2AWDM-A9DDash Camera

Winpal Electronics Co.,Ltd Room602, Building A1, Huafeng Hi-Tech Industrial Park, Hangkong road, Gushu, Xixiang, Baoan, Shenzhen, China 518102 Date: Sep 16, 2020 FCC ID: 2AWDM-A9D Model Number: A9D To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Winpal Electronics Co.,Ltd, declare that this EUT (FCC ID: 2AWDM-A9D) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name: Mr He Company: Winpal Electronics Co.,Ltd Address: Room602, Building A1, Huafeng Hi-Tech Industrial Park, Hangkong road, Gushu, Xixiang, Baoan, Shenzhen, China 518102 Phone: 0086 138 2356 3721 Fax: 0755-23228105 E-Mail: [email protected]

Winpal Electronics Co.,Ltd Agent Authorization Date: Sep 16, 2020 Company: Winpal Electronics Co.,Ltd Address: Room602, Building A1, Huafeng Hi-Tech Industrial Park, Hangkong road, Gushu, Xixiang, Baoan, Shenzhen, China 518102 Product Description: Dash Camera FCC ID Number: 2AWDM-A9D Tested Model Number: A9D We authorize Eurofins Product Service GmbH, Storkower Strasse 38c, D-15526 Reichenwalde, Germany, to act on our behalf on all matters concerning the certification of above mentioned equipment. We declare that Eurofins Product Service GmbH is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We, Winpal Electronics Co.,Ltd , the undersigned, hereby authorize Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.), Shenzhen Microwave Certification Services Co., Ltd. (Gilbert Lui, Marketing Manager) and Ka.Ma.S UG (Karin Schmidt, CEO) on our behalf, to apply to the Federal Communications Commission on our equipment. We, the undersigned, hereby authorize Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.) to act on our behalf in matters relating to the application for a FCC equipment authorization for mentioned FCC ID Number including the signing of Form 731, necessary forms and documents in connection with this application. Any and all acts carried out by Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.) on our behalf shall have the same effect as acts of our own. This authorization expires on February 28, 2022 Yours Sincerely, Winpal Electronics Co.,Ltd <Signature of Mr He > Name: Mr He Company: Winpal Electronics Co.,Ltd Address: Room602, Building A1, Huafeng Hi-Tech Industrial Park, Hangkong road, Gushu, Xixiang, Baoan, Shenzhen, China 518102 Phone: 0086 138 2356 3721 Fax: 0755-23228105 E-Mail: [email protected]

Winpal Electronics Co.,Ltd CONFIDENTIALITY REQUEST for Certification under the FCC Rules Date: Sep 16, 2020 Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the following product: FCC ID Number: 2AWDM-A9D Tested Model Number: A9D For the product stated above, we request that the following information be held confidential: Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days Block Diagram Schematic Diagram/ Circuit Diagram Circuit Description/ Operational Description Parts List Tune Up Information User’s Manual External Photos Internal Photos Test Setup Photos The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. Please do not hesitate to contact me if you have any queries. Yours Sincerely, Winpal Electronics Co.,Ltd <Signature of Mr He > Name: Mr He Company: Winpal Electronics Co.,Ltd Address: Room602, Building A1, Huafeng Hi-Tech Industrial Park, Hangkong road, Gushu, Xixiang, Baoan, Shenzhen, China 518102 Phone: 0086 138 2356 3721 Fax: 0755-23228105 E-Mail: [email protected]

Page: 3 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Page: 4 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT Page: 5 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT Page: 6 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 7 Appearance of EUT Photo 8 Appearance of EUT Page: 7 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 9 Appearance of EUT Photo 10 Appearance of EUT Page: 8 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 11 Appearance of EUT

Page: 1 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Appendix IFCC ID Label Size for the label: 20mm X30mm Model:A9D Input: 5Vdc 1.5A FCC ID: 2AWDM-A9D Made in China Page: 2 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

Page: 9 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 12 Internal of EUT Photo 13 Internal of EUT Page: 10 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 14 Internal of PCB Photo 15 Internal of PCB Page: 11 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 16 Internal of PCB Photo 17 Internal of PCB Page: 12 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 18 Internal of PCB Photo 19 Internal of PCB Page: 13 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 20 Internal of EUT Photo 21 Internal of EUT Page: 14 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 22 Internal of EUT Photo 23 Appearance of PCB Page: 15 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 24 Appearance of PCB Photo 25 Internal of EUT 2.4G WIFI Ant. Page: 16 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Photo 26 Appearance of PCB

Report No.: TB-MPE175526 Page: 1 of 3 TB-RF-075-1.0 Maximum Permissible Exposure Evaluation FCC ID: 2AWDM-A9D 1. Client Information Applicant : Winpal Electronics Co.,Ltd Address : Room602, Building A1, Huafeng Hi-Tech Industrial Park, Hangkong road, Gushu, Xixiang, Baoan, Shenzhen, China 518102 Manufacturer : Winpal Electronics Co.,Ltd Address : Room602, Building A1, Huafeng Hi-Tech Industrial Park, Hangkong road, Gushu, Xixiang, Baoan, Shenzhen, China 518102 2. General Description of EUT EUT Name : Dash Camera Models No. : A9D Model Different : N/A Brand Name : COXPAL Product Description : Operation Frequency: 802.11b/g/n(HT20): 2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz Number of Channel: 802.11b/g/n(HT20):11 channels 802.11n(HT40):7 channels conducted power: 802.11b: 15.85dBm 802.11g: 14.59 dBm 802.11n (HT20): 14.66 dBm 802.11n (HT40): 14.74 dBm Antenna Gain: 1.71dBi FPC Antenna Power Rating : Input:DC 12-24V Output USB 1: 5V 1A USB 2:5V 2.1A Software Version : Ver01 Hardware Version : Ver02 Connecting I/O Port(S) : Please refer to the User's Manual Remark : the MPE report used the EUT(TBBJ-20200903-19-2 #). Report No.: TB-MPE175526 Page: 2 of 3 TB-RF-075-1.0 MPE Calculations for WIFI 1. Antenna Gain: FPC Antenna:1.71dBi. 2. EUT Operation Condition: Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 3. Exposure Evaluation: Equation from page 18 of OET Bulletin 65, Edition 97-01 S=(PG)/4πR 2 Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna 4. Test Result: Worst Maximum MPE Result Mode N TX Freq. (MHz) Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/ cm 2 ) [S] 802.11b 1 2412 15.85 15±1 16 1.71 20 0.0117 2437 15.50 15±1 16 1.71 20 0.0117 2462 15.44 15±1 16 1.71 20 0.0117 802.11g 1 2412 14.46 14±1 15 1.71 20 0.0093 2437 14.59 14±1 15 1.71 20 0.0093 2462 14.17 14±1 15 1.71 20 0.0093 802.11n(HT20) 1 2412 14.51 14±1 15 1.71 20 0.0093 2437 14.66 14±1 15 1.71 20 0.0093 2462 14.26 14±1 15 1.71 20 0.0093 802.11n(HT40) 1 2422 14.65 14±1 15 1.71 20 0.0093 2437 14.74 14±1 15 1.71 20 0.0093 2452 14.55 14±1 15 1.71 20 0.0093 Note: (1) N TX = Number of Transmit Antennas (2) RF Output power specifies that Maximum Conducted Peak Output Power. Report No.: TB-MPE175526 Page: 3 of 3 TB-RF-075-1.0 5. Conclusion: As specified in Table 1B of 47 CFR 1.1310- Limits for Maximum Permissible Exposure (MPE), Limits for General Population/ Uncontrolled Exposure Frequency Range (MHz) Power density (mW/ cm 2 ) 300-1,500 F/1500 1,500-100,000 1.0 For 2.4WIFI:2412~2462 MHz 2422~2452 MHz MPE limit S: 1mW/ cm 2 The MPE is calculated as 0.0117 mW / cm 2 < limit 1mW / cm 2 . So, RF exposure limit warning or SAR test are not required. The EUT will only be used with a separation of 20cm or greater between the antenna and nearby persons and can therefore be considered a mobile transmitter per 47 CFR2.1091 (b). The RF Exposure Information page from the manual is included here for reference. Note For a more detailed features description, please refer to the RF Test Report. 6. Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. -----END OF REPORT-----

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC175525 Page: 1 of 77 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2AWDM-A9D Original Grant Report No. : TB-FCC175525 Applicant : Winpal Electronics Co.,Ltd Equipment Under Test (EUT) EUT Name : Dash Camera Model No. : A9D Series Model No. : ---- Brand Name : COXPAL Sample ID : TBBJ-202000903-19-1#& TBBJ-202000903-19-2# Receipt Date : 2020-09-07 Test Date : 2020-09-08 to 2020-09-16 Issue Date : 2020-09-17 Standards : FCC Part 15, Subpart C 15.247 Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC and IC requirements Test/Witness Engineer : Jack Deng Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC175525 Page: 2 of 77 TB-RF-074-1.0 Contents ---- ............................................................................................................................................................. 1 CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION TEST ........................................................................................... 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 12 5.3 Test Procedure ................................................................................................................... 13 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 1 3 6. RADIATED EMISSION TEST ................................................................................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 6.2 Test Setup ........................................................................................................................... 15 6.3 Test Procedure ................................................................................................................... 16 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Condition ................................................................................................. 17 6.6 Test Data ............................................................................................................................. 1 7 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 Deviation From Test Standard ......................................................................................... 19 7.5 EUT Operating Condition ................................................................................................. 19 7.6 Test Data ............................................................................................................................. 1 9 8. BANDWIDTH TEST .......................…

Text truncated - open the document above for the full version.

Page: 17 of 17 FCC ID: 2AWDM-A9D TB-RF-074-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) -----END OF REPORT-----
