PREFACE Thank you for purchasing TD-H8. It is a dual band/dual display amateur radio . Combining the latest technology in radio communication along with a sturdy mechanical frame, This product is the ideal and effective solution for the professionals who need to stay in touch with the working team (in construction sites, buildings, shows, trade fairs or hotels) or for leisure users that just want to keep up with friends and fa mi l y. IMPORTANT NOTICE To help you ward off bodily injury or property loss that may arise from improper operation, please read all the information carefully before using our products. This contains instructions for safe usage and RF energy awareness and control for compliance with applicable standards and regulation. Safety Information for Amateur Radios Your wireless handheld portable transceiver contains a low power transmitter. When the talk button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices. Table of Contents 1. GETTING STARTED 1.1 Regulations and Safety Warnings 1 1.2 Main features 4 1.3 Maintenance 5 2. BATTERY INFORMATION 2.1 Charging the Battery Pack 6 2.2 Charger Supplied 6 2.3 Use Caution with the Li-ion Battery 6 2.4 How to Charge 7 2.5 LED Indicator 7 2.6 How to Store the Battery 8 3. INSTALLATION OF ACCESSORIES 3.1 Installing the belt clip 9 3.2 installing the battery pack 9 3.3 Additional Speaker/Microphone (Optional) 9 4. RADIO OVERVIEW 4.1 Buttons and controls of the radio 11 4.2 Main controls and parts of the radio 12 4.3 Status Indications 14 4.4 Main keypad controls 14 5. BASIC OPERATIONS 5.1 Power on the radio 16 5.2 Adjusting the volume 16 5.3 Channel selection 16 5.4 Making a call 17 5.5 Frequency (VFO) mode 17 5.6 Channel (MR) mode 18 6. ADVANCED FEATURES 6.1 Frequency scanning 18 6.2 Channel scanning 18 6.3 CTCSS scanning 19 6.4 DCS scanning 19 6.5 Keypad lock 19 6.6 FM Radio (FM) 19 6.7 TX 1000Hz, 1450Hz, 1750Hz, 2100Hz repeaters tone 20 6.8 Manual Programming (Channels Memory) 20 6.9 Built-in LED Flashlight 21 6.10 Bluetooth Programming 22 7. WORKING THE MENU SYSTEM 7.1 Basic use 27 7.2 Using short-cuts 27 7.3 Functions and operations 28 Appendix A. - Trouble shooting guide 37 Appendix B. - Technical Specifications 38 Appendix C. - Shortcut Menu operations 39 Appendix D. - DCS Table 48 Appendix E. - CTCSS Table 50 GETTING STARTED 1.1 Regulations and Safety Warnings FCC Licensing Information This device complies with Part 97 and 15 of the federal Communications Commission (FCC) Rules. Operation is subject to the condition that that this device does not cause harmful interference. The radio operates on radio frequencies that are regulated by the Federal Communications Commission (FCC). To transmit on these frequencies, you are required to have a license issued by the FCC. To obtain forms, call the FCC forms hotline at: 1-800-418-3676 or go to http://www.fcc.gov For questions concerning commercial licensing, contact the FCC at 1-888- CALL-FCC (1-888-225-5322). Before filling out you application, you must decide which frequency you can operate on. NOTICE : Use of this radio outside the country where it was intended to be distributed is subject to government regulations and may be prohibited. FCC Regulatory Conformance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. Verification of harmful interference by this equipment to radio or television reception can be determined by turning it off and then on. The user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. Visit www.amazon.com/tidradio for more products 1 - Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. WARNING！MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR RADIOTELEPHONE SERVICE SIGNALS IS PROHIBIITED UNDER FCC RULES AND FEDERRAL LAW. EU Regulatory Conformance As certified by the qualified laboratory, the product is in compliance with the essential requirements and other relevant provisions of the Directive 2014/53/EU. All applicable EU regulations are regarded (2006/66/EC, 2011/65/EU,(EU)2015/863, 2012/19/EU). NOTE: It can be operating under 2000m. WARNING！ European Users should note that operation of this unit in Transmit mode requires the operator to have a valid Amateur Radio License from their respective Countries Amateur Radio Licensing Authority for the Frequencies and Transmitter Power levels that this Radio transmits on. Failure to comply may be unlawful and liable for prosecution. At this subject, refer to the “EU” specification guide 2014/53/EU. Please note that the above information is applicable to EU countries only Compliance with RF Exposure Standards The radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations; 47 CFR § 1.1307, 1.1310 and 2.1093 • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95.1:2005; Canada RSS102 Issue 5 March 2015…
