Product features Common function description Vol:Adjust volume Treble:Adjust treble Bass: Adjust bass Mic Vol:Adjust microphone volume Echo:Adjust Echo Mic:Wired microphone input This system can be used with PC, DVD, VCD, MP3, Electronic piano and any device with audio output. The amplifying circuit is designed with high performance and high fidelity, and equipped with professional and high quality speaker, it can make the sound field positioning clear and layered. The system voice effect is outstanding, the bass is surging and shocking, the middle tone is strong and bright, the treble is crisp and pleasant. Professional electronic frequency division circuit, so that the division point of the machine more accurate, better effect. The use of professional design and manufacture of large capacity batteries, as well as audio power supply capacitor makes the local power reserve margin more larger,more stable,better dynamic,higher SNR. Charging instructions When charging, connect a matched power adapter to AC 100~240V.Charging time is approximately 6 to 8 hours.Once fully charged unplug the power supply as leaving a full battery on charge may cause damage to the battery. Battery charge indicator:LED panel has battery status indicator.In the middle of the shape of the battery have four horizontal lines,each horizontal line represents 25% of electricity remaining.When no horizontal line in the shape of the battery or the shape flashes,please power off and promptly charge to avoid damage to the battery.When charging,the charge indicator on the back of the speaker flashes.The indicator stop blinking after full charged.Then please contiue to charge the battery for 1-2 hours to extend the battery life. Warning:If the battery is under voltage,please fully charge it within 48 hours.If the speaker have to be left unused for a long time,please let the battery fully charged,otherwise it will cause damage to the battery! In the process of playing,keep unit away from high temperature environments,high magnetic fields and high frequencies.If the system is fails to work,turn off the power source or pull out the USB disc/TF card,then reinsert it and it will resume play. Output power------------------------------------ Input sensitivity---------------------------------- SNR------------------------------------------ Frequency response-------------------------- Power supply--------------------- ≤30W 320mV ≥71dB 60Hz~20KHz AC 100-240V~,60Hz/50Hz Main technical specifications Portable bLUEBOOTH speaker sPortable bLUEBOOTH speaker sPortable bLUEBOOTH speaker VS-0866VS-0866VS-0866 Instruction Manual Trouble shooting guide *Above specifications are the specifications of the sampling machine and are for reference purpose only. *Because of continuous product improvement.specifications will keep changing at any time without prior notification. Remote control instructions *Image diagram, for reference only*Image diagram, for reference only 1.Under normal circumstances, the remote control should be used within a range of about 20 feet and 30 degrees from the remote reception window. 2.When operating the remote control, point the remote control at the receiver window of the machine. There should be no obstacles between the remote control and the machine. 3.If the receiving window is in the position of strong light, the remote control may fail. In this case, please remove the machine to avoid direct exposure to strong light. 4.Please don't make both new and old batteries work together,and regularly check whether the remote control batteries need to be replaced. 2 0 f e e t Mute Music number Input selection Turn up the volume Play/Pause Next Turn down the volume USB Sound field effect Play the record Record Bluetooth Previous MIC priority Repeat one/Random/Repeat all 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. Description of controls *Image diagram, for reference only Guitar USB/TF Microphone controls and basic operation Guitar jack: Connect guitar. Guitar Volume: Adjust the guitar volume. Recording funtion Recording funtion Recording funtion Bluetooth operation FM function 1.Microphone on 2.Microphone off 3.Screen Music files in USB and TF cards should be formatted as FAT32 on the computer. The order about music play is based on file name,if the music file names are as"01,02,03"in sequence.This product will play the file "01"first. Copy MP3 or WMA music files to USB/TF cards. It is recommended to delete unnecessary files and folders to speed up card reading and reduce card reading problems. 1 2 3 Please insert USB or TF card first and then press “●/►” into recording mode. When recording music at the first time, an new file "RECORD" will be created in the card and all recordings will be saved into the file. These recording files are automatically named as REC0001,REC0002,REC0003... in sequence. When recording music, press “●/►” to pause it and press again to continue. Press INPUT or “●/►” to quit recording mode. Please press “●/►” into recording-play mode(automatically play the musics recording before). Usually the machine will play the last recording music first. Press PREV( |◄◄) or NEXT( ►►|) to select the music. Press Replay on the remote control to replay music. If you would like to replay single music or all musics, please press Replay repeatedly. USB port: insert USB and play music. TF port: insert TF card and play music. Supports MP3, WMA, and WAV music formats, outstanding sound performance, high fax stereo design. INPUT: to switch external audio, MP3 / Bluetooth functions. ►||: press this key to pause the music, and press again to continue. |◄◄ / ►►|: when playing, select the PREVIOUS/NEXT music. Bluetooth connection method:Turn on the speaker,press the‘INPUT’key on the speaker panel,and the screen will show‘bT’.Use your phone to connect the Bluetooth of the speaker.The Bluetooth name is VS-0866. If the connection fails,please restart the device or the phone and try again. The use range of the Bluetooth is 32…

Text truncated - open the document above for the full version.

Fujian Yiyun Vegue Electronic Technology Co., Ltd. Room 3-D, Building D, No.24 Houyu Road, Jinan District, Fuzhou City, Fujian Province, China Tel: +86- 133 2886 3865 E-mail: [email protected] Series Models Description Date: 2020/07/06 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: 2AWSI-VS-0866 Dear Sir/Madam, We, Fujian Yiyun Vegue Electronic Technology Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only color and model number is different for these model: Product name: Portable speaker Model no.: VS-0866, VS-6633, VS-0650, VS-0808, VS-0505, VS-0803, VS-0606, VS-1003, VS-0503, VS-1088 Sincerely, Name: Hong Ying Company: Fujian Yiyun Vegue Electronic Technology Co., Ltd. Address: Room 3-D, Building D, No.24 Houyu Road, Jinan District, Fuzhou City, Fujian Province, China Phone: +86- 133 2886 3865 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: July 06, 2020 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AWSI-VS-0866 VS-0866, VS-6633, VS-0650, VS-0808, VS-0505, VS-0803, VS- 0606, VS-1003, VS-0503, VS-1088 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Hong Ying Company: Fujian Yiyun Vegue Electronic Technology Co., Ltd. Address: Room 3-D, Building D, No.24 Houyu Road, Jinan District, Fuzhou City, Fujian Province, China Phone: +86- 133 2886 3865 Fax: N/A E-Mail: [email protected]

Fujian Yiyun Vegue Electronic Technology Co., Ltd. Room 3-D, Building D, No.24 Houyu Road, Jinan District, Fuzhou City, Fujian Province, China Tel: +86- 133 2886 3865 E-mail: [email protected] Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7/6/2020 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AWSI-VS-0866 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Hong Ying Company: Fujian Yiyun Vegue Electronic Technology Co., Ltd. Address: Room 3-D, Building D, No.24 Houyu Road, Jinan District, Fuzhou City, Fujian Province, China Phone: +86- 133 2886 3865 Fax: N/A E-Mail: [email protected]

FCC ID: 2AWSI-VS-0866 FCC ID: 2AWSI-VS-0866 FCC ID: 2AWSI-VS-0866

FCC ID: 2AWSI-VS-0866 Portable speaker Model: VS-0866 FCC ID: 2AWSI-VS-0866 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AWSI-VS-0866 FCC ID: 2AWSI-VS-0866 FM antenna BT antenna FCC ID: 2AWSI-VS-0866 FCC ID: 2AWSI-VS-0866 Wireless Microphone RX antenna FCC ID: 2AWSI-VS-0866

RF Exposure evaluation FCC ID: 2AWSI-VS-0866 Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information VS-0866 can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna Identification in Internal photos Antenna type and antenna number Operate frequency band Maximum antenna gain Antenna 2.4G PCB Antenna 2.4GHz – 2.5 GHz 0 dBi 5. Conducted power Type Channel Output power (dBm) GFSK 00 2.425 39 2.811 78 1.332 π/4DQPSK 00 1.478 39 2.082 78 0.054 8DPSK 00 1.826 39 2.341 78 0.426 6. Manufacturing Tolerance GFSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 2.0 2.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 2.0 2.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 8DPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 2.0 2.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 7. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of the used antenna is 0dBi, the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) Duty Cycle MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW GFSK 3.0 1.9953 0 1.0 100% 0.0004 1.0000 π/4DQPSK 3.0 1.9953 0 1.0 100% 0.0004 1.0000 8DPSK 3.0 1.9953 0 1.0 100% 0.0004 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 8. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------
