Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221200049004 Page: 1 of 12 Winkey Wang EMC Technical Manager RF EXPOSURE EVALUATION REPORT Application No.: FYCR2212000490AT Applicant: Ruijie Networks Co., Ltd. Address of Applicant: Building 19, Juyuanzhou Industrial Park, No. 618 Jinshan Road, Cangshan District,Fuzhou, Fujian 350002 China Manufacturer: Ruijie Networks Co., Ltd. Address of Manufacturer: Building 19, Juyuanzhou Industrial Park, No. 618 Jinshan Road, Cangshan District,Fuzhou, Fujian 350002 China Equipment Under Test (EUT): EUT Name: Wireless Access Point Model No.: RG-RAP2260(H) Trade Mark: ,,,, FCC ID: 2AX5J-RAP2260H Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2022-12-06 Date of Evaluation: 2022-12-08 to 2023-01-03 Date of Issue: 2023-01-03 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221200049004 Page: 2 of 12 Revision Record Version Chapter Date Modifier Remark 01 2023-01-03 Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221200049004 Page: 3 of 12 2 Contents Page 1 Cover Page ......................................................................................................................................... 1 2 Contents ............................................................................................................................................. 3 3 General Information............................................................................................................................ 4 3.1 General Description of E.U.T. ....................................................................................................... 4 3.2 Details of E.U.T. ........................................................................................................................... 4 3.3 Separation Distance ..................................................................................................................... 5 3.4 Test Location ............................................................................................................................... 6 3.5 Test Facility .................................................................................................................................. 6 3.6 Deviation from Standards ............................................................................................................. 6 3.7 Abnormalities from Standard Conditions ....................................................................................... 6 4 FCC Radiofrequency radiation exposure limits ................................................................................ 7 4.1 Blanket 1 mW Blanket Exemption ................................................................................................. 7 4.2 MPE-based Exemption ................................................................................................................. 7 4.3 SAR-based Exemption ................................................................................................................. 8 5 Measurement and Calculation ..........................................................................................................11 5.1 Maximum transmit power ............................................................................................................11 5.2 RF Exposure Calculation .............................................................................................................12 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221200049004 Page: 4 of 12 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: 48V 1A, PoE For 2.4G WIFI: Operation Frequency: 802.11b/g/n(HT20)/ax(HEW20): 2412MHz to 2462MHz, 802.11n(HT40)/ax(HEW40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS(CCK, DQPSK, DBPSK) 802.11 g/n: OFDM(16QAM, 64QAM, QPSK, BPSK) 802.11 ax: OFDMA(16QAM, 64QAM, 256QAM, 1024QAM, QPSK, BPSK) Channel Spacing: 5MHz Number of Channels: 802.11b/g/n(HT20)/ax(HEW20): 11, 802.11n(HT40)/ax(HEW40):7 Antenna Type: PIFA Antenna Antenna Gain: Antenna1: 4.08dBi, Antenna2: 4.25dBi, Antenna3: 3.54dBi, Antenna4: 2.49dBi Directional gain = 4.25dBi For 5G WIFI: Operation Frequency: Band Mode Frequency Range(MHz) Number of channels UNII Band I 802.11a/n(HT20)/ac(HT20)/ax(HEW20): 5180-5240 4 802.11n(HT40)/ac(HT40)/ax(HEW40) 5190-5230 2 802.11ac(HT80)/ax(HEW80) 5210 1 802.11ac(HT160)/ax(HEW160) 5250 1 UNII Band II-A 802.11a/n(HT20)/ac(HT20)/ax(HEW20): 5260-5320 4 802.11n(HT40)/ac(HT40)/ax(HEW40) 5270-5310 2 802.11ac(HT80)/ax(HEW80) 5290 1 UNII Band II-C 802.11a/n(HT20)/ac(HT20)/ax(HEW20): 5500-5700 11 802.11n(HT40)/ac(HT40)/ax(HEW40) 5510-5670 5 802.11ac(HT80)/ax(HEW80) 5530,5610 2 802.11ac(HT160)/ax(HEW160) 5570 1 UNII Band III 802.11a/n(HT20)/ac(HT20)/ax(HEW20): 5745-5825 5 802.11n(HT40)/ac(HT40)/ax(HEW40) 5755-5795 2 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch SZCCS-TRF-01 Rev. A/0 Aug01,2022 Report No.: FYCR221200049004 Page: 5 of 12 802.11ac(HT80)/ax(HEW80) 5775 1 Modulation Type: 802.11a: OFDM(16QAM, 64QAM, QPSK, BPSK) 802.11n: OFDM(16QAM, 64QAM, QPSK, BPSK) 802.11ac: OFDM(16QAM, 64QAM, 256QAM, QPSK, BPSK) 802.11ax: OFDMA(16QAM, 64QAM, 256QAM, 1024QAM, QPSK, BPSK) DFS Function: Master TPC Function: Support Sample Type: Fixed device Antenna Type: PIFA Antenna Antenna Gain: U-NII-1: Antenna1:4.01dBi, Antenna2: 5.36dBi, Antenna3: 4.93dBi, Antenna4: 4.26dBi U-NII-2A: Antenna1:3.69dBi, Antenna2:…
