2AX5B-FR2006REDELECTRIC KIDS BUMPER CAR



Flat River Group LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May. 13, 2021 Subject; Request for Confidentiality FCC ID: 2AX5B-FR2006RED To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Mariah Carlson Title: Account Manager

Flat River Group LLC Agent Authorization Company: Flat River Group LLC Address: 306 Reed St., Belding, MI 48809 Belding, MI 48809 United States Product Name: ELECTRIC KIDS BUMPER CAR Model Number(s): FR2005 BLUE, FR2006 RED, FR2007 GREEN, FR2008 ORANGE, FR2009 PINK, FR2010 PURPLE, FR2011 YELLOW Product Description: ELECTRIC KIDS BUMPER CAR We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: May. 13, 2021 Name: Mariah Carlson Title: Account Manager Company: Flat River Group LLC

Model Difference Declaration To Whom It May Concern, We, Flat River Group LLC(ELECTRIC KIDS BUMPER CAR) ; Model Number: FR2005 BLUE, FR2006 RED, FR2007 GREEN, FR2008 ORANGE, FR2009 PINK, FR2010 PURPLE, FR2011 YELLOW; All model’s the function, s oftware and electric circuit are the same, only with a product color, appearance and model named different. Test sample model: FR2005 BLUE. Please contact me if you have any question. Name: Mariah Carlson Date: May. 13, 2021 Title: Account Manager Signature of applicant:

Annex A External Photos Report No.: HK2104161155‐E Page 1 of 3 Report No.: HK2104161155‐E Page 2 of 3 Report No.: HK2104161155‐E Page 3 of 3

FCC ID LABEL: Ca. 5mm x 10mm Include in manual: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label Location FCC ID: 2AX5B-FR2006RED

Annex B Internal Photos Report No.: HK2104161155‐E Page 1 of 3 Report No.: HK2104161155‐E Page 2 of 3 Report No.: HK2104161155‐E Page 3 of 3 Ant.

Page 1 of 22 Report No.: HK2104161155-E FCC TEST REPORT Test report On Behalf of Flat River Group LLC For ELECTRIC KIDS BUMPER CAR Model No.: FR2005 BLUE, FR2006 RED, FR2007 GREEN, FR2008 ORANGE, FR2009 PINK, FR2010 PURPLE, FR2011 YELLOW FCC ID: 2AX5B-FR2006RED Prepared for : Flat River Group LLC 306 Reed St., Belding, MI 48809 Belding, MI 48809 United States Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Apr. 24, 2021 ~ May. 20, 2021 Date of Report: May. 20, 2021 Report Number: HK2104161155-E Page 2 of 22 Report No.: HK2104161155-E TEST RESULT CERTIFICATION Applicant’s name ................. : Flat River Group LLC Address ................................. : 306 Reed St., Belding, MI 48809 Belding, MI 48809 United States Manufacture's Name ............ : Flat River Group LLC Address ................................. : 306 Reed St., Belding, MI 48809 Belding, MI 48809 United States Product description Trade Mark: N/A Product name ........................... : ELECTRIC KIDS BUMPER CAR Model and/or type reference : FR2005 BLUE, FR2006 RED, FR2007 GREEN, FR2008 ORANGE, FR2009 PINK, FR2010 PURPLE, FR2011 YELLOW Standards ............................. : FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Apr. 24, 2021 ~ May. 20, 2021 Date of Issue ........................................... : May. 20, 2021 Test Result .............................................. : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 22 Report No.: HK2104161155-E Table of Contents Page 1 . TEST SUMMARY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 Carrier Frequency of Channels 7 2.3 Operation of EUT during testing 7 2.4 DESCRIPTION OF TEST SETUP 7 2.5 MEASUREMENT INSTRUMENTS LIST 8 3 . CONDUCTED EMISSIONS TEST 9 3.1 Conducted Power Line Emission Limit 9 3.2 Test Setup 9 3.3 Test Procedure 9 3.4 Test Result 10 4 RADIATED EMISSION TEST 11 4.1 Radiation Limit 11 4.2 Test Setup 11 4.3 Test Procedure 12 4.4 Test Result 12 5 BAND EDGE 16 5.1 Limits 16 5.2 Test Procedure 16 5.3 Test Result 17 6 OCCUPIED BANDWIDTH MEASUREMENT 19 6.1 Test Setup 19 6.2 Test Procedure 19 6.3 Measurement Equipment Used 19 6.4 Test Result 19 7 ANTENNA REQUIREMENT 20 8 PHOTOGRAPH OF TEST 21 8.1 Radiated Emission 21 9 PHOTOS OF THE EUT 22 Page 4 of 22 Report No.: HK2104161155-E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release May. 20, 2021 Jason Zhou Page 5 of 22 Report No.: HK2104161155-E 1. TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS DESCRIPTION OF TEST RESULT CONDUCTED EMISSIONS TEST §15.207 N/A RADIATED EMISSION TEST §15.249 (a) / §15.209 COMPLIANT BAND EDGE §15.249 (d)/ §15.209 COMPLIANT OCCUPIED BANDWIDTH MEASUREMENT §15.215 (c) COMPLIANT ANTENNA REQUIREMENT §15.203 COMPLIANT 1.2 TEST FACILITY Te s t F i r m ： Shenzhen HUAK Testing Technology Co., Ltd. Address ： 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China 1.3 MEASUREMENT UNCERTAINTY Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.23dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.08dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 4.42dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.06dB, k=2 Page 6 of 22 Report No.: HK2104161155-E 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment ELECTRIC KIDS BUMPER CAR Model Name FR2005 BLUE Serial Model FR2006 RED, FR2007 GREEN, FR2008 ORANGE, FR2009 PINK, FR2010 PURPLE, FR2011 YELLOW Model Difference All model’s the function, software and electric circuit are the same, only with a product color, appearance and model na med different. Test sample model: FR2005 BLUE FCC ID 2AX5B-FR2006RED Antenna Type PCB Antenna Antenna Gain 0dBi Equipment ELECTRIC KIDS BUMPER CAR Operation frequency 2450MHz Number of Channels 1CH Modulation Type GFSK Power Source DC 3V from Battery Power Rating DC 3V from Battery Page 7 of 22 Report No.: HK2104161155-E 2.2 Carrier Frequency of Channels Description of Channel: Channel Frequency (MHz) 1 2450 2.3 Operation of EUT during testing Operating Mode The mode is used: Transmitting mode Channel: 2450MHz 2.4 DESCRIPTION OF TEST SETUP Operation of EUT during Radiation testing: The sample was placed (0.8m below 1GHz, 1.5m above 1GHz) above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. The worst case is X position EUT Page 8 of 22 Report No.: HK2104161155-E 2.5 MEASUREMENT INSTRUMENTS LIST Item Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval 1. L.I.S.N. Artificial Mains Network R&S ENV216 HKE-002 Jun. 18, 2020 1 Year 2. Receiver R&S ESR-7 HKE-010 Jun. 18, 2020 1 Year 3. RF automatic control unit Tonscend JS0806-2 HKE-060 Jun. 18, 2020 1 Y…

Text truncated - open the document above for the full version.

Tes t Model：FR2005 BLUE Radiated Emission
