2AWHN-P103treadmill

388 FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Zhejiang Aluk Fitness Equipment CO.Ltd Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/23/2024 U.S. Agent Designation Zhejiang Aluk Fitness Equipment CO.Ltd acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AWHN-P103): Name and company of U.S. agent: FCC US Agent, LLC Physical U.S. address of agent: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN of U.S. agent: 0033402884 Email address of U.S. agent: [email protected] FCC US Agent, LLC acknowledges their obligation to accept service of process on behalf of Zhejiang Aluk Fitness Equipment CO.Ltd. Zhejiang Aluk Fitness Equipment CO.Ltd with the FRN 0029600400 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Guangzheng Xu general manager Zhejiang Aluk Fitness Equipment CO.Ltd Signature Tim Payne Manager FCC US Agent, LLC 48_[model] US_Agent_2.911(d)(7) - U, V05

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2AWHN-P103 P103, P103B-1 We, Applicant Company Name: Zhejiang Aluk Fitness Equipment CO., Ltd Address: No 165 Meilong Road, West City, YongKang, Zhejiang 321300, China Phone: +86-579-89267576 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc.. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-09-23 Signature Date Name / Title: Guangzheng Xu / General Manager Company: Zhejiang Aluk Fitness Equipment CO., Ltd Address: No 165 Meilong Road, West City, YongKang, Zhejiang 321300, China Phone: +86-579-89267576 Fax: +86-579-89267576 E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2AWHN-P103 P103, P103B-1 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-09-23 Signature Date Name / Title: Guangzheng Xu / General Manager Company: Zhejiang Aluk Fitness Equipment CO., Ltd Address: No 165 Meilong Road, West City, YongKang, Zhejiang 321300, China Phone: +86-579-89267576 Fax: +86-579-89267576 E-Mail: [email protected]

Zhejiang Aluk Fitness Equipment CO., Ltd No 165 Meilong Road, West City, YongKang, Zhejiang 321300, China Date: September 23, 2024 FCC ID: 2AWHN-P103 Model Number: P103, P103B-1 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Zhejiang Aluk Fitness Equipment CO., Ltd hereby declare that our product (treadmill) Model Number: P103, P103B-1 board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Guangzheng Xu / General Manager Company: Zhejiang Aluk Fitness Equipment CO., Ltd Address: No 165 Meilong Road, West City, YongKang, Zhejiang 321300, China Phone: +86-579-89267576 Fax: +86-579-89267576 E-Mail: [email protected]

Page 1 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity External Photos of the EUT Fig. 1 Fig. 2 Page 2 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7

Page 1 of 1 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L 6.0cm x W 3.0cm) Label Location treadmill Model: P103 FCC ID:2AWHN-P103

Page 1 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 433M Receiver Antenna Page 2 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 BT ANT Page 4 of 4 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8

Page 1 of 5 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information FCC ID : 2AWHN-P103 EUT : treadmill Test Model : P103 Additional Model No. : P103B-1 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : Input: AC 120V, 60Hz Hardware Version : / Software Version : / Bluetooth Frequency Range : 2402MHz~2480MHz Channel Number : 79 channels for Bluetooth V4.2(DSS) 40 channels for Bluetooth V4.2 (DTS) Channel Spacing : 1MHz for Bluetooth V4.2 (DSS) 2MHz for Bluetooth V4.2 (DTS) Modulation Type : GFSK, π/4-DQPSK, 8-DPSK for Bluetooth V4.2(DSS) GFSK for Bluetooth V4.2 (DTS) Bluetooth Version : V4.2 Antenna Description : PCB Antenna, -0.58dBi(Max.) Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Devices 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. Page 2 of 5 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna Page 3 of 5 FCC ID:2AWHN-P103 Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 5. Antenna Information PCB Antenna can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Note Antenna PCB Antenna 2402MHz ~ 2480MHz -0.58dBi Bluetooth Antenna 6. Conducted Power [BT] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 -0.32 39 2441 -0.18 79 2480 -0.51 π/4-DQPSK 0 2402 0.18 39 2441 -0.91 79 2480 0.06 8DPSK 0 2402 -0.02 39 2441 0.94 79 2480 0.56 [BT LE] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 0.64 19 2440 -0.15 39 2480 0.65 [BT 2LE] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 -0.85 19 2440 -0.06 39 2480 0.47 7. Manufacturing Tolerance <BT> GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 0 0 0 Tolerance ± (dB) 1.0 1.0 1.0 π/4DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 0 0 0 Page 4 of 5 FCC ID:2AWHN-P103 Shenzhen LC…

Text truncated - open the document above for the full version.

Antenna Describe 1.Antenna Describe: 2. External View Drawing: Picture of Antenna Antenna PlateIFA Antenna Gain -0.58 dBi Max Frequency Range2402 - 2480 MHz Connector TypePCB Model Name FS-BT-D2 Company NameFitShow (Xiamen) Information Technology Co., Ltd Address 1302, No.1 Chengyi North Street, Software Park Phase III, Xiamen Torch High tech Zone, China 3.Test Data Frequency2.4GHz 2.41GHz 2.42GHz 2.43GHz 2.44GHz 2.45GHz 2.46GHz 2.47GHz 2.48GHz 2.485GHz Horizontal () H Peak EIRP (dBi)-0.47-1.23-2.1-2.23-2.18-2.17-1.96-2.5-3.35-4.05 H Directivity (dBi)4.454.284.083.893.873.974.124.234.234.18 H Efficiency (dB)-4.92-5.51-6.18-6.12-6.05-6.14-6.08-6.73-7.58-8.23 H Efficiency (%)32.2128.1224.124.4324.8324.3224.6621.2317.4615.03 H Gain (dBi) -0.58 -1.23-2.1-2.23-2.18-2.17-1.96-2.5-3.35-4.05 Maximum H Value (dBi)-0.47-1.23-2.1-2.23-2.18-2.17-1.96-2.5-3.35-4.05 Minimum H Value (dBi)-32.5-38.32 -39.99 -45.96 -42.99 -39.14 -36.62 -33.55 -32.89 -34.78 Vertical () V Peak EIRP (dBi)-7.95-8.31-9.05-9.17-8.59-8.09-7.56-7.73-8.09-8.6 V Directivity (dBi)5.075.25.024.754.955.155.165.175.295.33 V Efficiency (dB)-13.02 -13.51 -14.07 -13.92 -13.54 -13.24 -12.72-12.9-13.38 -13.93 V Efficiency (%)4.994.463.924.064.434.745.355.134.594.05 V Gain (dBi)-7.95-8.31-9.05-9.17-8.59-8.09-7.56-7.73-8.09-8.6 Maximum V Value (dBi)-7.95-8.31-9.05-9.17-8.59-8.09-7.56-7.73-8.09-8.6 Minimum V Value (dBi) -42.86 -40.86 -37.04 -41.11 -44.37 -38.86-44.8-44.22 -39.58 -39.93 4 、Test Pattern 2.4GHzUp View2.4GHzDown View2.4GHzFront View 2.45GHzUp View 2.45GHzDow n View 2.45GHzFro nt View 2.485GHzUp View 2.485GHzDo wn View 2.485GHzFr ont View 2.4GHz@Theta 0.0 Horizontal 2.4GHz@Theta 0.0 Vertical 2.4GHz@Theta 0.0 Total 2.45GHz@Theta 0.0 Horizontal 2.45GHz@Theta 0.0 Vertical 2.45GHz@Theta 0.0 Total 2.485GHz@Theta 0.0 Horizontal 2.485GHz@Theta 0.0 Vertical 2.485GHz@Theta 0.0 Total 2.4GHz@Theta 0.0 Horizontal 2.4GHz@Theta 0.0 Vertical 2.4GHz@Theta 0.0 Total 2.45GHz@Theta 0.0 Horizontal 2.45GHz@Theta 0.0 Vertical 2.45GHz@Theta 0.0 Total 2.485GHz@Theta 0.0 Horizontal 2.485GHz@Theta 0.0 Vertical 2.485GHz@Theta 0.0 Total

Page 1 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix B RF Test Data for BT LE (Conducted Measurement) Product Name: treadmill Test Model: P103 Environmental Conditions Temperature: 23.8 C Relative Humidity: 52.1% ATM Pressure: 100.0 kPa Test Engineer: Paddi Chen Supervised by: Nick Peng Page 2 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity B.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1M 2402 Ant 0.661 >=0.5 Pass NVNT BLE 1M 2440 Ant 0.65 >=0.5 Pass NVNT BLE 1M 2480 Ant 0.653 >=0.5 Pass NVNT BLE 2M 2402 Ant 1.135 >=0.5 Pass NVNT BLE 2M 2440 Ant 1.164 >=0.5 Pass NVNT BLE 2M 2480 Ant 1.163 >=0.5 Pass Page 3 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs -6dB Bandwidth NVNT BLE 1M 2402MHz Ant -6dB Bandwidth NVNT BLE 1M 2440MHz Ant Page 4 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT BLE 1M 2480MHz Ant -6dB Bandwidth NVNT BLE 2M 2402MHz Ant Page 5 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT BLE 2M 2440MHz Ant -6dB Bandwidth NVNT BLE 2M 2480MHz Ant Page 6 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity B.2 Maximum Peak Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT BLE 1M 2402 Ant 0.64 30 Pass NVNT BLE 1M 2440 Ant -0.15 30 Pass NVNT BLE 1M 2480 Ant 0.65 30 Pass NVNT BLE 2M 2402 Ant -0.85 30 Pass NVNT BLE 2M 2440 Ant -0.06 30 Pass NVNT BLE 2M 2480 Ant 0.47 30 Pass Page 7 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs Power NVNT BLE 1M 2402MHz Ant Power NVNT BLE 1M 2440MHz Ant Page 8 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Power NVNT BLE 1M 2480MHz Ant Power NVNT BLE 2M 2402MHz Ant Page 9 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Power NVNT BLE 2M 2440MHz Ant Power NVNT BLE 2M 2480MHz Ant Page 10 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity B.3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 Ant -15.93 8 Pass NVNT BLE 1M 2440 Ant -17.8 8 Pass NVNT BLE 1M 2480 Ant -16.05 8 Pass NVNT BLE 2M 2402 Ant -20.57 8 Pass NVNT BLE 2M 2440 Ant -19.19 8 Pass NVNT BLE 2M 2480 Ant -19.23 8 Pass Page 11 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs PSD NVNT BLE 1M 2402MHz Ant PSD NVNT BLE 1M 2440MHz Ant Page 12 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity PSD NVNT BLE 1M 2480MHz Ant PSD NVNT BLE 2M 2402MHz Ant Page…

Text truncated - open the document above for the full version.

Page 1 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT For Zhejiang Aluk Fitness Equipment CO.Ltd treadmill Test Model: P103 Additional Model No.:P103B-1 Prepared for : Zhejiang Aluk Fitness Equipment CO.Ltd Address : No 165 Meilong Road,West City,YongKang,Zhejiang,China,321300 Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : August 07, 2024 Number of tested samples : 2 Sample No. : A240805030-1, A240805030-2 Serial number : Prototype Date of Test : August 07, 2024 ~ August 15, 2024 Date of Report : August 16, 2024 Page 2 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC TEST REPORT FCC CFR 47 PART 15 C(15.247) Report Reference No. ................. : LCSA08064077EB Date of Issue .................................. : August 16, 2024 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address .......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Zhejiang Aluk Fitness Equipment CO.Ltd Address .......................................... : No 165 Meilong Road,West City,YongKang,Zhejiang,China,321300 Test Specification Standard ......................................... : FCC CFR 47 PART 15 C(15.247) Test Report Form No.................... : TRF-4-E-145 A/0 TRF Originator ................................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ..................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. EUT Description. .......................... : treadmill Trade Mark ..................................... : N/A Test Model ...................................... : P103 Ratings ........................................... : Input: AC 120V, 60Hz Result ............................................ : Positive Compiled by: Supervised by: Approved by: Jack Liu/Administrator Cary Luo/ Technique principal Gavin Liang/ Manager Page 3 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity FCC -- TEST REPORT Test Model............................... : P103 EUT......................................... : treadmill Applicant............................... : Zhejiang Aluk Fitness Equipment CO.Ltd Address.................................. : No 165 Meilong Road,West City,YongKang,Zhejiang,China,321300 Telephone............................... : / Fax.......................................... : / Manufacturer........................ : Zhejiang Aluk Fitness Equipment CO.Ltd Address................................... : No 165 Meilong Road,West City,YongKang,Zhejiang,China,321300 Telephone............................... : / Fax.......................................... : / Factory................................... : Zhejiang Aluk Fitness Equipment CO.Ltd Address................................... : No 165 Meilong Road,West City,YongKang,Zhejiang,China,321300 Telephone............................... : / Fax.......................................... : / Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCSA08064077EB August 16, 2024 Date of issue Page 4 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Revision History Report Version Issue Date Revision Content Revised By 000 August 16, 2024 Initial Issue --- Page 5 of 34 FCC ID:2AWHN-P103 Report No.: LCSA08064077EB Shenzhen LCS Compliance Testing Laboratory Lt…

Text truncated - open the document above for the full version.
