2AWVWCF8126ASAir Purifier

1 USE & CARE INSTRUCTIONS Air Purifier CF-8126AS 2 READ AND SAVE THESE INSTRUCTIONS WARNINGS Failure to comply with the warnings listed below may result in electric shock or serious injury. This product should be used only in accordance with the specifications outlined in this manual. Usage other than what has been specified here may result in serious injury. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: • Read all instructions before using appliance. • IMPORTANT - This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature. • To avoid fie or shock hazard, plug the appliance directly into a right AC electrical outlet. • Keep the cord out of heavy traffic areas. To avoid fie hazard, NEVER put the cord under rugs, near heat registers, radiator, stoves or heaters. • To protect against electrical hazards, DO NOT immerse in water or other liquids. Do not use near water. • Children cannot recognize the hazards associated with the usage of electrical appliances. For this reason, always supervise children when they are near the unit. • Always unplug the air purifier before moving it, opening the grill, changing filters, cleaning or whenever the air purifier is not in use. Be sure to pull by the plug and not the cord. • NEVER drop or insert any object into any openings. 3 • DO NOT run cord under carpeting. • DO NOT cover cord with throw rugs, runners, or similar coverings. • DO NOT route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over. • DO NOT operate any appliance with a damaged cord or plug, if motor fan fails to 4 rotate, after the appliance malfunctions, or if it has been dropped or damaged in any manner. Send to Customer Service for assistance. • Use appliance only for intended household use as described in this manual. Any other use not recommended by the manufacturer may cause fie, electric shock or injury to persons. • DO NOT use outdoors. • DO NOT place anything on top of unit. • NEVER block the air openings, grills/outlets or place on a soft surface such as a bed or sofa, as this could cause the unit to tip over, blocking the air intake or outtake opening. • DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so will void your warranty. The inside of the unit contains no user serviceable parts. All servicing should be performed by qualified personnel only. • WARNING: To reduce the risk of fire or electric shock, do not use this fan with any solid-state speed control device. Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. 5 PRODUCT STRUCTURE Air quality indicator Main unit UV lamp 6 Touch panel Lock Pre-filter HEPA filter Activated carbon filter Base 7 AIR CLEANING SYSTEM Improve your indoor air quality with your new Air Cleaning System. Multiple levels of cleaning include a combination of Pre-filter that traps big particals, HEPA filter that captures micro particles UV-C light technology enhances germ-killing. PRE-FILTER: Captures initial dust and allergen particles. HEPA FILTER: Captures dust, smoke, pollen and other allergens; Activated Carbon Filter: Removes odors and bad smells. OPERATING INSTRUCTIONS BEFORE OPERATING THE AIR PURIFIER: 1. Carefully remove your air purifier from box and plastic bag. 2. Select a firm, level and flat location for the air purifier. *For proper air flow, locate the unit at least 1 foot from any wall or furniture. *Make sure none of the grills are blocked. 8 3. Plug the power cord into a right voltage AC outlet. IMPORTANT: When moving the air purifier, always lift unit firmly by your hands. OPERATING THE AIR PURIFIER 1. POWER/FILTER RESET Soft press to turn on/ off the unit. Note: Press and hold POWER Button for 5 seconds to reset Filter Replace Indicator. 2. “TIMER” BUTTON: By pressing this button, the purifier can be timed to operate for intervals of 2, 4 and 8 hours, stopping automatically when the selected operating time has elapsed. 3. “AUTO/SLEEP” BUTTON: Under AUTO mode, the unit will automatically change the speed according to the air 9 quality level. Under SLEEP mode, all the lights will turn off and unit working in speed 1. 4. “SPEED” BUTTON: There are 4 speed setting. Press the button each time to select L(I),M(II),H(III) and Turbo speed. Speed I is sleep mode, select this speed and in 10s, all LED will be turned off. 5. “UV/ION/WIFI” BUTTON: Press this button to turn on/off the UV and Ionizer function. Note: Press the hold this button for 5 seconds to active the WIFI connection. INSTALLING & REMOVING FILTERS 1 FILTER REPLACE INDICATOR The FILTER RESET led light on indicates that it is time to replace the filter. Follow the instruction below to change filter and reset the program. *Combination Filter will last approximately 6 months. 1.Find the lock on the base of the unit. 2.Unock it by moving it to left. 3. Lift up the unit. 4. Get the dirty filter out and put a new one into. 5. Set back the unit and move the lock to right. 6. Press Power button for 3-5 seconds to reset the firmware. CLEANING & MAINTAINING 1 The machine should be cleaned at least once every month by a clean, dry, soft clot…

Text truncated - open the document above for the full version.

date：08/04/2020 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Air Purifier / CF-8126AS FCC ID: 2AWVWCF8126AS ) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions) required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Signature: Name: yulian Zhao Applicant: Airplove (Xiamen) Electronic Co., Ltd Address: 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China TEL: +86 15005056461

Date：08/04/2020 Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: yulian Zhao Applicant: Airplove (Xiamen) Electronic Co., Ltd Address: 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China TEL: +86 15005056461

Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 2 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 2

Model No. : CF-8126AS Rated Voltage : AC 120V Rated Current : 0.55A Rated frequency : 60Hz Rated power : 33W CERTIFIED TO CSA STD . C22.2 NO. 187 CONFORMS TO UL STD . 867 Manufacturer : Airplove (Xiamen) Electronic Co.,Ltd. Date Code :XXXX SN: IC: 26287-CF8126AS FCC ID: 2AWVWCF8126AS

Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 11 WLAN Antenna Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 7 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 8 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 9 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 10 of 11 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 11 of 11

Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 RF EXPOSURE EXEMPT REPORT APPLICANT : Airplove (Xiamen) Electronic Co., Ltd PRODUCT NAME : Air Purifier MODEL NAME : CF-8126AS BRAND NAME : Airplove FCC : 2AWVWCF8126AS STANDARD(S) : FCC §15.247 (i), §2.1091 RECEIPT DATE : July 03, 2020 TEST DATE : July 03, 2020 ISSUE DATE : July 30, 2020 Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Equipment Under Test (EUT) Description EUT Type: Air Purifier Hardware Version: N/A Software Version: 1.0.2 Frequency Bands: WLAN 2.4GHz: 2412 MHz ~ 2462 MHz Modulation Mode: 802.11b: DSSS 802.11g/n-HT20: OFDM Antenna Type: PCB Antenna Antenna Gain: WLAN 2.4GHz: 2.5 dBi Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm2) Averaging Time |E|2,|H|2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100000 1.0 30 Note: f = frequency in MHz *= Plane-wave equivalent power density Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna, R=0.2m Tune up produce power 802.11b1.78 24629.548.990.03191 802.11g1.78 24626.194.160.01471 802.11n201.78 24626.074.050.01431 Limit (mW/cm²) Protocol ANT Gain(gain of antenna in linear scale) Channel Frequency (MHz) Max Output Power to Antenna (dBm) Output Power to Antenna (mW) Power Density (mW/cm²) Antenna gain: 2.5 dBi (gain of antenna in linear scale=1.78) Mode 802.11b/g/n20:2412-2462MHz Detector Peak 802.11b 10 ±1dBm 802.11g 6 ±1dBm 802.11n20 6 ±1dBm

Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 45 Appendix A: Duty Cycle Test Result TestMode Antenna Channel Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 11B Ant1 2412 50.00 50.00 100.00 11G Ant1 2412 50.00 50.00 100.00 11N20SISO Ant1 2412 50.00 50.00 100.00 Test Graphs 11B_Ant1_2412 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 45 11G_Ant1_2412 11N20SISO_Ant1_2412 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 45 Appendix B: 6dB bandwidth Test Result TestMode Antenna Channel DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 9.160 2407.400 2416.560 >=0.5 PASS 2437 9.160 2432.400 2441.560 >=0.5 PASS 2462 8.640 2457.920 2466.560 >=0.5 PASS 11G Ant1 2412 16.560 2403.680 2420.240 >=0.5 PASS 2437 16.600 2428.680 2445.280 >=0.5 PASS 2462 16.560 2453.680 2470.240 >=0.5 PASS 11N20SISO Ant1 2412 17.800 2403.080 2420.880 >=0.5 PASS 2437 17.840 2428.080 2445.920 >=0.5 PASS 2462 17.720 2453.120 2470.840 >=0.5 PASS Test Graphs 11B_Ant1_2412 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 45 11B_Ant1_2437 11B_Ant1_2462 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 45 11G_Ant1_2412 11G_Ant1_2437 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 45 11G_Ant1_2462 11N20SISO_Ant1_2412 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 7 of 45 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 8 of 45 Appendix C: Occupied Channel Bandwidth Test Result TestMode Antenna Channel OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 13.970 2404.981 2418.951 --- PASS 2437 13.964 2429.975 2443.939 --- PASS 2462 13.976 2454.975 2468.951 --- PASS 11G Ant1 2412 17.186 2403.249 2420.435 --- PASS 2437 17.091 2428.347 2445.438 --- PASS 2462 17.104 2453.334 2470.438 --- PASS 11N20SISO Ant1 2412 18.121 2402.915 2421.036 --- PASS 2437 18.165 2427.884 2446.049 --- PASS 2462 18.143 2452.886 2471.029 --- PASS Test Graphs 11B_Ant1_2412 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 9 of 45 11B_Ant1_2437 11B_Ant1_2462 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 10 of 45 11G_Ant1_2412 11G_Ant1_2437 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 11 of 45 11G_Ant1_2462 11N20SISO_Ant1_2412 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 12 of 45 11N20SISO_Ant1_2437 11N20SISO_Ant1_2462 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 13 of 45 Appendix D: Conducted output power and E.I.R.P for DTS Test Result Test Result Test Mode Antenna Channel Conducted Power [dBm] E.I.R.P [dBm] Conducted Limit [dBm] E.I.R.P Limit (dBm) Verdict 11B Ant1 2412 9.06 11.56 <=30 <=36 PASS 2437 9.52 12.02 <=30 <=36 PASS 2462 9.54 12.04 <=30 <=36 PASS 11G Ant1 2412 5.63 8.13 <=30 <=36 PASS 2437 6.06 8.56 <=30 <=36 PASS 2462 6.19 8.69 <=30 <=36 PASS 11N20SISO Ant1 2412 5.62 8.12 <=30 <=36 PASS 2437 6.05 8.55 <=30 <=36 PASS 2462 6.07 8.57 <=30 <=36 PASS Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrica…

Text truncated - open the document above for the full version.

Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 54 EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: Air Purifie Model name: CF-8126AS FCC ID: 2AWVWCF8126AS IC ID: 26287-CF8126AS Test Report Number: EFGX20070051-IE-01-E01 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 54 Content 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 4 1.6 Test item 4 1.7 Test standards 6 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 7 2.3 Measurement uncertainty 7 2.4 Test mode 7 2.5 Test equipment utilized 8 2.6 Auxiliary Equipment Used during Test 8 2.7 Test software information 8 2.8 Customized Configurations 8 2.9 Test Environments 9 2.10 Test results 10 3 Technical Requirement 11 3.1 Conducted Emission 11 3.2 Conducted Peak output power 14 3.3 6dB bandwidth 15 3.4 99% bandwidth 16 3.5 Frequency Stability 17 3.6 Power spectral density 18 3.7 Spurious RF conducted emissions 19 3.8 Band edge 20 3.9 Spurious radiated emissions for transmitter 21 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 54 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : Airplove (Xiamen) Electronic Co., Ltd Address : 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China Telephone : +86 15005056461 Fax : N/A 1.4 Details of manufacturer Name : Airplove (Xiamen) Electronic Co., Ltd Address : 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China Telephone : +86 15005056461 Fax : N/A 1.5 Application details Date of receipt of application : July 03, 2020 Date of receipt of test item : July 03, 2020 Date of test : July 03, 2020 –July 23, 2020 Date of issue August 08, 2020 1.6 Test item Product type : Air Purifier Model name : CF-8126AS Brand : Airplove Serial number : N/A Ratings : AC 120V,60Hz,0.55A,33W Test voltage : AC 120V,60Hz FCC ID : 2AWVWCF8126AS IC ID : 26287-CF8126AS Additional information : N/A RadioTechnical data Frequency range : 802.11 b/g/n(HT20) :2412MHz – 2462MHz Radio Tech. : WLAN 2.4G Frequency channel : 802.11 b/g/n(HT20) :11 Modulation : DSSS,OFDM Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 54 Antenna type : PCB antenna Antenna gain : 2.5dBi Radio module Type : WLAN 2.4G Model : WBR1 Manufacturer : Tuya.Inc Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 54 1.7 Test standards Test Standards FCC Part 15 Subpart C July 23, 2020 Edition PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators RSS-247 Issue 2 February 2017 RSS-247 — Digital Transmission Systems (DTSs), Frequency Hop- ping Systems (FHSs) and Licence-Exempt Local Area Network (LE- LAN) Devices RSS-GEN Issue 5 March 2019 RSS-Gen — General Requirements for Compliance of Radio Appa- ratus Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. 3: KDB558074 D01 15.247 Meas Guidance v05r02 Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 7 of 54 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests performed. or The deviations as specified were ascertained in the course of the tests performed. 2.2 Test environment Temperature : 20 ... 25°C Relative humidity content : 30 ... 60% Air pressure : 100 ... 101kPa 2.3 Measurement uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncer- tainty in Measurement" (GUM) published by ISO. System Measurement Uncertainty Test Items Extended Uncertainty Uncertainty in conducted measurements 1.96dB Uncertainty for Conducted RF test RF Power Conducted: 1.16dB Frequency test involved: 1.05×10-7 or 1% Uncertainty for Radiated Spurious Emission 25MHz-3000MHz Horizontal: 4.46dB; Vertical: 4.5…

Text truncated - open the document above for the full version.

Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 2 Conducted Emission Radiated Emission test below 1GHz Test Report No.: EFGX20070051-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 2 Radiated Emission test Above 1GHz
