2AW97-XW32Bluetooth module

BLE4.2 Transparent Transmission Module User manual XW32-BLE V1.1 2019.09.11 CONTENTS 1. Version History, Disclaimer and Notice ............... 3 1.1 Version History ...................................................................................................... 3 1.2 Disclaimer and Notice .......................................................................................... 3 2. General Description............................................. 3 3. Package and Dimensions .................................... 4 4. Pin Assignment ................................................... 5 5. Product Function and Test Description ............... 6 6. UUID ................................................................... 6 7. Communication Interface for Module and MCU .. 6 7.1 Asynchronous Serial Communication ................................................................ 6 7.2 Packet Format ....................................................................................................... 6 7.3 Operation Mode Setting ....................................................................................... 6 8. AT Command ...................................................... 7 9.1 AT Command List ................................................................................................. 7 9.2 Set Baud Rate ....................................................................................................... 7 9.3 Read BLE Name ................................................................................................... 7 9.4 Set BLE Device Name ......................................................................................... 7 9.5 Read BLE MAC Address ..................................................................................... 8 9.6 Set BLE MAC Address ......................................................................................... 8 9.7 Read BLE Status: Broadcast/Connected .......................................................... 8 9.8 Set Broadcast Interval .......................................................................................... 8 9.9 Set Connection Interval ........................................................................................ 8 9.10 Disconnect BLE................................................................................................... 9 9.11 Reset/Restart....................................................................................................... 9 9.12 Read Parameter .................................................................................................. 9 9.13 Exit Command Mode .......................................................................................... 9 9.14 Shut Down ........................................................................................................... 9 9.15 Factory reset ........................................................................................................ 9 9.16 Version inquiry..................................................................................................... 9 9.17 Instruction help .................................................................................................... 9 9.18 Returned Error Code Indication ...................................................................... 10 9. Power consumption ........................................... 10 10. Recommended Reflow Profile ........................... 10 11. Appendix: Reference Specification ................... 10 FCC Requirement(FCC warning - Module)................ 11 1. Version History, Disclaimer and Notice 1.1 Version History Version Date Author Description V1.0 2019/03/26 Chen First draft V1.1 2019/09/11 Chen Update Description 1.2 Disclaimer and Notice The document is provided “AS IS”, without warranty of any kinds, including the implied warranties of merchantability and applies to any guarantee for a particular purpose, or non infringement, and any proposal, specification or sample of any guarantee mentioned anywhere else. This document does not bear any responsibility, including the use of the document information from infringement of any patent infringement liability. This document is not here by estoppel or otherwise, any intellectual property rights is granted the license, whether express or implied license. The information in this document might be modified for upgrade or other reasons. XINWU corporation reserves the rights to make change without notice. This document is used for design guide only, XINWU corporation try the best to supply the correct information, but it does not assure there is not any error in this document. All the ostensive or implied states, information, suggestion are not guaranteed. 2. General Description Module XW32-BLE is a highly integrated Bluetooth 4.2 dual mode with 2 Mbps data rate option. It integrates a high-performance RF transceiver, baseband, ARM9E core, rich feature peripheral units, programmable protocol and profile to support BLE application. The Flash program memory makes it suitable for customized applications. 3. Package and Dimensions Length （mm） Width （mm） Height （mm） PAD （bottom） （mm） Pin pitch （mm） 18 12 1.7±0.2 0.75 x 2.4 1.25 XW32-BLE module dimensions 4. Pin Assignment No. Pin name Description 1、3、4、 9、18、26 GND GND 2 ANT External antenna available when required 5 P31 IO interface， ADC1 6 P32 IO interface，ADC2 7 P14 IO interface， PWM4 8 VCCBAT 3.0V VCC 10 RSTN Reset, low effective(controlled by external MCU IO) 11 P00/TXD1 IO interface or UART1 RXD，for UART sending 12 P01/RXD1 IO interface ，UART1 RXD，for UART reception 13 P17 IO interface，UART_RXD2 14 P16 IO interface，UART_TXD2 15 P13 IO interface，PWM3 16 P33 IO interface，ADC3 17 P12 IO interface，PWM2 19 P10 IO interface，PWM0 20 P07 IO interface，PWM5，SPI_NSS， JTAG_TMS 21 P06 IO interface，SPI_MISO，PWM4，JTAG_TCK 22 P05 IO interface，SPI_MOSI ，JTAG_TDO 23 P04 IO interface，SPI_SCK ，JTAG_TDI 24 P03 IO interface，I2C_SDA , JTAG_NT…

Text truncated - open the document above for the full version.

\\DATA\EMC Case\2020 Projects In Progress\2020年8月\已出草稿\CQASZ20200800820E 芯伍 bluetooth module XW32-BLE FCC ID\提交机构\Modular-Approval-Letter.doc SHENZHEN XINWU TECHNOLOGY LIMITED FCC ID: 2AW97-XW32 MODULAR APPROVAL LETTER Modular Approval Requirement Yes No (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. ✔ (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over-modulation. ✔ (iii) The modular transmitter must have its own power supply regulation. ✔ (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a ‘‘unique’’ antenna coupler (at all connections between the module and the antenna, including the cable). The ‘‘professional installation’’ provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. ✔ (v) The modular transmitter must be tested in a stand-alone configuration ✔ (vi) The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. ✔ (vii) The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. ✔ (viii) The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. ✔ Signature: Printed name: jin jiang

FCC ID: 2AW97-XW32

FCC ID: 2AW97-XW32

FCC ID: 2AW97-XW32

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 RF Exposure Evaluation Report The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No. : CQASZ20200800820E-03 Applicant: SHENZHEN XINWU TECHNOLOGY LIMITED Address of Applicant: Floor 5, Building 2, Chungu Science park, Meisheng Huigu Science Park, 83 Dabao Road, Baoan District, Shenzhen Equipment Under Test (EUT): EUT Name: Bluetooth module Model No.: XW32-BLE Brand Name: N/A FCC ID: 2AW97-XW32 Standards: 47 CFR Part 1.1307 47 CFR Part 2.1093 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2020-08-10 Date of Test: 2020-08-10 to 2020-09-03 Date of Issue: 2020-09-03 Test Result : PASS* *In the configuration tested, the EUT complied with the standards specified above Tested By： ( Tiny You ) Reviewed By: ( Sheek Luo ) Approved By: ( Jack Ai ) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800820E-03 Page:2 of 7 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20200800820E-03 Rev.01 Initial report 2020-09-03 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800820E-03 Page:3 of 7 2 Contents Page 1 VERSION .....................................................................................................................................................................2 2 CONTENTS .................................................................................................................................................................3 3 GENERAL INFORMATION ......................................................................................................................................4 3.1 CLIENT INFORMATION ...............................................................................................................................................4 3.2 GENERAL DESCRIPTION OF EUT ...............................................................................................................................4 3.3 GENERAL DESCRIPTION OF BT ..................................................................................................................................4 3.4 GENERAL DESCRIPTION OF BLE ................................................................................................................................4 4 SAR EVALUATION ....................................................................................................................................................5 4.1 RF EXPOSURE COMPLIANCE REQUIREMENT ..............................................................................................................5 4.1.1 Standard Requirement .................................................................................................................................5 4.1.2 Limits ..............................................................................................................................................................5 4.1.3 EUT RF Exposure.........................................................................................................................................6 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800820E-03 Page:4 of 7 3 General Information 3.1 Client Information Applicant: SHENZHEN XINWU TECHNOLOGY LIMITED Address of Applicant: Floor 5, Building 2, Chungu Science park, Meisheng Huigu Science Park, 83 Dabao Road, Baoan District, Shenzhen Manufacturer: Shenzhen jingzhuo Electronic Technology Co., Ltd Address of Manufacturer: 4 / F, building C10, Fuyuan Industrial Town, Jiuwei, Xixiang street, Bao'an District, Shenzhen Factory: SHENZHEN YUANKONG TECHNOLOGY LIMITED Address of Factory: 4 / F, No. 39, Furong Road, Gushu community, Xixiang street, Bao'an District, Shenzhen 3.2 General Description of EUT Product Name: Bluetooth module Model No.: XW32-BLE Trade Mark: N/A Hardware Version: XW32-BLE-A0_V1.0.pcb Software Version: XW32-BLE_V1.5 Sample Type: Mobile Portable Fix Location EUT Power Supply: DC 2.2-3.6V 3.3 General Description of BT Operation Frequency: 2402MHz~2480MHz Modulation Technique: Frequency Hopping Spread Spectrum(FHSS) Modulation Type: GFSK Number of Channel: 79 Transfer Rate: 1Mbps Hopping Channel Type: Adaptive Frequency Hopping systems Test Software of EUT: BK RF Test (manufacturer declare ) Antenna Type: PCB Antenna Antenna Gain: 2.0dBi 3.4 General Description of BLE Operation Frequency: 2402MHz~2480MHz Modulation Type: GFSK Transfer Rate: 1Mbps Number of Channel: 40 Test Software of EUT: BK RF Test (manufacturer declare ) Antenna Type: PCB Antenna Antenna Gain: 2.0dBi Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800820E-03 Page:5 of 7 4 SAR Evaluation 4.1 RF Exposure Compliance Requirement 4.1.1 Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 4.1.2 Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance…

Text truncated - open the document above for the full version.

Shenzhen Huaxia Testing Technology Co., Ltd 1F., Block A of Tongsheng Technology Building, Huahui Road, Dalang Street, Longhua District, Shenzhen, China Telephone: +86-755-26648640 Fax: +86-755-26648637 Website: www.cqa-cert.com Report Template Version: V04 Report Template Revision Date: 2018-07-06 Test Report The test report is effective only with both signature and specialized stamp, The result(s) shown in this report refer only to the sample(s) tested. Without written approval of CQA, this report can’t be reproduced except in full. Report No. : CQASZ20200800820E-02 Applicant: SHENZHEN XINWU TECHNOLOGY LIMITED Address of Applicant: Floor 5, Building 2, Chungu Science park, Meisheng Huigu Science Park, 83 Dabao Road, Baoan District, Shenzhen Equipment Under Test (EUT): EUT Name: Bluetooth module Model No.: XW32-BLE Brand Name: N/A FCC ID: 2AW97-XW32 Standards: 47 CFR Part 15, Subpart C Date of Receipt: 2020-08-10 Date of Test: 2020-08-10 to 2020-09-03 Date of Issue: 2020-09-03 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above Tested By： ( Tiny You ) Reviewed By: ( Sheek Luo ) Approved By: ( Jack Ai ) Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800820E-02 Page:2 of 58 1 Version Revision History Of Report Report No. Version Description Issue Date CQASZ20200800820E-02 Rev.01 Initial report 2020-09-03 Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800820E-02 Page:3 of 58 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203/15.247 (c) ANSI C63.10 (2013) PASS AC Power Line Conducted Emission 47 CFR Part 15, Subpart C Section 15.207 ANSI C63.10 (2013) N/A Conducted Peak Output Power 47 CFR Part 15, Subpart C Section 15.247 (b)(1) ANSI C63.10 (2013) PASS 20dB Occupied Bandwidth 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Carrier Frequencies Separation 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Hopping Channel Number 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.247 (a)(1) ANSI C63.10 (2013) PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15, Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10 (2013) PASS Band-edge for RF Conducted Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2013) PASS RF Conducted Spurious Emissions 47 CFR Part 15, Subpart C Section 15.247(d) ANSI C63.10 (2013) PASS Radiated Spurious emissions 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2013) PASS Restricted bands around fundamental frequency (Radiated Emission) 47 CFR Part 15, Subpart C Section 15.205/15.209 ANSI C63.10 (2013) PASS N/A: Not Applicable, the EUT was working by DC. Shenzhen Huaxia Testing Technology Co., Ltd Report No.: CQASZ20200800820E-02 Page:4 of 58 3 Contents Page 1 VERSION .................................................................................................................................................................. 2 2 TEST SUMMARY .................................................................................................................................................... 3 3 CONTENTS .............................................................................................................................................................. 4 4 GENERAL INFORMATION ................................................................................................................................... 5 4.1 CLIENT INFORMATION .......................................................................................................................................... 5 4.2 GENERAL DESCRIPTION OF EUT .......................................................................................................................... 5 4.3 ADDITIONAL INSTRUCTIONS................................................................................................................................. 7 4.4 TEST ENVIRONMENT ............................................................................................................................................ 8 4.5 DESCRIPTION OF SUPPORT UNITS ......................................................................................................................... 8 4.6 STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................. 9 4.7 TEST LOCATION ................................................................................................................................................. 10 4.8 TEST FACILITY ................................................................................................................................................... 10 4.9 ABNORMALITIES FROM STANDARD CONDITIONS ............................................................................................... 10 4.10 OTHER INFORMATION REQUESTED BY THE CUSTOMER ...................................................................................... 10 4.11 EQUIPMENT LIST ................................................................................................................................................ 11 5 TEST RESULTS AND MEASUREMENT DATA .............................................................................................. 12 5.1 ANTENNA REQUIREMENT ................................................................................................................................... 12 5.2 CONDUCTED PEAK OUTPUT POWER ................................................................................................................... 17 5.3 20DB OCCUPY BANDWIDTH ............................................................................................................................... 21 5.4 CARRIER FREQUENCIES SEPARATION ............…

Text truncated - open the document above for the full version.

FCC ID: 2AW97-XW32 1 Photographs - EUT Test Setup 1.1 Radiated Spurious Emission 9KHz~30MHz: 30MHz~1GHz: FCC ID: 2AW97-XW32 Above 1GHz: 1.2 Conducted Emission
