1 Aira Inc. Confidential Wireless Charging with FreePower™ Technology 2 Aira Inc. Confidential User Manual Thank you for choosing the Aira FreePower™ Technology Wireless Charger. This wireless charging base is optimized to work with iPhone, iPod, iPodPro, Samsung, Google, Pixel and other wireless charging technology devices. The product is a wireless charger, which allows up to 3 devices to charge anywhere within the charging surface of the product. Package contents • Aira FreePower™ Technology Charging base • User Manual • AC Adaptor (65W) • Barrel Plug cable Features • FreePower™ Technology has the freedom to charge the device placed anywhere on the surface. • Proprietary Controlling circuitry. • Multi-Device Charging simultaneously. • High speed charging, up to 15W. • FOD (Foreign Object Detection). • LED indicator ring. • Bluetooth/Wifi. • Speaker. Charging your wireless device 1. Connect the AC adapter to the FreePower™ Technology base via the Barrel Jack cable, and to the wall outlet. 3 Aira Inc. Confidential Place the device(s) to be charged anywhere on the FreePower™ Technology base as indicated by the LED ring on the countertop. In about 1 second the FreePower™ Technology base and device will communicate and begin to charge. 4 Aira Inc. Confidential FCC ID: 2AWGG-CT-T09 FCC This device complies with Part 15, Subpart C, of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class C digital device, pursuant to Part 15, Subpart C, of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in an installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: To comply with the limits for an FCC Part 15 computing device, always use shielded signal cables. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 8 inches (20.3 cm) between the radiator and your body. 5 Aira Inc. Confidential Specifications • Input :110 - 240VAC, 50/60Hz, 1.8A • Output: up to 45W (Fast Charge) - charging time may vary based on device ⚠DANGER - To reduce the risk of electric shock • Always unplug the device from the electrical outlet • Do not reach for a device that has fallen into water. Unplug it immediately. • Do not place or store devices where it can fall or be pulled into a tub of or sink. • Do not place in or drop into water or other liquid. WARNING ⚠Read all instructions and warnings before using this product. Improper use may result in product damage, excess heat, fire, or explosion, for which you (“Purchaser”), and not Aira Inc. (“Manufacturer”) are responsible. To reduce the risk of burns, fire, electrical shock, or injury to persons: • Use AC Adaptor with UL approved. • Do not use with an extension cord. • Children should be closely supervised to ensure they do not play with the device. • Use this device only for its intended use as described in this manual. Do not use unauthorized accessories of devices. • Never operate this device if it has a damaged cord, plug, cable, or housing. If it is not working properly, if it has been dropped or damaged, return it to the dealer for examination or repair. • Keep the cord away from heated surfaces. • This device is designed for indoor use only. • Only set on dry surfaces. Do not place on surface wet from water or cleaning solvents. 6 Aira Inc. Confidential Troubleshooting Guide Description LED Ring Behavior Troubleshooting Powering on Charger The LED ring will power on to the color and brightness that it was previously set. Normal Operation Device Charging LED ring (if on) will pulse 3 times and then return to normal operation. Normal Operation Device Charge cycle complete Programmable Normal Operation FOD detected or Charging too hot LED ring will turn red. Check surface for FOD Remove the device System error/Power Adapter error LED ring will turn red. Power supply error, too low Wattage Replace with new AC Adapter Warranty Five year limited warranty to the original purchaser only in that this product is free from defects in workmanship and materials from the date of purchase (damages through normal wear and tear, alteration, misuse, neglect, accident, service by anyone other than the authorized service center, act of God not included). During this warranty period, upon verification of defects, this product will be repaired or replaced at the discretion of the manufacturer. This limited warranty is in lieu of all other warranties, express or implied, including, but not limited to implied warranty of merchantability or fitness for a particular purpose. For all warranty claims, the product must be returned with the proof of purchase to the manufacturer. Exclusio…
