2AX7X-JOWUACM1480 degree Rotation Car Mount with Wireless Charging

10W Car Wireless Charging Roller Car Phone Holder User Manual 1. Pre Setting: Press the top button to release the arms, put your phone in the middle of the holder and push the left and right arms concurrently to clamp your phone firmly. Arm clamp Silicone roller (1) Fits for Qi standard mobile phones; (2) Support 10W charging , as well as 10W / 7.5W /5W wireless charging; (3) Push the reset button , and place phone in jaws slantly then push the clamps to hold the phone securely; (4) The arm clamp can be flexibly extended, so it is easy to hold different mobile phones; (5) This wireless charger comes with over-current protection, overheat protection, short circuit protection; 2.To mount your phone to the wireless charging center, insert one side of phone and then push other side in. 3.Reset the clamp. Press the button on the top of the holder to release the arm clamp , then follow the step 1 to adjust the arm size with your phone. Material:ABS + PC Input power:5V2A, 9V/2A Output power:10W (Max) Effective Distance of Wireless Charging:3-6mm Conversion efficiency: standard charging ≥70%, fast charging ≥75% Working frequency:115-205KHz This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

C5266091_X10_Ed.2 1/1 JOWUAINTERNATIONALLIMITEDTAIWANBRANCH OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:January28,2021 Subject:RequestforConfidentiality FCCID:2AX7X-JOWUACM1 ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☐ User’sManual ☐ NOTE 1 ☐ InternalPhotos ☐ NOTE 1 ☐ PartsList/TuneUp ☐☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfo ☐ No NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodof______daysfromthedateofthe GrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name:ElvanHuang Title: ProductManager

C5266091_X8_Ed.1 1/1 Letter of Authorization JOWUA INTERNATIONAL LIMITED TAIWAN BRANCH Company: JOWUA INTERNATIONAL LIMITED TAIWAN BRANCH Address: 9F., No.156, Sec.3, Minsheng E. Rd., Songshan Dist., Taipei City 105, Taiwan (R.O.C.) Product Name: 480 degree Rotation Car Mount with Wireless Charging Model Number: JOWUACM1 FCC Identifier: 2AX7X-JOWUACM1 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name:Elvan HuangDate:January 28, 2021 Title:Product Manager Signature of applicant:

Page 1 of 3Report No.:FCS202101026 External photos Photo 1 Photo 2 Page 2 of 3Report No.:FCS202101026 Photo 3 Photo 4 Page 3 of 3Report No.:FCS202101026 Photo 5 Photo 6

LabelandLabelLocation FCCID:2AX7X-JOWUACM1 L*W:10mm*7mm whitefontonaBlacklabel

Page 1 of 3Report No.:FCS202101026 Photo 1 Photo 2 GPM8F8008C Page 2 of3ReportNo.:FCS202101026 Photo3 Photo4 Page 3 of3ReportNo.:FCS202101026 Photo5 Photo6 Antenna

Page1of4ReportNo.:FCS202101007W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com RFExposureEvaluation FCCID:2AX7X-JOWUACM1 1MeasuringStandard KDB680106D01RFExposureWirelessChargingAppsv03 2Requirements AccordingtoKDB680106clause5,b Inductivewirelesspowertransferapplicationsthatmeetallofthefollowingrequirementsareexcluded (1)Powertransferfrequencyislessthan1MHz. --Yes,thedeviceoperatedinthefrequencyrangefrom115KHzto205KHz (2)Outputpowerfromeachprimarycoilislessthanorequalto15watts. --Yes,themaximumoutputpoweroftheprimarycoilis10W (3)Thetransfersystemincludesonlysingleprimaryandsecondarycoils.Thisincludescharging systemsthatmayhavemultipleprimarycoilsandclientsthatareabletodetectandallowcouplingonly betweenindividualpairsofcoils. --Yes,thetransfersystemincludesonlysingleprimaryandsecondarycolis (4)Clientdeviceisplaceddirectlyincontactwiththetransmitter. --Yes,Clientdeviceisplaceddirectlyincontactwiththetransmitter (5)Mobileexposureconditionsonly(portableexposureconditionsarenotcoveredbythisexclusion). --Yes (6)TheaggregateH-fieldstrengthsat15cmsurroundingthedeviceand20cmabovethetopsurface fromallsimultaneoustransmittingcoilsaredemonstratedtobelessthan50%oftheMPElimit. --Yes,theEUTfieldstrengthlevelare50%xMPElimit. 3Limits Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactofhuman exposuretoradiofrequency(RF)radiationasspecifiedin1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Page2of4ReportNo.:FCS202101007W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com 4TestSetup 5TestProcedure 1)TheRFexposuretestwasperformedinanechoicchamber. 2)Themeasurementprobewasplacedattestdistance(15cmfromallsidesand20cmfrom thetop)whichisbetweentheedgeofthechargerandthegeometriccenterofprobe. 3)Thehighestemissionlevelwasrecordedandcomparedwithlimitassoonasmeasurement ofeachpoints(A,B,C,D,E)werecompleted 4)TheEUTwasmeasuredaccordingtothedictatesofKDB680106D01v03. Remark ： TheEUT’stestpositionA,B,C,DandEisvalidfortheEandHfieldmeasurements Page3of4ReportNo.:FCS202101007W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com 6Equipmentlist TestEquipmentManufacturerModelNo.SN.Cal.Date ExposureLevel Tester NardaELT-400N03565Jan28,2021 Electricand Magnetic fieldprobe 100cm2 NardaELTprobe100cm2M8976Jan28,2021 7Photo 8TestResult E-FiledStrengthat15cmfromtheedgessurroundingtheEUT(V/m) Page4of4ReportNo.:FCS202101007W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com Battery power Frequency Range(MHz) Test Position A Test Position B Test Position C Test Position D Limits (V/m) 1%0.115-0.2051.252.120.640.53614 50%0.115-0.2051.121.250.470.64614 95%0.115-0.2051.241.480.480.57614 Stand-by0.115-0.2051.412.590.670.65614 E-FiledStrengthat20cmfromthetopoftheEUT(V/m) Battery power Frequency Range(MHz) Test PositionE Limits (V/m) 1%0.115-0.2051.35614 50%0.115-0.2051.47614 95%0.115-0.2051.49614 Stand-by0.115-0.2051.51614 H-FiledStrengthat15cmfromtheedgessurroundingtheEUT(A/m) Battery power Frequency Range(MHz) Test Position A Test Position B Test Position C Test Position D Limits (A/m) 1%0.115-0.2050.620.540.740.571.63 50%0.115-0.2050.430.320.710.511.63 95%0.115-0.2050.570.370.640.461.63 Stand-by0.115-0.2050.390.560.610.551.63 H-FiledStrengthat20cmfromthetopoftheEUT(A/m) Battery power Frequency Range(MHz) Test PositionE Limits (A/m) 1%0.115-0.2050.741.63 50%0.115-0.2050.691.63 95%0.115-0.2050.611.63 Stand-by0.115-0.2050.591.63 Testedby:Reviewedby: ※※※※※ENDOFTHEREPORT※※※※※

FCCTestReport ReportNo:FCS202101026W01 Issuedfor Applicant: JOWUAINTERNATIONALLIMITEDTAIWANBRANCH Address: 9F.,No.156,Sec.3,MinshengE.Rd.,SongshanDist.,Taipei City105,Taiwan(R.O.C.) ProductName: ulIMIIIRWDRWWIRWD⦠DIITI⦠WIMDWM BrandName: JOWUA ModelName: JOWUACM1 SeriesModel: N/A FCCID: 2AX7X-JOWUACM1 IssuedBy:FluxComplianceServiceLaboratory Add:Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-Tech Industrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com Page2of24ReportNo.:FCS202101026W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com TESTRESULTCERTIFICATION Applicant’sName......................:JOWUAINTERNATIONALLIMITEDTAIWANBRANCH Address......................................: 9F.,No.156,Sec.3,MinshengE.Rd.,SongshanDist.,TaipeiCity 105,Taiwan(R.O.C.) Manufacture'sName ................ :AdaptertekTechnologyCo.,Ltd. Address......................................: No.4-2,Aly.30,Ln.1,Yi'anRd.,ZhongheDist.,NewTaipeiCity 235,Taiwan(R.O.C.) ProductDescription ProductName ........................... : 480degreeRotationCarMountwithWirelessCharging BrandName ............................. : JOWUA ModelName .............................. : JOWUACM1 SeriesModel .............................. : N/A TestStandards .......................... :FCCRulesandRegulationsPart15SubpartC,Section209 TestProcedure .......................... :ANSIC63.10:2013 ThisdevicedescribedabovehasbeentestedFCS,thetestresultsshowthattheequipmentunder test(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofFCS,thisdocument maybealteredorrevisedbyFCS,personalonly,andshallbenotedintherevisionofthedocument.. DateofTest .................................. : Date(s)ofperformanceoftests.:06Jan.2021~26Jan.2021 DateofIssue.................................:26Jan.2021 TestResult.....................................:Pass Testedby: (ScottShen) Reviewedby : (DukeQian) Approvedby: (KaitChen) Page3of24ReportNo.:FCS202101026W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com TableofContentsPage 1.SUMMARYOFTESTRESULTS5 1.1TESTFACTORY6 1.2MEASUREMENTUNCERTAINTY6 2.GENERALINFORMATION7 2.1GENERALDESCRIPTIONOFTHEEUT7 2.2DESCRIPTIONOFTHETESTMODES9 2.3DESCRIPTIONOFNECESSARYACCESSORIESANDSUPPORTUNITS10 2.4EQUIPMENTSLIST11 3CONDUCTEDEMISSIONMEASUREMENT12 3.1LIMIT12 3.2TESTPROCEDURE12 3.3TESTSETUP13 3.4TESTRESULTS13 4.RADIATEDEMISSIONMEASUREMENT16 4.1LIMIT16 4.2TESTPROCEDURE17 4.3TESTSETUP18 4.4TESTRESULTS19 6.20DBBANDWIDTHTEST22 6.1LIMIT22 6.2TESTPROCEDURE22 6.3TESTSETUP22 6.4TESTRESULTS23 7.ANTENNAREQUIREMENT24 7.1STANDARDREQUIREMENT24 7.2EUTANTENNA24 Page4of24ReportNo.:FCS202101026W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com RevisionHistory Rev.IssueDateEffectPageContents 0026Jan.2021AllInitialIssue Page5of24ReportNo.:FCS202101026W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com 1.SUMMARYOFTESTRESULTS FCCRulesandRegulationsPart15SubpartC,Section209 Standard Section TestItemJudgmentRemark 15.207ConductedEmissionPASS-- 15.209(a)(f)RadiatedSpuriousEmissionPASS-- 15.215(c)20dBBandwidthPASS-- 15.203AntennaRequirementPASS-- NOTE: (1)”N/A”denotestestisnotapplicableinthisTestReport (2)AlltestsareaccordingtoANSIC63.10-2013 Page6of24ReportNo.:FCS202101026W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com 1.1TESTFACTORY CompanyName:FluxComplianceServiceLaboratory Address: Room105FloorBaohaoTechnologyBuilding1NO.15Gongye WestRoadHi-TechIndustrial,SongshanlakeDongguan Telephone:+86-769-27280901 Fax:+86-769-27280901 FCCTestFirmRegistrationNumber:514908 Designationnumber:CN0127 A2LAaccreditationnumber：5545.01 1.2MEASUREMENTUNCERTAINTY Thereporteduncertaintyofmeasurementy±U,whereexpendeduncertaintyUisbasedona standarduncertaintymultipliedbyacoveragefactorofk=2,providingalevelofconfidenceof approximately95%. No.ItemUncertainty 1RFoutputpower,conducted±0.71dB 2UnwantedEmissions,conducted±2.98dB 3ConductedEmission(9KHz-150KHz) ±4.13dB 4ConductedEmission(150KHz-30MHz) ±4.74dB 5Allemissions,radiated(<1G)30MHz-1000MHz ±3.2dB 6Allemissions,radiated(1GHz-18GHz) ±3.66dB 7Allemissions,radiated(18GHz-40GHz) ±4.31dB Page7of24ReportNo.:FCS202101026W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com 2.GENERALINFORMATION 2.1GENERALDESCRIPTIONOFTHEEUT ProductName 480degreeRotationCarMountwithWirelessCharging TradeName JOWUA ModelName JOWUACM1 SeriesModel N/A ModelDifference N/A ChannelList PleaserefertotheNote2. Operationfrequency 115-205KHz ModulationType MSK AntennaType InductiveLoopAntennawith1.0dBi PowerSupply Input：DC5V/3A,9V/2A Output：5W/7.5W/10W Hardwareversionnumber V1.0 Softwareversionnumber V1.0 ConnectingI/OPort(s) PleaserefertotheUser'sManual Note: 1. Foramoredetailedfeaturesdescription,pleaserefertothemanufacturer’sspecifications ortheUser'sManual. Page8of24ReportNo.:FCS202101026W01 FluxComplianceServiceLaboratory Room105FloorBaohaoTechnologyBuilding1NO.15GongyeWestRoadHi-TechIndustrial,SongshanlakeDongguan Tel:769-27280901Fax:769-27280901http://www.fcs-lab.com 2.ChannelList ChannelFrequency(MHz) Low0.115 Middle0.125 High0.205 3.TableforFiledAntenna Ant.Brand Model Name AntennaTypeConnectorGain(dBi)…

Text truncated - open the document above for the full version.

Page 1 of2ReportNo.:FCS202101026 Above1GHzforradiatedemissiontestsetup Blow1GHzforradiatedemissiontestsetup Page 2 of2ReportNo.:FCS202101026 Conductionemissiontestingdevice
