2AW8CGJJKTDLED down light

INSTALLATION © Copyright 2023 Satco Products, Inc. 03/23 v1.2 STEP 1: Turn OFF power prior to installation. STEP 2: Remove existing trim installed in recessed housing (if necessary). STEP 3: If applicable, slide lamp holder bracket to its upward maximum position. If the lamp holder bracket is less than 4 1/2" from the bottom edge of the fixture enclosure, the lamp holder bracket must be removed. STEP 4: If necessary, remove the lamp holder mounting bracket and the lamp holder from the bracket, then attach the provided label to the existing luminaire. See Figure A. STEP 5: Install adapter into socket. See Figure B. STEP 6: Connect the orange terminals together. See Figure C. STEP 7: To install the 4" downlight, slide the downlight up into the recessed housing. Push the trim until the outer edge is flush with the ceiling surface. See Figures D & F. STEP 8: To install the 5"/6" downlight, insert torsion springs into luminaire housing brackets. Gently push up trim and slide the LED downlight up into the recessed housing until the trim is flush with the ceiling. See Figures E & F. STEP 9: Installation is complete. Turn power ON. STEP 10: App Connection: To connect your device, download the free “Starfish Smart Lighting” App from the app store. Please refer to our Starfish User Guide for detailed instructions on how to pair your device. For Installation into existing recessed LED luminaire with compatible connectors: • Follow STEPS 1 and 2 above. STEP 3: Discard medium base adapter. • Skip STEPS 4 and 5 above. Continue with STEPS 6 – 9 above. STA RFISH ™ SMART WIFI LED RETROFIT DOWNLIGHTS Model: LJC-US-SDLG3F-Y4C10.5W950-RGBCW12W-21V1；LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1 LJC-US-SDLG3F-F4C10.5W950-RGBCW13W-21V1 ；LJC-US-SDLG3F-F6C13W950-RGBCW13W-21V1 INSTALLATION AND SAFETY INSTRUCTIONS IMPORTANT: Read before installing fixture. Retain for future reference. WARNING: Risk of Fire or Electric Shock • LED Retrofit Kit installation requires knowledge of luminaries electrical systems. If not qualified, do not attempt installation. Contact a qualified electrician. • T o reduce risk of fire and over-heating, secure all connections. • TURN OFF the electrical power before proceeding. • Install this kit only in luminaires that have the construction features and dimensions shown in the photographs and/or drawings and where the input rating of the retrofit kit does not exceed the input rating of the luminaire. • The electrical rating of this product is 120V/60Hz. • T o prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects. • D o not make or alter any open holes in an enclosure of wiring or electrical components during kit installation. • This retrofit kit is accepted as a component of a luminaire where the suitability of the combination shall be determined by authorities having jurisdiction. •This device is not intended for use with emergency exits. •Suitable for wet locations, covered ceiling-mounted luminaire. Orange terminals C Adaptor B Lamp holder bracket A F S115 6 8 : 4" (101mm)S11570 : 5"/6" (152mm) S115 6 9 : 4" (101mm)S11571: 5"/6" (152mm) Download the STARFISH App D E IMPORTANTE: Lea esto antes de instalar el accesorio. Consérvelo para referencia futura. ADVERTENCIA: Riesgo de Incendio y Descarga Eléctrica • Pa ra instalar el juego de reemplazo de LED, debe tener conocimiento sobre sistemas eléctricos de luminarias. Si no está calificado, no trate de realizar la instalación. Póngase en contacto con un electricista calificado. • Para reducir el riesgo de incendio y sobrecalentamiento, asegúrese de que todas las conexiones estén firmes. • Antes de continuar, corte la energía eléctrica. • Instale este juego solo en luminarias que tienen las características y las dimensiones de construcción que se muestran en las fotografías o los diagramas y en donde la capacidad nominal de entrada del juego de reequipamiento no supere la capacidad nominal de la luminaria. • La clasificación eléctrica de este producto es de 120V/60Hz. • Para evitar daños o abrasión al cableado, no lo exponga a los bordes de las hojas metálicas ni otros objetos afilados. • Dur ante la instalación del juego, no realice ni altere ningún orificio de apertura en un gabinete para cableado o componentes eléctricos. • Este juego de reemplazo es aceptado como componente de la luminaria si la combinación es adecuada de acuerdo a las autoridades que tengan jurisdicción. (Vendido únicamente a Canadá.) • No es conveniente el uso en salidas de emergencia. • Adecuado para lugares húmedos, luminaria de techo cubierta. INSTALACIÓN: PASO 1: Desconecte la alimentación antes de realizar la instalación. PASO 2: Retire la moldura instalada en la carcasa empotrada (de ser necesario). PASO 3: Si se requiere, deslice el soporte de la lámpara a su posición superior máxima. Si el soporte de la lámpara tiene menos de 4 1/2" desde el borde de la parte inferior del gabinete del accesorio, se debe quitar el soporte de la lámpara. PASO 4: Si es necesario, quite el soporte de montaje y el soporte de la lámpara del soporte y coloque la etiqueta proporcionada en la luminaria existente. Observe la Figura A. PASO 5: Instale el adaptador en el receptáculo. Consulte la Figura B. PASO 6: Conecte juntas las terminales naranjas. Consulte la Figura C. PASO 7: Para instalar la luz descendente de 4", deslícela hacia arriba dentro de la carcasa empotrada. Empuje la moldura hasta que el borde exterior quede al ras con la superficie del techo. Consulte las Figuras D y F. PASO 8: Para Downlight de 5"/6", inserte los resortes de torsión en los soportes de la carcasa de la luminaria. Empuje suavemente hacia arriba la moldura y deslice la luz descendente LED hacia arriba en la carcasa empotrada hasta que la moldura quede al ras con el techo. Ver Figuras E y F. PASO 9: La instalación está completa. Encienda la alimentación. PASO 10: Conexión de la aplicación: Para conectar su dispositivo, descargue la aplicación gratuita “Starfish Smar…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: MW Lighting Inc FRN: 0033654096 Contact Name: Kelly Yao Address: 17578 Rowland St, City of Industry, CA 91748, United States Telephone No: (909) 972-6777 Email: [email protected] Applicant: Company name: HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Product Description: LED down light Grantee code: 2AW8C FCC ID: 2AW8CGJJKTD Contact Name: xianwen Xiong Address: NO 35 YANGSHAN ROAD,GAOHONG ZONE, HANGZHOU, China Telephone No: 18922867300 Email: [email protected] [HANGZHOU LIJIACHENG ELECTRIC CO.,LTD] certifies that, as of the date of this filing of the application with the TCB, [MW Lighting Inc] is our designated US agent for service of process for the above referenced FCC ID. [HANGZHOU LIJIACHENG ELECTRIC CO.,LTD] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [MW Lighting Inc] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2023/05/18 Applicant’s Name: xianwen Xiong US Agent’s Name: Kelly Yao Title: Product Manager Title: Manager Signature: Signature:

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Grantee code: 2AW8C FCC ID: 2AW8CGJJKTD Contact Name: xianwen Xiong Address: NO 35 YANGSHAN ROAD,GAOHONG ZONE, HANGZHOU, China Telephone No: 18922867300 Email: [email protected] i. HANGZHOU LIJIACHENG ELECTRIC CO.,LTD (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. HANGZHOU LIJIACHENG ELECTRIC CO.,LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. HANGZHOU LIJIACHENG ELECTRIC CO.,LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 2023/05/18 Applicant’s Name: xianwen Xiong Title: Product Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

HANGZHOU LIJIACHENG ELECTRIC CO.,LTD NO 35 YANGSHAN ROAD,GAOHONG ZONE, HANGZHOU, China DATE : 06/17/2023 HANGZHOU LIJIACHENG ELECTRIC CO.,LTD NO 35 YANGSHAN ROAD,GAOHONG ZONE, HANGZHOU, China Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Name Damon Hu Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-38826678-850 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. Applicant name HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address NO 35 YANGSHAN ROAD,GAOHONG ZONE, HANGZHOU, China Yours sincerely, Signatory Name xianwen Xiong Position Product Manager Company Name HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address NO 35 YANGSHAN ROAD,GAOHONG ZONE, HANGZHOU, China Tel 18922867300 E-Mail [email protected]

Declaration of difference Date: 2023-05-22 To Whom It May Concern: The Product: LED Downlight Model No.: LJC-US-SDLG3F-Y4C10.5W950-RGBCW12W-21V1 LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1 LJC-US-SDLG3F-F4C10.5W950-RGBCW13W-21V1 LJC-US-SDLG3F-F6C13W950-RGBCW13W-21V1 Model difference: 1.LJC-US-SDLG3F product name 2.YcircularFsquare 3.6C6-inch4C4-inch 4.10.5W , 13W:Product power 5. C can be 8 or 9 represents CRI. 6. 1st X can be A for CCT tunable or Blank for single CCT. 7. 2nd X can be 5, 4, 3, 2 or 1 for LED series qty. 8. 3rd and 4th X can be 27, 30, 35, 40, 50, 57 or 65 represents highest CCT. 9. 5th and 6th X can be 18, 20, 22 or 25 represents lowest CCT. 10. 1st S can be 1 for anti glare, or 2 for non-anti glare. 11. 2nd S can be any number represent junction box color. 12. V can be 1, 2, 3, 4, 5, 6 for lamp case color. 13. # can be any numbers represents the commercial code Yours sincerely, Signature NameXiong Xianwen PositionProduct Manager Company Name HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address No. 35 Yangshan Road, Gaohong Industrial Zone, Lin'an City, HANGZHOU Zhejiang Tel / Fax/ [email protected] 1/1

C5266091_X8_Ed.1 1/1 Letter of Authorization HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Company: HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address: NO 35 YANGSHAN ROAD,GAOHONG ZONE, HANGZHOU, China Product Name: LED down light Model Number: LJC-US-SDLG3F-Y4C10.5W950-RGBCW12W-21V1, LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1, LJC-US-SDLG3F-F4C10.5W950-RGBCW13W-21V1, LJC-US-SDLG3F-F6C13W950-RGBCW13W-21V1 FCC Identifier: 2AW8CGJJKTD We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: xianwen Xiong Date: 2023/05/18 Title: Product Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2023/05/18 Subject: Request for Confidentiality FCC ID: 2AW8CGJJKTD To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: xianwen Xiong Title: Product Manager

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23040334-2E Page 1 of 7 AppendixI: Photos of the EUT Product Name : LED down light Model Number : LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23040334-2E Page 2 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23040334-2E Page 3 of 7

Conforms to UL Std. 1598C Cert. to CSA Std. C22.2 No.250.1 5020418 0523 ETL CLASSIFIED -SUITABLE FOR WET LOCATIONS ÉS -TYPE IC -INSTALLATION SUR PLAFOND COUVERT SEULEMENT -CONVIENT AUX EMPLACEMENTS MOUILL -TYPE IC -TYPE IC -COVERED CEILING MOUNT ONLY -INSTALLATION SUR PLAFOND COUVERT SEULEMENT Made in Thailand JA8-2022 Model:LJC-US-SDLG3F-Y4C10.5W950-RGBCW12W-21V1 Input:10.5W,AC120V,650LM,90CRI 60Hz,0.1A CCT:2000-5000K -SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 40°C -PEUT ÊTRE UTILISÉ À UNETEMPÉRATURE AMBIANTE N’EXCÉDANT PAS 40°C FCC ID2AW8CGJJKTD -DO NOT USE WITH DIMMERS -NE PAS UTILISER AVEC DES GRADATEURS Conforms to UL Std. 1598C Cert. to CSA Std. C22.2 No.250.1 5020418 0523 ETL CLASSIFIED -SUITABLE FOR WET LOCATIONS ÉS -TYPE IC -INSTALLATION SUR PLAFOND COUVERT SEULEMENT -CONVIENT AUX EMPLACEMENTS MOUILL -TYPE IC -TYPE IC -COVERED CEILING MOUNT ONLY -INSTALLATION SUR PLAFOND COUVERT SEULEMENT Made in Thailand JA8-2022 Model:LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1 Input:13W,AC120V,850LM,90CRI 60Hz,0.12A CCT:2000-5000K -SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 40°C -PEUT ÊTRE UTILISÉ À UNETEMPÉRATURE AMBIANTE N’EXCÉDANT PAS 40°C FCC ID2AW8CGJJKTD -DO NOT USE WITH DIMMERS -NE PAS UTILISER AVEC DES GRADATEURS label location

Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23040334-2E Page 4 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23040334-2E Page 5 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23040334-2E Page 6 of 7 Dongguan Dongdian Testing Service Co., Ltd. Case No.: DDT-Q23040334-2E Page 7 of 7 END OF REPORT BT& WIFI Ant.

Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23040334-2E03 TRF No.: KDB447498 D01 Ver.1.0 Page 1 of 8 RF EXPOSURE REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address : No. 35 Yangshan Road, Gaohong industrial Zone, Lin'an City, Hangzhou China. Equipment under Test : LED down light Model No. : LJC-US-SDLG3F-Y4C10.5W950-RGBCW12W-21V1, LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1, LJC-US-SDLG3F-F4C10.5W950-RGBCW13W-21V1, LJC-US-SDLG3F-F6C13W950-RGBCW13W-21V1 Trade Mark : N/A FCC ID : 2AW8CGJJKTD Manufacturer : HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address : No. 35 Yangshan Road, Gaohong industrial Zone, Lin'an City, Hangzhou China. Report No.: DDT-RE23040334-2E03 Issued Date: May 25, 2023 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23040334-2E03 TRF No.: KDB447498 D01 Ver.1.0 Page 2 of 8 Table of Contents Test report declares.......................................................................................................3 1. General Information .................................................................................................................. 5 1.1. Description of equipment ......................................................................................................... 5 1.2. Assess laboratory ..................................................................................................................... 6 2. RF Exposure Evaluation .......................................................................................................... 7 2.1. Requirement .............................................................................................................................. 7 2.2. Calculation method ................................................................................................................... 7 2.3. Estimation result ....................................................................................................................... 8 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23040334-2E03 TRF No.: KDB447498 D01 Ver.1.0 Page 3 of 8 Test Report Declare Standard Used: KDB447498 D01 General RF Exposure Guidance v06 We Declare: The equipment described above is assessed by Dongguan Dongdian Testing Service Co., Ltd and in the configuration assessed the equipment complied with the standards specified above. The assessed results are contained in this report and Dongguan Dongdian Testing Service Co., Ltd is assumed of full responsibility for the accuracy and completeness of these assess. After evaluation, our opinion is that the equipment In Accordance with above standard. Report No: DDT-RE23040334-2E03 Date of Receipt: Apr. 07, 2023 Date of Test: Apr. 07, 2023 ~ May 16, 2023 Prepared By: Approved By: __________________ ______________________ Tiger Mo /Engineer Damon Hu/EMC Manager Note: This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Dongguan Dongdian Testing Service Co., Ltd. Applicant : HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address : No. 35 Yangshan Road, Gaohong industrial Zone, Lin'an City, Hangzhou China. Equipment under Test : LED down light Model No. : LJC-US-SDLG3F-Y4C10.5W950-RGBCW12W-21V1, LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1, LJC-US-SDLG3F-F4C10.5W950-RGBCW13W-21V1, LJC-US-SDLG3F-F6C13W950-RGBCW13W-21V1 Trade Mark : N/A Manufacturer : HANGZHOU LIJIACHENG ELECTRIC CO.,LTD Address : No. 35 Yangshan Road, Gaohong industrial Zone, Lin'an City, Hangzhou China. E S T T I N N A I G D S G E N R O V D I C E N A C U O G . , G L N T O D D . Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23040334-2E03 TRF No.: KDB447498 D01 Ver.1.0 Page 4 of 8 Revision History Rev. Revisions Issue Date Revised By --- Initial issue May 25, 2023 Dongguan Dongdian Testing Service Co., Ltd Report No.:DDT-RE23040334-2E03 TRF No.: KDB447498 D01 Ver.1.0 Page 5 of 8 1.General Information 1.1. Description of equipment EUT Name : LED down light Model Number : LJC-US-SDLG3F-Y4C10.5W950-RGBCW12W-21V1, LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1, LJC-US-SDLG3F-F4C10.5W950-RGBCW13W-21V1, LJC-US-SDLG3F-F6C13W950-RGBCW13W-21V1 Difference of models : LJC-US-SDLG3F-W#CWWWCXX-######SSM-ZZV# Model difference: 1. LJC-US-SDLG3F:product name 2. Y: circular; F: square 3. 6C: 6-inch; 4C: 4-inch 4. 10.5W 13W: Product power 5. C can be 8 or 9 represents CRI. 6. 1st X can be A for CCT tunable or Blank for single CCT. 7. 2nd X can be 5, 4, 3, 2 or 1 for LED series gty. 8. 3rd and 4th X can be 27, 30, 35, 40, 50, 57 or 65 represents highest CCT. 9. 5th and 6th X can be 18, 20, 22 or 25 represents lowest CCT. 10. 1st S can be 1 for anti glare, or 2 for non-anti glare. 11. 2nd S can be any number represent junction box color. 12. V can be 1, 2, 3, 4, 5, 6 for lamp case color. 13. # can be any numbers represents the commercial code Above models are identical in schematic, only the name and structure are different for all the models, therefore the test performed on the model LJC-US-SDLG3F-Y6C13W950-RGBCW12W-21V1. EUT function description : Please reference user manual of this device Power Supply : AC 120V/60Hz Radio Technology : BLE: Bluetooth V5.0 2.4G WIFI: IEEE 802.11b/g/n Operation frequency : BLE: 2402 MHz - 2480 MHz 2.4G WIFI: IEEE 802.11b: 2412MHz-2462MHz IEEE 802.11g: 2412MHz-2462MHz IEEE 802.11n HT20: 2412MHz-2462MHz IEEE 802.11n HT40: 2422MHz-2452MHz Modulation : BLE: GFSK 2.4G WIFI: IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n HT20, HT40: OFDM (64QAM, 16QAM, QPSK, BPSK) Transmitter rate : BLE: 1 Mbps 2.4G WIFI: IEEE 802.11b: up to 11 Mbps IEEE 802.11g: up to 54 Mbps IEEE 802.11n HT20: up to 72.2 Mbps IEEE 802.11n HT40: up to 150 Mbps Antenna Type : FP…
