2AWVWCF8700ASAir Purifier

USE & CARE INSTRUCTIONS Air Purifier CF-8700AS READ AND SAVE THESE INSTRUCTIONS WARNINGS Failure to comply with the warnings listed below may result in electric shock or serious injury. This product should be used only in accordance with the specifications outlined in this manual. Usage other than what has been specified here may result in serious injury. To reduce the risk of electrical shock, fire or injury to persons: Read all instructions before using the air purifier. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • This appliance is not a substitute for proper ventilation, regular vacuum cleaning or use of an extractor hood or fan while cooking. • Leave at least 20cm free space behind and on both sides of the appliance and leave at least 30cm free space above the appliance. • During the operation of the product, please place the unit at least 2m away from equipment which involve electric wave such as televisions, radios or wave clocks, in case electrical interference occurs to such equipment. • Remove the power plug from the wall outlet before cleaning the unit and when not using the unit. Electrical shock from bad insulation and or fire from short circuit may occur as a result. • When removing the power plug, always hold the plug and never pull the cord. Electrical shock and/or fire from short circuit may occur as result. • Do not use the air purifier if the power cord or plug is damaged or the connection to the wall outlet is loose. • Do not insert fingers or foreign objects into the intake or air outlet. • Do not use this air purifier near gas appliances or fireplaces. • Do not block the air inlet and outlet, e.g. by placing items on the air outlet or in front of the air inlet. • Do not let water or any other liquid or flammable detergent enter the appliance to avoid electric shock and/or a fire hazard. • Do not clean the appliance with water or any other liquid or a (flammable) detergent to avoid electric shock and/or a fire hazard. • Do not place anything on top of the appliance and do not sit on the appliance. • Do not place the appliance directly below an air conditioner to prevent condensation from dripping into the appliance. • Do not use this appliance when you have used indoor smoke-type insect repellents or in places with oily residues, burning incense or chemical fumes. • Do not use the appliance in a room with major temperature changes, as this may cause condensation inside the appliance. • Do not use the appliance in wet surroundings or in surroundings with high ambient temperatures, such as the bathroom, toilet or kitchen. Structure 1. Front panel 2. Filter: washable pre-filter, HEPA filter and activated carbon filter 3. UV-C lamp 4. Air outlet Before first use Note: The appliance comes with all filters fitted inside, but the packaging of the filters need to be removed before using the appliance. 1. Carefully remove your air purifier from box and plastic bag. 2. Select a firm, level and flat location for the air purifier. *For proper air flow, locate the unit at least 1 foot from any wall or furniture. *Make sure none of the grills are blocked. 3. Before using, remove the filters,unpack them and place them back to the appliance. 4. Plug the power cord into a right voltage AC outlet. IMPORTANT: When moving the air purifier, always lift unit by the carrying handle located on back. Purification system Improve your indoor air quality with your new Air Cleaning System. Multiple levels of cleaning include a combination HEPA filter that captures allergens, and Activated Carbon filter to remove odors. UV-C light technology enhances germ-killing. 1. Washable Pre-filter: Traping big particles like human hair, pet hair and bird feather etc., help extend life of HEPA and Activated Carbon filter. 2. HEPA filter: The high-performance HEPA filter is over 99.97 % efficient in trapping all allergens and airborne contaminates down to 0.3 micron in size such as: lung damaging dust, mold spores, plant spores, pet dander, pollen etc.. 3. Activated Carbon filter: The activated carbon filter reduce the toxic fumes, foul odors and other VOCs effectively. 4. UV-C: UV Light (254NM) destroys micro-organisms such as germs, viruses, bacteria and fungi (such as mold toxins). Operation Guidance 1. Power button: Press to turn ON/Off the unit. 2. Fan speed: Press this button one or more times to select the desired fan speed. 3. Sleep mode: Press the button to turn on/off the sleep mode. In sleep mode, the moon indicator flickers 5s, display and all LED turns off, device runs in ultra-quiet mode. Press any button can cancel the sleep mode. 4. UV/ION button: Press this button to turn on/off UV lamp and ION function. 5. Wifi button: Press and hold for 5 seconds to active or reset wifi connection. 6. Timer setting: Press this button to set working time, device will be turn off when time is up the setting (from 1 to 24 hours). Note: Filter Reset: Filter symbol on display indicate you to change a new filter. Replace a new filter according to the instruction in page 6. Fan speed indicator Speed 1 Speed 2 Speed 3 Speed 4 Turbo UV light indicator Auto operation indicator Timer indicator Sleep mo…

Text truncated - open the document above for the full version.

date：07/09/2020 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Air Purifier / CF-8700AS FCC ID: 2AWVWCF8700AS ) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagrams, Schematics, Operational Descriptions) required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Signature: Name: yulian Zhao Applicant: Airplove (Xiamen) Electronic Co., Ltd Address: 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China TEL: +86 15005056461

Date：09/07/2020 Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: yulian Zhao Applicant: Airplove (Xiamen) Electronic Co., Ltd Address: 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China TEL: +86 15005056461

Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 3 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 3 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 3

Model No : CF-8700AS Rated Voltage : AC 120V Rated Current : 1A Rated frequency : 60Hz Rated power : 80W CERTIFIED TO CSA STD . C22.2 NO. 187 CONFORMS TO UL STD . 867 Manufacturer : Airplove (Xiamen) Electronic Co.,Ltd. Date Code :XXXX SN: IC: 26287-CF8700AS FCC ID: 2AWVWCF8700AS

Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 7 of 13 WLAN Antenna Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 8 of 13 WLAN Antenna Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 9 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 10 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 11 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 12 of 13 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 13 of 13

Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 RF EXPOSURE EXEMPT REPORT APPLICANT : Airplove (Xiamen) Electronic Co., Ltd PRODUCT NAME : Air Purifier MODEL NAME : CF-8700AS BRAND NAME : Airplove FCC ID : 2AWVWCF8700AS STANDARD(S) : FCC §15.247 (i), §2.1091 RECEIPT DATE : July 20, 2020 TEST DATE : July 20, 2020 ISSUE DATE : August 7, 2020 Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Equipment Under Test (EUT) Description EUT Type: Air Purifier Hardware Version: N/A Software Version: N/A Frequency Bands: 802.11b/g/n20: 2412 MHz ~ 2462 MHz 802.11n40:2422 ~ 2452MHz Modulation Mode: 802.11b: DSSS 802.11g/n-HT20/HT40: OFDM Antenna Type: PCB Antenna Antenna Gain: WLAN 2.4GHz: 2.5 dBi Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm2) Averaging Time |E|2,|H|2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100000 1.0 30 Note: f = frequency in MHz *= Plane-wave equivalent power density Eurofins Electrical Testing Service(Shenzhen)Co.,Ltd 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna, R=0.2m Tune up produce power 802.11b1.78 2437 15.12 32.51 0.1151 1 802.11g1.78 2437 10.52 11.27 0.0399 1 802.11n201.78 2412 10.93 12.39 0.0439 1 802.11n401.78 2437 6.474.44 0.0157 1 Limit (mW/cm²) Protocol ANT Gain(gain of antenna in linear scale) Channel Frequency (MHz) Max Output Power to Antenna (dBm) Output Power to Antenna (mW) Power Density (mW/cm²) Antenna gain: 2.5 dBi (gain of antenna in linear scale=1.78) Mode 802.11b/g/n20:2412-2462MHz 801.11n40:2422-2452MHz Detector Peak 802.11b 15±1dBm 802.11g 10 ±1dBm 802.11n20 10 ±1dBm 802.11n40 6 ±1dBm

Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 69 Appendix A: Duty Cycle Test Result TestMode Channel Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] 11B 2412 50.00 50.00 100.00 2437 50.00 50.00 100.00 2462 50.00 50.00 100.00 11G 2412 50.00 50.00 100.00 2437 50.00 50.00 100.00 2462 50.00 50.00 100.00 11N20SISO 2412 50.00 50.00 100.00 2437 50.00 50.00 100.00 2462 50.00 50.00 100.00 11N40SISO 2422 50.00 50.00 100.00 2437 50.00 50.00 100.00 2452 50.00 50.00 100.00 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 69 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 69 11B_Ant1_2462 11G_Ant1_2412 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 69 11G_Ant1_2437 11G_Ant1_2462 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 69 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 69 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 7 of 69 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 8 of 69 Appendix B: 6dB Bandwidth Test Result TestMode Antenna Channel DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 10.080 2406.920 2417.000 >=0.5 PASS 2437 10.160 2431.920 2442.080 >=0.5 PASS 2462 10.120 2456.920 2467.040 >=0.5 PASS 11G Ant1 2412 16.640 2403.680 2420.320 >=0.5 PASS 2437 16.640 2428.680 2445.320 >=0.5 PASS 2462 16.640 2453.680 2470.320 >=0.5 PASS 11N20SISO Ant1 2412 17.800 2403.120 2420.920 >=0.5 PASS 2437 17.760 2428.120 2445.880 >=0.5 PASS 2462 17.840 2453.080 2470.920 >=0.5 PASS 11N40SISO Ant1 2422 36.480 2403.760 2440.240 >=0.5 PASS 2437 36.480 2418.760 2455.240 >=0.5 PASS 2452 36.480 2433.760 2470.240 >=0.5 PASS Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 9 of 69 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 10 of 69 11B_Ant1_2462 11G_Ant1_2412 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 11 of 69 11G_Ant1_2437 11G_Ant1_2462 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 12 of 69 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 13 of 69 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 14 of 69 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 Test Report No.: EFG20070186-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 15 of 69 Appendix C: Occupied Channel Bandwidth Test Result TestMode Antenna Channel OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B A…

Text truncated - open the document above for the full version.

Test Report No.: EFGX20070186-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 67 EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC&IC Compliance Test Report for Product name: Air Purifie Model name: CF-8700AS FCC ID: 2AWVWCF8700AS IC: 26287- CF8700AS Test Report Number: EFGX20070186-IE-01-E01 Test Report No.: EFGX20070186-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 67 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 5 2 Technical test 6 2.1 Summary of test results 6 2.2 Test environment 6 2.3 Measurement uncertainty 6 2.4 Test mode 7 2.5 Test equipment utilized 7 2.6 Auxiliary Equipment Used during Test: 8 2.7 Test software information: 8 2.8 Customized Configurations 8 2.9 Test setup- ac line conducted 9 2.10 Setup diagram for conducted tests 9 2.11 Setup diagram for peak power output tests 9 2.12 Setup diagram for radiated tests below 30MHz 10 2.13 Setup diagram for radiated tests below 1GHz 10 2.14 Setup diagram for radiated tests above 1GHz 10 2.15 Test results 11 3 Technical Requirement 12 3.1 Conducted emission AC power port 12 3.2 Duty cycle 15 3.3 6dB bandwidth 16 3.4 99% Occupied Bandwidth 17 3.5 Frequency Stability 18 3.6 Conducted Peak output power 19 3.7 Power spectral density 20 3.8 Conducted Spurious Emissions 21 3.9 Band edge 22 3.10 Spurious radiated emissions for transmitter 25 Test Report No.: EFGX20070186-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 67 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : Airplove (Xiamen) Electronic Co., Ltd Address : 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China Telephone : +86 15005056461 Fax : N/A 1.4 Details of manufacturer Name : Airplove (Xiamen) Electronic Co., Ltd Address : 3F-4F,No.823-1, Fangshan Dong Er Road, Xiang’an District, Xiamen,Fujian,China Telephone : +86 15005056461 Fax : N/A Test Report No.: EFGX20070186-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 67 1.5 Application details Date of receipt of application : July 20, 2020 Date of receipt of test item : July 20, 2020 Date of test : July 20, 2020 –August 07, 2020 Date of issue : September 10, 2020 1.6 Test item Product type : Air Purifier Model name : CF-8700AS Brand : Airplove Serial number : N/A Ratings : AC120V,60Hz,1A,80W Test voltage : AC120V,60Hz FCC ID : 2AWVWCF8700AS IC ID : 26287- CF8700AS Additional information : N/A RadioTechnical data Frequency range : 802.11 b/g/n(HT20) :2412MHz – 2462MHz 802.11 n(HT40) :2422MHz – 2452MHz Radio Tech. : WLAN 2.4G Frequency channel : 802.11 b/g/n(HT20) :11 802.11 n(HT40) :7 Modulation : DSSS,OFDM Antenna type : PCB antenna Antenna gain : 2.5dBi Radio module Type : WLAN 2.4G Model : WR1 Manufacturer : Tuya.Inc 1.7 Test standards Test Standards FCC Part 15 Subpart C August 26, 2020 PART 15 - RADIO FREQUENCY DEVICES Subpart C - Intentional Radiators RSS-247 Issue 2 February 2017 RSS-247 — Digital Transmission Systems (DTSs), Frequency Hop- ping Systems (FHSs) and Licence-Exempt Local Area Network (LE- LAN) Devices RSS-GEN Issue 5 March 2019 RSS-Gen — General Requirements for Compliance of Radio Appa- ratus Test Method 1: ANSI C63.4-2014, American National Standard for Methods of Measurement of Radio-Noise Emis- sions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. 2: ANSI C63.10-2013, American National Standard for Testing Unlicensed Wireless Devices. 3: KDB558074 D01 15.247 Meas Guidance v05r02 Test Report No.: EFGX20070186-IE-01-E01 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 6 of 67 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course of the tests performed. or The deviations as specified were ascertained in the course of the tests performed. 2.2 Test environment Ac line conducted Enviroment Parameter Temperature Relative Humidity 101.5Kpa 24.2 57.3% RF Conducted Enviroment Parameter Temperature Relative Humidity 101.5Kpa 24.7 59.6% Radiated Enviroment Parameter Temperature Relative Humidity 101.5Kpa 24.3 52.7% 2.3 Measurement uncertainty The uncertainty is calculated using the methods suggested in the "Guide to the Expression of Uncer- tainty in Measurement" (GUM) published by ISO. System Measurement Uncertainty Test Items Extended Uncertainty Uncertainty in conducted measure…

Text truncated - open the document above for the full version.

Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 1 of 2 Conducted Emission Radiated Emission test below 1GHz Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 2 of 2 Radiated Emission test Above 1GHz
