2AWWQ-KBBM1111Side Table

SmartSideTable PRODUCTREFS-KBBM1111/KBBM1112/KBBM1113/KBBM1114 AssemblyInstruction Thank you for purchasing the Smart Side Table. In order to make the best use of this product and to use it safely, please read the manual carefully before use and keep it for future reference. Imported By: Imported by: Forward Industries, 33401. U.S.A Issue1-06/07/2020 ① SafetyandCareAdvice 1. The maximum weight that can be placed on this product is 33LBS. 2. This product must not be used as a seat. 3. Always use the original AC adapter and power cable, otherwise it may cause slow wireless charging, poor bluetooth speaker function. In extreme cases, an incompatible AC adapter may burn out. Specifications Drive units: Subwoofer 6.5"4 Ω 40W x 1pcs + Full range 2.75" 8 Ω 15W x 2pcs+Tweeter Φ 31mm 6 Ω 10W X2pcs RMS: 65W (35W+15W*2) Bluetooth frequency: 2. 402-2. 480GHz Bluetooth compatible version: 4. 2 Bluetooth transmit distance: Up to 32.8 feet Working voltage: DC 18V=3.5 A USB input: 5V=2.4A Wireless Charging: 5W (5V=1A) Power Supply: AC adapter ,100-240V ～ 50/60Hz Function Bluetooth Aux In USB charger function Wireless charger function TWS function ( true wireless stereo ) EQ ( Movie / Pop / Rock ) ② MainComponents MainbodyQty1(16.14*13inch) Legs Qty 4 ( 6.7inch ) Legs Qty 4 (10inch) Note:twosizelegsoptionssupplied Accessories PowerCableQty1(39.37inch)ACpowerAdapterQty1(47.24inch) 3.5mmAuxCableQty1(37.4inch) EVApadSpareParts （ Ifrequired ） Qty4(1.18inch) ③ AssemblySteps Step1 Place main bodyupside down on to a clean fat surface. Note:Ensure the surface is suitably protected to prevent any scratches or damage to the main body. Screw legsinto position on the underside of main body. Note:Two different legs length options are supplied. Step2 With the help, Carefully turn the side table over into the standing position. Step3 Plug the AC power adapter into the ‘DC IN’ port on main body. Connect the AC power adapterto the power cable. Plug power cableinto an electric socket for mains power. ④ Controls/Functions 1. POWER / TWS 2. PLAY / PAUSE / PHONE 3. VOLUME - 4. VOLUME + 5. EQ ( Movie / Pop / Rock ) 6. WIRELESS CHARGING SYMBOL 7. USB PORT 5V2.4A 8. DC IN 9. AUX IN PORT ⑤ PowerOn/Off 1. Connect the power adapter with the DC port (please make sure you use the original adapter supplied). You will hear "Power on" from the speaker. The speaker will automatically enter Bluetooth mode as default, and you will hear "Bluetooth, waiting for connection". 2. Press and hold the [] button to turn the unit off. You will hear "Power off". 3. Press and hold the [] button to turn the unit back on. AUX Auto Switch (LED indicator: the left LED light) 1. Insert the AUX cable into the AUX socket on the rear panel. The speaker will switch to AUX mode automatically. The green LED light will be on. The Bluetooth mode will be switched off. 2. After taking out the AUX cable, the Bluetooth mode will be switched back on automatically. You will hear the command "Bluetooth, waiting for connection" or "Bluetooth" . Bluetooth Connection and Play (LED indicator: the left LED light) 1. With the power on and the unit in Bluetooth mode, it will automatically switch to pairing state. The blue LED light will flash slowly. The Bluetooth device name is ‘KBBM Side Table’. 2. A phone or other device can now be paired with the unit. 3. You will hear "Bluetooth is Connected" after pairing. The blue LED light will become constant. If pairing fails, the blue LED light will flash quickly. 4. During music playback, the music can be paused by short pressing the 【】 button. It will play again after a further short press of the 【】 button. 5. When this unit is connected to a smart phone, press and hold the 【】 button to switch off the Bluetooth connection. You will hear " Bluetooth disconnected, waiting for connection". 6. Another device can be connected by repeating paring with Kobe. It is not possible to have two devices connected simultaneously. 7. The best distance between smart phone and speaker is ≤ 32.8 feet. ⑥ Volume control 1. Press the 【 ➕ 】 button to increase the volume. The white LED indicator will flash during adjustment. The speaker will automatically defaults to mid volume when switched on. You will hear the voice prompt“ Maximum volume”when volume is max. 2. Press the 【 ➖ 】 button to decrease the volume. EQ Switch( LED indicator: the middle LED light ) When the speaker is switched on and connected, the EQ button can be used to selected different music playback style. A short press will switch between Pop ( Red LED illuminated) Rock (Green and Red LED illuminated) Movie (Green and Red LED illuminated) A further short press will turn to normal mode. USBCharging The USB port (5V2.4A) can charge mobile devices even when the unit is turned off, providing the AC adapter is connected, to a mains power source that is switched on. Wireless Charging 1. If you have a mobile device with wireless charging capability, it can be charged by placing it on the wireless charging symbol on the removable tray. 2. Make sure that the smart phone is within the charging area. Once charging begins, the charging signal will be showed on the phone screen. You can remove your smart phone form the charging area at any time to end the charging process. 3. The wireless charger will charge compatible mobile devices even when the unit is turned off, providing the AC adapter is connected, to a mains power source that is switched on. 4. Some phone cases may inhibit the wireless charging function. It may be necessary to remove the phone cases to improve wireless charging efficiency. TWS Function(LED indicator: the right LED light ) 1. If you have two Side tables, you can listen to music in TWS mode via Bluetooth. Turn on both tables. ⑦ Double click the 【】 button of one speaker. The speaker will enter TWS paring mode. Your will hear an acoustic signal and the orange LED indicator flash rapidly. After TWS pairing, the LED of main speaker will become constant, and the LED of sub-speak…

Text truncated - open the document above for the full version.

FCC ID: 2AWWQ-KBBM1111

Label Location On EUT Label Product Name: Side Table Model No.: KBBM1111 FCC ID: 2AWWQ-KBBM1111 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AWWQ-KBBM1111 BTANT Wireless chargerANT

version01 Forward Industries Declaration concerning Antenna Specification It is hereby declared that the product Model No.: KBBM1111, KBBM1112, KBBM1113, KBBM1114 FCC ID : 2AWWQ-KBBM1111 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: BDR&EDR Model No. of antenna: N/A Type of antenna: PCB Antenna Gain of the antenna: 0.5 dBi Frequency range: 2402-2480MHz Wireless charger: Model No. of antenna: KBBM1111 Type of antenna: Inductive loop coil Antenna Antenna Gain of the antenna: 0 dBi Frequency range: 110.1-205KHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Forward Industries Address: 105 South Narcissus Avenue, Suite 412, West Palm Beach, FL 33401, USA City:West Palm Beach ZIP / Postal code: 33401 Country:United Kingdom Place:United KingdomDate: 2020-07-28 Signature:

Report No.: 18220WC00087603FCC ID: 2AWWQ-KBBM1111Page 1 of 14 Code:AB-RF-05-a FCC TEST REPORT Client Name: Forward Industries Address: 105 South Narcissus Avenue, Suite 412, West Palm Beach, FL 33401, USA Product Name: Side Table Date: Jul. 28, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00087603FCC ID: 2AWWQ-KBBM1111Page 2 of 14 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 6 2. Measurement and Result ..................................................................................................................................... 7 2.1. Requirements .............................................................................................................................................. 7 2.2. Test Setup .................................................................................................................................................... 8 2.3. Test Procedure ............................................................................................................................................ 8 2.4. Test Result ................................................................................................................................................... 8 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 8 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 ................................................................................................................................................................ 10 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 12 Report No.: 18220WC00087603FCC ID: 2AWWQ-KBBM1111Page 3 of 14 Code:AB-RF-05-a TEST REPORT Applicant: Forward Industries Manufacturer: DG BLUEMAN TECHNOLOGY CO., LTD. Product Name: Side Table Model No.: KBBM1111, KBBM1112, KBBM1113, KBBM1114 Trade Mark: N.A. Rating(s): Input: DC 18V, 3.5A (via adapter input: AC 100-240V, 50/60Hz, 1.5A; output: DC 18V, 3.5A) USB Output: DC 5V, 2.4A Wireless Output: 5W Max Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptJul. 02, 2020 Date of TestJul. 02~17, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00087603FCC ID: 2AWWQ-KBBM1111Page 4 of 14 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Side Table Model No.: KBBM1111, KBBM1112, KBBM1113, KBBM1114 (All samples are with same inside structure and PCBA except the appearance color, so we prepare "KBBM1114" for test only). Trade Mark: N.A. Test Power Supply: AC 120V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency: BT: 2402~2480MHz Wireless charger: 110.1-205KHz Transfer Rate:BT: 1/2/3 Mbits/s Number of Channel:BT: 79 Channels Modulation Type: BT: GFSK,π/4-DQPSK, 8-DPSK Wireless charger: ASK Antenna Type: BT: PCB Antenna Wireless charger: Inductive loop coil Antenna Antenna Gain(Peak): BT: 0.5 dBi Wireless charger: 0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: Forward Industries Address: 105 South Narcissus Avenue, Suite 412, West Palm Beach, FL 33401, USA Manufacturer: DG BLUEMAN TECHNOLOGY CO., LTD. Address : Room 101, No.5, Shunxing Five Road, Dajingtou, Dalang Town, Dongguan City, Guangdong Province Factory: DG BLUEMAN TECHNOLOGY CO., LTD. Address : Room 101, No.5, Shunxing Five Road, Dajingtou, Dalang Town, Dongguan City, Guangdong Province Report No.: 18220WC00087603FCC ID: 2AWWQ-KBBM1111Page 5 of 14 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter A: Manufacturer: SHENZHEN FUJIA APPLIANCE CO., LTD. M/N: FJ-SW20171803500D Input: 100-240V~ 50/60Hz, 1.5A Max Output: DC 18V, 3.5A, 63.0W Adapter B: Manufacturer: Shenzhen QiXin Electronics Co., Ltd. M/N: QX72W180350D2 Input: 100-240V~ 50/60Hz, 1.5A Out…
