2AWQY-54020HYPERVOLT PLUS BT

Hypervolt Plus Operating Instructions | Mode d’emploi | Instrucciones de operación Bedienungsanleitung | Instruções de operação | PLEASE READ PRIOR TO USE The Hypervolt Plus is a handheld percussion massage device that helps relieve muscle soreness and stiffness, accelerates warmup and recovery before and after physical activity, and promotes circulation. OPERATING Switch your Hypervolt Plus to the ON position at the base of the handle. Once your device is powered ON a blue light will illuminate, plus (up to) four green lights for battery level. Next, activate the pressure sensor by pressing the speed setting button once. Wait five seconds as the white lights sequence and turn off. Your Hypervolt Plus is now ready for use. Change speeds (1-3) by pressing the speed setting button once per speed. The blue lights above the speed setting button will indicate the current speed. To change head attachments insert the desired head directly into the shaft / opening while pushing firmly. For the Fork attachment allign the “groove” on the fork with the recess on the shaft / opening and push firmly. CLEANING AND STORAGE Make sure the power is OFF and the battery charger is not attached. Use a damp, clean, cloth and gently wipe your Hypervolt Plus. Store in a clean, cool place when not in use. SPECIFICATIONS 1. Removable battery release 2. Handle / rechargeable lithium-ion battery 3. Speed indicators (3) 4. Speed setting button 5. Pressure sensor indicators 6. Battery level indicators (4 / LED band) 7. ON / OFF power switch 8. Interchangeable head attachments (5) 9. Bluetooth® connection indicator AC charger: 110-240V 50/60Hz - .5A - 24VDC- 1A Frequency (Hz): level 1 - 1800/30, level 2 - 2400/40, level 3 - 3200/53 Weight: 3 lbs/1.3 kg EN 1 2 3 4 5 6 8 7 9 DANGER: TO REDUCE RISKS OF ELECTRIC SHOCK, FIRE, AND PERSONAL INJURY, OR PROPERTY DAMAGE, THIS PRODUCT MUST BE USED IN ACCOR- DANCE WITH THE FOLLOWING WARNINGS, CAUTIONS AND SAFETY INSTRUCTIONS: IMPORTANT SAFETY INSTRUCTIONS The Hypervolt (the term “Hypervolt” shall refer to both the Hypervolt and Hypervolt Plus models) is for adult use only and should always be used in accordance with the following warnings and instructions. When using the Hypervolt use only on dry, clean surfaces of the body by lightly pressing and moving across the body for approximately sixty(60) seconds per region. The Hypervolt should only be used on soft tissue areas of the body and should not be used on any hard or bony areas of the body, including the head. Please immediately stop use of the Hypervolt upon experiencing any pain or discomfort, apart from light muscle soreness. Bruising can occur from use of the Hypervolt, regardless of the pressure setting, and if bruising does occur you should not use the Hypervolt on the bruised area until the bruise is fully healed. Use of the Hypervolt should also be avoided on all bruises, contusions, rashes or irritated or injured areas of the skin until they are fully healed. When using the Hypervolt be sure to keep fingers, toes, hair, and other body parts away from the back of the applicator to avoid pinching or hair entanglement. The Hypervolt should be kept dry, should never be immersed in water and should be kept away from liquids and heat sources at all times. The ventilation holes on the Hypervoltshould be kept free of dust, debris and/or any other substance that could penetrate the holes, including but not limited to liquids, dirt, sand, or food. You should never operate the Hypervolt for more than one (1) continuous hour at a time and after each use please allow the Hypervolt to rest for a minimum of thirty (30) minutes before using it again. THE HYPERVOLT SHOULD ONLY BE CHARGED WITH THE TWO PRONGED, DOUBLE INSULATED, 26VDC HYPERICE CHARGER (MODEL NUMBER SK03T1-2600100W2 OR MX24D2-2801000) THAT WAS SUPPLIED WITH THE UNIT. DO NOT CHARGE THE HYPERVOLT OVERNIGHT OR LEAVE THE HYPERVOLT UNATTENDED WHEN CHARGING OR IN USE. After charging the Hypervolt, the charger should be unplugged from the Hypervolt’s battery handle prior to use. Prior to disposing of a Hypervolt unit the battery must be removed. The battery must be complied with safely at an appropriate e-waste disposal or recycling facility. The Hypervolt should never be used for any purpose other than its intended use, should not be dropped, and should never be tampered with or altered in any way. PLEASE DO NOT USE THE HYPERVOLT, OR ANY PERCUSSION OR VIBRATION DEVICE WITHOUT FIRST OBTAINING APPROVAL FROM YOUR PHYSICIAN IF ANY OF THE FOLLOWING APPLY: Pregnancy, diabetes with complications such as neuropathy or retinal damage, wear of pace-makers, recent surgery or injury, epilepsy or migraines, herniated disks, spondylolisthesis, spondylol-ysis, or spondylosis, recent joint replacements or IUD’s, metal pins or plates or any concerns about your physical health. Frail individuals and children should be accompanied by an adult when using any percussion or vibration device. These contra indications do not mean that you are not able to use a percussion or vibrationdevice but we advise that before doing so you consult your physician. Ongoing research is being done on the effects of percussion massage for specific medical disorders that may result in the shortening of the list of contra indications as shown above. VEUILLEZ LIRE AVANT D’UTILISER Hypervolt Plus est un dispositif de massage à percussion portatif qui aide au soulagement de la douleur et de la raideur musculaires, accélère l’échauffement et la récupération avant et après l’activité physique et favorise la circulation sanguine. FONCTIONNEMENT Mettez le commutateur du dispositif Hypervolt Plus sur la position Marche (ON), située à la base de la poignée. Une fois que votre dispositif est en marche, une lumière bleue s’allume, ainsi que ( jusqu’à) quatre lumières vertes pour indiquer le niveau de la batterie. Ensuite, activez le capteur de pression en appuyant une fois sur le bouton de réglage de la vitesse. Attendez cinq sec…

Text truncated - open the document above for the full version.

Hyperice, Inc. (June 23. 2020) MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT: HYPERVOLT PLUS BT Model: 54020 001-00 FCC ID: 2AWQY-54020 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the -Schematic -Block diagram -Operation description required to be submitted with this application be permanently withheld from public review. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Signature Name: Jack Wang Title: Manager Company: Hyperice, Inc. Address: 525 Technology Drive, Suite 100 Irvine, California 92618 Contact Information: E-mail [email protected] Tel: +86-769-27280901

Hyperice, Inc. (June 23. 2020) Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Flux Compliance Service Laboratory to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature Name: Jack Wang Title: Manager Company: Hyperice, Inc. Address: 525 Technology Drive, Suite 100 Irvine, California 92618 Contact Information: E-mail [email protected] Tel: +86-769-27280901

External photos Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

Label and Label Location FCC ID: 2AWQY-54020 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation L*W: 25mm*10mm Black font on a white label

Internal photos Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Antenna

FCC Test Report Report No: FCS202005003W01 Issued for Applicant: Hyperice, Inc. Address: 525 Technology Drive, Suite 100 Irvine, California 92618 Product Name: HYPERVOLT PLUS BT Brand Name: Hyperice Model Name: 54020 001-00 Series Model: N/A FCC ID: 2AWQY-54020 Issued By: Flux Compliance Service Laboratory Add: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Page 2 of 34 Report No.: FCS202005003W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com TEST RESULT CERTIFICATION Applicant’s Name ................... : Hyperice, Inc. Address .................................. : 525 Technology Drive, Suite 100 Irvine, California 92618 Manufacture's Name .............. : Guangdong ESINO Technology Group Co.,Ltd Address .................................. : No.7 Xifu Street, Lincun, Tangxia Town, Dongguan City, Guangdong Province, China Product Description Product Name ........................ : HYPERVOLT PLUS BT Brand Name ......................... : Hyperice Model Name ........................... : 54020 001-00 Series Model .......................... : N/A Test Standards ....................... : FCC Rules and Regulations Part 15 Subpart C, Section 249 Test Procedure ....................... : ANSI C63.10:2013 This device described above has been tested FCS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of FCS, this document may be altered or revised by FCS, personal only, and shall be noted in the revision of the document.. Date of Test ............................... : Date (s) of performance of tests : 06 May. 2020 ~ 20 May. 2020 Date of Issue ............................. : 20 May. 2020 Test Result ................................. : Pass Tested by : (Chris Chen) Reviewed by : (Jack Chen) Approved by : ( Andy yue) Page 3 of 34 Report No.: FCS202005003W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.4 EQUIPMENTS LIST 11 3 CONDUCTED EMISSION MEASUREMENT 12 3.1 LIMIT 12 3.2 TEST PROCEDURE 12 3.3 TEST SETUP 13 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 16 4.1 LIMIT 16 4.2 TEST PROCEDURE 17 4.3 TEST SETUP 18 4.4 TEST RESULTS 19 5. BAND EDGE TEST 25 5.1 LIMIT 25 5.2 TEST PROCEDURE 25 5.3 TEST SETUP 26 5.4 TEST RESULTS 27 6. 20 DB BANDWIDTH TEST 31 6.1 LIMIT 31 6.2 TEST PROCEDURE 31 6.3 TEST SETUP 31 6.4 TEST RESULTS 32 7. ANTENNA REQUIREMENT 34 7.1 STANDARD REQUIREMENT 34 7.2 EUT ANTENNA 34 Page 4 of 34 Report No.: FCS202005003W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com Revision History Rev. Issue Date Effect Page Contents 00 20 May. 2020 All Initial Issue Page 5 of 34 Report No.: FCS202005003W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.249 Meas Guidance v05r02 FCC Part 15.249,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.205(a), 15.209(a), 15.249(a), 15.249(c) Radiated Spurious Emission PASS -- 15.209 Field strength of fundamental PASS -- 15.249(d) Band Edge Emission PASS -- 15.215(c) 20dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1)” N/A” denotes test is not applicable in this Test Report (2) All tests are according to ANSI C63.10-2013 Page 6 of 34 Report No.: FCS202005003W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 1.1 TEST FACTORY Company Name: Flux Compliance Service Laboratory Address: Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Telephone: +86-769-27280901 Fax: +86-769-27280901 FCC Test Firm Registration Number: 514908 Designation number: CN0127 A2LA accreditation number：5545.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.71dB 2 Unwanted Emissions, conducted ±2.988 dB 3 Conducted Emission (9KHz-150KHz) ±4.13 dB 4 Conducted Emission (150KHz-30MHz) ±4.74 dB 5 All emissions,radiated(<1G) 30MHz-1000MHz ±5.2 dB 6 All emissions,radiated (1GHz -18GHz) ±3.66 dB 7 All emissions,radiated (18GHz -40GHz) ±4.31 dB Page 7 of 34 Report No.: FCS202005003W01 Flux Compliance Service Laboratory Room 105 Floor Bao hao Technology Building 1 NO.15 Gong ye West Road Hi-Tech Industrial, Song shan lake Dongguan Tel: 769-27280901 Fax:769-27280901 http://www.fcs-lab.com 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name HYPERVOLT PLUS BT Trade Name Hyperice Model Name 54020 001-00 Series Model N/A Model Difference N/A Channel List Please refer to …

Text truncated - open the document above for the full version.

Blow 1GHz for radiated emission test setup Above 1GHz for radiated emission test setup Power line conducted emission test setup
