2AWMC-MN73AHMARA

User Manual Quick Starter Guide For the optimal out of box MARA experience, please follow the below steps out of box: 1.Assembly 2.Enable WiFi 3.Enable Rotation Manager for full portrait mode. 4.Enable Floating Keyboard . 5.Enable App Store set up to download and install apps. www.refliko.com 1 Parts List 4 Installation of stand to device 5 Turning on device 7 Home Bar 8 Mirror Mode On/Off 8 Setting up Wifi 8 Setting up the Rotation Manager 11 Setting up the Floating Keyboard 16 Android 7 Nougat 23 How to Login to App Store 23 How to Download and Install Apps 23 TECHNICAL SPECIFICATIONS 24 FCC 26 Federal Communications Commission (FCC) Statement 26 Important Safety Instructions 27 Danger - To reduce the risk of electric shock: 27 Warning - To reduce the risk of burns, fire, electric shock, or injury to persons: 27 Warnings 28 Cleaning REFLIKO MARA 28 2 3 Parts List 4 Installation of stand to device 5 6 Turning on device Press the Red Switch to the “I” position to turn on 7 Home Bar Mirror Mode On/Off 1.Tap the icon “Display Off” to turn the display off to make MARA into a normal mirror. 2.Tap anywhere on the display, to wake up the device. Setting up Wifi 1.Swipe down from top of screen 2.Click and hold on WiFi Icon until WiFi Settings appears 8 3.Find Your WiFi Network 4.Select Your WiFi Network 9 5.If prompted, enter your WiFi password 6.After entering password, click Connect 10 Setting up the Rotation Manager 1.Swipe up from Bottom of the Screen 11 2.Open Rotation Manager App 12 3.Swipe Left to Continue 13 4.Click on the icon until you see “Forced Portrait” 5.Swipe Left 14 6.Click on the highlighted icon until “Permanent Notification Off” is seen 7.Click on the highlighted icon until “Rotation Manager Running” is seen 8.Click the highlighted check mark to finish 15 Setting up the Floating Keyboard 1.Swipe down from top of screen 2.Click on the Settings Icon 3.Click on Languages & Input 16 4.Click on Virtual Keyboard 5.Click on Manage Keyboards 6.Enable Gboard 17 7.Click OK to allow Gboard to be used 8.Swipe from Left of Screen 18 9.Click on Settings Home 10.Click on the Search Icon 11.Select the keyboard option 19 12.Enable GBoard 13. Click on the Google logo until you see the ellipsis 14. Click on the ellipsis 20 15. Click on Floating 21 16. Keyboard should now be floating 22 Android 7 Nougat REFLIKO MARA runs on “Pure and Stock” Android 7 Nougat. This means you get the ideal experience as the operating system was originally designed and intended. There are a number of available tutorials on how to use Android that can be found online by searching keywords “Android 7 tutorial” Here are some of our suggested tutorials: Written: https://www.androidauthority.com/android-7-0-features-673002/ Video: https://www.youtube.com/watch?v=6JKve8YLwu4 For iOS users: https://www.youtube.com/watch?v=Fg05ZPfyEyA How to Login to App Store How to add account to MARA : https://support.google.com/googleplay/answer/2521798?hl=en How to Download and Install Apps How to download and install apps to MARA : https://support.google.com/googleplay/answer/113409?hl=en&ref_topic=2450266# 23 TECHNICAL SPECIFICATIONS 24 25 Important Safety Instructions When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using the REFLIKO MARA. Danger - To reduce the risk of electric shock: Always unplug this appliance from the electrical outlet immediately after using and before cleaning. Warning - To reduce the risk of burns, fire, electric shock, or injury to persons: 1. An appliance should never be left unattended when plugged in. Unplug from outlet when not in use, and before putting on or taking off parts. 2. Do not operate under blanket or pillow. Excessive heating can occur and cause fire, electric shock or injury to persons. 3. This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Keep children under the age of 13 away from this machine. 4. Use this appliance only for its intended use as described in this manual. Do not use attachment not recommended by the manufacturer. 5. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped in water. 6. Do not carry this appliance by the supply cord or use the cord as a handle. 7. Keep the cord away from heated surfaces 8. Never operate the appliance with the air openings blocked. 9. Never drop or insert any object into any opening. 10. Do not use outdoors 11. Do not operate where aerosol spray products are being used or where oxygen is being administered. 27 Warnings 1. Always ensure that the REFLIKO MARA is wiped down after each use to keep it sanitary. 2. Cleaning and user maintenance shall not be made by children without supervision. 3. This appliance is suitable for moderate climates only. 4. The ventilation must not be impaired by covering the appliance with items such as newspapers, table cloths, curtains, etc. 5. Naked flame sources, such as candles, must not be placed on appliance. 6. In case of broken cords or plugs, the cable must be replaced. 7. The appliance is suitable for indoor use only. Cleaning REFLIKO MARA While cleaning your REFLIKO MARA, use a clean microfiber or soft cloth to wipe down the mirror. Avoid using cleaning fluids as this could damage the oleophobic coating on the glass. 28 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Ru…

Text truncated - open the document above for the full version.

Refliko Inc. July 26. 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AWMC-MN73AH Product Name: MARA. Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature Name: Kendall Chow Title: Manager Company: Refliko Inc. Address: 793 Ames Ave, Milpitas, CA 95305

Refliko Inc. July 26. 2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Signature Name: Kendall Chow Title: Manager Company: Refliko Inc. Address: 793 Ames Ave, Milpitas, CA 95305

Refliko Inc. . July 26, 2020: Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Flux Compliance Service Laboratory 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Company: Refliko Inc. Address: 793 Ames Ave, Milpitas, CA 95305 (Applicant Name and address) Signature Name: Kendall Chow Title: Manager Company: Refliko Inc. Address: 793 Ames Ave, Milpitas, CA 95305

Model difference declaration letter Differences Description We Refliko Inc. state: Product： MARA. Model Name： MN73AH1A012AA, MN73AH1A022AA, MN73AH1A032AA The above product with same circuit, PCB layout, electrical parts, materials and wiring structures, Appearance shape, the materials of decorative accessories is same, only different color, Signatory Date: 2020-07-17 Signature Name: Kendall Chow Title: Manager Company: Refliko Inc. Address: 793 Ames Ave, Milpitas, CA 95305

External photos Photo 1 Photo 2 Photo 3 Antenna

Label and Label Location FCC ID: 2AWMC-MN73AH This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation L*W: 15mm*8mm Black font on a white label

Internal photos Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

FCC Test Report Report No: FCS202007011W01 Issued for Applicant: Refliko Inc. Address: 793 Ames Ave, Milpitas, CA 95305 Product Name: MARA. Brand Name: REFLIKO Model Name: MN73AH1A012AA Series Model: MN73AH1A022AA, MN73AH1A032AA FCC ID: 2AWMC-MN73AH Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page 2 of 35 Report No.: FCS202007011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : Refliko Inc. Address .................................. : 793 Ames Ave, Milpitas, CA 95305 Manufacture's Name .............. : Refliko Inc. Address .................................. : 793 Ames Ave, Milpitas, CA 95305 Product Description Product Name ........................ : MARA. Brand Name ......................... : REFLIKO Model Name ........................... : MN73AH1A012AA Series Model .......................... : MN73AH1A022AA, MN73AH1A032AA Test Standards ....................... : FCC Rules and Regulations Part 15 Subpart C, Section 249 Test Procedure ....................... : ANSI C63.10:2013 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ............................... : Date (s) of performance of tests : 06 July, 2020 ~ 14 July, 2020 Date of Issue ............................. : 14 July, 2020 Test Result ................................. : Pass Tested by : (Chris Chen) Reviewed by : (Jack Chen) Approved by : ( Andy yue) Page 3 of 35 Report No.: FCS202007011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.4 EQUIPMENTS LIST 11 3 CONDUCTED EMISSION MEASUREMENT 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 13 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 17 4.3 TEST SETUP 18 4.4 TEST RESULTS 19 5. BAND EDGE TEST 26 5.1 LIMIT 26 5.2 TEST PROCEDURE 26 5.3 TEST SETUP 27 5.4 TEST RESULTS 28 6. 20 DB BANDWIDTH TEST 32 6.1 LIMIT 32 6.2 TEST PROCEDURE 32 6.3 TEST SETUP 32 6.4 TEST RESULTS 33 7. ANTENNA REQUIREMENT 35 7.1 STANDARD REQUIREMENT 35 7.2 EUT ANTENNA 35 Page 4 of 35 Report No.: FCS202007011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Revision History Rev. Issue Date Effect Page Contents 00 14 July, 2020 All Initial Issue Page 5 of 35 Report No.: FCS202007011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1. SUMMARY OF TEST RESULTS FCC Part 15.249,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.205(a), 15.209(a), 15.249(a), 15.249(c) Radiated Spurious Emission PASS -- 15.209 Field strength of fundamental PASS 15.249(d) Band Edge Emission PASS -- 15.215(c) 20dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) All tests are according to ANSI C63.10-2013 Page 6 of 35 Report No.: FCS202007011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1.1 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.71dB 2 Unwanted Emissions, conducted ±2.98 dB 3 Conducted Emission (9KHz-150KHz) ±4.13 dB 4 Conducted Emission (150KHz-30MHz) ±4.74 dB 5 All emissions,radiated(<1G) 30MHz-1000MHz ±3.2 dB 6 All emissions,radiated (1GHz -18GHz) ±3.66 dB 7 All emissions,radiated (18GHz -40GHz) ±4.31 dB Page 7 of 35 Report No.: FCS202007011W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name MARA. Trade Name REFLIKO Model Name MN73AH1A012AA Series Model MN73AH1A022AA, MN73AH1A032AA Model Difference The above product with same circuit, PCB layout, electrical parts, materials and wiring structures, Appearance shape, the materials of decorative accessories is same, only different color Channel List Please refer to t…

Text truncated - open the document above for the full version.

Blow 1GHz for radiated emission test setup Above 1GHz for radiated emission test setup Conducted EMISSION MEASUREMENT
