2AWQV-C200Scanner

C200 Series Quickstart Guide CHARGE BATTERY: Insert USB cable by the Scan button and connect to adaptor or if using charging cradle, connect USB cable and insert C200. Red LED is ON when charging. POWER ON C200: Press the Scan button to power on. OPTION 1: Connect to Windows using RF dongle. • Scan Pair, LED will flash green. • Insert dongle in spare Windows USB port, LED will turn blue when connected. • Dimensions and barcodes will now be sent to the active Windows app. OPTION 2: Connect to Android or Windows using Bluetooth Direct Mode (HID). • Scan BT Direct (HID). • Scan Pair or hold Scan button for 6 seconds to enter pairing mode. LED will flash alternately blue and green. (To cancel pairing mode press Scan twice). • Connect Cubetape from Android or Windows connection menu. LED will turn blue when connected. • Dimensions and barcodes will now be sent to the active app. OPTION 3: Connect to 3rd Party Android or Windows app using Bluetooth Application Mode (SPP). • Scan BT App (SPP). • Refer to 3rd Party Application Guide. DEFAULTS AND FACTORY RESET Factory default settings are: Connect to Windows host using dongle Units = inches Suffix DIM = TAB Output = nearest inch Suffix GEN = TAB Return to factory settings anytime by scanning Scanner Defaults and Wireless Defaults. For full manual go to www.cubetape.com/downloads For support email support @ cubetape.com BT A pp ( SPP) BT D irect ( HID ) Pair C200 RF DongleUSB Cable ScanStik Utilities Bigfoot Silicone Tip Charge Cradle (if selected) Charge Cradle also contains the Shortcuts QR Code on base. Quickstart Guide IN THE BOX How to use Cubetape ScanStik ScanStik is an adhesive label that lets you easily scan in dimensions of up to 2” (50mm), using a Cubetape device. Peel the ScanStik and place it on an easily accessible reference edge - such as the side of the scale workbase. The yellow arrows should point towards the reference edge. Place the package to be measured with its back edge next to the reference edge, and over the ScanStik. Use the Cubetape to scan the barcode on the ScanStik closest to the package. It may be easiest to scan down the package until the scanner reads the barcode on the ScanStik. 1 2 3 C200 Series Quickstart Guide V1 CHARGE BATTERY: Insert USB cable by the Measure button and connect to adaptor or if using charging cradle, connect USB cable and insert C200. Red LED is ON when charging. POWER ON C200: Press the Measure button to power on. OPTION 1: Connect to Windows using RF dongle. • Scan Pair, LED will flash green. • Insert dongle in spare Windows USB port, LED will turn blue when connected. • Dimensions and barcodes will now be sent to the active Windows app. OPTION 2: Connect to Android or Windows using Bluetooth Direct Mode (HID). • Scan BT Direct (HID). • Scan Pair or hold measure button for 6 seconds to enter pairing mode. LED will flash alternately blue and green. (To cancel pairing mode press Measure twice). • Connect Cubetape from Android or Windows connection menu. LED will turn blue when connected. • Dimensions and barcodes will now be sent to the active app. OPTION 3: Connect to 3rd Party Android or Windows app using Bluetooth Application Mode (SPP) • Scan BT App (SPP). • Refer to 3rd Party Application Guide. DEFAULTS AND FACTORY RESET Connect to Windows host using dongle. Factory default setting are: Units = inches Suffix DIM = TAB Interval = nearest inch Suffix GEN = TAB Return to factory defaults at anytime by scanning Restore Scanner Defaults and Restore Wireless Defaults. For full manual go to www.cubetape.com/downloads For support email support @ cubetape.com Scanner D efaults Wireless D efaults BT A pp ( SPP) BT D irect ( HID ) Pair C200 RF DongleUSB Cable ScanStik Utilities Bigfoot Silicone Tip Charge Cradle (if selected) Quickstart Guide IN THE BOX How to use Cubetape ScanStik ScanStik is an adhesive label that lets you easily scan in dimensions of up to 2” (50mm), using a Cubetape device. Peel the ScanStik and place it on an easily accessible reference edge - such as the side of the scale workbase. The yellow arrows should point towards the reference edge. Place the package to be measured with its back edge next to the reference edge, and over the ScanStik. Use the Cubetape to scan the barcode on the ScanStik closest to the package. It may be easiest to scan down the package until the scanner reads the barcode on the ScanStik. 1 2 3 Regist ration Scan Registration QR code or visit www.cubetape.com/register to register your device Regist ration Scan Registration QR code or visit www.cubetape.com/register to register your device Shortcuts QR Scanner D efaults Wireless D efaults SET SUFFIX Select preferred suffix for use with Dimensional (DIM) and General (GEN) items. SET UNITS AND OUTPUTS Select preferred units - inches or cm and output. HOW TO MEASURE 1. Hook the tape end over the far edge of the package. 2. Align the tape exit point to the near edge of the package. 3. Press the Scan button to record and transmit the measurement. ASSEMBLY 1. The tape cassette has guide rails on both sides. 2. The C200 Pod has guide grooves on both sides. 3. Spring latch locks into the tape cassette. 4. Align grooves and rails. 5. C200 Pod slides down into the tape cassette. 6. The latch in the C200 Pod locks into the tape cassette. Output 0 .5 Output N earest 1 Output N ext 1 Units c m Units in Suffix D im C R Suffix D im T AB Suffix G en C R Suffix G en T AB GroovesGrooves Spring Latch Guide Rails 4 5 6 1 3 2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 1 3 2 C200 Series Quickstart Guide Scan Registration QR code or visit www.cubetape.com/register to register your device Scan Button FCC warning statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can ra…

Text truncated - open the document above for the full version.

Parceltools Pty Ltd * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 3/23/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AWQV-C200 Per section 2.911(d)(7) of the FCC rules, Parceltools Pty Ltd (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: JOC Australia Inc Physical U.S. Company Address: 18351 Colima Road Ste 585 Rowland Heights,California,91748 United States of America Agent contact name/Title : Benjamin. Smith/Vice President Agent Email Address: [email protected]/[email protected] Tel No.: +1(626) 217 4778 FRN No.: 0033379421 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different to Applicant): Signed: Signed: Printed name: John.Levisohn Printed name: Benjamin. Smith Title: Director Title: Vice President Company Name: Parceltools Pty Ltd Company Name: JOC Australia Inc Date: 3/23/2023 Date: 3/23/2023

Parceltools Pty Ltd Covered Equipment Certification Attestation Letter 3/23/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AWQV-C200 Parceltools Pty Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Parceltools Pty Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: John Levisohn Title: General manager Company Name: Parceltools Pty Ltd. Date: 3/23/2023

2023-03-23 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AWQV-C200 Product Name: Scanner Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name John Levisohn Position Director Company Name Parceltools Pty Ltd Address 18 Larkin St Waverton, NSW 2060 Australia Tel +612 80819099 Fax / Email [email protected]

FCC ID: 2AWQV-C200 IC: 26231-C200

Label Size: 3.0x1.0cm FCC ID: 2AWQV-C200 IC: 26231-C200 Model No.: C200 Label location

FCC ID: 2AWQV-C200 IC: 26231-C200 BT ANT 2.4G TX ANT 2.4G RX ANT

FCC ID: 2AWQV-C200 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison 2.4G: Worse case Mode: Output power= -1.394 dBm, Ant gain= -0.93 dBi, EIRP=-2.324 dBm [2441MHz: -2.324dBm(0.59mW) output power(EIRP)] (0.59mW /5mm)·[√2441(GHz)]= 0.18 <3.0 for 1-g SAR BLE: Worse case Mode: Output power= -4.205dBm, Ant gain= 2.99dBi, EIRP= -1.215dBm [2480MHz: -1.215dBm(0.76mW) output power(EIRP)] (0.76mW /5mm)·[√2402(GHz)]= 0.24 <3.0 for 1-g SAR Then 2.4G and BLE cannot transmit at the same time. Then SAR evaluation is not required
