2AWC3-MG-S01AAndroid dongle

FCC Statement 1. Set up a hotspot on the smartphone · Go to Wi-Fi hot spot settings on the smartphone with an internet connection. · Set up Wi-Fi hotspot to be available. 2. Connect to Wi-Fi on M stick · Go to Wi-Fi settings on M stick. · Turn on Wi-Fi and select the smartphone from the detected list. · Enter the smartphone’s hotspot password Simple User Manual C – USB port for ex ternal devices (Type F) D – Heat dissipa tion hole E – Firmware update button A – USB port for connec tion (Type M) B – Sta tus indic ator 1. Insert into USB port · Insert the M stick into the USB port on the car display that supports Android Auto. · Android Auto button will be activated on the car display. 2. Tap Android Auto button · Tap Android Auto button on the car display. 3. Proceed Setup Wizard · Select the language you want in the Setup Wizard · Tap START button · Do no t use the product f or anything other than its original purpose. · Do not touch the product or USB port with wet hands or other body parts. · Do not leave the product in a place where there is a risk of overheating. · Place the product in a dry, moisture-free place.· · Product can be damaged where the temperature is high or low. · Be careful not to damage the product. · Avoid dropping the product or external impact. · If the product is damaged, do not use it damaged. · Do not modify, separate or repair the product at your discretion. · Be careful when cleaning the product. ·  Be careful not t o suck or bite the product by children, infants or pets. · Do not stab your body such as e yes or ears or put the product in your mouth. · If you are using a hearing aid, check and use the information related to electromagnetic waves. ·  Do not stor e the product with metal products such as coins and keys. · Do not leave the produc t in a magnetic field. ·  While driving, follow relevant laws and regulations or road safety rules for product use. The contents of the user manual may v ary depending on the software version of the product, the car display or the smartphone, and some changes may be made without user notification. Copyright ⓒ M GEARS Product appearanceHow to useHow to connect to the internetCaution Product specification Product components - M stick - Simple user manual - USB ex tension cable - USB Y extension cable www.m-gears.c om - 2 -- 3 -- 4 -- 5 - NameAndroid dongle ModelMG-S01 OS)Android 9 CPUQuad-core (Cortex-A53) RAM2GB LPDDR4 ROM16GB eMMC ConnectivityUSB 2.0 / Wi-Fi (2.4GHz) / Bluetooth 4.2 PowerDC 5V / 2.5W Size/Weight3.5x10x1.5cm / 0.3kg <Android(Samsung)><iPhone> * This product is available on c ar displays with Android Auto that have been released since 2017. Please refer to the website for the list of supported vehicles. * Please ref er to the website for information on how to update firmware. * Network dat a from the smartphone connected by Wi-Fi is used when using real-time contents. * Please ref er to the website for detailed information on how to connect to the internet. * To use the hotspo t, you need a SIM that can be tethering. B A E C D - 6 - Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body Android dongle

UBRIDGECo.,Ltd. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2021-04-09 Subject;RequestforLongTermConfidentiality FCCID:2AWC3-MG-S01A ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:HeewonJeong Title:Business

UBRIDGECo.,Ltd. 1-1704,AceHightechCity,775,Gyeongin-ro,Yeongdeungpo-gu, Seoul,SouthKorea AgentAuthorization Company:UBRIDGECo.,Ltd. Address:1-1704,AceHightechCity,775,Gyeongin-ro,Yeongdeungpo-gu,Seoul, SouthKorea ProductName:Androiddongle ModelNumber(s):MG-S01 ProductDescription:Androiddongle WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2021-04-09 Name:HeewonJeong Title:Business Company:UBRIDGECo.,Ltd.

Page 1 of 4 Appendix B: Photographs of EUT Product: Android dongle Model: MG-S01 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

LabelArtworkandLocation Model:MG-S01 Label： Size:L*W=30*10mm Androiddongle ModelNo.:MG-S01 FCCID:2AWC3-MG-S01A Location

Page 1 of 5 Appendix B: Photographs of EUT Product: Android dongle Model: MG-S01 Internal Photos BT/WIFI ANT Page 2 of 5 Page 3 of 5 Page 4 of 5 Page 5 of 5

Maximum Permissible Exposure Applicable Standard According to §1.1307(b), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. For BT: Remark: 1) The maximum output power for antenna is -1.93dBm (0.64mW) at 2402MHz, 2.14dBi antenna gain(with 1.64 numeric antenna gain.) 2) For mobile or fixed location transmitters, no SAR consideration applied. The minimum separation generally be used is at least 20cm, even if the calculation indicate that the MPE distance would be lesser. Maximum Permissible Exposure output power= 0.64mW Numeric Antenna gain= 1.64 Substituting the MPE safe distance using d=20cm into above equation. Yields: S=0.000199*P*G Where P=Power in mW G=Numeric antenna gain S=Power density in mW/cm 2 Power density= 0.000209mW/cm 2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.) For WIFI: Remark: 1) The maximum output power for antenna is 9.58dBm (9.08mW) at 2437MHz, 2.14dBi antenna gain(with 1.64 numeric antenna gain.) 2) For mobile or fixed location transmitters, no SAR consideration applied. The minimum separation generally be used is at least 20cm, even if the calculation indicate that the MPE distance would be lesser. Maximum Permissible Exposure output power=9.08mW Numeric Antenna gain= 1.64 Substituting the MPE safe distance using d=20cm into above equation. Yields: S=0.000199*P*G Where P=Power in mW G=Numeric antenna gain S=Power density in mW/cm 2 Power density= 0.002963mW/cm 2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.)

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AWC3-MG-S01A Product: Android dongle Model No.: MG-S01 Additional Model No.: N/A Trade Mark: N/A Report No.: TCT210331E008 Issued Date: Apr. 23, 2021 Issued for: UBRIDGE Co., Ltd. 1-1704, Ace Hightech City, 775, Gyeongin-ro, Yeongdeungpo-gu, Seoul, South Korea Issued By: Shenzhen Tongce Testing Lab TCT Testing Industrial Park, Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT210331E008 Page 2 of 67 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 6 4.1. Test environment and mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations .................................................................. 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ..................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. 20dB Occupy Bandwidth .................................................................................... 18 6.5. Carrier Frequencies Separation ......................................................................... 23 6.6. Hopping Channel Number .................................................................................. 28 6.7. Dwell Time ............................................................................................................ 31 6.8. Pseudorandom Frequency Hopping Sequence ................................................ 36 6.9. Conducted Band Edge Measurement ................................................................ 37 6.10. Conducted Spurious Emission Measurement ................................................. 41 6.11. Radiated Spurious Emission Measurement .................................................... 45 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT210331E008 Page 3 of 67 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Android dongle Model No.: MG-S01 Additional Model No.: N/A Trade Mark: N/A Applicant: UBRIDGE Co., Ltd. Address: 1-1704, Ace Hightech City, 775, Gyeongin-ro, Yeongdeungpo-gu, Seoul, South Korea Manufacturer: Shenzhen Tomato Technology Co., Ltd Address: Room 1106, Huatong Building, SunGangDong Road, LuoHu District, Shenzhen, Guangdong Province, P.R.China 518022 Date of Test: Apr. 01, 2021 – Apr. 22, 2021 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Apr. 22, 2021 Aaron Mo Reviewed By: Date: Apr. 23, 2021 Beryl Zhao Approved By: Date: Apr. 23, 2021 Tomsin Report No.: TCT210331E008 Page 4 of 67 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(1) PASS 20dB Occupied Bandwidth §15.247 (a)(1) PASS Carrier Frequencies Separation §15.247 (a)(1) PASS Hopping Channel Number §15.247 (a)(1) PASS Dwell Time §15.247 (a)(1) PASS Radiated Emission §15.205/§15.209 PASS Band Edge §15.247(d) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT210331E008 Page 5 of 67 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: Android dongle Model No.: MG-S01 Additional Model No.: N/A Trade Mark: N/A Bluetooth Version: V4.2 Operation Frequency: 2402MHz~2480MHz Transfer Rate: 1/2/3 Mbits/s Number of Channel: 79 Modulation Type: GFSK, π/4-DQPSK, 8DPSK Modulation Technology: FHSS Anten…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Android dongle Model: MG-S01 Radiated Emission Page 2 of 2 Conducted Emission
