2AX5J-RAP6262Wireless Access Point

81-88 9-16 17-24 25-32 33-40 89-96 41-48 49-56 57-84 85-72 73-80 97-104 1-8 1 2 3 4 5 6 7 ABCD 8 9 1 2 3 4 10

11 12 13 14 ABCD 15 16 17 1 2 3 4 18 19

20 21 22 23 ABCD 24 25 1 2 3 4 26 27 28

29 30 31 ABCD 32 33 1 2 3 4 34 35 36 37

38 39 ABCD 40 41 1 2 3 4 42 43 44 45

46 47 ABCD 48 49 1 2 3 4 50 51 52 53

54 55 ABCD 56 57 1 2 3 4 58 59 60 61

62 63 ABCD 64 65 1 2 3 4 66 67 68 69

70 71 ABCD 72 73 1 2 3 4 74 75 76 77

78 79 ABCD 80 81 1 2 3 4 82 83 84 85 防水膠圈 86 ABCD

87 88 89 1 2 3 4 90 91 92 93 94 95 ABCD 96

97 1 2 3 4 98 99 100 101 102 ABCD 103 104

RG-RAP6262 Wi-Fi 6 AX3000 High Performance Outdoor Access Point Highlights 'UFO' design, a perfect blend of high performance and full coverage. Enter the era of ultra-high Wi-Fi 6 speed. Extra-distance access point deployment with SFP port. IP68 protection, rock-solid in harsh environments. Easily expand extra outdoor Wi-Fi with Reyee Mesh. DATASHEET Highlight Features A Perfect Blend of High Performance and Full Coverage Wi-Fi 6 AX3000 Omni-directional Antennas SFP Port Free Cloud Management Enter the Era of Ultra-high Wi-Fi 6 Speed With a revolutionary combination of OFDMA and 1024QAM, the latest 802.11ax standard, and the 160MHz band, RG-RAP6262 wireless aggregation rate reaches 2.976Gbps. RG-RAP6262 Reyee Mesh RG-RAP6262(G) 2976 1775Mbps Mbps Highlight Features Support Extra-Distance Access Point Deployment With gigabit SFP port, the device supports up to 20km transmission from datacenter with single mode fiber Rock-solid in Harsh Environments Adopts completely sealed, waterproof, dustproof, moisture proof and flame-retardant, wind erosion protection, Wide Temperature range, and 4kV surge protection design. IP68 Protection 4kV Lighting Protection Wind Erosion Protection -30°C ~ 65°C Flame-Retardant Highlight Features Omni-directional Coverage with Long Range Built-in 5 high gain antennas, supports full coverage with radius of 100 meters at 2.4GHz, and 300 meters at 5GHz*. Easily Expand Extra Outdoor Wi-Fi with Reyee Mesh Less wiring, more relaxing *The maximum range of Wi-Fi coverage is calculated based on field tests. The real transmission range may vary, according to the environment, receiving device, etc. Highlight Features Easy Installation, Firmly Fixed Rack-separated mounting design, easily installation on high. Replace plastic cable ties by iron hoop. Cloud, Make Your Business Easy Remote monitoringRemote Wi-Fi managementCloud portal authentication Wireless intelligent optimization Specifications Basic Feature Wi-Fi Standards Wi-Fi 6 (IEEE 802.11ax) Wi-Fi 5 (IEEE 802.11ac Wave 2) Wi-Fi 4 (IEEE 802.11n) IEEE 802.11a IEEE 802.11b/g MIMO 2.4GHz, 2×2, MU-MIMO 5GHz, 2×2, MU-MIMO Max. Wi-Fi Speed 2.4GHz: 574Mbps 5GHz: 2402Mbps Antenna 5 Antenna Type Built-In Omnidirectional Antenna Gain 2.4GHz: 4.38dBi 5 GHz: 7.5dBi Transmit Power EIRP: ≤32dBm (2.4GHz) ≤34.7dBm (5GHz) country-specific restrictions apply Myamar: 2400 MHz~2483.5 MHz ≤ 20 dBm 5150 MHz~5350 MHz ≤ 23 dBm 5470 MHz~5850 MHz ≤ 25 dBm Thailand: 2400 MHz~2483.5 MHz ≤ 20 dBm 5150 MHz~5350 MHz ≤ 23 dBm 5470 MHz~5725 MHz ≤ 25 dBm 5725 MHz~5850 MHz ≤ 30 dBm Fixed Ports 1 × 10/100/1000 Base-T port 1 × 1GBase-X SFP port 1 × DC port 1 × Reset button Max. Clients 512 Recommended Clients 110 Max. SSIDs 8 Recommended Wi-Fi Coverage Radius 2.4GHz: 50 meters 5GHz: 150 meters The Wi-Fi coverage is related to the installation environment of the access point. Specifications Max. Wi-Fi Coverage Radius 300 Meters Operation Frequency Bands 802.11b/g/n/ax: 2.400 GHz to 2.4835 GHz 802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz country-specific restrictions apply Software Feature WLAN Basic Features Power Adjustment Frequency Bandwidth 2.4 GHz: Auto/20/40 MHz 5 GHz: Auto/20/40/80/160 MHz Roaming Layer 2 roaming Layer 3 roaming OFDMA Beamforming WMM Radar Signal Detection and Frequency Hopping (DFS) WLAN Security Wi-Fi Password 16 Digits Security Mode WPA-PSK, WPA2-PSK, WPA/WPA2-PSK Blacklist and Whitelist Enhanced User Experience Wi-Fi Optimization STA Limit Removing Low-RSSI STAs Adjusting Sending Rate of Beacon and Probe Response Basic Feature Syslog Recording Why Users Lose Connection Auto Channel and Power Adjustment on Cloud RSSI Threshold for STA Access Load Balancing Networks Network Access Mode PPPoE Client DHCP Client Static IP VLAN DHCP Server System Cloud Management APP Management APP Upgrade APP Restart Scheduled Restart Default Access/Password 10.44.77.253 No Password Required by Default Local Upgrade Online Upgrade Dual-bin Backup Factory Reset Language Chinese English System Log Software Feature Specifications Diagnostics Network Check Physical LED Indicator 1 × System LED indicator 1 × Wi-Fi LED indicator 1 × SFP LED indicator 1 × LAN LED indicator Buttons 1 × Reset button Dimensions (W × D × H) 230 mm x 230 mm x 195 mm (Without Mounting Bracket) Weight ≤1.4 kg (Without Mounting Bracket) DC Port Dimensions Outer Diameter: 5.5 mm Inner Diameter: 2.1 mm Length: 10 mm Installation Wall-Mountable/Pole-Mountable Mounting Bracket Dimensions (W × D × H) 155mm x 129mm x 35mm Mounting Hole Pattern 65 mm x 110 mm Mounting Hole Diameter 9 mm Pole Diameter 70 mm to 140 mm Power Supplies IEEE 802.3at PoE DC 12V/2A Power Consumption < 24W PoE Power Budget NA Environmental Operating Temperature -30°C ~ 65°C Storage Temperature -40°C ~ 85°C Operating Humidity 0% ~ 100% Noncondensing System Specifications Storage Humidity 0% ~ 100% Noncondensing IP(Ingress Protection) IP68 Port Surge 4kV MTBF > 400000H Physical Specifications Antenna Schematic 2.4GHz 5GHz Package Contents Package InformationRG-RAP6262 Access Point 1 Power Adapter 0 Quick Start Guide 1 Cat5E UTP Cable 0 Mounting Bracket 1 Rack-mount Brackets 1 Screw 2 × M8×20 4 × M8×60 Warranty Card 1 Package Weight 4.62 kg Package Dimension (w x d x h) 475 mm x 305 mm x 270 mm Ruijie Networks Co., Ltd Floor 11, East Wing, Zhongyipengao Plaza, No.29 Fuxing Road, Haidian District, Beijing China Website: https://www.ruijienetworks.com No part of this document may be reproduced or transmitted in any form or any means without prior written consent of Ruijie Networks Co., Ltd. This content is applicable only to regions outside the China mainland. Ruijie Networks Co., Ltd. reserves the right to interpret this content. The information contained herein is subject to change without notice. Nothing herein should be construed as constituting an additional warranty. Ruijie Networks Co., Ltd. shall not be liable for technical or editorial errors or omissions contained he…
