conditions ................................................................................................................................ 3 System overview ........................................................................................................................................... 4 Installation .................................................................................................................................................... 5 Required tools ........................................................................................................................................... 5 Perquisites ................................................................................................................................................. 5 Installation steps ....................................................................................................................................... 6 Replacing batteries ....................................................................................................................................... 7 Troubleshooting ............................................................................................................................................ 8 Camera does not connect to the network ................................................................................................ 8 Camera head is loose ................................................................................................................................ 8 Camera does not turn on .......................................................................................................................... 8 Battery operated ................................................................................................................................... 8 Power cable operated ........................................................................................................................... 8 Camera does not send images .................................................................................................................. 8 Support ......................................................................................................................................................... 9 Warnings ..................................................................................................................................................... 10 FCC Class B Warning .................................................................................................................................... 11 FCC Warning (Modification statement) ...................................................................................................... 12 ISED Warning (Modification statement) ..................................................................................................... 13 FCC RF Exposure Warnings ......................................................................................................................... 14 FCC Interference statement (if it is not placed in the device) .................................................................... 15 Specifications Power supply • Trax Shelf Camera V2.0 Battery - model IOT-BAT-2019-1 Or • 5V/500mA via micro-B USB power only cord – see warning Wi-Fi • 802.11 b/g/n Radio • Supports WPA2 personal and enterprise security Camera module • Resolution- 3280x2448, 8MP • Aspect ratio- 4:3 • f. number- 2.0 • DFOV- 76.7 • PDAF autofocus Operating conditions • For indoor use only • -20 to 50C operating condition and -40 to 70C storage • 90% humidity System overview Trax Shelf Camera V2.0 is a low energy, low profile wireless camera for the retail industry. Trax Shelf Camera V2.0 is designed to capture and digitize the shelf; It consists of a camera controller that can support up to 3 camera modules. Trax Shelf Camera V2.0 can be powered using a micro-B USB power cable OR on a dedicated battery pack. • 3 SMA connectors for up to 3 camera modules • Micro-B USB power input. Installation Required tools • Trax Shelf Camera V2.0 • Flat screwdriver • Hex screwdriver 2.5mm - bracket holder Perquisites Prior to starting the installation, make sure to verify the following things: 1. Wi-Fi router, access point or any other Wi-Fi infrastructure 2. Gateway device is on and connected both to the local network and the cloud. 3. Trax Shelf Camera V2.0 is pre-configured to the installation site Installation steps 1. Locate the designated installation spot according to the installation plan. 2. Verify the camera controller and camera module position on the shelf – use a cable collector to tentatively hold the cable in place. 3. Connect the camera modules to the controller unit by screwing the SMA connector clockwise. 4. Prepare the installation surface by cleaning any dust or glue residue from the shelf. 5. Detach the camera controller holder and the battery pack holder from the units by pulling the rails back. 6. Remove the adhesive cover from the two double-sided tape strips on the camera controller holder and the battery pack holder. 7. Attach the camera controller holder and the battery pack holder in the designated area. In case more than one battery pack is in use, make sure to fit t…

Text truncated - open the document above for the full version.

DATE : 2021-03-05 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Trax Technology Solutions Pte Ltd and 65 Chulia Street, #19-01, OCBC Centre, Downtown Core 049513, Singapore Signature: Name: Sakal Heng Title: Legal Counsel Company: Trax Technology Solutions Pte Ltd

Manufacturer Trax Technology Solutions Pte Ltd Label Declaration sticker Label size 38mm (w) x 22mm (h) - Declaration sticker 38mm (w) x 22mm (h) - Serial sticker Label location

FCC ID: 2AW6Y-CAM20 IC: 26479-CAM20 RF Exposure Evaluation FCC Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: 2AW6Y-CAM20 IC: 26479-CAM20 Test Result of RF Exposure Evaluation Wifi Channel Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result Lowest 28.56 0.005686 1.0 PASS Middle 30.55 0.006078 1.0 PASS Highest 31.41 0.006249 1.0 PASS Antenna gain: 0dBi FCC ID: 2AW6Y-CAM20 IC: 26479-CAM20 IC Limits Transmitters are exempt from routine SAR and RF exposure evaluations provided that they comply with the requirements of sections 2.5.1 or 2.5.2. 2.5.1 SAR evaluation is required if the separation distance between the user and/or bystander and the antenna and/or radiating element of the device is less than or equal to 20 cm, except when the device operates at or below the applicable output power level (adjusted for tune-up tolerance) for the specified separation distance defined in Table 1 2.5.2 RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 cm, except when the device operates as follows: • below 20 MHz 6 and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1 W (adjusted for tune-up tolerance); • at or above 20 MHz and below 48 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 4.49/ƒ 0.5 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 48 MHz and below 300 MHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 0.6 W (adjusted for tune-up tolerance); • at or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10 -2 ƒ 0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz; • at or above 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 5 W (adjusted for tune-up tolerance). FCC ID: 2AW6Y-CAM20 IC: 26479-CAM20 Test Result of RF Exposure Evaluation According to RSS-102 RF exposure section 2.5.2 is calculated. The minimum separation distance is 20cm declared by manufacturer Test Result of RF Exposure Evaluation 2.4G WIFI 14.97dbm(802.11n(HT20) Highest channel) 1.31*10 -2 *2462 0.6834 =2721.93mW EIPR=14.97dbm(31.41mW)< 2721.93mW Antenna gain: 0dBi

Global United Technology Services Co., Ltd. Report No.: GTS202012000270-01 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 46 TEST REPORT Applicant: Trax Technology Solutions Pte Ltd Address of Applicant: 65 Chulia Street, #19-01, OCBC Centre, Downtown Core 049513, Singapore Manufacturer: Trax Technology Solutions Pte Ltd Address of Manufacturer: 65 Chulia Street, #19-01, OCBC Centre, Downtown Core 049513, Singapore Equipment Under Test (EUT) Product Name: Shelf Camera v2.0 Model No.: 2019-01 HVIN: 2.0 Trade Mark: N/A FCC ID: 2AW6Y-CAM20 IC: 26479-CAM20 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 RSS-Gen Issue 5 RSS-247 Issue 2 Date of sample receipt: January 12, 2021 Date of Test: January 12, 2021-March 04, 2021 Date of report issued: March 05, 2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202012000270-01 Page 2 of 46 2 Version Version No. Date Description 00 March 05, 2021 Original Prepared By: Date: March 05, 2021 Project Engineer Check By: Date: March 05, 2021 Reviewer Report No.: GTS202012000270-01 Page 3 of 46 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 TEST FACILITY .................................................................................................................................... 7 5.5 TEST LOCATION ................................................................................................................................. 7 5.6 ADDITIONAL INSTRUCTIONS ................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 10 7.1 ANTENNA REQUIREMENT ................................................................................................................... 10 7.2 CONDUCTED EMISSIONS ................................................................................................................... 11 7.3 CONDUCTED PEAK OUTPUT POWER .................................................................................................. 14 7.4 CHANNEL BANDWIDTH & 99% OCCUPY BANDWIDTH .......................................................................... 15 7.5 POWER SPECTRAL DENSITY ............................................................................................................. 20 7.6 SPURIOUS EMISSION IN NON-RESTRICTED & RESTRICTED BANDS ....................................................... 23 7.6.1 Conducted Emission Method ..................................................................................................... 23 7.6.2 Radiated Emission Method ........................................................................................................ 28 7.7 FREQUENCY STABILITY ..................................................................................................................... 43 8 TEST SETUP PHOTO ............................................................................................................................ 46 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 46 Report No.: GTS202012000270-01 Page 4 of 46 4 Test Summary Test Item Section Result Antenna requirement FCC part 15.203/15.247 (c) RSS-Gen Section 6.8 Pass AC Power Line Conducted Emission FCC part 15.207 RSS-Gen Section 8.8 Pass Conducted Peak Output Power FCC part 15.247 (b)(3) RSS-247 Section 5.4(d) Pass Channel Bandwidth & 99% OCB FCC part 15.247 (a)(2) RSS-247 Section 5.2(a) & RSS-Gen 6.7 Pass Power Spectral Density FCC part 15.247 (e) RSS-247 Section 5.2(b) Pass Band Edge FCC part 15.247(d) RSS-Gen 8.10 & RSS-247 5.5 Pass Spurious Emission FCC part 15.205/15.209 RSS-Gen Section 8.9 & 8.10 Pass Remark: Test according to ANSI C63.10:2013 and RSS-Gen Pass: The EUT complies with the essential requirements in the standard. Measurement Uncertainty Test Item Frequency Range Measurement Uncertainty Notes Radiated Emission 9kHz ~ 30MHz  4.34dB (1) Radiated Emission 30MHz ~ 1000MHz  4.24dB (1) Radiated Emission 1GHz ~ 26.5GHz  4.68dB (1) AC Power Line Conducted Emission 0.15MHz ~ 30MHz  3.45dB (1) Note (1): The measurement uncertainty is for coverage factor of k=2 and a level of confidence of 95%. Report No…

Text truncated - open the document above for the full version.

Radiated Emission
