2AWT2-AUD20Body worn camera

Audax Body Worn Video System 20-1 Chest Camera - User Guide 1. System Components The system is supplied in a soft case complete with the following: A. Chest Camera B. Internal (non-removable) 32Gb Solid State memory (64Gb and 128Gb optional) C. USB 2.0 cable D. Wall Socket USB Charger E. 360̊ crocodile clip F. Dock / KlickFast type connector 2. System Features • Full HD video recording • Solid State memory • Still image capture • Audio • IR (Auto or Manual) • GPS • 140° Wide Angle Lens • Secure, password protected files • IP67 V.20200604 3. NOTES / WARNINGS Charging Battery – Prior to first use of the system, charge the battery for a minimum of four hours. When the battery is fully charged, the Red “POWER” LED on the top of the device will turn OFF. Please note that your camera may arrive already fully charged, so don't be surprised if, the first time you try to charge it, the red “charging” light does not come on. Connection to PC – The Camera DOES NOT allow direct connection to a PC for downloading of data. The ONLY way this can be achieved is by using the CamManager software (Please note that this process is different if using the Audax Docking Station). Changing Settings – We recommend that all recorded video / image files are backed up before changing any system settings. Failure to do so may cause recorded footage/files to be deleted. Internal Memory – Gaining or attempting to gain physical access to the Internal Memory will invalidate the system Warranty. Cables – Only ever use the supplied chargers and cables. Using other “similar” cables may invalidate the system Warranty. Password Protection – The Chest Camera device has two different Passwords set: a. The “Settings” Menu has the initial password set as 000000 (Please see Section 6, para Q for details of how to set Passwords). The software will not allow access to settings and downloading without using this password. Audax recommend that this Password is re-set and safely recorded at the earliest opportunity. b. The “Replay” Menu has the initial password set as 000001 (Please see Section 6, para R for details of how to set Passwords). This allows that you can give this password to the user so that they can view recorded footage (if you require). However, they will NOT be able to access other areas (settings / downloading) with this password. Audax recommend that this Password is re-set and safely recorded at the earliest opportunity. IMPORTANT NOTE: If, after setting, your password is lost then the device will have to be returned to be re-set. In that event, a fee will be chargeable and any footage held on the unit might be erased as part of the re-setting process. Screen Protectors – The Chest Camera device may be dispatched with a protective film covering the camera lens (front) and viewing screen (back). Please ensure that the film is peeled off before using. 4. Views Top a. Power (Left) – RED LED shows the device is charging GREEN LED shows the device is ON b. Work – RED LED (flashing) shows the device is Recording Video. This LED will show AMBER (flashing) when recording Audio Only. Front a. Top left – White light filter Top right – IR Sensor Centre – Camera lens Bottom Left/Right – IR Illuminators - b. Record (Video) button Left c. USB connection d. Audio only button e. Manual IR button Right a. SOS button (Live Streaming ONLY) b. Camera (still image) button c. Power “on / off” button Rear a. 360° detachable clip b. Display Screen c. (1) “Menu” / “OK” button d. (2) “Up” button e. (3) “Down” button f. (4) “Back” / “Replay” button 1 2 3 4 5. General System Operation (please refer to buttons listed above) a. Power On/ Off 1. Press the POWER ON / OFF button for 1 second; the camera will turn on and enter the standby mode (the device will vibrate). IMPORTANT NOTE: Please also see section 6 para S regarding the “LCD auto off” function and para T regarding the “Auto shutdown” function. When the device is ON, pressing the POWER button for 1 second will turn the device OFF b. Video Recording 1. Once turned on, the device will automatically enter the camera preview mode and a live picture will be shown on the display screen. Press the RECORD button to commence recording; the device may vibrate and the “work” LED on the top will change to RED (flashing). A RED circle will also show on the display screen. 2. Press the RECORD button again to stop recording; the device may vibrate and the “work” RED LED will turn off. At this point, recording will stop (unless Post-event recording has been selected) and the video will be saved. 3. If recording is required in “low light” conditions, press the IR button (unless IR “Auto” has been previously selected). The IR illuminators will be turned on and the device will enter the night shooting mode. IMPORTANT NOTE: Video recorded when IR has been selected will be in black and white only. c. Still Images 1. Once turned on, the device will automatically enter the camera preview mode. Press the PHOTO button to take still images. 2. As already mentioned in b.3. above; if photos are to be taken in “low light” conditions, turn on the IR illuminators (unless IR “Auto” has been previously selected). IMPORTANT NOTE: Still images taken when IR has been selected will be in black and white only. 3. When recording Video, the PHOTO button can be pressed to capture a picture while still recording at that time. d. Audio recording 1. Once turned on, the camera will automatically enter the camera preview mode. Press the AUDIO button to record audio ONLY. The device will vibrate and the “work” LED on the top will change to AMBER (flashing). 2. Press the AUDIO button again to end audio recording, and the audio file will be automatically saved. e. Video Playback The device has been designed and manufactured with a one-touch playback button and quick playback button. When in the “standby” state, press the PLAYBACK button to enter the playback menu. IMPORTANT NOTE: Playback of video, still images and audio only recording…

Text truncated - open the document above for the full version.

Audax Global Solutions Ltd Statement We Audax Global Solutions Ltd Hereby Declare that The product Body worn camera, models no. Audax ® 20-1 camera, Audax ® Chest Camera, Audax ® 19-1 camera are all identical in interior structure, electrical circuits and components, and just the model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Company Name: Audax Global Solutions Ltd

July 17, 2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Timeway Testing Laboratories/ 5/F,Block 4, Anhua Industrial Zone.,No.8 TaiRan Rd.CheGongMiao,FuTian District, Shenzhen,CHINA. (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Audax Global Solutions Ltd / c/o Francis Clark LLP, North Quay House, Sutton Harbour, Plymouth, United Kingdom <Signature>： Name：Adam Liardet Title：Manager Company：Audax Global Solutions Ltd

July 17, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AWT2-AUD20 Product Name: Body worn camera Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>： Name：Adam Liardet Title：Manager Applicant Company：Audax Global Solutions Ltd

Label Location

FCC ID: 2AWT2-AUD20 RF Exposure Applicable Standard Accordin g to §1.1307(b)(5), systems operating under the provisions of this section shall be o perated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. The Section 4.3.1 and Appendix A of KDB447498 D01 V05 was used as the guidance. Calculation Result (Worse case) High Channel [(max. power of channel, including tu ne-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] =0.675/5 * 1.58= 0.213, this value is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. The SAR measurement is not necessary.

Report No.: FCC 2006194-03 File reference No.: 2020-07-16 Applicant: Audax Global Solutions Ltd Product: Body worn camera Model No.: Audax ® 20-1 camera, Audax ® Chest Camera, Audax ® 19-1 camera Trademark: Audax ® Test Standards: FCC Part 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10, FCC Part 15.247 for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: July 16, 2020 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No.: FCC2006194-03 Page 2 of 81 Date: 2020-07-16 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No.: FCC2006194-03 Page 3 of 81 Date: 2020-07-16 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.............................................................................…
