Remote Dog Training System User manual Model：AFU-WHO-0002 Thank you for purchasing our product. In order to use this product safely, please read the manual before using it. Please keep it properly after reading for further checking and reference. Tips: If the function of the product described in the instructions has been upgraded, no further notice will be given. 2 1.Accessories list ⚫ 1 x remote control unit ⚫ 1 x collar tie ⚫ 1 x pet collar unit ⚫ 1 x USB charging cable ⚫ Three pairs of metal contacts of collar unit (long and short, one pair has been installed on the collar unit) In the multi collar set, there are multiple collar control units. 2.Remote control ○ 1antenna ○ 2LCD screen ○ 3 [Electrostatic] button ○ 4 Channel selection [turn left] button ○ 5 Intensity selection [decrease] button ○ 6[Vibration] button ○ 7Intensity selection [increase] button ○ 8Channel selection [turn right] button ○ 9[sound] / [confirm] multiplex button ○ 10Safety lock [unlock] button ○ 11 USB TYPE-C charging port 3 3.Remote control LCD display interface 4 LCD display icon definition Position Display Name Description 1 Signal Indicates the signal strength of the collar unit,the currently selected channel is hidden when the collar is not paired, when it’s paired but off-line it will flash. 2 Lock When locked, it will be displayed and hidden after unlocking. When it’s unlocked,press the [vibration] or [static] button, the operation will be prohibited, and the lock icon will flash. 3 Wearindicat ion If the collar is not worn properly, the icon will flash. 4 Collar power Battery level indication of the collar. 5 Dynamic level Indicates the output intensity of sound, vibration and static action. 5 6 Set level Indicates the set sound, vibration, static action intensity, and the set number will flash when the output intensity is selected 7 Sound indication The sound symbol indicates that the vibration and static action will be accompanied by sound, and no display means that there is no sound accompanying with vibration and static electricity action. When the [sound] button is pressed alone, it will flash. 8 Remote control power The battery power display of remote control,it will flash when charging. 9 Channel number Collar unit channel number, range 1- 9, flashes when channel is selected. 10 Vibration indication When the [vibration] button and the [unlock] button are pressed at the same time, it will flash 6 LCD display and back light definition 11 Electrostatic indication When the [electrostatic] button and the [unlock] button are pressed at the same time, it will flash Color Definition description White Power on The back light color of the screen is white after the remote control is turned on Yellow Vibration mode When the [vibration] button and [unlock] button are pr essed at the same time, the screen back light color is yellow Red Electrostatic mode When the [electrostatic] button and the [unlock] button are pressed at the same time, the screen back light color is red 710 4.Collar unit views ○ 1 Electrostatic generation metal contact ○ 2 USB type-C charging interface and silicone cover ○ 3 Working and charging LED indicator light ○ 4 Switch on / off button LED status light Collar status LED indicator light displays Power off LED light off Power on Three LED lights indicate the battery power. They are on every 15 seconds when the No back light Stand by The LCD displays, but the back light is off. No screen display Power off LCD doesn’t display when it’s power off 810 arcade is on. When the switch button is pressed or when the remote control indication is received, it will be on Pair Three LED lights cycles flash alternately Charging The flashing indicates the charging progress of the battery, and all three LED lights are on when the battery is fully charged Low power Three LED lights flash quickly at the same time, and then turn off, and the device automatically turns off at the same time 5.How to train The training system can cooperate with the password to form a conditioned response to the pet. When the [sound ], [vibration ] ,[static ] buttons of the remote control are pressed, the signal will be sent to the collar unit, and the collar unit will perform corresponding actions. The setting of action level can control the collar unit to output different intensity of sound, vibration and static electricity signals. In training, you can choose different action mode and intensity. In training, start with a low intensity. If the pet reacts to the choice of intensity , the intensity selection is appropriate. If there is no response, the intensity setting can be gradually increased to avoid using too high intensity in the beginning to cause too strong stimulation to the pet. The training system is equipped with long and short metal contacts. When the dog's hair is too thick, it is necessary to replace the longer metal contacts. Select the appropriate length of metal contacts for pets to ensure the contact. On the the remote control screen, you can check the display of the [wearing instructions] icon to confirm whether the metal contacts are effectively contacted. When using, it is necessary to adjust the appropriate length of the neck collar. If it is too loose, the metal contact will not be able to contact effectively, and if it is too tight, it may cause irritation to 910 the pet skin. In order to avoid possible skin damage, the device is designed to take up to 15 seconds each time when a button is pressed. Do not allow the collar to be worn by the pet for more than 12 hours. Check the neck area after usage, if rashes or pain occurs, stop using it until the skin is completely healed. If the condition persists, consult your veterinarian. 6.Safety tips Warning: Do not use on aggressive dogs. If you are not sure that the product is suitable for your dog, consult your dog trainer or your veterinarian. This product is only suitable for healthy dogs and non aggressive dogs. Please read the instructions in the manual c…
