FCC Software Configuration Control Declaration Rev1.1 FIBRAIN sp. z o.o. FCC Software Configuration Control Declaration Date: Oct.18, 2022 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: HGU/HL-4GXV-F, HLE-3GX-F Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Date: 2022-10-18 Name: Radoslaw Ziemba Title: Head of Active Equipment Signature of applicant

FIBRAIN sp. z o.o. Agent Authorization Company:FIBRAIN sp. z o.o. Address: Poland, Zaczernie 190F, 36-062 Product Name: HGU Model Number(s): HL-4GXV-F, HLE-3GX-F We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Date: Oct. 18, 2022 Signature: Name: Radoslaw Ziemba Title: Head of Active Equipment Company: FIBRAIN sp. z o.o.

FIBRAIN sp. z o.o. Date: Oct 18, 2022 Offic e of Engineering Technology Federal Communications Commission 743 5 Oakland Mill s Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2AWIZHL4GXVF To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure FCC Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705 . OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Radoslaw Ziemba Title: Head of Active Equipment

FIBRAIN sp. z o.o. Model Confirmation Letter We, FIBRAIN sp. z o.o. , certify the product: HGU , Model No.: HL-4GXV-F, HLE-3GX-F Their electrical circuit design, layout, components used and internal wiring are identical, Only the color will be different ,so the name will be different. Test sample model: HL-4GXV-F Signiture: Grantee Contact: Radoslaw Ziemba Company Name: FIBRAIN sp. z o.o. Date: 2022-10-18 FCC ID: 2AWIZHL4GXVF

Label place SIZE: 70*45mm Sample:

2.4GWIFI ANT1 5GWIFI ANT1

FCC ID: 2AWIZHL4GXVF RF Exposure Evaluation According to KDB447498D01 General RF Exposure Guidance v06 4.3.1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. Limits According to FCC Part1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in part1.1307(b) F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4* Pi * R 2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Result of RF Exposure Evaluation 2.4GW IFI Antenna1& Antenna2 Gain: 2.0dBi, MIMO Gain:5.01dBi 5GW IFI Antenna1& Antenna2 Gain: 1.5dBi, MIMO Gain: 4.36dBi Antenna Gain: The maximum Gain measured in fully anechoic chamber is 1.0 in linear scale. Output Power Into Antenna & RF Exposure Evaluation Distance: Measurement Data The Max Conducted Peak Output Power data refer to report Report No.: ZKT-220929L7324-01& ZKT-220929L7324-02 2.4GW IFI: worst mode and channel Test channel Antenna Output Power (dBm) Tune up tolerance (dBm) ANT1 ANT2 SUM ANT1 ANT2 SUM TX 802.11n20 Mode CH01 17.74 17.774 20.77 17±1 17±1 20.01±1 CH06 17.369 16.362 19.90 17±1 17±1 20.01±1 CH11 17.431 16.780 20.13 17±1 17±1 20.01±1 Test worst case Maximum tune-up Power (dBm) Maximum tune-up Power (mW) Calculated value (mW/cm2) Limit (mW/cm2) ANT1 ANT2 SUM ANT1 ANT2 SUM / / 18 18 21.01 63.1 63.1 126.2 0.0796 1.0 Remark: 1)The Max Conducted Peak Output Power data refer to report Report No.: ZKT-220929L7324-01 2) Pd = (Pout*G)/(4* Pi * R 2 )=( 126.2*3.17)/(4*3.1415*20*20)= 0.0796, G=10 gain/10 =3.17 5GW IFI- worst mode and channel: Mode Test channel Antenna Output Power (dBm) Tune up tolerance (dBm) Max Tune up (dBm) ANT1 ANT2 SUM ANT1 ANT2 SUM n(20MH z) 36 6.596 6.478 9.55 7±1 7±1 10.01±1 11.01 40 7.667 7.022 10.37 7±1 7±1 10.01±1 11.01 48 7.063 6.963 10.02 7±1 7±1 10.01±1 11.01 Test worst case Maximum tune-up Power (dbm) Maximum tune-up Power (mW) Calculated value (mW/cm2) Limit (mW/cm2) 11.01 12.618 0.00685 1.0 Remark: 1)The Max Conducted Peak Output Power data refer to report Report No.: ZKT-220929L7324-02 2) Pd = (Pout*G)/(4* Pi * R 2 )=( 12.618*2.73)/(4*3.1415*20*20)= 0.00685 , G=10 gain/10 =2.73 EUT RF Exposure Evaluation simultaneous transmission operations According to 865664D02 2.2 d) 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits : Simultaneous transmission mode The sum of the ratios SUM Limit 2.4G W IFI + 5G W IFI 0.0796+0.00685 0.08645 1.0 conclusion : 0.08645 < 1.0, So there is no sar requirement NOTE:1. EUT wifi-5G module & wifi-2.4G module is more than 20cm away from the human body. 2.The sum of the ratios(2.4GW IFI + 5G W IFI) is less than the limit value of 1.0, so there is no sar requirement.

P ower Tree V CC 5V FOR USB VINDC DC_12V +3 _3V_BD D DR_1.5V Max 3A DC-DC <BUCK> DC-DC <BUCK> DC-DC <BUCK> Max 2A U9 08 LDO 供电 L E9643 语音 E N7571 BOSA LED FLASH +3_3V EN7528 【 U6 21 】 L DO EN7528-EFUSE M ax 3A +3 _3V_RF Fo r MT7975 TXG For MT7975 For MT7915 +3 _3V_BD D C-DC <BUCK> Max 2A V CCK_BD EN7571_1_0V EN7528_VCCK VCCK 1.2V D C-DC <BUCK> Max 2A 1. 8V M T7915D MT7975D D C-DC <BUCK> Max 4A 1. 0V MT7915D W iFi部分供电 [10]CO-CLK-OUT +3_3V +3_3V +3_3V VCCK DDRVCCIO +3_3V AVDD33_BG AVDD33_XTAL +3_3V VCCK AVDD33_MEMPLL +3_3V VCCK +3_3V [8]DDR_A5 [8]DDR_A0 [8]DDR_A9 [8]DDR_A13 [8]DDR_CKE [8]DDR_CLK_N [8]DDR_CLK_P [6]PON_TX_DIS [7]TXVN_A_P1 [7]TXVN_D_P1 [7]TXVN_C_P1 [7]TXVN_B_P1 [7]TXVP_C_P1 [7]TXVP_B_P1 [7]TXVP_A_P1 [7]TXVP_D_P1 [7]TXVN_A_P2 [7]TXVN_D_P2 [7]TXVN_C_P2 [7]TXVN_B_P2 [7]TXVP_C_P2 [7]TXVP_B_P2 [7]TXVP_A_P2 [7]TXVP_D_P2 [7]TXVN_D_P3 [7]TXVP_B_P3 [7]TXVP_C_P3 [7]TXVN_A_P3 [7]TXVN_C_P3 [7]TXVP_D_P3 [7]TXVP_A_P3 [7]TXVN_B_P3 [7]TXVN_D_P0 [7]TXVN_A_P0 [7]TXVN_C_P0 [7]TXVN_B_P0 [7]TXVP_B_P0 [7]TXVP_C_P0 [7]TXVP_D_P0 [7]TXVP_A_P0 [14] VGASP_SENSE [8]DDR_A15 [8]DDR_A12 [8]DDR_A14 [8]DDR_A11 [8]DDR_A2 [8]DDR_A10 [8]DDR_BA2 [8]DDR_WE_N [8]DDR_BA0 [8]DDR_A3 [8]DDR_A4 [8]DDR_CS_N [8]DDR_A7 [6]PON_TX_FAULT [6]PON_BURST_EN [6]PON_RX_SD [6]PON_TX_SD PCIE_RESET0 PCIE_RESET1 [6]I2C_SCL [6]I2C_SDA [6]PON_RXP [6]PON_RXN [8]DDR_BA1 [8]DDR_A1 [8]DDR_CAS_N [8]DDR_A6 [8]DDR_RAS_N [8]DDR_ODT [8]DDR_DQ15 [8]DDR_DQ14 [8]DDR_DQ4 [8]DDR_DQ6 [8]DDR_DQ12 [8]DDR_DQ9 [8]DDR_DQS0 [8]DDR_DQS0_N [8]DDR_RESET# [8]DDR_A8 [8]DDR_DQ2 [8]DDR_DQ11 [8]DDR_DQ13 [8]DDR_DQ0 [8]DDR_DQM1 [8]DDR_DQ10 [8]DDR_DQ1 [8]DDR_DQ3 [8]DDR_DQ8 [8] DDR_DQ5 [5,9]GPIO0 [6]PON_TXP [6]PON_TXN DDR_DQ0 DDR_DQ15 R_EXT DDR_DQ9 DDR_DQ2 DDR_DQ11 DDR_DQ12 DDR_CLK_P PCIE_VRT1 DDR_CLK_N TANA_GE DDR_DQ4 DDR_DQ6 DDR_DQ3 DDR_DQ13 DDR_DQ8 DDR_DQ5 DGINP DDR_DQ10 GPIO0 DDR_DQ14 DDR_DQ1 PCIE_TXN0 PCIE_TXN1 XTAL_IN PCIE_TXP1 XTAL_OUT PCIE_TXP0 DDR_VREF [9]USB_LED [4]EFUSE 2_5V_EFUSE [4]EFUSE [4,8]DDR_DQM0 [4,8] DDR_DQ7 [5]TP [5]TN [4]XTAL_IN [4]XTAL_OUT PCIE_TXP0 PCIE_TXN0 [4,10] PCIE_CKN0_1 [4,10] PCIE_CKP0_1 PCIE_TXP1 PCIE_TXN1 [4,10] PCIE_CKP1_1[4,10]PCIE_CKN1_1 +3_3V +3_3V VCCK +3_3V +3_3V VCCK [4,8]DDR_DQM0 [4,8]DDR_DQ7 [8]DDR_DQS1 [4,9]USB_DP1 [8]DDR_DQS1_N [4,9]USB_DM1 [4,9]USB_DP1 [4,9]USB_DM1 [4,8]DDR_DQ7 [4,8]DDR_DQM0 [4]DDR_DQS1/AVDD33_USB [4]DDR_DQS1_N/USB_DP1 [4]GND/USB_DM1 [4]USB0_DM/SSUSB_VRT [4]AVDD33_USB/SSUSB_TXP [4]USB_DP1/SSUSB_TXN [4]USB_DM1/AVDDK_SSUSB [4]AVDD33_USB/SSUSB_RXP [4]AVDDK_SSUSB/SSUSB_RXN [4]AVDDK_SSUSB/SSUSB_RXN [4]AVDD33_USB/SSUSB_RXP [4]USB_DM1/AVDDK_SSUSB [4]USB_DP1/SSUSB_TXN [4]AVDD33_USB/SSUSB_TXP +3_3V [4]USB0_DM/SSUSB_VRT [4]GND/USB_DM1 [4]DDR_DQS1_N/USB_DP1 [4]DDR_DQS1/AVDD33_USB +3_3V P0_LED+JTAG_TCK P1_LED+JTAG_TDI P2_LED+JTAG_TDO P3_LED+JTAG_TMS [10] PERST_N PCIE_RESET1 PCIE_RESET0 [5,8]SPI_CLK [5,8]SPI_MOSI [5,8] SPI_MISO [8] SPI_CS [12,13] ZMISO1 [12,13]ZMOSI1 [12,13] ZSYNC1 [12,13] ZCLK1 [9] GPIO27_SEL1 [9] GPIO23_SEL0 [9] GPIO26_SEL2 [14]3V3_PWM [14] 5V_EN [14] VCCK_PWM [9] LED_USB_GPIO2 UART_TXD UART_RXD [9] LED_BB_N_GPIO4 [9]LED_PWR_N_GPIO8 [9] WAN_LED_GPIO6 [9]LED_ALARM_N_GPIO7 [9] WPS_SW_GPIO9 [9] LED_SW_GPIO10 [9]WLAN_SW_GPIO11 [9]LED_5G_N_GPIO1 [9] GPIO22 [13]ZSI_RESET PCIE_RXN0_1 PCIE_RXP0_1 PCIE_RXN1_1 PCIE_RXP1_1 PCIE_CKN1_1 PCIE_CKN0_1 PCIE_CKP0_1 PCIE_CKP1_1 PCIE_TXP0_2 PCIE_TXN0_2 PCIE_TXP1_2 PCIE_TXN1_2 [4,10] PCIE_CKN0_1 [4,10]PCIE_CKP0_1 [4,10]PCIE_TXP0_2 [4,10] PCIE_TXN0_2 [4,10] PCIE_RXP0_1 [4,10] PCIE_RXN0_1 [4,10] PCIE_RXP1_1 [4,10]PCIE_RXN1_1 [4,10] PCIE_CKN1_1 [4,10] PCIE_CKP1_1 [4,10] PCIE_TXP1_2 [4,10]PCIE_TXN1_2 PCIE_RXN0_1 PCIE_RXP0_1 PCIE_RXN1_1 PCIE_RXP1_1 PCIE_TXP1_2 PCIE_TXN1_2 PCIE_CKN1_1 PCIE_CKN0_1 PCIE_TXP0_2 PCIE_TXN0_2 PCIE_CKP0_1 PCIE_CKP1_1 [9] LED_2.4G_N_GPIO3 GPIO0 拉低 高安模式 GPIO0 拉高 非高安模式 GPIO0 不能悬空 悬空可能导致不断重启 7528内置DDR 上R18 2.5V 7528外置DDR 上R17 GND EN7528HU EN7528DU EN7528DU PCIE0(2.4G) EN7528DU PCIE1(5G) Layout diff. 100R Layout diff. 90R Layout diff. 90R Layout diff. 90R Layout diff. 90R Layout diff. 100R 5 R102 0R C107 1uF C106 1uF C109 0.1uF C171 0.1uF C173 0.1uF C174 0.1uF 2.5x3.2 1 2 4 3 Y100 [XTAL,25MHz,2.5x2.0, 15pF] R163 9.31KR,1% R11724.3KR,1% C101 301R, 1% C100 301R, 1% R161 NC/24.3KR,1% R162 100KR R1351KR 110:DDR_DQS1#/USB_DP1 109:DDR_DQS1/AVDD33_USB 108:DDR_DQM0/USB_DP0 107:DDR_DQ7/USB_DM0 EN7528HU/DU 1 AVDD33_PON 2 PON_RXP 3 PON_RXN 4 AVDDK_PON 5 VCCK 6 VCCK 7 PON_TX_DIS 8 VCCIO33 9 PON_TX_FAULT 10 PON_TX_SD 11 PON_RX_SD 12 PON_BURST_EN 13 I2C_SDA 14 I2C_SCL 15 GPIO30 16 GPIO31_P0_LED 17 GPIO32 18 GPIO33_P1_LED 19 GPIO34 20 GPIO35_P2_LED 21 GPIO36 22 GPIO37_P3_LED 23 VCCIO33 24 PCIE_RESET0 25 PCIE_RESET1 26 EFUSE 27 VCCK 28 VCCK 29 VCCK 30 VCCK 31 AVDDK_PE1 32 PCIE_CKP1 33 PCIE_CKN1 34 PCIE_VRT1 35 AVDD33_PE1 36 PCIE_TXP1 37 PCIE_TXN1 38 AVSSK_PE1 39 AVDDK_PE1 40 PCIE_RXP1 41 PCIE_RXN1 42 VCCK 43 VCCK 44 PCIE_CKP0 45 PCIE_CKN0 46 AVDDK_PE0 47 PCIE_TXN0 48 PCIE_TXP0 49 AVSSK_PE0 50 PCIE_RXP0 51 PCIE_RXN0 52 AVDD33_PE0 53 DDR_A8/NC 54 DDR_RESET/NC 162 VCCK 161 VCCK 160 VCCIO33 159 GPIO0 158 UART_RXD 157 UART_TXD 156 GPIO39 155 GPIO38 154 GPIO11 153 GPIO10 152 GPIO9 151 GPIO8 150 GPIO7 149 GPIO6 148 GPIO4 147 GPIO3 146 GPIO2 145 GPIO1 144 GPIO22 143 PON_RX_DIS 142 VCCK 141 VCCK 140 VCCK 139 GPIO29 138 VCCIO33 137 GPIO28 136 GPIO23 135 GPIO5 134 GPIO25 133 GPIO24 132 GPIO27 131 GPIO26 130 ZMISO1/IMISO1 129 ZMOSI1/IMOSI1 128 ZSYNC1/IRESET1 127 ZCLK1/ICLK1 126 SPI_MISO 125 SPI_MOSI 124 SPI_CLK 123 SPI_CS 122 VCCIO33 121 HW_RSTN 120 VCCK 119 VCCK 118 AVDDK_USB/SSUSB_RXN 117 AVDD33_USB/SSUSB_RXP 116 USB_DM1/AVDDK_SSUSB 115 USB_DP1/SSUSB_TXN 114 AVDD33_USB/SSUSB_TXP 113 USB_DP0/AVDD33_USB 112 USB_DM0/SSUSB_VRT 111 AVSS/USB_DM1 110 DDR_DQS1#/USB_DP1 109 DDR_DQS1/AVDD33_USB 216 PON_TXP 215 PON_TXN 214 AVDD33_XTAL 213 XTAL_OUT 212 XTAL_IN 211 REFCK_OUT 210 REXT 209 AVDD33_BG 208 DGINP 207 TN 206 TP 205 TEN 204 AVDD33_GPPLL 203 PLL_TP 202 PLL_TN 201 VCCK 200 VCCK 199 AVDD33_LD 198 TXVN_D_P3 197 TXVP_D_P3 196 TXVN_C_P3 195 TXVP_C_P3 194 TXVN_B_P3 193 TXVP_B_P3 192 TXVN_A_P3…

Text truncated - open the document above for the full version.

Project No.: ZKT- 220929L7324-02 Page 1 of 133 FCC TEST REPORT FCC ID: 2AWIZHL4GXVF Report Number............................... : ZKT-220929L7324-02 Date of Test................................................. : Sep. 14, 2022 -- Oct. 12, 2022 Date of issue .................................... : Oct. 12, 2022 Total number of pages ..................... : 133 Test Result ....................................... : PASS Testing Laboratory. ....................... : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ......................... : FIBRAIN sp. z o.o. Address .......................................... : Poland, Zaczernie 190F, 36-062 Manufacturer's name ................... : FIBRAIN sp. z o.o. Address .......................................... : Poland, Zaczernie 190F, 36-062 Test specification: Standard .......................................... : FCC CFR Title 47 Part 15 Subpart E Section 15.407 ANSI C63.10:2013 KDB 789033 D02 V01r02 Test procedure................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-110_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF ................................... : Dated: 2020-01-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................. : HGU Trademark ...................................... : / Model/Type reference ...................... : HL-4GXV-F, HLE-3GX-F Ratings ............................................ : DC 12V Adapter Project No.: ZKT-220929L7324-02 Page 2 of 133 Testing procedure and testing location: Testing Laboratory .................................. : Shenzhen ZKT Technology Co., Ltd. Address ..................................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Alen He Tested by (name + signature) .................... : Joe Liu Reviewer (name + signature)..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-220929L7324-02 Page 3 of 133 Table of Contents Page 1. VERSION 5 2. SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3. GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 3.5EQUIPMENTS LIST FOR ALL TEST ITEMS 11 4. EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 TEST PROCEDURE 12 4.1.3 DEVIATION FROM TEST STANDARD 12 4.1.4 TEST SETUP 13 4.1.5 EUT OPERATING CONDITIONS 13 4.1.6 TEST RESULT 14 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 17 4.2.5 EUT OPERATING CONDITIONS 18 4.2.6 TEST RESULTS 19 5.POWER SPECTRAL DENSITY TEST 73 5.1 APPLIED PROCEDURES / LIMIT 73 5.2 TEST PROCEDURE 73 5.3 DEVIATION FROM STANDARD 73 5.4 TEST SETUP 73 5.5 EUT OPERATION CONDITIONS 74 5.6 TEST RESULT 74 6. -26 DB & 6DBM EMISSION BANDWIDTH 90 6.1 APPLIED PROCEDURES / LIMIT 90 6.2 TEST PROCEDURE 90 6.3 DEVIATION FROM STANDARD 90 6.4 TEST SETUP 90 6.5 EUT OPERATION CONDITIONS 90 Project No.: ZKT-220929L7324-02 Page 4 of 133 6.6 TEST RESULT 90 7. OUTPUT POWER TEST 106 7.1 APPLIED PROCEDURES/LIMIT 106 7.2 DEVIATION FROM STANDARD 106 7.3 TEST SETUP 106 7.4 EUT OPERATION CONDITIONS 106 7.5 TEST RESULT 107 8. OUT OF BAND EDGE EMISSION 109 8.1 TEST PROCEDURE 109 8.2 DEVIATION FROM STANDARD 109 8.3 TEST SETUP 109 8.4 EUT OPERATION CONDITIONS 109 8.5 TEST RESULTS 109 9. FREQUENCY STABILITY MEASUREMENT 122 9.4 TEST RESULT 122 10.ANTENNA REQUIREMENT 131 10. TEST SETUP PHOTO 132 11. EUT CONSTRUCTIONAL DETAILS 133 Project No.: ZKT-220929L7324-02 Page 5 of 133 1. VERSION Report No. Version Description Approved ZKT-220929L7324-02 Rev.01 Initial issue of report Oct. 12, 2022 Project No.: ZKT-220929L7324-02 Page 6 of 133 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Result Remark 15.203/15.247 (c) Antenna requirement PASS 15.207 AC Power Line Conducted Emission PASS 15.407 (a) (b) Spurious Radiated Emissions and Band Edge PASS 15.407 (e) /15.403(i) 6 dB bandwidth, 26dB Emission Bandwidth& 99% Occupied Bandwidth PASS 15.407 (a) Power Spectral Density PASS 15.407 (a)(1)(2)(3) Maximum conducted output power PASS 15.407 (g) Frequency Stability PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Project No.: ZKT-220929L7324-02 Page 7 of 133 2.1 TEST FACILITY Shenzhen ZKT Technology Co., Ltd. Add. : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China FCC Test Firm Registration Number: 692225 Designation Number: CN1299 IC Registered No.: 27033 2.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 Project No.: ZKT-220929L7324-02 Page 8 of 133 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Product Name: HGU Model No.: HL-4GXV-F Serial No.: HLE-3GX-F Model difference: Their electrical circuit design, layout, components used and internal wiring are identical, Only the c…

Text truncated - open the document above for the full version.

Project No.: ZKT-220929L7324-02 Page 90 of 133 6. -26 DB & 6DBM EMISSION BANDWIDTH Test Requirement: Part 15 Subpart C Section 15.407 (e) Test Method: KDB 789033 D02 v02r01 6.1 APPLIED PROCEDURES / LIMIT FCC Part15.407 (e) Bandwidth Limit U-NII-1 N/A U-NII-3 ≥ 500 kHz 6.2 TEST PROCEDURE Place the EUT on the table and set it in the transmitting mode. Remove the antenna from the EUT and then connect a low-loss RF cable from the antenna port to the spectrum analyzer. Set the spectrum analyzers RBW = approximately 1% of the emission bandwidth, VBW >RBW, Detector = Peak, Span>26dB bandwidth, and Sweep = auto ,Trace mode = max hold. Measure the maximum width of the emission that is 26dB down from the maximum of the emission. Compare this with the RBW setting of the analyzer. Readjust RBW and repeat measurement as needed until the RBW/EBW ratio is approximately 1%. Repeat until all the rest channels were investigated. 6.3 DEVIATION FROM STANDARD No deviation. 6.4 TEST SETUP 6.5 EUT OPERATION CONDITIONS The EUT tested system was configured as the statements of 2.4 Unless otherwise a special operating condition is specified in the follows during the testing. 6.6 TEST RESULT Temperature： 26°C Relative Humidity： 54% Pressure： 101kPa Test Voltage ： AC 120V Test Mode ： TX Project No.: ZKT-220929L7324-02 Page 91 of 133 U-NII-1 802.11 Mode Channel No. Frequency [MHz] 26dB Bandwidth [MHz] ANT1 ANT2 a 36 5180 19.30 19.48 40 5200 19.42 19.33 48 5240 19.21 19.28 n (20MHz) 36 5180 19.66 19.56 40 5200 19.79 19.59 48 5240 19.47 19.45 n (40MHz) 38 5190 39.07 38.85 46 5230 39.22 39.45 ac (20MHz) 36 5180 20.00 19.96 40 5200 19.74 19.86 48 5240 20.10 19.92 ac(40MHz) 38 5190 40.42 40.30 46 5230 40.37 40.49 ac(80MHz) 42 5210 80.25 80.14 ax (20MHz) 36 5180 21.82 21.98 40 5200 21.22 21.39 48 5240 21.92 21.76 ax(40MHz) 38 5190 39.43 39.35 46 5230 39.55 39.50 ax(80MHz) 42 5210 80.16 80.25 U-NII-3 802.11 Mode Channel No. Frequency [MHz] -6db Bandwidth [MHz] Limit ANT1 ANT2 a 149 5745 16.38 15.49 ≥ 500 kHz 157 5785 16.34 16.36 165 5825 16.31 16.40 n (20MHz) 149 5745 16.53 17.50 157 5785 15.69 16.62 165 5825 17.48 17.09 n (40MHz) 151 5755 33.93 35.15 159 5795 35.16 32.67 ac (20MHz) 149 5745 17.65 17.66 157 5785 17.69 17.69 165 5825 17.69 17.64 ac(40MHz) 151 5755 35.99 36.02 159 5795 36.17 35.85 ac(80MHz) 155 5775 76.14 76.41 ax (20MHz) 149 5745 19.11 19.07 157 5785 19.06 19.11 165 5825 19.04 19.08 ax(40MHz) 151 5755 38.05 38.14 159 5795 38.12 38.08 ax(80MHz) 155 5775 77.75 77.93 Test plot as follows: Project No.: ZKT-220929L7324-02 Page 92 of 133 U-NII-1 – 802.11a ANT1 ANT2 CH36-5180MHz CH36-5180MHz CH40-5200MHz CH40-5200MHz CH48-5240MHz CH48-5240MHz Project No.: ZKT-220929L7324-02 Page 93 of 133 U-NII-1 – 802.11n (20MHz) ANT1 ANT2 CH36-5180MHz CH36-5180MHz CH40-5200MHz CH40-5200MHz CH48-5240MHz CH48-5240MHz Project No.: ZKT-220929L7324-02 Page 94 of 133 U-NII-1 – 802.11n (40MHz) ANT1 ANT2 CH38-5190MHz CH38-5190MHz CH46-5230MHz CH46-5230MHz U-NII-1 – 802.11ac 20MHz) ANT1 ANT2 CH36-5180MHz CH36-5180MHz Project No.: ZKT-220929L7324-02 Page 95 of 133 CH40-5200MHz CH40-5200MHz CH48-5240MHz CH48-5240MHz U-NII-1 – 802.11ac (40MHz) ANT1 ANT2 CH38-5190MHz CH38-5190MHz Project No.: ZKT-220929L7324-02 Page 96 of 133 CH46-5230MHz CH46-5230MHz U-NII-1–802.11ac (80MHz) ANT1 ANT2 CH42 5210MHz CH42 5210MHz U-NII-1 – 802.11ax 20MHz) ANT1 ANT2 CH36-5180MHz CH36-5180MHz Project No.: ZKT-220929L7324-02 Page 97 of 133 CH40-5200MHz CH40-5200MHz CH48-5240MHz CH48-5240MHz U-NII-1 – 802.11ax (40MHz) ANT1 ANT2 CH38-5190MHz CH38-5190MHz Project No.: ZKT-220929L7324-02 Page 98 of 133 CH46-5230MHz CH46-5230MHz U-NII-1 –802.11ax (80MHz) ANT1 ANT2 CH42 5210MHz CH42 5210MHz U-NII-3 –802.11a ANT1 ANT2 CH149 -5745MHz CH149 -5745MHz Project No.: ZKT-220929L7324-02 Page 99 of 133 CH157 -5785MHz CH157 -5785MHz CH165 -5825MHz CH165 -5825MHz U-NII- 3 –802.11n (20MHz) ANT1 ANT2 CH149 -5745MHz CH149 -5745MHz Project No.: ZKT-220929L7324-02 Page 100 of 133 CH157 -5785MHz CH157 -5785MHz CH165 -5825MHz CH165 -5825MHz U-NII- 3 – 802.11n (40MHz) ANT1 ANT2 CH151 -5755MHz CH151 -5755MHz Project No.: ZKT-220929L7324-02 Page 101 of 133 CH159 -5795MHz CH159 -5795MHz U-NII-3 –802.11ac (20MHz) ANT1 ANT2 CH149 -5745MHz CH149 -5745MHz CH157 -5785MHz CH157 -5785MHz Project No.: ZKT-220929L7324-02 Page 102 of 133 CH165 -5825MHz CH165 -5825MHz U-NII- 3 – 802.11ac (40MHz) ANT1 ANT2 CH151 -5755MHz CH151 -5755MHz CH159 -5795MHz CH159 -5795MHz Project No.: ZKT-220929L7324-02 Page 103 of 133 U-NII-3– 802.11ac (80MHz) ANT1 ANT2 CH155 -5775MHz CH155 -5775MHz U-NII-3–802.11ax (20MHz) ANT1 ANT2 CH149 -5745MHz CH149 -5745MHz CH157 -5785MHz CH157 -5785MHz Project No.: ZKT-220929L7324-02 Page 104 of 133 CH165 -5825MHz CH165 -5825MHz U-NII- 3 – 802.11ax (40MHz) ANT1 ANT2 CH151 -5755MHz CH151 -5755MHz CH159 -5795MHz CH159 -5795MHz Project No.: ZKT-220929L7324-02 Page 105 of 133 U-NII- 3 – 802.11ax (80MHz) ANT1 ANT2 CH155 -5775MHz CH155 -5775MHz Project No.: ZKT-220929L7324-02 Page 106 of 133 7. OUTPUT POWER TEST Test Requirement: 15.407 (a)(1)(2)(3) Test Method: KDB 789033 D02 v02r01 7.1 APPLIED PROCEDURES/LIMIT For an indoor access point operating in the band 5.15-5.25 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W provided the maximum antenna gain does not exceed 6 dBi. For the band 5.725-5.850 GHz, the maximum conducted output power over the frequency band of operation shall not exceed 1 W. In addition, the maximum power spectral density shall not exceed 30 dBm in any 500-kHz band. Test Item Limit Result Max conducted output power 1W / 30dbm Pass Max conducted output power 1 W / 30dbm Pass 7.2 DEVIATION FROM STANDARD No deviation. 7.3 TEST SETUP 7.4 EUT OPERATION CONDITIONS The EUT tested system was configured as the statements of 2.4 Unless otherwise a special operating condition is specified in the follows during the testing. Project No.: ZKT-220929L7324-02 Page 107 of 133 7.5 TEST RESULT Temperature： 26°C Relative Humidity： 54% Pressur…

Text truncated - open the document above for the full version.

深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD Antenna Test Report 产品名称: AUX-BT/WIFI FPC ANT PRODUCT NAME 客户名称： GUANGDONG UNION TECHNOLOGY CO., LTD CUSTOMER NAME 料号： T408-13MB-185 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 1.Purpose Standardize product specifications and test methods for mobile communication terminal antennas produced by OnePlus to avoid errors caused by differences in test conditions and methods. 2.Overview of product categories and product models 2.1 Product model overview This report mainly outlines the electrical results of the antenna designed for the KST103SD_J project. The design frequency band of this antenna is: 2.4G WIFI segment. 3.Description of basic parameters and experimental equipment 3.1 Basic parameters Product electrical performance index Operating frequency 2400-2480MHz 4800-5850 MHz VSWR 2400-2480 MHz: < 2.0 4800-5850 MHz: < 1.35 Antenna gain 2400-2480 MHz: 1.5dBi Max 4800-5850 MHz: 1.09dBi Max Radiation efficiency 2400-2480 MHz: > 30% 4800-5850 MHz: > 38% impedance 50 ohm Product material description FPC Electrolytic copperPI coaxial Braided wire + terminal Product Environmental Description Operating temperature - 30 ̊C ~ + 85 ̊C stored temperature - 30 ̊C ~ + 85 ̊C 3.2 Experimental equipment description ListTesting projectEquipment 1. S Parameters 1.Return loss 2. VSWR at Network analyzer: Agilent 8753ES 2. Coupling power test 1. Transmission power 2. Receiving sensitivity Comprehensive tester: Agilent 8960 E5515C 3. Radiation pattern and gain 1. Radiation pattern 2. Antenna gain 1. Darkroom ： 7x4x3 m (3D) 2. Network analyzer ： Agilent 8753ES 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 4.Antenna Test Data 4.1 Efficiency/Gain Fre.(Mhz)Efficiency(%)Gain(dBi) 2400 52.251.24 2410 51.411.10 2420 53.251.30 2430 55.471.28 2440 55.631.41 2450 58.47 2.0 2460 54.631.45 2470 53.251.33 2480 53.671.14 5.1 test chart 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD 4850 37.621.35 5850 38.12 1.16 6.1 VSWR 深圳市星源创科技有限公司 SHENZHEN Xingyuanchuang TECHNOLOGY CO.,LTD
